V-tech VM344 User manual

Go to www.vtechphones.com
to register your product for
enhanced warranty support
and latest VTech product news.
VM344
Quick start guide
What’s in the box VM344 baby monitor system
63ē
63ē
Once you power on your baby monitor, your parent unit displays image from the baby unit, and the LINK LED
light turns on. The ON/OFF LED light of the baby unit also turns on.
4
Status check
Night vision
The baby unit has infrared LEDs that allow you to
see your baby at night or in a dark room. When the
baby unit detects low light levels, the infrared LEDs
turn on automatically.
NOTES
It is normal if you see a short white glare on your
parent unit screen as the baby unit is adapting to the
dark environment.
When the infrared LEDs are on, the image is in black
and white. This is normal due to external light sources.
TIP
Depending on the surroundings and other interfering
factors, like lightings, objects, colors and backgrounds,
the display resolution may vary. Adjust the baby unit’s
angle, or place the baby unit at a higher level to prevent
glare and blurry display.
•
•
•
Baby’s room Living room
2
Install the battery
THIS SIDE UP
1
2
2
1
More than 1 meter
(3 feet)
1
Connect and power on - Baby unit
2
1
Dim mode
With dim mode preset to on, your parent unit display will dim after 10 minutes of inactivity to conserve energy.
Press any button on your parent unit to restore screen brightness.•
10 min inactivity
Sound-activated Screen
On
O
Sound activation
Automatically turns on the parent unit screen when the
baby unit detects a sound after the screen is turned off.
When no sound is detected within 50 seconds, the screen is
automatically turned off to save power.
CAUTION
To prevent high-pitched screeching noise from your baby monitor:
Make sure your baby units and parent unit are more than 1 meter (3 feet) apart.
Turn down the volume of your parent unit before caring for your baby.
•
-
-
3
1
2
3
Connect and power on - Parent unit
More than 1 meter
(3 feet)
More than 1 meter
(3 feet)
63ē
6U]KXOTMUT
2s
1
2
6U]KXOTMUT

Insert the screws into the
holes and tighten the screws
until only 1/4 inch of the
screws are exposed.
Place the baby unit on the wall mount.
Tighten the screw into the threaded socket
at the bottom to secure the baby unit. Align
the holes on the wall mount with the screws
on the wall, and slide the wall mount down
until it locks into place.
If you drill the holes into a stud,
go to step 3.
-OR-
If you drill the holes into an object
other than a stud, insert the wall
anchors into the holes. Tap gently on
the ends with a hammer until the wall
anchors are flush with the wall.
Align the wall mount and screws
with the holes in the wall as shown.
Tighten the screw in the middle
hole first, so that the wall mount
position is fixed.You can tighten the
other screw in the top hole.
Place the baby unit on the wall
mount. Tighten the screw into the
threaded socket at the bottom to
secure the baby unit.
2
1
Place the wall mount on a wall and
then use a pencil to mark the top
and the bottom holes as shown.
Remove the wall mount and drill
two holes in the wall (7/32” drill bit).
NOTES
Check for reception strength and
camera angle before drilling the holes.
•
1
2
3
Mount the baby monitor (optional)
OR
Change different views (require additional baby units - VM314)
Press VIEW to switch between the images of the baby units.
Press VIEW
Press PATROL to alternately view the image from the baby units every 10 seconds.
Press SPLIT to view the images from all baby units at once.
Press VIEW
You can view from different baby units if you have more than one baby units in your system (VM314 purchased separately).
Specifications are subject to change without notice.
© 2015 VTech Communications, Inc. All rights reserved.
12/15. VM344_QSG_V3.0. Document order number: 96-010955-030-100
Overview - Parent unit
VIEW / LCD ON/OFF
PATROL
SPLIT
Antenna
Speaker
Stand
At least 1 meter
(3 feet)
Zoom
TALK
+ / VOL / -
On/off
MENU/SELECT
Arrow keys
Light indicators
Microphone
Overview - Baby unit
Microphone
Camera
Light sensor
Infrared LEDs
Temperature
sensor
Antenna
+ / VOL / -
Speaker
ON/OFF switch
ON/OFF light
Basic operation - Parent unit
Adjust speaker volume
Press + / VOL / -to adjust your parent unit speaker
volume.
Press to zoom in or out.
63ē
63ē
63ē
Alert Tone
Low Bettery Tone
No Link Alert
Sound alert in split-view
Alert Tone
Low Bettery Tone
No Link Alert
Sound alert in split-view
LCD is turning off...
63ē
63ē
63ē
6U]KXOTMULL
6U]KXOTMUT
2s
6U]KXOTMULL
Pan, tilt, zoom
Press and hold , , or to move the camera.
63ē
63ē
63ē
Talk
Press and hold TALK to talk to the baby unit.
Turn off the screen
Press and hold LCD ON/OFF to switch off the screen.
You can still hear sound from the selected baby unit.
Use the menu
Press MENU/SELECT to enter the menu, choose
a menu item, or save a setting.
While in the menu:
Press or to scroll up or down.
Press to select an item, or save a setting.
Press BACK to return to the main menu or
idle screen.
•
•
•
Turn off the parent unit
Press and hold to power off your parent unit.
Basic operation - Baby unit
Adjust speaker volume
Press + / VOL / -to adjust your baby unit
speaker volume.
Turn off the baby unit
Slide the ON/OFF switch to the right to power
off your baby unit.
2s
Long press
