V-tech IP-MR18S User manual

IP-MR18S
User Manual
Door Station
Please read this manual carefully before using the product you purchase, and keep it well for future
use. We reserve the right to modify the specication in this manual at any time without notice.
1 2 3
654
7 8 9
#0
*
RF CARD

Contents
1. Parts and Functions..................................1
2. Terminal Descriptions ...............................1
3. Door Station Mounting..............................2
4. Basic System Connection ..........................3
5. Door Lock Connections .............................4
6. Door Station Congurations ......................5
7. Software,UI And Voice Data Updating ........9
8. How to use code unlock function ...............10
9. Change Unlcok Code ...............................11
10. User Card Management..........................12
11. Specication.........................................13

1. Parts and Functions
2. Terminal Descriptions
Camera Lens
Night View LED
Speaker
With rainy cover
350 mm
128 mm
1 2 3
654
7 8 9
#0
*
LCD Screen
ID Card Window
Digital Keypad
Microphone
Touch Key
RF CARD
12
3
Adjustable Camera
Connectiong Port
SD Card Slot
12
3
RS-485
P - P+
JWP
JWB(OUT)
T/R -
CN-LK T/R+
J/KMB JP-LK
EB+ EB- N.O LK+ LK-
+12V
12
3
• +12V:12VDCpoweroutput.
• LK-(GND):Powerground.
• LK+(COM):CommoncontactoftheRelay.
• NO.:NormallyopencontactoftheRelay(Canbesettobenormallyclosed)
• EB+:Exitbuttonconnectionport.(ShortEB+&EB-tounlock)
• EB-:Exitbuttonconnectionport.
• JP-LK:Forelectroniclocksafetytypesetting(refertoDoorStationLockConnections).
• T/R-, T/R+:Reserved.
• JWP(P+,P-): Powerinputfordoorstation
• JWB(OUT): BUSOutput(IncludingData,audioandvideosignal)
• SD Card Slot: forupdatingthesoftware,UI,Namelistdata,orvoicedataofdoorstation.
-1-

3. Door Station Mounting
1 2 3
4
7
5 6
Drill a hole and attach the
rainy cover to it
Attach screws to fix the
metal box
Attach the unit to the rainy
cover correctlly
Attach the baffle to protect
the unit from droping
The last view for all mounting
The view for rainy
cover after mounted
Adjust the camera angle and attach the
metal to the panel and wire correctly.
Camera
angle
1
47
mm
3
95
m
m
4
2mm
RF CARD
-2-

4. Basic System Connection
Thebasicsystemconsistsof:Doorstation,Distributor,Monitor,Powersupplyandlock.
-3-
Connect to next C5-F4
C5-F4
C5-F4
12 V DC lock
- +
PS5
1 2 3
654
7 8 9
#0
*
RF CARD
85~260AC
PS5
RS-485
P - P+
JWB(OUT)
T/R -
CN-LK
T/R+
J/KMB JP-LK
EB+ EB- N.O LK+ LK-
+12V
12
3
1 2 3
654
7 8 9
#0
*
RF CARD

5. Door Lock Connections
JP_LK
12V 300mA
Jumper set to 2-3 position
+
-+12V
LK - (GND)
LK+(COM)
N.O.
EB+
EB -
1 2 3
set to Normally open on the
Unlock Relay mode
+
+
-
-
+12V
LK - (GND)
LK+(COM)
N.O.
EB+
EB -
Remove the Jumper
set to Normally Open on the
Unlock Relay mode (default)
JP_LK
1 2 3
Note: Cut off this line when
using external power supply
-4-
1. Internal Power Supply Mode
Notethatthedoorstationcanonlyoutput12Vdcpower,Anyhigh-powerlockshoulduseex-
ternalpowerconnection,oritmightcausedamagetothedoorstation.
• Theratedpowerofthelockmustbelessthan12Vdc300mAwhenusinginternalpower
supplymode;
• TheGNDmustconnecttothenegativeofthelock,andtheCOMconnecttothepositive;
• It'srecommendedthatthejumpersetto2-3positionforPower-on-to-Unlocksafety
type(Normally open mode);
• Ifdifferentunlockingtimeisneededtobeconfigured,changetheUnlock Timingon
doorstation.
Connection for Power-on-to-Unlock type:
2. External Power Supply Mode
Iftheelectroniclockisover12Vdc,additionalpowersupplyforthelockisneeded.
• Thepowersupplyforthelockmustbelessthan48Vdc1.5A.
• TheJumpermustberemovedwhenusingexternalpowersupply.It'srecommendedthe
unlockmodesettoPower-on-to-Unlocktype(Normally open mode).
• Ifdifferentunlockingtimeisneededtobeconfigured,changetheUnlock Timingon
doorstation.
Connection for Power-to-Unlock type:

6. Door Station Congurations
About Debug State:
TheDebugStateisyourstartingpointforusingalltheapplications.Toopenthedebug
state,pleaserefertothefollowingsteps:
WhenDoorStationisin
standby,press'#'key
Press"2#"keytoexitoutthedebugstate.
Input'9008',theninputthe
AdminCode.(66666666by
default)
DebugStatemenuislaunched
[ 9 0 0 8 ]
1 2 3
654
7 8 9
#0
*
RF CARD
About Debug Tools:
DuringworkingatDebugState,press"1#"toentertoolspage,DebugToolsoverviewisshown
asbelow:
-5-

Table1:Menuoverview
-6-
Item Submenu
1. Installer Setup
1.IDCode[0-11]
2.UnlockTiming[01]
3.UnlockOutput[0]
4.MonitorTiming[030]
5.DoorplateMode[0]
6.WaitingTiming[030]
7.TalkingTiming[090]
8.InstallerCode...
9.Default...
2. Setup
1.Language[0]
2.ToneSelect[01]
3.ToneVolume[3]
4.UnlockCode[1111]
5.CardMemory[0]
6.Clock...
7.SetupCode
8.About
9.Default...
3. Card Manage
1.AddCard...
2.DeleteByCard
3.DeleteByM.code
4.CardsInformation
5.Format
4. Online Monitors Tosearchtheonlinemonitors,inputthemonitorcode
numbertosearch
5. Online Devices Tosearchtheonlinedoorstations.Max.4doorstation
canbesearched

Basic Tools Detail:
Table2(InstallerSetup):
-7-
Item Description Factory
set
1.IDCode
1.WhenthereisonlyonedoorstationandnoC5-IPC,
setto0.Andsetthetypeofdistributorusedwithit.
WhenC5-IPCisconnected,mustnotbesetto0.
2.WhenC5-MDSisconnected,besettofrom1~8
accordingtowhichportitisconnectedontheC5-MDS
3.Whenusedascommondoorstation,setto9
[0]
Single
2.UnlockTiming Tosetthetimethathowlongthedoorkeepsopen
whendoorisreleased.Rangefrom01to99seconds.
[01]
1seconds
3.UnlockOutput
Tosettheunlockmodetomatchthecorresponding
lock.Rangefrom0to1.
0:Power-on-to-UnlockMode(NormallyOpenMode)
1:Power-off-to-UnlockMode(NormallyClosedMode)
0
4.MonitorTiming Toshowthemonitortime,Rangefrom6sto600s 600s
5.DoorplateMode
Tosetthecallingmode.Ifsetto0,it'stheauto
mode,thatmeansthecallingwillbeactivateddirectly
afterinputting4digitscode.Ifsetto1,it'sthemanual
mode,thatmeansyoushouldpress"#"buttontoacti-
vatethecallingafterinputtingthecode.
[0]
Automode
6.WaitingTiming Toshowthecallingwaittime,Rangefrom6sto600s 40s
7.TalkingTiming Toshowthelimitationtimeoftalking,Rangefrom6sto
600s 90s
8.InstallerCode... Tochangedoorstationadministratorcode [66666666]
9.Default...
Notethisoperationisirreversible.Oncerestoreis
activated,allparameterswillreturntofactorydefault
settingexcepttheinformationofaccesscard.
* Notethatyoucanuseanotherway(#+8001+66666666)toentertheInstaller Setup
mode.

Table3(Setup):
-8-
Item Description Factory
set
1. Langua ge reserved.
2 .  To n e  S e l e c t  SelectthechimeofDoorStationincallingwaitstate. 01
3 .  To n e  V o l u m e  Adjustthetonevolumefordoorstationincalling.Range
from01~15 03
4 .  U n l o c k  C o d e  TochangeunlockcodeinCommonCodeUnlockmode,
in4-digitsformat.1111isthedefaultunlockcode. 1111
5.CardMemory
Tochoosetousethememoryofdoorstationorthatof
C5-IPCwhenaccesscardsareinuse
0-UsememoryofDSforaccess
1-UseC5-IPCforaccess
0
6.Clock...
Tosetdateandtime.
Dateformat:ifsetto0,dateformatisDD/MM/YY,ifsetto
1,dateformatisMM/DD/YY.
Timeformat:ifsetto0,timeformatis24hourstandard.If
setto1,timeformatis12hourstandard.
7.SetupCode TochangetheProgramCode. [88888888]
8.About
1.Hardwareversion---ToshowtheDoor
Station(includingACS)hardwareinformation
2.Softwareversion---ToshowtheDoor
Station(includingACS)softwareinformation
3.ManufactureDate---Toshowthemanufacturingdate
4.DialingCounts---Toshowthecalloperationcounts
5.CallsCounts---Toshowtheestablishedcallingcounts
6.UnlockCounts---Toshowtheunlockoperationcounts
9.Default... RestoreallSetupparameterstofactorydefault
setting,Pleasenotethatthisoperationisanirreversible
* Notethatyoucanuseanotherway(#+8002+66666666)toentertheSetupmode.

-9-
Item Description Factory
set
1.AddCard... Toaddtheusercard
2.DeleteByCard Todeletecardbyusercard
3.DeleteByM.code Todeletecardbyroomcode
4.CardsInformation Toshowtheinformationsaboutcards
5.Format Toformatinformationsaboutcards
Table4(CardManage):
* Notethatyoucanuseanotherway(#+8007+66666666)toentertheCard Managemode.
7. Software,UI And Voice DataUpdating
It'sconvenientforusertochangethesoftware,UI,Namelistdata,orvoicedata.Justputthe
conglestotheSDcardandinserttheSDcardintodoorstationandbymeansofthedigital
keypad,only30secondsisneededtoupdate.
Insert SD card
12
3
RS-485
P - P+
JWP
JWB(OUT)
T/R -
CN-LK T/R+
J/KMB JP-LK
EB+ EB- N.O
LK+
LK-
+12V
12
3

-10-
8. How to use code unlock function:
Pleaserefertothefollowingoperations:
[ 0003 ]
1 2 3
654
7 8 9
#0
*
RF CARD
1 2 3
654
7 8 9
#0
*
RF CARD
WhentheDoorStationisin
standby,Press“#”
Ifveriedcorrectly,
dooropen
Input4digitsUnlockCode
directly
[ 8014 ]
1 2 3
654
7 8 9
#0
*
RF CARD
[ 66666666 ]
1 2 3
654
7 8 9
#0
*
RF CARD
1 Firmware update
2 Voice update
3 UI update
4 Namelist update
Select (1~4) to update
WhentheDoorStationisin
standby,Press"#+8014
TheupdateitemmenuInput"66666666"

-11-
Press“#”,Input“8002”,
theninputSetupCodeor
AdminCode(88888888or
66666666bydefault)
Pressandhold
button.
Inputsetting
code(001~300),
thenpress“#“to
save.
Inputroomnum-
ber,thenpress
“#“tosave.
Inputnewpass-
word,thenpress
“#“tosave.
Press“4”toenterunlock
codeitem.
9. Change Unlcok Code:
IfdoorstationrunsasDebugState,youcanpress“1#”toactivateToolsMenu,thenselect“2”
toentersetuppage,thenselect4item.IfitrunsasNormalState,followthesesteps:
Atthistime,youcansettheprivateunlockcode,followthesesteps:
[ 8002 ]
1 2 3
654
7 8 9
#0
*
RF CARD
4. Unlock Code [1111]
[----]
(****)
4. Unlock Code [1111]
[----]
(****)
[005]
Input setting code
[0058]
Input room number
Setting code: 005
RF CARD
4. Unlock Code
4. Unlock Code [----] [----]
[8888]
Input new password
Setting code: 005
4. Unlock Code [0058] [----]
[8888]
Input new password
Setting code: 005
4. Unlock Code [0058] [8888]
Onthispage,[1111]isthe
commonunlockcode.you
canchangethecommon
unlockcode.Input4digits
number,thenpress“#”to
update.

-12-
Delete user cards:
RegisteredUserCards/KeyFobscanbedeletedfromtheDoorstation,oncedoingthedelete
operation,thecard/keyfobscannotopenthedooranymore.Theycanalsobere-registered
againtobecomeavalidUserCard/UserKeyFob.TherearetwowaystodeleteUserCards/
UserKeyFobs:
1.Deletebycard:showtheunwantedcard(s)whentheDoorstationisinDeleteCardMode
2.Deletebyroomnumber:deletealltheregisteredUserCardsrelatedtothatroomnumber.
EnterAddCardmenu,and
RoomCodeisasked.
InputRoomCode Readthecardtobe
authorized
1.Add Card...
[----]
Please Input Room Code
1.Add Card...
[0001]
Show The Card
1.Add Card...
[0001]
Card Numbs:000125789
User
Card
10. User Card Management:
ThissectionexplainshowtocongurethekeyfobfunctiononIP-MR18S,Thekeyfobisused
toopenthelock.Total320keyfobscanberegisteredwithonedoorstation.Whenswipingthe
fobtothedoorstation,thedistancemustbelessthan3centimeter.
KeyFobsmustberegisteredontheDoorstationthatcanbeusedtoopenthedoor.
Register the Key Fobs:
AlltheregisteredkeyfobsarecalledUserCards/UserKeyFobs.Newfobs/cardsneedto
beregisteredonebyonetotheDoorstationtobecomeavalidUserCard/UserKeyFob;and
everyUserCard/UserKeyFobisrelatedtoacertainMonitorAddress(Flatcode).
WhentheDoorstationisstandby,press[#]-->[9008]-->Password([66666666bydefault])
togetintotheDebugModeMenu,thenPress[1#]-->[3]CardManage-->[1]AddCardtoget
intotheAddCardpage.Pleaseseethefollowings.

Delete By Card:
InDebugState,Press[1#]-->[3]Card
Manage-->[2]DeleteByCardtoenter
DeletebyCardpage.asshownonthe
right,thenshowthecardsyouwantto
deleteonebyone.
InDebugState,Press[1#]-->[3]Card
Manage-->[3]DeleteByM.Codetoenter
DeletebyM.Codepage.asshownonthe
right,thenInputtheRoomCode,press
“#”toconrm;allassociatedcardswillbe
deleted.
Delete by Room Number:
3.Delete By M.code
[----]
Please Input Room Code
3.Delete By M.code
[0001]
Please Input Room Code
2.Delete By Card
Show The Card
Card Numbs:000125789
User
Card
2.Delete By Card
11. Specication
●Power supply: DC 18~24V
●Camera Lens : 1/4 ACS 4T image sensor with DSP processor
●Power consumption: Standby 3W;Working status 7.5W
●Screen: 3.5 inch TFT
●Resolution: 320(R, G, B)X240 pixels
●Video signal: CCIR/EIA Optional
●Wiring: Cat5
●Dimension: 350(H)×128(W)×46(D)mm
-13-

C5-ENG-IP-MR18S-V1 2015S1126
