UTE UH2-44-SET User manual

www.ute.de
UH2-44-SET
4x4 HDMI 2.0 HDBaseT Matrix Switcher
with 4 Receivers
All Rights Reserved
Version: UH2-44 _2019V1.4
User Manual

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
Preface
Read this user manual carefully before using the product. Pictures shown in this
manual are for reference only. Different models and specifications are subject to real
product.
This manual is only for operation instruction, please contact the local distributor for
maintenance assistance. The functions described in this version were updated till
November, 2019. In the constant effort to improve the product, we reserve the right to
make functions or parameters changes without notice or obligation. Please refer to the
dealers for the latest details.
All product function is valid till 2019-11.
Trademarks
Product model and logo are trademarks of U.T.E. electronic GmbH & Co. KG.
Any other trademarks mentioned in this manual are acknowledged as the properties of
the trademark owner. No part of this publication may be copied or reproduced without
the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in
which case the user at their own expense will be required to take whatever measures
may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
SAFETY PRECAUTIONS
To ensure the best performance from the product, please read all instructions carefully
before using the device. Save this manual for further reference.
⚫Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
⚫Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
⚫Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
⚫Using supplies or parts not meeting the specifications of product may cause damage,
deterioration or malfunction.
⚫Refer all servicing to qualified service personnel.
⚫To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
⚫Do not put any heavy items on the extension cable in case of extrusion.
⚫Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
⚫Install the device in a place with fine ventilation to avoid damage caused by
overheat.
⚫Keep the module away from liquids.
⚫Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
⚫Do not twist or pull by force ends of the optical cable. It can cause malfunction.
⚫Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
⚫Unplug the power cord when left unused for a long period of time.
⚫Information on disposal for scrapped devices: do not burn or mix with general
household waste, and please treat them as normal electrical wastes.

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
Table of Contents
1. Product Introduction....................................................................................................1
1.1 Features ............................................................................................................2
1.2 Package List ......................................................................................................3
2. Panel Description........................................................................................................4
2.1 4x4 HDMI 2.0 HDBT Matrix Switcher UH2-44 ...................................................4
2.1.1 Matrix Switcher Front Panel.....................................................................4
2.1.2 Matrix Switcher Rear Panel .....................................................................5
2.2 4K60 HDMI2.0 HDBaseT Receiver....................................................................7
2.2.1 HDBT Receiver Front and Rear Panel.....................................................7
3. System Connection.....................................................................................................8
3.1 Usage Precaution ..............................................................................................8
3.2 System Diagram UH2-44...................................................................................8
4. Button Control.............................................................................................................9
4.1 Signal Switching ................................................................................................9
4.1.1 Switch an input to an output ....................................................................9
4.1.2 Switch an input to several outputs ...........................................................9
4.2 Panel Button Locking/Unlocking ......................................................................10
4.3 Status Information Inquiry................................................................................10
4.4 EDID Management ..........................................................................................11
4.4.1 Enter EDID management tab.................................................................11
4.4.2 To copy the EDID data from one HDBT output to one or several inputs 11
4.4.3 To copy the EDID data from one HDMI output to one or several inputs 12
4.4.4 To invoke the built-in EDID data ............................................................12
4.5 Audio Setting ...................................................................................................14
4.5.1 Audio Source Selection .........................................................................14
4.5.2 L+R Output Audio Volume Control.........................................................15
4.6 Preset Setting ..................................................................................................16
4.6.1 Save the current switching routing to a preset.......................................16
4.6.2 Recall a saved preset ............................................................................16
4.7 IP Address Inquiry............................................................................................17

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
5. GUI Control...............................................................................................................18
5.1 Signal Switching ..............................................................................................19
5.2 Audio Setting ...................................................................................................20
5.2.1 Audio Source Selection .........................................................................20
5.2.2 L+R Output Audio Volume Control.........................................................21
5.3 Configuration ...................................................................................................22
5.3.1 Down-scaling.........................................................................................22
5.3.2 HDCP Setting ........................................................................................23
5.3.3 EDID Copy.............................................................................................24
5.3.4 EDID Setting..........................................................................................25
5.4 CEC Control ....................................................................................................26
5.4.1 Input Source Device Control..................................................................26
5.4.2 HDBT Output Device Control.................................................................27
5.4.3 HDMI Output Device Control .................................................................28
5.5 RS232 Control .................................................................................................29
5.6 Access Setting .................................................................................................30
5.7 Interface Setting...............................................................................................31
5.8 Network Setting ...............................................................................................32
5.9 GUI Upgrade ...................................................................................................33
6. IR Control..................................................................................................................34
6.1 IR Remote Control...........................................................................................34
6.2 IR Pass-through Control ..................................................................................35
6.2.1 Control Local Input Device from Remote ...............................................35
6.2.1.1. Control local input device through IR OUT port ..................35
6.2.1.2. Control local input device through IR ALL OUT port ...........36
6.2.2 Control Remote Output Device from Local ............................................37
6.2.2.1. Control remote device through IR IN port...........................37
6.2.2.2. Control remote device through IR ALL IN port....................38
7. RS232 Control ..........................................................................................................39
7.1 RS232 Control Connection ..............................................................................39
7.1.1 Control the Matrix Switcher from Local ..................................................39

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
7.1.2 Control the Matrix Switcher from Remote ..............................................40
7.1.3 Control the Remote Third-party Device from Local................................41
7.1.4 Control the Local Third-party Device from Remote................................42
7.2 RS232 Control Software ..................................................................................43
7.3 RS232 Commands ..........................................................................................44
7.3.1 System Setting ......................................................................................44
7.3.2 Signal Switching ....................................................................................48
7.3.3 Audio Setting .........................................................................................50
7.3.4 HDCP Setting ........................................................................................52
7.3.5 EDID Management ................................................................................53
7.3.6 Third-party Device Control.....................................................................55
7.3.7 CEC Control ..........................................................................................56
7.3.7.1. Control the input source: ....................................................57
7.3.7.2. Control the output display device: ......................................57
8. Firmware Upgrade ....................................................................................................58
9. Specification .............................................................................................................59
9.1 Matrix Switcher UH2-44...................................................................................59
9.2 HDBaseT Receiver ..........................................................................................61
10. Panel Drawing ........................................................................................................63
11. Troubleshooting & Maintenance..............................................................................64
12. Customer Service ...................................................................................................65

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 1 www.ute.de
1. Product Introduction
UH2-44-Set is a professional HDMI 2.0 HDBaseT matrix switcher Kit, which consists
of a 4x4 HDMI2.0 HDBaseT Matrix Switcher (UH2-44) four HDBaseT Receivers and
accessories.
The UH2-44 matrix switcher is a four-input by four-output HDBaseT and HDMI matrix
with HDCP 2.2 and up to 4K/UHD@60Hz video support.
It transmits 4K video to distances up to 40 meters (131 feet) and 1080p video to
distances up to 70 meters (230 feet) over a single CATx Ethernet cable.
The four HDBaseT outputs support 24V Power over Cable (PoC) feature, allowing the
receivers to draw their power from the matrix over the HDBaseT cable.
The UH2-44 matrix switcher features comprehensive EDID management and
advanced HDCP handing to ensure maximum functionality with a wide range of video
sources.
The matrix switcher not only supports bi-directional IR, RS232 extension but also has
IR, RS232, and TCP/IP control options.
The product provides performance in control and transmission, which could be used in
a number of different installation scenarios, for example, with computers, for
monitoring purposes, large screen displays, conference systems, television education,
bank security institutions, etc.

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 2 www.ute.de
1.1 Features
⚫4x4 HDBaseT matrix switcher with audio matrix.
⚫Fully compliant with the HDMI 2.0 and HDCP 2.2.
⚫Supports HDMI resolution up to 4K@60Hz 4:4:4, HDR10.
⚫Features four mirrored HDMI outputs for four HDBaseT outputs, and the four HDMI
outputs support 4K to 1080p down-scaling.
⚫The four HDBaseT outputs support 24V PoC, allowing the receivers to draw their
power from the matrix switcher over the HDBaseT cable.
⚫Transmits 4K signal to the distance up to 131 feet (40 meters) and 1080p signal to
the distance up to 230 feet (70 meters) over a single CATx Ethernet cable.
⚫Supports audio matrix. Provides four digital SPDIF audio outputs and four analog
L+R audio outputs for HDMI input audio de-embedding and HDBaseT output audio
de-embedding. Moreover, the four digital SPDIF audio outputs supports ARC audio
output from receivers.
⚫Volume adjustment for analog L+R audio outputs.
⚫Supports comprehensive EDID management and advanced HDCP handling.
⚫Controllable via front panel buttons, RS232 local and pass-through, IR local and
pass-through, CEC, and TCP/IP (built-in GUI).

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 3 www.ute.de
1.2 Package List
HDBaseT Matrix
Switcher
⚫1x UH2-44: 4x4 HDMI 2.0 HDBaseT matrix switcher
⚫2x Mounting Ears with 6 Screws
⚫4x Plastic Cushions with 4 Screws
⚫1x IR Receiver
⚫1x IR Remote
⚫1x RS232 Cable (3-pin to DB9)
⚫8x 3-pin Terminal Blocks
⚫1x Power Cord
HDBaseT Receiver
⚫4x HDBaseT Receivers
⚫8x Mounting Ears with 16 Screws
⚫16x Plastic Cushions
⚫4x 3-pin Terminal Blocks
⚫1x User Manual
Note: Please contact your dealer immediately if you found any damage or defect
in the components.

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 4 www.ute.de
2. Panel Description
2.1 4x4 HDMI 2.0 HDBT Matrix Switcher UH2-44
2.1.1 Matrix Switcher Front Panel
Figure 2-1 Front Panel UH2-44
①LCD Screen: Presents real-time operation status.
②Power LED: Illuminates RED when the device is in standby mode, illuminates
GREEN when device is powered on.
③IR Sensor and its LED: Illuminates RED when the IR sensor receives an IR
signal from the IR remote to control the matrix switcher. The IR sensor is on the
right side of the LED.
④INPUT: Four buttons for input source selection.
⑤OUTPUT: Four buttons for output channel selection.
⑥Menu Buttons:
⚫LOCK: Lock or unlock the front panel buttons.
⚫PRESET: Preset setting.
⚫MENU/↲: Menu or confirm button.
⚫BACK: Go back to the previous operation.
⚫UP: Page up.
⚫DOWN: Page down.
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product.

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 5 www.ute.de
2.1.2 Matrix Switcher Rear Panel
Figure 2-2 Rear Panel UH2-44
①INPUT: Four type-A female HDMI input ports to connect HDMI sources.
②IR IN:
⚫1~4: Four 3.5mm jacks to connect four IR receivers. Each IR input is
associated with the respective HDBaseT output and cannot be switched
separately. It makes up a bi-directional IR transmission with the IR OUT on the
corresponding HDBaseT receiver.
⚫ALL IN: 3.5mm jack to connect the IR receiver to transmit the IR signal from
the ALL IN port to all HDBaseT receivers.
③IR OUT:
⚫1~4: Four 3.5mm jacks to connect four IR emitters to send the IR signal
received from the corresponding HDBaseT receivers.
⚫ALL OUT: 3.5mm jack to connect the IR emitter to send the IR signal received
from all HDBaseT receivers.
④OUTPUT: Four HDBaseT RJ45 outputs to connect the four HDBaseT receivers,
and four local HDMI ports to connect local displays.
⑤AUDIO MATRIX OUT/ARC: Four 3-pin terminal blocks and four Toslink
connectors to connect speakers or amplifiers for HDMI input audio de-embedding
or HDBaseT output audio de-embedding, and the four Toslink connectors can
also be used for ARC audio output from HDBaseT receivers. They can make up
an audio matrix to be set by front panel buttons, GUI or RS232 commands.
⑥RS232: Four 3-pin terminal blocks to control the third-party devices base on
RS232 pass-through feature. There is a one-to-one correspondence between the
four RS232 ports and the four RS232 ports of four HDBaseT receivers.
AUDIO MATRIX OUT / ARC
IR EY E
16789
2345

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 6 www.ute.de
⑦CONTROL:
⚫RS232: 3-pin terminal block to connect the control device (e.g. PC) to control
the matrix switcher by RS232 commands.
⚫IR EYE: 3.5mm jack to connect IR receiver to control the matrix switcher by
the IR remote.
⚫FW: Type-A USB port for firmware upgrade.
⚫TCP/IP: RJ45 port to connect the control device (e.g. PC) to control the matrix
switcher by GUI.
⑧AC100V~240V: Power port to connect an AC 100V~240V power by the power
cord.
⑨GROUND: Connect to earth to ensure the unit is well grounded.
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product.

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 7 www.ute.de
2.2 4K60 HDMI2.0 HDBaseT Receiver
2.2.1 HDBT Receiver Front and Rear Panel
Figure 2-3 Front and Rear Panel HDBT Receiver
①Power LED: The LED illuminates red when power is applied.
②ARC Mode: Press the button with paper clip or other sharp tool to enable the
ARC mode, and then the left LED illuminates blue. Press it again to exit the ARC
mode and the LED is off. When the ARC audio is selected as the audio source for
the SPDIF output of matrix switcher, the ARC mode will be enabled automatically.
③ARC Audio In: Toslink connector to connect ARC audio source device (e.g.TV).
④FW: Micro-USB port for firmware upgrade.
⑤HDMI Out: Type-A female HDMI output port to connect HDMI display (e.g.TV).
⑥Audio Breakout: If the ARC mode is OFF, the Toslink connector is connected to
speaker or amplifier for HDMI source audio de-embedding. Note that if the ARC
mode is ON, this port has no audio output.
⑦IR In: 3.5mm jack to connect the IR receiver for IR pass-through.
⑧IR Out: 3.5mm jack to connect the IR emitter for IR pass-through.
⑨RS232: 3-pin terminal block to connect the RS232 control device (e.g. PC) or a
third-party device to be controlled.
⑩HDBT In: RJ45 port to connect the HDBT output port of switcher/transmitter by
CATx Ethernet cable. The LINK LED illuminates orange when there is a valid
HDBaseT link between the switcher/transmitter and the receiver. The HDCP LED
illuminates green when the video contains HDCP content.
⑪DC 24V: DC connector for the power adapter connection. If the
switcher/transmitter is connected to the power adaptor, the receiver doesn’t need
to connect power adaptor due to the HDBT output port of switcher/transmitter
supports 24V PoC output.
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product.
12345678911
10

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 8 www.ute.de
3. System Connection
3.1 Usage Precaution
⚫Make sure all components and accessories included before installation.
⚫System should be installed in a clean environment with proper temperature and
humidity.
⚫All of the power switches, plugs, sockets, and power cords should be insulated and
safe.
⚫All devices should be connected before power on.
3.2 System Diagram UH2-44
The following diagram illustrates typical input and output connections that can be
utilized with this matrix switcher UH2-44:
Figure 3-1 Connection and System Diagram
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product
Tx Rx
LINKHDCP
AUDIOMATRIX OUT / ARC
IR EYE
Rece iv er
Proj ec tor
Remo te
IR Emitter
Game C onsol e
IR Emi tt er
IR Rec ei ver
Remo te
Appl y TV
Lapt op
4K Blu -Ray
Disp lay Lap to p Route r
Remo te
IR Rec ei ver
IR Rec ei ver
HDMI :
IR:
RS23 2:
HDBa seT:
Ethe rn et:
Audi o:
Ampl if ier Spe aker
Spea ke r Spe ak er Spea ke r Spe ak er

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 9 www.ute.de
4. Button Control
The matrix switcher can be controlled by using the buttons on the front panel.
Whenever a command is accepted, the indicators of all the buttons pressed will blink
three times then they will go off. If the command fails, the indicators will go off
immediately without blinking.
4.1 Signal Switching
4.1.1 Switch an input to an output
Operation: INPUT# + OUTPUT# + MENU/↲
Example: Switch Input 1 to Output 2:
Press INPUT 1 Press OUTPUT 2
Press to confirm.
Note: In default status, 4 IR OUT ports correspond with 4 HDMI INPUTS. When
you switch an HDMI input, the corresponding IR OUT will be switched
synchronously.
4.1.2 Switch an input to several outputs
Operation: INPUT# + OUTPUT# + OUTPUT# +… + MENU/↲
Example: Switch Input 1 to Output 2, 3, and 4.
Press INPUT 1 Press OUTPUT 2, 3,4
Press to confirm.
SWITCH:1 ->
SWITCH:1 ->
2
SWITCH:1 ->
SWITCH:1 ->
2 3 4

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 10 www.ute.de
4.2 Panel Button Locking/Unlocking
Press and hold at least three seconds.
Press and hold to unlock.
4.3 Status Information Inquiry
Press Press enter status
information tab. Press or navigation buttons to check the
previous or next item respectively.
LCD Screen
Description
Report the signal switching status.
Report the connection status of all HDMI input ports.
Y means the corresponding input port is connected to a
source device, N means there is no connection between
the input port and source device.
1~4=HDBaseT output 1~4.
Report the connection status of all HDBT output ports.
Y means the corresponding output port is connected to
an HDBaseT receiver, N means there is no connection
between the output port and HDBaseT receiver.
5~8=HDMI loop output 1~4.
Report the connection status of all HDMI loop output
ports.
Y means the corresponding output port is connected to
a display device, N means there is no connection
between the output port and display device.
HDBT Matrix
System Locked
HDBT Matrix
System Unlocked
Status Info <
EDID Management
IN 1111
1234
OUT
IN 1234
YYYY
LINK
OUT 1234
YYYY
LINK
OUT 5678
YYYY
LINK

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 11 www.ute.de
4.4 EDID Management
The Extended Display Identification Data (EDID) is used by the source device to
match its video resolution with the connected display. By default, the four source
devices invoke the fifth built-in EDID: 4K@60Hz HDR 2CH.
4.4.1 Enter EDID management tab
Press Press to select EDID Management.
Press enter EDID management tab.
Press or navigation buttons to select the below items:
✓Learn HDBT OUT
✓Learn HDMI OUT
✓Built-in EDID
4.4.2 To copy the EDID data from one HDBT output to one or several inputs
Example: Input 1, 2, 3 and 4 learn the EDID data of HDBT output 2.
Select Learn HDBT OUT Press to confirm.
Press OUTPUT 2
Press INPUT 1,2, 3,4.
Press to confirm.
Status Info
EDID Management <
Learn HDBT OUT <
Learn HDMI OUT
PRESS INPUT KEY
Learn HDBT OUT 1
PRESS INPUT KEY
Learn HDBT OUT 2
1 2 3 4
Learn HDBT OUT 2

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 12 www.ute.de
4.4.3 To copy the EDID data from one HDMI output to one or several inputs
Example: Input 1 and 2 learn the EDID data of HDMI output 4.
Select Learn HDMI OUT Press to confirm.
Press OUTPUT 4
Press INPUT 1 and 2.
Press to confirm.
4.4.4 To invoke the built-in EDID data
There are six types of built-in EDID data can be invoked, as shown as below:
No.
EDID
Video
Audio
1
1080p
2CH
2
1080p HDR
MultiCH
3
4K@30Hz HDR
2CH
4
4K@60Hz HDR
MultiCH
5 (Default)
4K@60Hz HDR
2CH
6
4K@60Hz HDR
MultiCH
User Custom
Learn HDBT OUT
Learn HDMI OUT <
PRESS INPUT KEY
Learn HDMI OUT 1
PRESS INPUT KEY
Learn HDMI OUT 4
1 2
Learn HDMI OUT 4

UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 13 www.ute.de
Example: Input 1 and 2 invoke the built-in EDID data: 4K@30Hz HDR 2CH.
Select Built-in EDID Press to confirm.
Press or navigation buttons to select the
built-in EDID to be invoked Press INPUT 1 and 2.
Press to confirm.
Learn HDMI OUT
Built-in EDID <
PRESS INPUT KEY
1080P 2CH <
PRESS INPUT KEY
4K30HDR 2CH <
1 2
4K30HDR 2CH <
