UTEPO UTP7301EOC User manual

Grounding terminal
Board diagram
Please follow below installation steps
Please check the following items before installation. If any missing, please contact the dealer.
Power adapter
Ethernet Extender 1 pcs
MIT hanger 2 pcs
User mannal 1 pcs
1 pcs
1) Please turn off the signal source and the device's power, installation with power on may damage the
device;
2) Check if the network cable and other transmission line is occupied by other device;
3) Use a network cable to connect RJ45 port of SV-Unit and Ethernet switch, use another network cable
or coaxial cable to connect EOC port of SV-Unit and EOC port of IPC-Unit;
4) Use a network cable to connect IP camera with RJ45 port of IPC-Unit;
5) Check if the installation is correct and device is good, make sure all the connection is reliable and
power up the system;
6) Make sure the network is normal.
This Ethernet extender consists of one SV-Unit and one IPC-Unit. It can transfer Ethernet signal from
IPC-Unit to carrier signal and extend it to SV-Unit through coaxial cable or network cable. Then it
transfers carrier signal to Ethernet signal long
distance Ethernet signal, security network surveillance and network transformation
project where coaxial cables and ethernet cables are arranged mixed.
. It can fully satisfy the transmission requirements of
and be widely used in
Feature
The equipment consists of two parts: SV-Unit and IPC-Unit. SV-Unit has 12V DC port, one RJ45 input
port and two output ports: BNC and RJ45; IPC-Unit has two input ports: BNC and RJ45, one RJ45
output port and one 12V DC port;
Adopt advanced transmission technoloy to transmit Ethernet signal up to 1200m through coaxial
cable and transmit Ethernet signal up to 700m through network cable;
Ethernet delay less than 1ms; meet point to point application;
Standard: IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX;
Protection: excellent circuit isolation protection, superior product anti-thunder , anti-satic and anti-
interference;
Appearance: durable and delicate, meet MIT rack installation standard, working temperature: 0℃～
55℃;
Installation: Plug-and-play, no setting required.
Ethernet Extender
User Manual
Caution
12
1)
distance!
2) BNC connector and RJ45 port of the equipment can't be used at the same time!
Please use 75-5 standard or above coaxial cable and Cat5e/6 cable to get the longest transmission
Ethernet Extender
Instruction:
IPC left board
VerB 1.1
Grounding terminal
EOC
IPC right board
SV left board SV right board
Device must be connected with lightning protection grounding; otherwise protection level will reduce;
please use above No.20 wire to connect the grounding terminal.
Caution
EOC
LED Status
RJ45 input/output port
EOC RJ45
Yellow Light
Green Light
Yellow /Green Light
Flash
/
Indicate
communication
/
On
Indicate power
supply normal
Indicate cable
connected
Indicate cable
connection normal
Application
12V
12V
Coa xial Cabl e
IP Camera
DC12V
Cat5e/6
LCD
NVR
IP Camera
IPC-unit
Cat5e/6
Ethernet Switch
Cat5e/6
SV-unit
SV-unit
IPC-unit
DC12V
DC12V
DC12V
Powe r
Powe r
Installation steps

连接接 口
Specification
连接接 口
Item
Description
Power
Power Supply
Power adapter supply
Voltage Range
DC 12V
Consumption
＜2W
Ethernet Port
Parameter
Ethernet Port
EOC: 0--100Mbps Ethernet port:10/100Mbps;
transmission bandwidth changes based on
transmission distance, please refer to table 1
Transmission Distance
EOC coaxial cable: 0-1200m
EOC network cable: 0-700m
Transmission Medium
75-5 or above coaxial cable and Cat5e/6 cable
Ethernet
Exchange
Ethernet standard
IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX
Ethernet delay
＜1ms
Status
LED Indicator
Input/output ports:
power status(RJ45 yellow)
network signal transmission(RJ45 green);
EOC: indicate cable connection(RJ45 yellow/green)
Protection
Level
ESD
1a Contact Discharge level 3
1b Air Discharge level 3
IEC61000-4-2
Communication Port Anti-
thunder Protection
IEC61000-4-5 level 3
Operation
Environment
Working Temperature
0℃~55℃
Storage Temperature
-40 ~85℃℃
Humidity(No-Condensing)
0~95%
Mechanical
Dimension(L×W×H)
63.2mm×82mm×25mm
Material
Aluminum
Color
Black
Weight
IPC:134g; SV:134g
连接接 口
Trouble Shooting
Please find the following solution when the device doesn't work
Please confirm if the installation according to factory installation request;
Please confirm if the RJ45 cable order is in accordance with the EIA/TIA568A or 568B industry
standards;
The maximum transmission distance depends on the signal source and cable quality, please do not
exceed the maximum transmission distance;
Please replace a failure device with a proper one to check if the device is broken;
If the problem still exists, please contact the factory.
Products are subject to change without prior notice
Ethernet Extender
34
Table 1:
Picture 1:
Ethernet Extender
SV<->IPC cable length L
Bandwidth（Mbps）
75-5 coaxial
cable
Cat5
100m
54.8
61
200m
54.6
53.7
300m
54.5
52.7
400m
54.4
51.3
500m
54.1
51
600m
53.9
47.1
700m
53.6
35.1
800m
53.1
/
900m
52.2
/
1000m
50.3
/
1100m
48.5
/
1200m
47.2
/
Instruction: Test data in table 1 is required under a lab environment by the test
method in picture 1. In actual case, there maybe some differences due to different
cables and environments.
Ethernet
switch SV IPC
100m 100m Camera
L
