Utax P-C2155w MFP User manual

QUICKGUIDE P-C2155w MFP
Operation panel
For more details refer to the Operation
Guide on the co-packed DVD.
1 [Status/Job Cancel] key: Displays the Status/
Job Cancel screen.
2 [Document Box/USB] key: Displays the
Document Box/USB screen.
3 [System Menu/Counter] key: Displays the
System Menu/Counter screen.
4 [FAX] key: Displays the FAX screen.
5 [Send] key: Displays the screen for sending.
You can change it to display the Address Book
screen.
6 One Touch keys: Recalls the destination
registered for One Touch Keys.
7 [Wi-Fi] indicator: Blinks during Wi-Fi connection.
8 [Black & White] key: Selects black and white
mode.
9 [Full Color] key: Selects full color mode.
10 Select keys: Selects the menu displayed at the
bottom of the message display.
11 [Processing] indicator: Blinks while printing or
sending/receiving.
12 [Memory] indicator: Blinks while the machine is
accessing the machine memory or fax memory.
13 Message display: Displays the setting menu,
machine status, and error messages.
14 [Wi-Fi Direct] key: Set Wi-Fi Direct, and show
information necessary for connection and the
connection status.
15 [On Hook] key: Switches between on-hook and
off-hook when manually sending a FAX.
16 
destination or adds a destination.
17 [Address Recall/Pause] key: Calls the previous
destination. Also used to enter a pause when
entering a FAX number.
18 [Address Book] key: Displays the Address Book
screen.
19 [Copy] key: Displays the Copy screen.
20 [Function Menu] key: Displays the function
menu screen.
21 [Back] key: Returns to the previous display.
22 [Attention] indicator: Lights or blinks when an
error occurs and a job is stopped.
23 Arrow keys: Increments or decrements
numbers, or selects menu in the message
display. In addition, moves the cursor when
entering the characters.
24 [OK] key: Finalizes a function or menu, and
numbers that have been entered.
25 Numeric keys: Enter numbers and symbols.
26 [Stop] key: Cancels or pauses the job in
progress.
27 [Start] key: Starts copying and scanning
operations and processing for setting
operations.
28 [Quiet Mode] key: Lower speed for quiet
processing.
29 [Authentication/Logout] key: Authenticates
user, and exits the operation for the current
user (i.e. log out).
30 [Energy Saver] key: Puts the machine into
Sleep Mode. Recovers from Sleep if in Sleep
Mode.
31 Program keys: Used to register or recall
programs.
32 [Reset] key: Returns settings to their default
states.
33 [Clear] key: Clears entered numbers and
characters.
1415 9 13 20 33 32 31 30 2916171819
23 764 5 8 10 11 12 21 22 23,24 25 26 27 28
1

Copy operation
❶ Press
COPY.
❷ Press
PAPER using the select keys
below the message display.
❸ Press
ARROW UP/DOWN to select
cassette or multipurpose tray.
❹ 
OK.
Paper source
selection
❶ Select the setting to reduce the noise
for printing, scanning and copying.
❷ Press
QUIET MODE key on the Opera-
tion panel.
❸ When this function is activated, the
QUIET MODE key blinks.
Quiet Mode
Change the following settings if
needed:
DUPLEX, COLLATE, COMBINE, ORIGINAL
SIZE/-ORIENTATION, COLOR SELECTION,COLOR
BALANCE or DENSITY.
❶ Press FUNCTION MENU.
❷ Use ARROW UP/DOWN to choose the
desired function.
❸ OK.
❹ Change the desired settings.
OK.
❺ Press START to start copying.
Convenient
copy functions
Registered.
z Program 2
❶ Change the current settings as
desired.
❷ Press one program key for 3 seconds.
❸ The destination registered to the
program keys is recalled and automatic-
ally entered on the screen.
Registering
settings to
program key
Ready to copy.
Copies: 1
Letter
q sA Letter a
100%
[ Zoom ] [ Paper ]
; Color Balance T
<
Saturation T
[ Exit ]
: Color Selection T
Function Menu: a b
Function Menu:
a b
Function Menu: a b
8 Original Image T
9
Density T
[ Exit]
7 Orig Orientation T
Function Menu: a b
5 Combine T
6
Original Size T
[ Exit]
4 Zoom T
Function Menu: a b
*********************
2 Collate T
3
Duplex T
[ Exit]
1 Paper Selection T

QUICKGUIDE P-C2155w MFP
Send operation
Send Job Log: a b
0004
p Broadcast u
0003 b 0756545865 u
0002
p Morgan@home N v
[ Detail ]
If the documents are still fed, press
STOP.
❶ Press STATUS/JOB CANCEL.
❷ Use ARROW UP/DOWN to select SEND JOB
STATUS.
❸ OK.
❹ Use ARROW UP/DOWN to select the job
to be cancelled.
❺ Press CANCEL using the select keys
below the message display.
❻ YES using the select
keys below the message display. Com-

slip might be printed.
❶ Press STATUS/JOB CANCEL.
❷ To check received documents use
ARROW UP/DOWN and select PRINT JOB
STATUS.
To check send documents use ARROW UP/
DOWN and select SEND JOB STATUS.
❸ OK.
❹ Use ARROW UP/DOWN to select the
desired job.
❺ The result is displayed. Press DETAIL
to view all related items.
❶ To wake up the device press the
button ENERGY SAVER.
❷ Place the originals on the platen or in
the document processor.
❸ Press SEND.
❹ Use ARROW UP/DOWN to select E-MAIL.
❺ OK.
❻ Enter the destination e-mail address.
Use ABC TEXT to select the type of
characters. Use LEFT/RIGHT ARROW to
move the cursor.
❼ OK.
❽ If there are additional destinations,
press the CONFIRM/ADD DESTINATION key
and select ADD .
❾ Press CONFIRM/ADD DESTINATION to

10 Press START. Transmission starts.
Check
transmission
result
Sending E-mail
Cancelling fax job
Send to: a b
*********************
2 G Folder(SMB)
3 H Folder(FTP)
1 p E-mail
Address Entry:
B b
*
ABC
[ Text ]
Ready to send.
Dest.: 1
p :sally@########### N
1-sided 300x300dpi
[ Duplex ] [ScanRes.]
Send Job Status: a b
0010
b 0123456789 r
0011 p Broadcast
*********************
[ Cancel ] [ Menu ]
0017 b 9876543210

Select Key No.: a b
*********************
2 No. 12
[ Exit ]
1 No. 1
❶ Press
SYSTEM MENU/COUNTER.
❷ Use
ARROW UP/DOWN to choose EDIT
DESTINATION.
❸ Press
OK.
❹ Use
ARROW UP/DOWN to choose ADDRESSBOOK.
❺ 
OK.
If the addressbook contains no entries, press
the menu key using the select keys below the
message display.
❻ Use
ARROW UP/DOWN to choose ADD ADDRESS.
❼ Choose
CONTACTOK. Next,
enter destination name, fax number and e-mail
address.
❽ Press
EDIT to see more details. Use LEFT/RIGHT
ARROW to select the items.
❾ 
OK.
❶ In the basic screen for fax, press the
ONE-TOUCH key that you want to register and
hold it (2 seconds).
❷ Use
ARROW UP/DOWN to choose a key.
❸ 
OK.
❹ Use
ARROW UP/DOWN to choose an entry from
the addressbook.
❺ 
OK.
❶ Press
ENERGY SAVER.
❷ Place the originals on the platen or in the
document processor.
❸ Press
FAX.
❹ Press
FAX RES. using the select keys below the
message display. Select the resolution suitable
OK.
❺ Enter the fax number of the receiving system
using the numeric keys.
You can also select the fax destination from the
addressbook by pressing
ADDRESSBOOK.
❻ Press
START. The documents are fed and the
transmission begins.
Sending Fax
Registering a new
destination
Registering a new
One-touch key
Ready to send.
2010/05/25 12:30
Text+Photo 200x100dpi
[Orig.Img] [FAX Res.]
Edit Destination: a b
*********************
2 Print List
[ Exit ]
1 Addressbook
Menu:
a b
*********************
2 Delete
3 Add Address
1 Detail Edit
Detail: C b
Contact Name 1/7
[Edit ]
