Utopia Roseberry User manual

Installation Guide
Roseberry Washstand Unit
Important Information
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the installation
environment (i.e., wall type/structure and the combined weight of the cabinet and basin) and
use appropriate fixings.
•Care should be taken when drilling to avoid any hidden wires or pipes.
Installation
Unpack the components. The drawer unit and legs are supplied in
separate packaging. Remove the drawer box by pulling the drawer
fully out and lifting it upwards.
Place a dust sheet flat on the floor to protect the unit during assembly.
Place the right-hand leg section flat on the floor. Using a crosshead
screwdriver, screw a metal dowel screw into each leg section. Push
a wooden dowel into each of the corresponding pre-drilled holes.
Push the towel rail supports onto the leg section over the screws and
dowels. Place a cam into the base of each of the towel rail supports
and tighten with a screwdriver.
Place the drawer unit onto the right-hand leg section. Using a
crosshead screwdriver, screw four supplied bolts through the
pre-drilled holes in the drawer unit into the threaded inserts in the
leg section.
Screw a metal dowel screw into the opposite end of each of the
towel rail supports. Push a wooden dowel into each of the
corresponding pre-drilled holes.
Place the left-hand leg section onto the towel rail supports over
the screws and dowels. Insert a cam into each of the towel rail
supports and tighten with a screwdriver.
Using a crosshead screwdriver, screw four supplied bolts through
the pre-drilled holes in the drawer unit into the threaded inserts in
the left-hand leg section.

When assembly is complete, turn the unit onto its legs and place in
the final installation position. Drill through the back rail and into the
wall. Secure the unit in place using fixings suitable for the wall type.
Re-fit the drawer box by placing it onto the extended runners and
pushing it back into the closed position until an audible click is heard.
Place the towel slats into the slots on the towel rail
supports.
Drawer Box Removal and Replacement
To remove the drawer box, pull the drawer fully out and lift it upwards.
To re-fit the drawer box, pull the runners fully out, place the drawer
box on the runners and push it rearwards until it clicks into place.
Drawer Front Removal
Slide the slide the drawer side covers rearwards to expose the
screws. Using a crosshead screwdriver, turn the screws shown to
release the drawer front. Where there are two screws on each
drawer side, turn the top screw first followed by the bottom one.
Drawer Front Adjustment
Slide the drawer side covers rearwards to expose the adjustment
screws.
•To raise or lower the drawer front, turn the larger screws with
a crosshead screwdriver until adjusted as required.
•To move the drawer front from side to side, turn the smaller
screws.
•To adjust the tilt of the drawer front, remove the caps from the
tops of the drawer sides. Use a cross-head screwdriver to
adjust as required.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Freestanding Washbasin Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
•If the fascia is to be cut, use a saw with a fine-toothed blade ensuring that the room is well
ventilated. Any cut edges should be sealed with PVA glue or silicone sealant to prevent the
ingression of moisture.
Installation
Secure the unit to the wall by drilling through the back rail and
using suitable fixings for the wall type.
If this cabinet is being fitted in a run, secure the units together with
suitable fixings through the gables. Try to hide the fixings where
possible behind shelves or hinge plates.
Door hinge adjustment
•To square the door against the cabinet, turn screws A until adjusted
as required.
•To adjust the door closer to or further away from the cabinet, turn
screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once the
door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Fitted Washbasin Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
•If the fascia is to be cut, use a saw with a fine-toothed blade ensuring that the room is well
ventilated. Any cut edges should be sealed with PVA glue or silicone sealant to prevent the
ingression of moisture.
Installation
Remove the doors, fascia panel and shelf and turn the unit upside
down. Push the legs firmly into the leg sockets.
Stand the unit back on its legs against the wall. Adjust the legs
on the units until they are level. Secure the units to the wall by
drilling through the back rail and using suitable fixings for the wall type.
If this cabinet is being fitted in a run, secure the units together with
suitable fixings through the gables. Try to hide the fixings where
possible behind shelves or hinge plates.
Door hinge adjustment
•To square the door against the cabinet, turn screws A until adjusted
as required.
•To adjust the door closer to or further away from the cabinet, turn
screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once the
door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Wall Mounted Washbasin Unit
Important Information
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the installation
environment (i.e. wall type/structure and the combined weight of the cabinet and basin) and
use appropriate fixings.
•Care should be taken when drilling to avoid any hidden wires or pipes.
•To prevent the cabinet falling from the wall this product must be fixed using the wall
attachment device and brackets provided.
Installation
Mark a horizontal line on the wall at the required height X---X. Ensure that the
wall brackets will fit inside the width of the cabinet and are equally spaced to
ensure even distribution of weight. Secure the wall brackets to the wall using
suitable fixings.
Hook the unit onto the wall brackets so that the spring locks the arm
into place.
Turn screws A to move the cabinet up and down on the wall. When the
cabinet is level, turn screws B to tighten the cabinet to the wall.
Drawer Box Removal and Replacement
To remove the drawer box, pull the drawer fully out and lift it upwards.
To re-fit the drawer box, pull the runners fully out, place the drawer
box on the runners and push it rearwards until it clicks into place.
Drawer Front Removal
Slide the slide the drawer side covers rearwards to expose the
screws. Using a crosshead screwdriver, turn the screws shown to
release the drawer front. Where there are two screws on each
drawer side, turn the top screw first followed by the bottom one.
Drawer Front Adjustment
Slide the drawer side covers rearwards to expose the adjustment
screws. To raise or lower the drawer front, turn the larger screws with
a crosshead screwdriver until adjusted as required. To move the
drawer front from side to side, turn the smaller screws. To adjust the tilt
of the drawer front, remove the caps from the tops of the drawer sides.
Use a cross-head screwdriver to adjust as required.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Wall Mounted Washbasin Unit With LED Lighting
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that this product is fitted by a suitably qualified Part P registered
electrician in accordance with current IEE & Building Regulations.
•It is the installer’s responsibility to carry out a thorough assessment of wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
•To prevent the cabinet falling down this product must be fixed using the wall attachment
device provided.
•The light source in this luminaire is not replaceable. When the light source reaches its
end of life, the whole luminaire must be replaced.
•The terminal block used to connect the leads to the electrical supply can be of either the
screw- or screw-less type and should be rated at 240V 6A with 4 terminals. The cable
tails do not need to be crimped when connected to the terminal block.
•The driver can be screwed to the internal side of the cabinet or left to hang in the void
between the cabinet and the wall.
•This product should be used only with a mains supply that is protected by a 30mA
Residual Current Device.
•This product is IP20 Rated and is only suitable for installation in Outside Zones in a
bathroom. It is not suitable to be fitted in zones 0, 1 or 2.
Connection to Mains Electrics
1. Turn off the electrical supply.
2. Connect the cable from the cabinet light to the connector on the driver (A).
3. Connect the driver cable to the electrical supply in the bathroom (B). It is recommended
that this light is connected to a separate switched feed or to a room motion sensor.
4. Turn the electrical supply back on and check that the lights function as required.
WARNING
RISK OF ELECTRIC SHOCK
Turn off Mains Electric prior to commencing
work.

Installation
Mark a horizontal line on the wall at the required height X---X. Ensure
that the wall brackets will fit inside the width of the cabinet and are
equally spaced to ensure even distribution of weight. Secure the wall
brackets to the wall using suitable fixings.
Hook the unit onto the wall brackets so that the spring locks the arm
into place.
To alter the position of the cabinet on the wall, adjust the two screws
in each hanging bracket. Adjusting screws A will move the cabinet up
and down. When the cabinet is level on the wall, screws B will tighten
the cabinet to the wall.
Drawer Box Removal and Replacement
To remove the drawer box, pull the drawer fully out and lift it upwards.
To re-fit the drawer box, pull the runners fully out, place the drawer
box on the runners and push it rearwards until it clicks into place.
Drawer Front Removal
Slide the slide the drawer side covers rearwards to expose the
screws. Using a crosshead screwdriver, turn the screws shown to
release the drawer front. Where there are two screws on each
drawer side, turn the top screw first followed by the bottom one.
Drawer Front Adjustment
Slide the drawer side covers rearwards to expose the adjustment
screws. To raise or lower the drawer front, turn the larger screws with
a crosshead screwdriver until adjusted as required. To move the
drawer front from side to side, turn the smaller screws. To adjust the tilt
of the drawer front, remove the caps from the tops of the drawer sides.
Use a cross-head screwdriver to adjust as required.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Cloakroom Washbasin Unit
Important Information
•Ensure product contents are complete.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the installation
environment (i.e. wall type/structure and the combined weight of the cabinet and basin) and
use appropriate fixings.
•Care should be taken when drilling to avoid any hidden wires or pipes.
•To prevent the cabinet falling from the wall this product must be fixed using the wall
attachment device and brackets provided.
Installation
Mark a horizontal line on the wall at the required height X---X. Ensure
that the wall brackets will fit inside the width of the cabinet and are equally
spaced to ensure even distribution of weight. Secure the wall brackets to
the wall using suitable fixings.
Hook the unit onto the wall brackets so that the spring locks the arm
into place.
To alter the position of the cabinet on the wall, adjust the two screws in
each hanging bracket. Adjusting screws A will move the cabinet up and
down. When the cabinet is level on the wall, screws B will tighten the cabinet
to the wall.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once
the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Back-To-Wall Toilet Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
Installation
Remove the top fascia panel first by pulling it away from the cabinet
with equal force on each side.
Turn the unit upside down. Push the legs firmly into the leg sockets.
Stand the unit back on its legs against the wall. Adjust the legs
on the units until they are level. Secure the unit to the wall by
drilling through the back rail and using suitable fixings for the wall type.
If this cabinet is being fitted in a run, secure the units together with
suitable fixings through the gables. Try to hide the fixings where
possible behind shelves or hinge plates.
To cut the lower fascia panel to accommodate the soil pipe and cistern
flush pipe, use a jigsaw with a fine-toothed blade suitable for timber.
Ensure that the room is well ventilated when cutting the material.
All cut edges must be sealed with PVA glue or good-quality, sanitary
grade silicone sealant to prevent the ingression of moisture.
Fit the top fascia panel last, after plumbing connections have been made
and installation completed.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Full Height Toilet Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
Installation
To fit a concealed cistern into the WC unit, pull the front top
fascia away from the cabinet with equal force on each side.
The lower front panel can now be lifted upwards away from
the cabinet. Secure the cistern in position according to the
instructions supplied with it.
To secure the WC unit against the wall, drill through the rear
top rail. Fix the unit in position using suitable fixings.
To cut the lower front panel to accommodate the toilet soil
pipe and cistern flush pipe, use a jigsaw with a fine-toothed
blade suitable for timber. Ensure that the room is well
ventilated when cutting the material.
All cut edges must be sealed with paint, PVA glue or good-quality
sanitary grade silicone sealant to prevent the ingression of moisture.
Re-fit the top fascia panel last, after plumbing connections
have been made and installation completed.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Drawer Line Unit
Important Information
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the installation environment (i.e.
wall type/structure and the combined weight of the cabinet and basin) and use appropriate fixings.
•Care should be taken when drilling to avoid any hidden wires or pipes.
•To prevent the cabinet falling from the wall this product must be fixed using the wall attachment device
and brackets provided.
Installation
Turn the unit upside down and push the legs firmly into the leg sockets.
Stand the unit on its legs against the wall. Adjust the legs on the units
until they are level.
Secure the unit to the wall by drilling through the back rail and using
suitable fixings for the wall type.
If this cabinet is being fitted in a run, secure the units together with suitable
fixings through the gables. Try to hide the fixings where possible behind
shelves or hinge plates.
Drawer Box Removal and Replacement
To remove the drawer box, pull the drawer fully out and lift it upwards.
To re-fit the drawer box, pull the runners fully out, place the drawer
box on the runners and push it rearwards until it clicks into place.
Drawer Front Removal
Slide the slide the drawer side covers rearwards to expose the
screws. Using a crosshead screwdriver, turn the screws shown to
release the drawer front. Where there are two screws on each
drawer side, turn the top screw first followed by the bottom one.
Drawer Front Adjustment
Slide the drawer side covers rearwards to expose the adjustment
screws. To raise or lower the drawer front, turn the larger screws with
a crosshead screwdriver until adjusted as required. To move the
drawer front from side to side, turn the smaller screws. To adjust the tilt
of the drawer front, remove the caps from the tops of the drawer sides.
Use a cross-head screwdriver to adjust as required.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten
once the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough cleaning,
occasionally wipe your furniture with a soft cloth dampened with a mild detergent solution. Surfaces should
be thoroughly dried with a lint free cloth to prevent watermarks. Under no circumstances should solvent
cleaning agents, bleach or abrasive cleaning agents or cloths be used. Spills should be removed
immediately using a clean cloth. All bathroom furniture will deteriorate through prolonged periods of
exposure to high levels of condensation so bathrooms must be adequately ventilated using suitable
extraction. Failure to ensure adequate ventilation may invalidate your guarantee. If it required to use the
touch-up paint, ensure that the surface is dry and clean and free from dust or oils. The paint should be
applied using a slightly damp sponge. Carefully dap the paint onto the required area and leave it to dry.
Multiple coats may be required to build-up the paint to give the required finish.

Installation Guide
Roseberry Curved End Unit
Important Information
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the installation
environment (i.e. wall type/structure and the combined weight of the cabinet and
basin) and use appropriate fixings.
•Care should be taken when drilling to avoid any hidden wires or pipes.
•To prevent the cabinet falling from the wall this product must be fixed using the wall
attachment device and brackets provided.
Installation
Unclip the doors from the curved end unit.
If you are installing these units as floor-standing, turn the cabinet
upside down and fit the adjustable legs. Screw the plinths to the bottom
of the units if they are being used.
Mark a horizontal line on the wall at the required height. Note that the marked line
passes through the centre of the wall brackets for the central washbasin unit and along
the top of the wall brackets for the curved end unit. Ensure that the wall brackets will fit
inside the width of each cabinet.
Floor-standing Wall-hung
Secure the wall brackets to the wall using suitable fixings.
Fit the washbasin unit first, following the instructions supplied with it. Hang the curved
end unit next, ensuring that the wall bracket is securely located.
Re-fit the doors onto the cabinets. Ensure that the doors and drawer fronts are all
aligned before fitting the plinth, if used.
Using suitable screws, secure the curved end unit to the washbasin unit by screwing
through the gables. Try to hide the fixings behind the drawer runners or shelves.

To alter the position of the cabinet on the wall, the lower screws in
the hanging brackets will move the cabinet up and down.
When the cabinet is level on the wall, turn the top screws in the curved
cabinet wall brackets to tighten the unit to the wall.
If required, secure the straight plinth to the rear of the curved plinth(s)
using suitable screws before clipping it to the legs.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once
the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more
thorough cleaning, occasionally wipe your furniture with a soft cloth dampened with a
mild detergent solution. Surfaces should be thoroughly dried with a lint free cloth to
prevent watermarks. Under no circumstances should solvent cleaning agents, bleach or
abrasive cleaning agents or cloths be used. Spills should be removed immediately using
a clean cloth. All bathroom furniture will deteriorate through prolonged periods of
exposure to high levels of condensation so bathrooms must be adequately ventilated
using suitable extraction. Failure to ensure adequate ventilation may invalidate your
guarantee. If it required to use the touch-up paint, ensure that the surface is dry and
clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats
may be required to build-up the paint to give the required finish.

Installation Guide
Roseberry Single Base Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
Installation
Remove the shelf, turn the unit upside down and push the legs
firmly into the leg sockets.
Stand the unit back on its legs against the wall. If fitting a run
of units, fix them together through the gable panels. Where
possible, try to hide the fixings behind shelves or hinge plates.
Adjust the legs on the units until they are level.
Secure the unit to the wall by drilling through the back rail
and using suitable fixings for the wall type.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once
the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Double Base Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
Installation
Remove the shelf, turn the unit upside down and push the legs
firmly into the leg sockets.
Stand the unit back on its legs against the wall. If fitting a run
of units, fix them together through the gable panels. Where
possible, try to hide the fixings behind shelves or hinge plates.
Adjust the legs on the units until they are level.
Secure the unit to the wall by drilling through the back rail
and using suitable fixings for the wall type.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once
the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Corner Base Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
Installation
Remove the shelf, turn the unit upside down and push the legs
firmly into the leg sockets.
Stand the unit back on its legs against the wall. If fitting a run
of units, fix them together through the gable panels. Where
possible, try to hide the fixings behind shelves or hinge plates.
Adjust the legs on the units until they are level.
Secure the unit to the wall by drilling through the back rail
and using suitable fixings for the wall type.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten once
the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Open Shelf Base Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is recommended that a technically competent installer undertakes installation.
•It is the installer’s responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
Installation
Remove the shelf and turn the unit upside down. Push
the legs firmly into the leg sockets.
Stand the unit on its legs against the wall. Adjust the legs
on the units until they are level.
Secure the unit to the wall by drilling through the back rail
and using suitable fixings for the wall type.
If this cabinet is being fitted in a run, secure the units
together with suitable fixings through the gables. Try to
hide the fixings where possible behind shelves or hinge
plates.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Single Wall Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is the installer’s responsibility to carry out a thorough assessment of wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
•To prevent the cabinet falling down this product must be fixed using the wall attachment
device provided.
Installation
It may be necessary to snap the wall plate in half at the marked line
to create two wall brackets. Mark a horizontal line on the wall at the
required height X---X. Ensure that the wall brackets will fit inside the
width of the cabinet and are equally spaced to ensure even distribution
of weight. Secure the wall brackets to the wall using suitable fixings.
Hook the unit onto the wall brackets ensuring that the brackets are
securely located.
To alter the position of the cabinet on the wall, adjust the two screws in
each hanging bracket. The top screws will move the cabinet closer to or
further away from the wall. The lower screws will move the cabinet up
and down.
If this cabinet is being fitted in a run, secure the units together with suitable
fixings through the gables. Try to hide the fixings where possible behind
shelves or hinge plates.
A securing screw should be fitted through the back of the unit through the
fixed back of the cabinet and into the wall, this will help to stabilise the unit.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten
once the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Double Wall Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is the installer’s responsibility to carry out a thorough assessment of wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
•To prevent the cabinet falling down this product must be fixed using the wall attachment
device provided.
Installation
It may be necessary to snap the wall plate in half at the marked line
to create two wall brackets. Mark a horizontal line on the wall at the
required height X---X. Ensure that the wall brackets will fit inside the
width of the cabinet and are equally spaced to ensure even distribution
of weight. Secure the wall brackets to the wall using suitable fixings.
Hook the unit onto the wall brackets ensuring that the brackets are
securely located.
To alter the position of the cabinet on the wall, adjust the two screws in
each hanging bracket. The top screws will move the cabinet closer to or
further away from the wall. The lower screws will move the cabinet up
and down.
If this cabinet is being fitted in a run, secure the units together with suitable
fixings through the gables. Try to hide the fixings where possible behind
shelves or hinge plates.
A securing screw should be fitted through the back of the unit through the
fixed back of the cabinet and into the wall, this will help to stabilise the unit.
Door hinge adjustment
•To square the door against the cabinet, adjust screws A.
•To adjust the door closer to or further away from the cabinet,
adjust screws B.
•To adjust the door vertically, slacken screws C. Re-tighten
once the door is adjusted as required.
•To remove the door hinges from the cabinet, press button D.
•To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.

Installation Guide
Roseberry Open Shelf Wall Unit
Important Information
•Read the instructions carefully.
•Check the product for any signs of damage and remove any protective film.
•It is the installer’s responsibility to carry out a thorough assessment of wall type and the
weight of the cabinet and use appropriate fixings.
•Care should be taken when drilling walls to avoid any hidden wires or pipes.
•To prevent the cabinet falling down this product must be fixed using the wall attachment
device provided.
Installation
It may be necessary to snap the wall plate in half at the marked line
to create two wall brackets. Mark a horizontal line on the wall at the
required height X---X. Ensure that the wall brackets will fit inside the
width of the cabinet and are equally spaced to ensure even distribution
of weight. Secure the wall brackets to the wall using suitable fixings.
Hook the unit onto the wall brackets, ensuring that the brackets are securely
located.
To alter the position of the cabinet on the wall, adjust the two screws in each
hanging bracket. The top screws will move the cabinet closer to or further away
from the wall. The lower screws will move the cabinet up and down.
A securing screw should be fitted through the back of the unit through the fixed
back of the cabinet and into the wall, this will help to stabilise the unit.
If this cabinet is being fitted in a run, secure the units together with suitable
fixings through the gables. Try to hide the fixings where possible behind
shelves or hinge plates.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Glass or mirrored panels should be cleaned using a non-solvent based glass cleaner and a
soft cloth. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee. If it required to use the touch-up paint, ensure that the surface is
dry and clean and free from dust or oils. The paint should be applied using a slightly damp
sponge. Carefully dap the paint onto the required area and leave it to dry. Multiple coats may be
required to build-up the paint to give the required finish.
