UTEPO UTP104P-HD User manual

Board Diagram
Please check device below and accessories before installation, if you find any missing, please
contact your supplier.
4ch Passive HD Video UTP Transceiver 1pcs
Accessories(ears,screws,pads) 1kit
Installation manual 1pcs
1) Turn off the power of the camera and display before installation;
2) Check if the cables and display device are occupied;
3 Connect monitor or DVR and BNC connector of over coaxial cable) the product
4 Connect the product push terminal UTP cable connector or RJ45 connector and camera )
output port over UTP cable ;
5 Check whether installation is correct, the device is good, make sure all connection is reliable, )
connect power cable, system is power on;
6 Make sure network is normal.)
Features
Application
4ch Passive HD Video UTP Transceiver
DVR
Monitor
Co ax
4ch Passive HD Video UTP Transceiver
VID EO
3
41
2
VID EO
3
41
2
VID EO
3
41
2
Coax Port
Terminal Block Port
RJ45 Port
UTP C at5/5e/6
Notice
Transmission distance is related to wire quality, please use standard UTP cable and coaxial cable.
RJ45 connector and screw push terminal connection mode can not use at the same time,
choose only one of them.
12
Installation steps
Please install as following steps:
4ch Passive HD Video UTP Transceiver
User Manual
The 4ch passive HD (non-amplified) video UTP transceiver allows transmission of real-
t i me a n d h i g h-per f o r m a n ce c o lor or m o nochr o m e ( B / W ) C C T V v i d e o o r
HDCVI/AHD/HDTVI HD video over UTP cable,perfect for multi-point surveillance.
VerB 1.0
Passive,no need of power supply;
HDCVI HDTVI AHD CVBS 4 in 1 Compatible design; Real-time transmission, no delay;
Recommendation transmission distance as below:
1) HDCVI1080p: 100m ; HDCVI 720P: 370m( passive to passive);
2)HDTVI 720P/1080p: 200m ( passive to passive);
3) AHD-L/M 720p/960P: 330m; AHD-H 1080P: 330m(passive to passive);
4)Analog video: 500m ( passive to passive);
RJ-45 or green terminal block to be chosen to connect UTP cable;
Protection: Strong surge protection, ESD and lighting protection;
Structure: delicate design, support MIT structure, easy operation.
Front board
Back board

连接接口
34
4ch Passive HD Video UTP Transceiver
Specification
Item Description
Function
Transmission Channel 4 channel
Video Connector 4 channel
Transmission Distance Please refer to table 1
Video
Transmission
Performance
and Connector
Coaxial Video Connector Female BNC Connector
UTP Cable Video Connector Female RJ45 Connector
8 channel screw push terminal
Compatible Video Format HDCVI HDTVI AHD CVBS
Signal Transmission Width 0~70MHz
Anti-interference >60dB
Protection Level
Coaxial Video Connector Surge 2KV per：IEC61000-4-5
UTP Cable Communication
Connector Surge Protection 2KV(different mode) per:IEC61000-4-5
ESD
1a contact discharge level 3
1b air discharge level 3
per： IEC61000-4-2
Operation
Environment
Operation Temperature 0~55℃
Storage Temperature -40~85℃
Humidity 0~95%
Physical
Properties
Dimension(L*W*H)85mm （Include connector length)×82mm×25mm
Shell Aluminum
Color Black
N.W. 154g
连接接口
Trouble shooting
If the equipment fails to work, please solve the problem as following method
Check if it's according to the manual;
the real distance not exceeds the allowed transmission distance;
Make sure the cables are quality;
Replace the device at question by a normal working device;
Please contact your vendor if trouble still exists.
If choose RJ-45,make sure both ends of UTP cable are same(both 568A or both 568B)
If choose green terminal block,make sure cable of same color be in the same pin;
Check all connection(like BNC,RJ-45);
Make sure
4ch Passive HD Video UTP Transceiver
Specification change will not be noticed
Table 1:
Instruction:
The test data in table 1 is required under lab environment by passive to passive,In
actual case, there maybe some differences due to different cable and environment.
Signal Source
HDCVI
(720P)
HDCVI
(1080P)
HDTVI
(720P/1080P)
AHD-L/M
(720P/960P)
AHD-H
(1080P)
Analog
Video
Recommendation
distance
370m
100m
200m
330m
330m
500m
