V-fit S2020 User manual

S2020 Indoor Studio Cycle
SERIAL NO: KL 2924-UK

Contents
Section Page
General Information . . . . . . 4
Before You Start . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . 6
Exercise Information . . . . . . 7
Exercise Monitor Instruction 12
Assembly & Adjustments . . . 14
Protect the environment by not disposing of this product with household waste.

General Information
Quality
This exercise product has been designed and
manufactured to comply with the latest (BS EN 957)
British and European Safety Standards.
Questions
Should you encounter any difficulty with the assembly,
operation or use of your exercise product or if you
think that you may have parts missing, please DO NOT
return it to your retailer but contact us first for help and
advice, asking for CUSTOMER SUPPORT, by any of the
following means.
Tel:- 0800 3 101 202 or
[phone]
Email:- [email protected]
Website: www.benysports.co.uk
CUSTOMER SUPPORT open from 9.00am to 5.00pm
from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8 Riparian Way,
The Crossings Business Park,
Cross Hills,
West Yorkshire.
BD20 7BW
Queries
If you do have any queries, please ensure that you have
the following information ready for our Customer Support
Staff:
YOUR NAME
YOUR ADDRESS
YOUR PHONE NUMBER
PRODUCT MAKE OR BRAND
PRODUCT MODEL
PRODUCT SERIAL NUMBER
DATE OF PURCHASE
NAME OF RETAILER
PART NUMBERS REQUIRED
Guarantee
Beny Sports Co. UK Ltd. guarantee's its product range for
DOMESTIC USE ONLY for a period of 1 YEAR from the
original certified date of purchase. During this period we
have the right to: -
a). Provide parts for the purchaser to effect repair.
b). Repair the product, returned to our warehouse
(at the purchaser's cost).
c). Replace the product if it is deemed (by us) to be
economical to do so.
This guarantee does not cover wear and tear on
upholstery or consumables.
This guarantee does not cover abuse, defects caused by
storage or use outside those intended.
If you need to advise us of a defect with your product and
in order for us to service any requirement for replacement
parts or repairs, we will ask for proof of purchase. Failure
to do so will result in any claim for replacement parts or
repairs being refused.
This guarantee, (both given and implied) applies to the
original purchaser only, is not transferable and will be
invalidated if used outside of the above criteria.
This guarantee is valid only in the United Kingdom and Eire.
This does not affect your statutory rights as a consumer.
Customer Support
Tel:- 0800 3 101 202 or
[phone]
Email:- [email protected]
Website: www.benysports.co.uk
CUSTOMER SUPPORT open from 9.00am to 5.00pm
from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8 Riparian Way,
The Crossings Business Park,
Cross Hills,
West Yorkshire.
BD20 7BW
Page 4

Before you Start
Tools
If required, all of our products are supplied with basic tools, which will
enable you to successfully assemble your product. However, you may find
it beneficial to have a soft-headed hammer and perhaps an adjustable
spanner handy as this may help.
Prepare the Work Area
It is important that you assemble your product in a clean, clear,
uncluttered area. This will enable you to move around the product
while you are fitting components and will reduce the possibility of
injury during assembly.
Work with a Friend
You may find it quicker, safer and easier to assemble this product with
the help of a friend as some of the components may be large, heavy
or awkward to handle alone.
Open the Carton.
Carefully open the carton that contains your product, taking note of
the warnings printed on the carton to ensure that the risk of injury is
reduced. Be aware of sharp staples that may be used to fasten the
flaps as these may cause injury. Be sure to open the carton the right
way up, as this will be the easiest and safest way to remove all the
components.
Unpack the Components
Carefully unpack each component, checking against the parts list that
you have all the necessary parts to complete the assembly of your
product.
Please note that some of the parts may be pre-fitted to major
components, so please check carefully before contacting our
CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before
contacting us first.
Page 5

Safety
Before you undertake any programme of exercise that will increase
cardiovascular activity please be sure to consult with your doctor.
Frequent strenuous exercise should be approved by your doctor and
proper use of your product is essential. Please read this manual
carefully before commencing assembly of your product or starting to
exercise.
* Please keep all children away from exercise products when in
use. Do not allow children to climb or play on them when they
are not in use.
* For your own safety, always ensure that there is at least 1 Metre
of free space in all directions around your product while you are
exercising.
* Regularly check to see that all nuts, bolts and fittings are
securely tightened. Periodically checking all moving parts for
obvious signs of wear or damage.
* Clean only with a damp cloth, do not use solvent cleaners. If you
are in any doubt, do not use your product, but contact
CUSTOMER SUPPORT by any of the means listed on the
opposite page.
* Before use, always ensure that your product is positioned on a
solid, flat surface. If necessary, use a rubber mat underneath to
reduce the possibility of damaging flooring or slipping in use.
* Always wear appropriate clothing and footwear such as training
shoes when exercising. Do not wear loose clothing that could
become caught or trapped during exercise.
Storage and Use
Your product is intended for use in clean dry conditions. You
should avoid storage in excessively cold or damp places as this may
lead to corrosion and other related problems that are outside our
control.
Weight Limit
Your product is suitable for users weighing:
330 LBS / 23.5 Stones / 150KG or less.
Conformity
This product conforms to:
It is NOT suitable for therapeutic purposes.
If any part of your product
becomes damaged, broken
or badly worn do not use
the equipment until the
defective parts have been
replaced
Warning
BS EN ISO 20957-1 and BS EN957-10 Class (H) - HOME USE - Class (C).
Page 6

Exercise information
Beginning
How you begin to exercise will vary from person to person. If you
have not exercised for a long period of time, have been inactive for a
while, or are severely overweight you MUST start slowly, increasing
your exercise time gradually, by perhaps only a few minutes for each
session per week.
Combine a carefully structured nutritious diet with a simple but
effective exercise routine and this can help make you feel better, look
better and will almost certainly enable you to enjoy life more.
Aerobic Fitness
Aerobic exercise is simply defined as any sustained activity that
increases the supply of oxygen to your muscles via the blood pumped
by your heart. With regular exercise, your cardiovascular system will
become stronger and more efficient. Your recovery rate i.e. the time
taken for your heart to reach its normal resting level, will also
decrease.
Initially you may only be able to exercise for a few minutes each day.
Do not hesitate to breathe through your mouth should you need more
oxygen. Use the "talk test". If you cannot carry on a conversation
while exercising, you are working too hard! However, aerobic fitness
will be gradually built up with regular exercise, over the next six to
eight weeks.
Do not be discouraged if it takes longer than this to begin to feel less
lethargic, everyone is different and some will achieve their targets
quicker than others. Work at your own, comfortable pace and the
results will come. The better your aerobic fitness the harder you will
have to work to stay in your target zone.
Page 7

Exercise Information
Warm Up
A successful exercise programme consists of three parts, Warm Up,
Aerobic Exercise and Cool Down. Never start a training session
without warming up. Never finish one without cooling down correctly.
Perform between five and ten minutes of stretching before starting
your workout to prevent muscle strains, pulls and cramps.
Aerobic Exercise Session
Those new to exercise should exercise no more than every other day
to start with.
As your fitness level increases, increase this to 2 in every 3 days.
When you are comfortable with your routine, exercise for 6 days per
week. Always take at least one day off per week.
Exercising in your Target Zone
To ensure that your heart is working in its exercise target zone, you
need to be able to take your pulse. If you do not have a pulse monitor
(either from the product you are using or a proprietary independent
unit) you will need to locate the pulse in your carotid artery. This is
situated in the side of the neck and can be felt by using the index and
middle fingers. Simply count the number of beats you feel in 10
seconds and then multiply by six to get your pulse rate. This should
be taken before you start to exercise for easy reference.
People who have a greater aerobic fitness, have a lower resting pulse
level and will also be able to exercise with a higher pulse level.
Target Zone
To determine your target zone, see the chart opposite. If you are new
to exercise and by definition unfit, refer to the left column. If you
exercise regularly and have good aerobic fitness, refer to the right
column.
Incorrect or excessive
training may damage your
health. Please read the
exercise information first.
Note
Page 8

Exercise Information
USERS
AGE
(Years)
20-24
25-29
30-34
35-39
40-44
45-49
50-54
55-59
60 and over
UNCONDITIONED
TARGET ZONE - A
(Beats per Minute)
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
110 - 130
105 - 125
CONDITIONED
TARGET ZONE - B
(Beats per Minute)
155 - 175
150 - 170
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
Cool Down
To decrease fatigue and muscle soreness, you should also cool down
by walking at a slow relaxed pace for a minute or so, to allow your
heart rate to return to normal.
Warm Up and Cool Down Exercises
Hold each stretch for a minimum of ten seconds and then relax.
Repeat each stretch two or three times. Do this before your Aerobic
Exercise session and also after you have finished.
Head Roll
Rotate your head to the right for one count, feeling a slight pull on the
left side of your neck. Next, rotate your head back for one count,
stretching your chin. Then rotate your head to the left for one count,
feeling a slight pull on the right side of your neck. Lastly, drop your
head to your chest for one count. Repeat 2 to 3 times.
Toe Touch
Slowly bend forward from your waist, letting your back and shoulders
relax as you lower your trunk. Gently stretch down as far as is
comfortable and hold for 10 seconds.
Target Zone (con't)
Page 9

Exercise Information
Shoulder Lift
Rotate and lift your right shoulder up towards your ear for one count.
Relax then repeat for the left shoulder.
Repeat 3 - 4 times.
Calf / Achilles Stretch
Turn towards the wall and place both hands on it. Support yourself
with one leg while the other is placed behind you with the sole flat on
the floor. Bend the front leg and lean towards the wall, keeping the
rear leg straight so that the calf and Achilles tendon are stretched
hold for 5 seconds. Repeat with the other leg.
Repeat 2 - 3 times.
Side Stretch
Open both arms to the side and gently lift them above your head.
Reach your right arm as high as you can for one count, gently
stretching the muscles of the stomach and lower back. Repeat the
action with your left arm.
Repeat 3 - 4 times.
Inner Thigh Stretch
Sit on the floor and pull your legs toward your groin, the soles of your
feet together. Hold your back straight and lean forward over your feet.
Tighten the thigh muscles and hold for 5 seconds. Release and repeat
3 - 4 times.
Hamstring Stretch
Sit on the floor with your right leg extended and place your left foot
flat against the right inner thigh. Stretch forward toward the right foot
and hold for 10 seconds. Relax and then repeat with the left leg
extended.
Repeat 2 - 3 times.
Page 10

Exercise Information
Basic Aerobic Training Programme
For your basic Aerobic Exercise routine we suggest that you try the
following. Remember, breathe correctly, exercise at your own pace
and do not over-train as injury may result.
Week 1 & 2
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 3 & 4
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 5 & 6
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 7 & 8
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 9 & beyond
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Exercise 4 minutes at 'A'
Rest 1 minute
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Exercise 5 minutes at 'A'
Rest 1 minute
Exercise 3 minutes at 'A'
Exercise slowly 2 minutes
Exercise 6 minutes at 'A'
Rest 1 minute
Exercise 4 minutes at 'A'
Exercise slowly 3 minutes
Exercise 5 minutes at 'A'
Exercise 3 minutes at 'B'
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Exercise 4 minutes at 'A'
Exercise slowly 3 minutes
Exercise 5 minutes at 'A'
Exercise 3 minutes at 'B'
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Repeat entire cycle 2 or 3
times
This is only a suggested programme and may not suit every
individual's needs.
Page 11

Exercise Monitor Instruction
EXERCISE MONITOR USER INSTRUCTIONS
Your Exercise Monitor has been specially designed to help you plan and
view your exercise performance.
MONITOR FUNCTION SPECIFICATIONS
MONITOR OPERATING METHOD & SPECIFICATIONS
SCAN (AUTOMATICALLY SCANS EACH FUNCTION) Every 6 Seconds
TIME (MINUTES AND SECONDS - COUNT UP / DOWN)
0.00 - 99.59 Minutes and Seconds
DISTANCE (EXERCISE DISTANCE KM - COUNT UP / DOWN) 0.0 - 99.5 Kilometres
CALORIE BURN (COMPUTED THEORETICAL CALORIE BURN*) 0.00 - 999.9 Kcal THEORETICAL*
PULSE (ACTUAL EXERCISE PULSE RATE**) + RECOVERY 30 - 230 Beats per Minute**
SPEED (REPRESENTATIVE SPEED - KM/H) 0.00 - 999.9 Kilometres per Hour
RPM Displayed Figure 0 – 999 rpm
POWER SOURCE 2 x AA (1.5v) POWER CELLS
STORAGE TEMPERATURE
-10°c - +60°c
OPERATING TEMPERATURE
0°c - +40°c
SET
Press SET key to increase value.
Press and hold the key to increase value faster.
MODE/ENTER
RESET
RECOVERY
to enter recovery mode to monitor heart rate recovery ability.
Page 12

Exercise Monitor Instruction
RECOVERY
The RECOVERY key will only be valid if a pulse is detected. TIME will show "0:60" (seconds)
and counts down to 0. The screen will show F1 to F6 after the countdown.
For Heart Rate Recovery Levels see the chart below. Press the RECOVERY key again to return to the start.
PLEASE DISPOSE OF OLD BATTERIES CAREFULLY AND CONSIDERATELY
F1 - Outstanding F2 -Excellent F3 - Good F4 - Fair F5 - Below Average F6 - Poor
NOTE: - Please refer to the guide in your Assembly & Training Manual for information and
guidance on Exercise Pulse Limits.
BATTERY INSTALLATION
To fit the necessary BATTERIES - (NOT SUPPLIED) to your Exercise Monitor,
remove the BATTERY COVER at the REAR of the monitor.
Carefully fit the batteries by fitting between the exposed contacts in the battery
compartment. Ensure that batteries are fitted with the '+' / '-' ends matching.
Failure to fit batteries correctly may result in damage to your Exercise
Monitor that is not covered by our guarantee.
USING YOUR EXERCISE MONITOR
START to exercise or press the ENTER/ENTER key and the Exercise Monitor will begin to register
the various functions.
The Exercise Monitor will enter SLEEP Mode is there is no signal detected for 4 minutes
You are able to set Exercise Targets in the following functions: - TIME, DISTANCE, CALORIE
BURN and HEART RATE.To set targets for these functions, press the SET key when the function
is active on the LCD screen. This will enable you to programme TIME, DISTANCE, CALORIE BURN
and HEART RATE to count down from your set targets.
MOISTEN your HANDS slightly before using the Pulse Function to ensure good contact is
made on the Sensor Pads. Failure to do this may result in a bad connection and erratic Pulse readings.
A representative reading, which should not be used for medical or therapeutic reasons, will show
after approximately 5 seconds. The readings will stabilise after approximately 10 seconds.
Page 13

Assembly & Adjustments
LEVELLING THE CYCLE
niamdedlewyrotcafasahelcyCgniniarTruoy,ytilibatsdnaytirucesroF
frame and once fully assembled correctly, should not need further alignment.
However, in the interest of safety, please always ensure that your Training
Cycle is positioned on a solid, flat surface. If necessary, use a rubber mat
underneath to reduce the possibility of damaging flooring or slipping in use.
If you need to make a fine adjustment, simply turn the Foot Pads (14)
on the stabilisers to compensate for uneven floors.
14
Page 14

Assembly & Adjustments
RESISTANCE ADJUSTMENT
To increase the intensity of your workout, simply adjust the Brake
Knob (30). Turning clockwise will increase the resistance created
by the brake Pad.
To stop the flywheel quickly, push down on the Brake Knob (30).
In accordance with BS EN 957,
the braking (resistance) system
on this cycle is speed
independent.
Note
Note
30
The flywheel can be stopped by
pushing down on the brake knob
if emergency.
For your safety, always make
sure the flywheel is locked
by full tightening brake knob
while it is without using.
30
A B
Page 15

Assembly & Adjustments
HANDLEBAR ADJUSTMENT
To adjust the user height of the Handlebar (18), unscrew the
Adjuster Knob (7) a few turns until it can be pulled out to alter
the position of the Handlebar to the desired setting.
SEAT ADJUSTMENT
In addition to the vertical and lateral adjustment, the Saddle (13)
angle can be adjusted by slackening the nuts on either side of the
seat rails, selecting the required position and re-tightening.
7
13
7
7
Page 16

ACCESSORY FITMENT LIST
The following accessories are supplied in a pack and should be checked before attempting assembly.
The are all the accessories you will need to complete the assembly of your product.
Assembly & Adjustments
Page 17

Attach the Rear Stabiliser Tube (4) to the Main Frame (16)
using 2 x M8 x 45mm Carriage Bolts (3), 2 x M8 Flat Washers
(5), 2 x M8 Spring Washers (19) and 2 x M8 Dome Nuts (6).
Attach the Front Stabiliser Tube (15) to the Main Frame with
the same 2 x M8 x 45mm Carriage Bolts (3), 2 x M8 Flat
Washers (5), 2 x M8 Spring Washers (19) and 2 x M8 Dome
Nuts (6). Fix the Bottle Cage (24) to the Main Frame using
2 x Screws (25).
Note 1
Beny Sports Co. UK Ltd
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire.
BD20 7BW
Carefully unpack each component, checking against the parts list that
you have all the necessary parts to complete the assembly of your
product.
Please note that some of the parts may be pre-fitted to major
components, so please check carefully before contacting our
CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before
contacting us first.
Tel:- 0800 3 101 202 or
[phone]
Email:- [email protected]
Website: www.benysports.co.uk
CUSTOMER SUPPORT is open from 9.00am to 5.00pm from Monday
to Friday
Assembly & Adjustments
Do NOT FULLY TIGHTEN any
Bolts, Nuts or Fittings at this
stage unless specifically
instructed to do so.
32
16
6
19
5
4
3
24
25
6
19
5
15
3
Page 18

Assembly & Adjustments
2Slide the Saddle Post (10) into the Main Frame (16) and secure at the
desired height with Knob (7). Slide the Saddle Axis (12) into the Saddle
Post (10) and secure at the desired reach with 1 x Knob (7). Place
Saddle (13) on the Saddle Axis and securely tighten.
Note
Set the saddle at an appropriate
height allowing for a slight bend
in the knee when the pedal is at
its lowest position.
13
12
10
7
7
16
Page 19

Assembly & Adjustments
3The Pedals (1L and 1R) are marked “L” and “R” for Left and Right.
Fit them to their appropriate Crank Arm. The Right Crank Arm is on the
right hand side of the cycle as you sit on it.
Note
One Pedal is supplied with a
RIGHT HAND THREAD for the
RIGHT HAND SIDE of the cycle
and must be fitted by turning
CLOCKWISE. The other Pedal is
supplied with a LEFT HAND THREAD
for the LEFT HAND SIDE and must
be fitted by turning ANTI-CLOCKWISE.
16
1R
1L
Page 20
