V-ZUG Adora 55 SL User manual

Operating instructions
Design-integrated, fully integrated Adora SL
Dishwasher

Thank you for choosing to buy one of our products. Your appliance is made to high
standards and is easy to use. Nevertheless, please take the time to read these operating
instructions in order to familiarize yourself with the appliance and get the best use out of
it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance at the
time these operating instructions went to press. The right to make technical modifications
for the purpose of the further development of the appliances is reserved.
Validity
The model number corresponds to the first alphanumerics on the identification plate.
These operating instructions apply to:
Model designation Model number Type Size system
Adora 55 SL 41127 – 41132 GS55SL… 55 (SMS)
Adora 60 SL 41135 – 41140 GS60SL… 60 (EURO)
Adora 60 SLWP 41133, 41134 GS60SLWP… 60 WP (EURO)
Variations depending on the model are noted in the text.
© V-ZUG Ltd., CH-6302 Zug, 2019
2

3
Contents
1 Safety precautions 5
3 Appliance description 9
3.1 Construction ........................................................... 9
3.2 Operating and display elements.......................10
4 Programme overview 11
4.1 Programme ...........................................................11
4.2 Additional functions.............................................12
4.3 EcoManagement..................................................12
5 Operation 13
5.1 Preparing the appliance .....................................13
5.2 Dish washing tips ................................................13
5.3 Hints on loading the cutlery drawer * ..............14
5.4 Loading tips for the upper basket ....................14
5.5 Loading tips for the lower basket.....................17
5.6 Detergent...............................................................20
5.7 Selecting a programme......................................21
5.8 Delayed start ........................................................23
5.9 Interrupting a programme ..................................24
5.10 Aborting a programme before time .................24
5.11 Operation with the childproof lock activated..24
5.12 End of programme ..............................................25
5.13 EcoManagement statistics.................................25
6 V-ZUG-Home 26
6.1 Conditions .............................................................26
6.2 Initial set-up...........................................................26
7 User settings 27
7.1 Overview of user settings...................................27
7.2 Changing user settings ......................................27
7.3 Language ..............................................................28
7.4 Contrast .................................................................28
7.5 Acoustic signal.....................................................28
7.6 All in 1....................................................................28
7.7 Water hardness....................................................28
7.8 Rinse agent dosage............................................29
7.9 Water hardness unit ............................................29
7.10 DryPlus...................................................................29
7.11 RinsePlus................................................................29
7.12 Hot water connection...........................................29
7.13 OptiStart..................................................................29
7.14 EcoManagement...................................................30
7.15 Clear counter.........................................................30
7.16 Childproof lock......................................................30
7.17 Heat pump (depending on model)....................30
7.18 V-ZUG-Home mode..............................................30
7.19 Automatic door opener........................................31
7.20 Temperature unit...................................................31
7.21 Interior light ............................................................31
7.22 Tank storage duration..........................................31
7.23 Emptying the tank in the event of a power fail-
ure............................................................................31
7.24 Automatic standby................................................32
7.25 Factory setting.......................................................32
8 Care and maintenance 33
8.1 Cleaning the interior and exterior ......................33
8.2 Cleaning the spray arms .....................................33
8.3 Cleaning the filter system....................................34
8.4 Refilling with regeneration salt ...........................34
8.5 Filling with rinse agent .........................................35
8.6 Draining the storage tank....................................35
9 Trouble-shooting 36
9.1 Error messages.....................................................36
9.2 Other possible problems.....................................38
9.3 Unsatisfactory washing results...........................39
9.4 In the event of a power failure ...........................40
10 Accessories and spare parts 40
11 Technical data 42
11.1 Product fiche .........................................................43
11.2 Consumption data ................................................44
11.3 Note for testing institutes ....................................46
11.4 Noise measurement .............................................46
12 Disposal 47
13 Notes 48

4
14 Service & Support 51

5
1 Safety precautions
Read the operating instructions be-
fore using the appliance for the first
time.
1.1 General safety precautions
▪This appliance can be used
by children aged8 and above
and by persons with reduced
physical, sensory or mental
capabilities, or lack of experi-
ence and/or knowledge,
provided they are supervised
or have been instructed on
the safe use of the appliance
and have understood the haz-
ards involved. Children must
not play with the appliance.
Cleaning and user mainten-
ance shall not be undertaken
by children without supervi-
sion.
▪If an appliance is not
equipped with a mains cable
and a plug or other means for
disconnecting from the mains
with a contact opening on
each pole complying with the
conditions of overvoltage cat-
egory III for full isolation, an
isolating device must be in-
corporated into the perman-
ently installed electrical install-
ation in accordance with the
installation regulations.
▪If the mains cable of this ap-
pliance is damaged, it must
be replaced by the manufac-
turer or its Customer Services
or a similarly qualified person
in order to avoid hazard.
1.2 Appliance-specific safety
precautions
▪Never use a steam cleaner to
clean the appliance.
▪If the appliance is installed on
a carpeted floor ensure that
the ventilation openings on
the base of the appliance are
not obstructed.
▪Only leave the appliance door
open in the at-rest position.
An open appliance door
poses a danger of tripping or
injury. Do not sit or rest on
the appliance door or use it
as a storage surface.
▪CAUTION: Knives and other
items with sharp points must
be placed with the point
downwards or placed hori-
zontally in the basket.
▪CAUTION: Do not drop or in-
sert knives, forks or other
sharp items in the opening of
the door lock.
▪No detergent must enter the
opening of the door lock. This
can cause the door lock to
malfunction.

1 Safety precautions
6
▪The appliance is only suitable
for washing household dishes
and cutlery with water and
standard dishwasher deter-
gent. The appliance is for use
in the home and for the inten-
ded purpose only. No liability
is assumed for any damage
caused by improper or incor-
rect use.
▪Capacity: 12 or 13 interna-
tional place settings (SMS 55,
cutlery drawer *). 13 or 14 in-
ternational place settings
(EURO 60, cutlery drawer *).
* Depending on model
▪This appliance is designed to
be used for household and
similar purposes such as:
staff kitchens in shops, offices
and other commercial
premises; agricultural proper-
ties; by customers in hotels,
motels and other residential
facilities; in bed-and-breakfast
hotels.
1.3 Correct use
▪Any repairs, modifications or manipula-
tions to the appliance, especially any
electrically live parts, may only be car-
ried out by the manufacturer, its Cus-
tomer Services or a similarly qualified
person. Repairs if carried out incorrectly
may cause serious injury, damage to
the appliance and fittings, as well as af-
fect the functioning of the appliance. If
the appliance is not working properly or
in case of a repair order, follow the in-
structions given in the «Service & Sup-
port» section. Please contact our Cus-
tomer Services if necessary.
1.4 Instructions for use
▪If the appliance is visibly damaged, do
not use it. Contact our Customer Ser-
vices.
▪If the appliance is not functioning prop-
erly, disconnect it from the power sup-
ply immediately.
▪Use original spare parts only.
▪Retain these operating instructions for
future reference.
▪Avoid opening the appliance door unne-
cessarily during operation. The dishes
and water may be hot – scalding haz-
ard! The steam that escapes can dam-
age wood combination fascias. Spec-
tacles can steam up, impairing your vis-
ion.
▪Do not wash objects that are soiled with
inflammable or corrosive solvent, paint,
wax, chemicals (acids or bases) or iron
chippings or that can shed fibres in the
appliance.
▪Packaging material, e.g. plastic film and
polystyrene, can be dangerous for chil-
dren. Danger of suffocation! Keep pack-
aging material away from children.
How to avoid damaging the appliance
▪Before closing the appliance door and
starting a programme ensure that there
are no foreign objects (e.g. nails or pa-
per clips) or pets in the appliance. For-
eign objects can damage parts of the
appliance as well as the dishes.
▪Never fill the rinse agent reservoir or
the regeneration salt reservoir with de-
tergent! If this were to happen, however,
do not operate the appliance under any
circumstances, as this could cause ex-
pensive damage to it. Call Customer
Services.

1 Safety precautions
7
▪Do not lean on any part of the appli-
ance – risk of accident!
▪Turn off the water tap during longer ab-
sences.
▪The appliance must be connected to
the mains supply to ensure appliance
protection (overflow protection, among
other things).
1.5 Transport and installation
Front
Tilt max. 90° to the right!
Transport the appliance in an upright posi-
tion only! Transporting it in any other posi-
tion will result in damage to the appliance!
When carried carefully without being
shaken, the appliance may be tilted a
maximum of 90° to the left (viewed from
the front).
1.6 How to avoid damaging the
appliance
▪Before closing the appliance door and
starting a programme ensure that there
are no foreign objects (e.g. nails or pa-
per clips) or pets in the appliance. For-
eign objects can damage parts of the
appliance as well as the dishes.
▪Never fill the rinse agent reservoir or
the regeneration salt reservoir with de-
tergent! If this were to happen, however,
do not operate the appliance under any
circumstances, as this could cause ex-
pensive damage to it. Call Customer
Services.
▪Do not lean on any part of the appli-
ance – risk of accident!
▪Turn off the water tap during longer ab-
sences.
▪The appliance must be connected to
the mains supply to ensure appliance
protection (overflow protection, among
other things).
1.7 Notes on using the
operating instructions
Graphical operating instructions can be
downloaded on the internet from
www.vzug.ch.

2 Using for the first time
After changing the location of an appliance that has a heat pump, it must be left to
stand in the normal operating final position for around 2 hours before it can be op-
erated again.
The appliance must be installed and connected to the electricity supply by a quali-
fied fitter/electrician in accordance with the separate installation instructions.
Before operating the newly installed appliance for the first time, the following steps
should be taken:
2.1 Before using for the first time
▸ Switch on the power and turn on the water tap.
▸ Set (see page 28) the water hardness.
▸ Fill the salt reservoir with approximately 1.0l water and 1 kg regeneration salt. Wipe
away any excess salt on the edge of the salt reservoir.
▸ Fill the rinse agent reservoir with rinse agent.
▸ Run the programme without dishes to protect the appliance from corrosion from
any excess salt and to remove traces of grease left behind from the manufacturing
process.
The refill indicator can flash during the first few wash cycles. goes out when the salt
concentration in the reservoir is evenly distributed.
Setting the door weight
Set the door weight, if required.
8

3 Appliance description
3 Appliance description
3.1 Construction
2
3
1
4
8
7
6
9
5
10
2
1
1Baskets
2Spray arms
3Cutlery basket
4Rinse agent reservoir
5Operating and display elements
6Quick operating instructions
7Detergent dispenser
8Salt reservoir
9Filter system
10 «Small» cutlery basket *
11
12
13
11 Cutlery drawer *
12 Function light *
13 Plain text display on glass panel *
* Depending on model
9

3 Appliance description
3.2 Operating and display elements
34
32
111
1 Buttons 2 Programme sym-
bols
3 Additional function
symbols /
Indicator symbols
Programme selec-
tion
Eco programme Energy saving /
OptiStart
EcoManagement Automatic Partial load
SteamFinish Daily quick Rinse agent
refill indicator
Partial load Sprint «All in 1» detergent
Delayed start Intensive SteamFinish
End of pro-
gramme
Silent Salt refill indicator
Party V-ZUG-Home
Extra programmes
4 Display Acoustic signal Function light
(depending on model)
▪Programme name
with duration/temper-
ature
▪Programme progress
and time remaining
▪Additional functions
▪Hints and trouble-
shooting
An acoustic signal is
emitted at the end of the
programme and in the
event of a malfunction.
▪Illuminates during the pro-
gramme sequence.
▪Flashes during the final
drying phase.
10

4 Programme overview
4 Programme overview
4.1 Programme
Programme time, water consumption and energy consumption can be reduced by select-
ing the and additional functions.
Eco programme: The most efficient programme in terms of water and en-
ergy consumption for normally dirty dishes (declaration programme).
Automatic: Optimum cleaning with minimal water and energy consumption.
Not for burnt-on or dried leftovers.
Daily quick: Quick programme for normally soiled daily dishes. Cleans with
high spray pressure.
Sprint: For slightly dirty dishes such as drinks glasses or coffee cups and
saucers. Not suitable for slowly dissolving tabs.
Intensive: For very dirty dishes, particularly with starchy leftovers (mashed
potato, rice etc.).
Silent: Exceptionally quiet programme for washing the dishes at night. Suit-
able for normally soiled dishes.
Party: Quick wash programme for lightly soiled dishes that need to be
cleaned quickly, e.g. at a party or an aperitif. Not suitable for tabs. Only use
detergent in powder or gel form.
Programme start after heat-up phase:
Heating up for 10 mins.
The flashing symbol indicates that one of the following programmes
was selected. The programme selected is shown in the display.
Glass: Gentle programme for glasses.
Fondue/Raclette: For heavy soiling, particularly suitable for burned-on soil-
ing. Only use dishwasher-safe table- and kitchenware. Add detergent to the
pre-rinsing compartment, if necessary.
Hygiene: For items where hygiene requirements are high (e.g. baby bottles,
cutting boards...). Clean the filter system before starting the programme.
Machine care: The appliance and in particular the storage tank are rinsed
hygienically clean. Clean the filter system before starting the programme.
Add dishwasher cleaner as per the manufacturer’s instructions.
Pre-rinsing: To prevent soiling drying on if intending to start a wash pro-
gramme later.
11

4 Programme overview
4.2 Additional functions
Depending on the user settings, select between two functions.
1 × Energy saving: The wash temperature is reduced by 5 °C, lowering
energy consumption by about 10 %. Gentle on glasses. The pro-
gramme time is shortened slightly.
Appliances with a heat pump: overall energy consumption is reduced
by up to 30 %, however the programme time is extended.
2 × OptiStart: If the «OptiStart» user setting is active, a delayed start is
set. During the delayed start, the dishes are soaked and this im-
proves the cleaning results and reduces the energy consumption.
SteamFinish: During rinsing, steam is generated, which settles on the
glasses and leads to optimum drying results. The programme takes
around 15 minutes longer.
Partial load: For a small load of dishes. The amount of water used is re-
duced by up to 6l and the duration of the programme is shortened by
up to 36minutes. Depending on the programme selected and the elec-
trical connection, the time saving may be less than 36 minutes.
Delayed start: Allows you to wash during off-peak hours (e.g. at off-peak
electricity rates). A delayed start of between 30 minutes and 24hours
can be set.
4.3 EcoManagement
Only active if «EcoManagement» is turned on in the user settings.
EcoManagement provides information on the energy and water consump-
tion of the appliance and supports the sustainable use of energy. The fol-
lowing consumption information can only be retrieved when no pro-
gramme is running:
▪Energy and water consumption of the last programme
▪Total energy and water consumption
▪Average energy and water consumption of the last 25 programmes
The energy and water consumption of a programme is displayed during
programme selection. At the end of a programme, the energy and water
consumption of the last programme run is displayed.
The values can vary according to programme, load, additional functions
and user settings.
12

5 Operation
5 Operation
5.1 Preparing the appliance
After changing the location of an appliance that has a heat pump, it must be left to
stand in the normal operating final position for around 2 hours before it can be op-
erated again.
▸ Remove any coarse or hard pieces of food or foreign objects (such as toothpicks) left
on the dishes.
▸ Load the baskets. After loading, check that the spray arms can turn freely.
5.2 Dish washing tips
General notes
▪Do not overload the baskets.
▪Dishes, pots and pans with heavily burned-on food debris stuck to them should be
soaked in water first.
▪Load beverage and food containers such as cups, glasses, pots, etc. with the opening
facing downwards so that the water can drain off.
▪When loading, ensure glasses do not touch so as to prevent damage and water
spots.
▪When cleaning range hood grease filters, select the programme and use the max-
imum amount of detergent.
Dishes
Not all table- and kitchenware are dishwasher safe.
▪Clean wooden or plastic parts that are sensitive to damage from heat and detergent
suds by hand.
▪Pottery has a tendency to crack or chip.
▪The printing on glass and porcelain is hard-wearing only to a point and eventually over
time can wear off.
▪Glassware, depending on the type and the detergent being used, can become cloudy.
Check with your glassware supplier as to whether your glassware is dishwasher safe.
▪Stress and tension in thick cut crystal glasses and dishes can cause cracking.
▪Do not wash dishes with adhesive labels on them. Adhesive labels can come off and
clog up the filter system.
▪Objects made of silver, copper and tin tend to discolour, turning brown or black.
▪Spots tend to form on aluminium. Wash aluminium separately or by hand.
13

5 Operation
5.3 Hints on loading the cutlery drawer *
* Depending on model
▸ Where possible, load spoons with
handles between the tines.
▸ With thick-handled spoons or if the side
is raised (see below), place the mouth-
piece between the tines.
▸ Tall glasses: Raise the right side by
2cm or push it into the middle.
If tall glasses hit the cutlery drawer frame, they could get damaged.
5.4 Loading tips for the upper basket
▸ Arrange smaller items such as saucers,
glasses, cups and dishes.
▸ If using the fold-down racks 1, stagger
the items.
▸ Rest glasses on the fold-down glass
holder 2.
1
2
14

5 Operation
Glass holder
Particularly suitable for tall glasses.
▸ Push the glass holders 1 gently down or,
alternatively, pull them up until they en-
gage.
1
Easy prongs
For placing drinking glasses, baby bottles,
vases and carafes anywhere in the basket.
▸ Put easy prong 1 over basket prongs.
▸ Use 2 easy prongs for wider vessels.
1
Racks
The racks 1 can also be used as glass
holders. Remove the racks to accommod-
ate tall glasses.
1
15

5 Operation
Dismantling/Adjusting the height of the
racks
Push the rack 1 up by the hooks 2.
Push the rack inward and then out.
▸ Hook the rack in the higher position 3, if
required.
2.
1.
3
2
1
Adjusting the upper basket
The height of the upper basket can be adjusted by around 2–4 cm (depending on
model). It can be inclined in various ways.
▸ To raise: Hold the upper basket at the
sides by the grips 1 and raise it into the
position required.
1
▸ To lower: Hold the upper basket at the
sides by the grips 1.
▸ Raise the upper basket slightly and
press the button 2 at the same time. The
locking device is released.
▸ Lower the upper basket into the position
required, release the button and engage
the basket.
▸ Put plastic bowls in the upper basket.
1
2
16

5 Operation
5.5 Loading tips for the lower basket
▸ Load larger items such as plates, bowls,
platters, pots and pans.
▸ Load wide items (soup plates, lids, etc.)
at the back on the right.
Fold-down tines
For a larger area for loading e.g. large
plates, pans, dishes or a number of cups
and glasses.
Cooking trays can be placed between the
prongs. Use easy prongs for greater stabil-
ity.
▸ Pull up the locking grip 1 at the side.
▸ Fold the tines down.
1
17

5 Operation
Easy prongs
For placing drinking glasses, baby bottles,
vases and carafes anywhere in the basket.
▸ Put easy prong 1 over basket prongs.
▸ Use 2 easy prongs for wider vessels.
1
Cleaning baking and steaming trays
The upper basket has to be removed for
larger trays.
▸ Slide the upper basket out as far as pos-
sible.
▸ Remove the basket safety lock 2 by
pushing it upwards.
▸ Pull the upper basket out of its guides.
▸ Load baking trays, using easy prongs for
greater stability.
2
▸ When the upper basket is put back, the basket safety lock 2 must be returned to the
locking position.
18

5 Operation
Cutlery basket
To avoid injury, place knives and cutlery with sharp edges or points into the cut-
lery basket in such a way that they do not stick out (points facing downwards).
Do not drop or insert knives, forks or other sharp items in the opening of the door
lock. Risk of damage to the appliance!
Knives and cutlery with sharp edges or points may also be placed horizontally in the up-
per basket.
▸ Place the cutlery basket over the folded-
down prongs anywhere in the basket.
▸ Distribute cutlery loosely in the basket,
with handles pointing down (except for
knives and the like). Spoons should not
be stuck together.
▸ To prevent items of cutlery sticking to-
gether, water spots during drying, and
smaller items slipping through the bas-
ket, put the inserts 1 supplied on the cut-
lery basket.
1
When closing the appliance door, ensure no items of cutlery are sticking out of the
tub or are trapped. The leak tightness of the appliance cannot otherwise be as-
sured.
19

5 Operation
5.6 Detergent
Choice of detergent
Never use washing-up liquid. Heavy foaming can cause malfunctions. Strictly ob-
serve the dosage instructions printed on the packaging and contact the detergent
manufacturer if you have any questions. Using too high or low a dosage can cause
damage to the appliance.
▸ Only use detergent specially formulated for dishwashers.
Tabs may not dissolve properly at a wash temperature of below 55 °C, affecting the
cleaning performance of the appliance.
NOTE! The «Party» programme is not suitable for the use of tabs! Only use detergent in
powder or gel form!
Combination cleaning products ( tabs/powder)
Continue to use regeneration salt and rinse agent for a good cleaning performance.
▸ Set to
All in 1 ON
in the user settings. The programmes and displays are ad-
apted to suit the detergent.
When the or refill indicators flash, continue to refill with regeneration salt or
rinse agent.
▸ If, after washing and drying, the results are not satisfactory, use conventional cleaning
products. Set to
All in 1 OFF
in the user settings. For complaints, contact the
detergent manufacturer.
Adding the detergent
No detergent must enter the opening of the door lock. This can cause the door
lock to malfunction.
Powder
▸ Open the detergent dispenser by push-
ing the release catch in the direction of
the arrow.
▸ Add the detergent to the detergent com-
partment. For dosage, follow the deter-
gent manufacturer’s instructions.
▸ Observe the «20 and 30 ml» level marks
1.
▸ For heavier soiling, add approximately 1
teaspoon of detergent to the
pre-rinsing compartment 2.
▸ Close the cover.
1
2
20
