OPERATING INSTRUCTIONS
B-100SP Ultraviolet Lamp
General Information for Ultraviolet Inspection
For maximum visibility, test for fluorescence in a darkened area. Fluores-
cence may be bright or dim, depending on the amount of fluorescing agent
present. Be careful to distinguish fluorescence from blue light reflection on
polished metal surfaces.
UVP Model UVC-503 Safety
Goggles are recommended
to reduce blue haze result-
ing from eye fluorescence
caused by reflected
longwave UV radiation.
Installation
An 8-foot line cord with 3-
prong plug is supplied. If the
outlet does not accommo-
date the 3-prong plug, use a
2-prong adapter and attach
the grounding lead to the
center screw of the outlet
plate.
Operation and Maintenance
1. To install the bulb and bulb-protector, expand the bezel retainers over
the circular plastic holders and slide the front bezel assembly forward.
2. Expand the silver filter assembly spring clips outward to release the
filter assembly from lamp body.
Warranty
UVP, LLC warrants its ultraviolet lamps to be free of defects in materials and
workmanship for a period of one (1) year from the date of purchase. The
foregoing warranty of UVP shall be of no force and effect if buyer has modified
or damaged the product. Bulbs and filters are warranted for 90 days.
All warranties or merchantability and fitness for any prupose and all other
warranties, expressed or implied, except those expressly set forth herin, are
deemed waived and excluded.
UVP’s duty under the warranty is limited to replacement and/or repair of the
defective part at the option of UVP, Inc. UVP shall not be liable for any ex-
penses or damages incurred by the purchaser except as expressly set forth
herein, and in no event shall UVP be liable for any special, incidental or
consequential damages of any kind. This warranty does not supersede any
statutory rights that may be available in certain countries.

3. The bulb and bulb-protector can now be installed. Point the lamp face
upward and drop in the bulb-protector. Next, screw the bulb in. The bulb
should fit snugly against the inside rim of the bulb-protector.
4. Replace the filter assembly and front bezel. You are now ready to oper-
ate the lamp.
5. Plug the lamp into an appropriate electrical outlet and switch the lamp
on. Allow approximately five minutes to reach full intensity.
Notes: When use is intermittent, it is preferable to leave the lamp burning.
Thisassureslongerbulblifeandavoidsdelayinrestarting. Restarting does
not take place immediately as the mercury vapor within the bulb must cool.
Delay is typically 4 to 8 minutes. Any interruption in the power supply, such
as an excessive drop in voltage, will extinguish the arc. Restarting typically
will be delayed while the mercury vapor cools. Full voltage must be restored
to permit the arc to strike.
Replacement Parts List
B-100SP Ultraviolet Lamp (115 VOLT/60Hz)
PART NO. PART NAME QTY
14-0070-02 END CAP 1
23-0051-02 FRONT BEZEL 1
38-0168-01 LENS BEZEL ASSEMBLY 1
34-0049-01 BULB, SELF-BALLASTED 1
17-0057-01 BULB PROTECTOR 1
77-0007-02 LAMP FIXTURE ASSEMBLY 1
Accessories
PART NO. PART NAME
34-0022-01 BULB, FLOOD
89-0068-01 FINGER GUARD
19-0124-01 LAMP VISOR
CAUTION
1. Wear hand and eye protection if filter glass is cracked. Replace broken
filter as soon as possible.
2. To avoid electrical shock hazard, unplug lamp before servicing.
3. Bulb runs very hot; allow unit to fully cool before servicing.
4. Bulb contains mercury. If bulb breaks, wear gloves to remove.
If repair of the lamp is necessary, remove bulb prior to shipping to the repair
facility. A Return Authorization Goods (RGA) number must be obtained
from UVP to return the item.
23-0051-02
38-0168-01
14-0070-02
77-0007-02
34-0049-01
17-0057-01
