V-ZUG Adora S Series User manual

Dishwasher
Integrated Adora S
Operating instructions
V-ZUG Ltd

2
Thank you for choosing to buy one of our products. Your appliance is made
to high standards and is easy to use. Nevertheless, please take the time to
read these operating instructions in order to familiarize yourself with the ap-
pliance and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appli-
ance at the time these operating instructions went to press. The right to make
technical modifications for the purpose of the further development of the ap-
pliance is reserved.
Symbols used
AIndicates step-by-step instructions.
– Describes how the appliance reacts to the steps taken.
䡲Indicates a list.
Validity
The model number corresponds to the first three digits on the identification
plate. These operating instructions apply to the models:
© V-ZUG Ltd, CH-6301 Zug, 2009
Denotes important safety precautions. Failure to observe said pre-
cautions can result in injury or damage to the appliance or fittings!
Denotes useful tips for the user.
Model Type Model no. Norm
Adora 55 S GS55Si/-c 182 SMS 55
Adora 55 S GS55S-Gi/-c 184 SMS 55
Adora 60 S GS60Si/-c 186 EURO 60
Adora 60 S GS60S-Gi/-c 188 EURO 60

3
Contents
Safety precautions 5
Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . 5
Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Children in the home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Note on use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Your appliance 10
Appliance description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating and display elements . . . . . . . . . . . . . . . . . . . . . 12
Programme overview 14
Additional functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Fondue/Raclette programme . . . . . . . . . . . . . . . . . . . . . . . 17
User settings 19
3in1 detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Childproof lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Water hardness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rinse aid dosage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Operation 24
Preparing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Loading the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Loading tips for the upper basket . . . . . . . . . . . . . . . . . . . . 26
Loading tips for the lower basket . . . . . . . . . . . . . . . . . . . . 30
Adding detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Programme selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Selecting additional functions . . . . . . . . . . . . . . . . . . . . . . . 36
Delayed start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Interrupting a programme . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Aborting a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
End of programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Operation with childproof lock activated . . . . . . . . . . . . . . . 41

… Contents
4
Care and maintenance 43
General cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Cleaning the exterior of the appliance . . . . . . . . . . . . . . . . . 43
Cleaning the filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cleaning the spray arms . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cleaning the water inlet filter . . . . . . . . . . . . . . . . . . . . . . . . 46
Filling with regeneration salt . . . . . . . . . . . . . . . . . . . . . . . . 47
Filling with rinse aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Trouble-shooting 49
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Interruption in power supply . . . . . . . . . . . . . . . . . . . . . . . . 53
Dishwashing tips 54
Technical data 55
Accessories and spare parts . . . . . . . . . . . . . . . . . . . . . . . . 56
Note for testing institutes . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Disposal 60
Index 61
Repair service 63
Quick instructions 64

5
Safety precautions
In accordance with the requirements of IEC 60335-1:
䡲This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless supervised or unless they have been given instruction
concerning the use of the appliance by a person responsible for their
safety.
Before using for the first time
䡲The appliance must be installed and connected to the electricity supply in
accordance with the separate installation instructions. The necessary work
should be carried out by a qualified fitter or electrician.
䡲Fill the salt reservoir of the water softener with approximately 1.5 l water
and 1 kg regeneration salt.
䡲Mix the salt solution well using a wooden spoon.
䡲It is advisable to run a wash programme without any dishes ( pro-
gramme with detergent) in order to remove traces of grease left behind
from the manufacturing process.
The appliance corresponds to recognised technology standards
and the relevant safety regulations. Proper use of the appliance is
however essential to avoid damage and accidents. Please therefore
follow the precautions given in these operating instructions.
For hygiene reasons, regeneration salt is also recommended for use
with low water hardness and 3in1 detergents.
The appliance was tested with water before being shipped. There may
therefore still be traces of water left in the appliance.

… Safety precautions
6
Correct use
䡲The appliance is only suitable for washing household dishes and cutlery
with water and standard dishwasher detergent. It is designed for use in the
home and the above-mentioned purpose only. No liability is assumed for
any damage caused by improper or incorrect use.
䡲Any repairs, modifications or manipulations to the appliance, especially
any electrical parts, should only be carried out by the manufacturer, its Cus-
tomer Services or similarly qualified persons. Repairs if carried out incor-
rectly may cause serious injury, damage to the appliance and fittings, as
well as affect the functioning of the appliance. If the appliance is not work-
ing properly or in case of a repair order, follow the instructions given in the
'Repair service' section. If necessary, please contact Customer Services.
䡲Use original accessories and spare parts only.
䡲Retain these operating instructions for future reference. If you sell or pass
the appliance on to a third party, please ensure these operating instruc-
tions accompany the appliance, together with the instructions on installa-
tion. In this way, the new owner can inform themselves about how to use
the appliance correctly and read the pertinent safety precautions.

… Safety precautions
7
Children in the home
䡲Packaging material (e.g. plastic, polystyrene) can be dangerous for chil-
dren. Danger of suffocation! Keep packaging material away from children.
䡲The appliance is designed for use by adults who are familiar with these op-
erating instructions. Children are often unable to recognise the danger of
electrical appliances. Ensure proper supervision and do not allow children
to play with the appliance – there is a danger that children could get locked
inside.
䡲The water in the appliance is not to be used as drinking water. Detergent
residue in the appliance could cause eye or skin irritation! Keep children
away from open appliance.
䡲Detergents can irritate the eyes, mouth and throat and even cause choking!
Keep detergents, regeneration salt and rinse agents out of the reach of
children.
䡲Use the childproof locking facility.

… Safety precautions
8
Note on use
䡲Do not use the appliance if visibly damaged or any of the connections are
damaged. Contact Customer Services.
䡲In the event of any defects or faults, contact Customer Services.
䡲If the appliance is not operating properly, turn off the water tap and discon-
nect the appliance from the electricity supply immediately.
䡲Do not sit or lean on the appliance door. After loading or unloading the ap-
pliance, do not leave the appliance door open as it can pose a risk – dan-
ger of tripping and bruising!
䡲Due to risk of injury, place knives and cutlery with sharp edges or points
into the cutlery basket in such a way that they do not stick out (points facing
downwards). Knives and cutlery may also be placed horizontally in the up-
per basket.
䡲Do not lean on the upper basket – risk of accident!
䡲Keep animals away from the appliance.
䡲To protect your dishes and cutlery, read the 'Dishwashing tips' section.
䡲Only use detergent, rinse agent and regeneration salt explicitly recom-
mended for use with your appliance by the manufacturer in the operating
instructions. Follow the directions for use carefully.
䡲Do not use the appliance without any or too little detergent – risk of causing
damage to the appliance.
䡲Do not use washing-up liquid as it can cause excessive foaming, causing
your appliance to malfunction.
䡲Store detergent and regeneration salt in a cool, dry place. Lumpy detergent
can cause problems. Please follow the safety warnings issued by the de-
tergent and rinse agent manufacturers carefully.
Switching off the power to the appliance disables the built-in over-
flow protection system.

… Safety precautions
9
䡲Never fill the rinse agent reservoir or the regeneration salt reservoir with de-
tergent. If this were to happen, however, do not operate the appliance un-
der any circumstances, as this could cause expensive damage to it. Please
contact our service centre, which can be found in the 'Repair service'
section.
䡲After filling the salt reservoir, run the «Pre-rinsing» programme.
䡲Do not wash objects that are soiled with inflammable or corrosive solvent,
paint, wax, chemicals (acids or bases) or iron chippings or that can shed
fibres in the appliance.
䡲Do not use solvents (e.g. turpentine, benzine) instead of, or in addition to,
water in the appliance – fire or explosion hazard!
䡲Before closing the appliance door and starting a programme ensure that
there are no foreign objects or pets in the appliance. Foreign objects which
can rust, such as nails and paper clips, can damage parts of the appliance
as well as the dishes.
䡲Avoid opening the appliance door during operation. The dishes and water
may be hot – scalding hazard! The steam that escapes can damage wood
combination fascias. Spectacles can steam up, impairing your vision.
䡲Do not leave the premises for a longer period of time when the appliance
is in operation.
䡲During longer absences, always turn off the water tap before cutting the
power going to the appliance by pulling out the plug or switching off the
fuse. Never pull the plug out of the mains socket by the cable. The mains
socket and the water connection are generally located in the cabinet adja-
cent to the appliance (under the kitchen sink, behind the waste bin).
䡲Do not spray the outside of the appliance with water. Do not use a steam
cleaner.
䡲From time to time, check the drain hose for tears, kinks, twists, bends, etc.

10
Your appliance
Appliance description
䡲Capacity: 12 place settings
䡲7programmes
«Daily wash»
«Quick wash/Glass care»
«Fondue/Raclette»
«Intensive»
«Pre-wash»
«Normal/Standard»
«Hygiene»
䡲Additional functions
«Energy saver»
«Wash upper basket only»
«Delayed start»
䡲3in1 detergent
䡲Childproof lock
䡲Overflow protection
䡲4-digit digital display
䡲Automatic limescale sensor
䡲Automatic rinse aid dosage
䡲Air fan drying

… Your appliance
11
Construction
1Door handle
2Operating and display elements
3Appliance door
4Baskets
5Salt reservoir
6Coarse and fine filters
7Rinse aid reservoir
8Detergent dispenser
9Quick programme guide
10 Cutlery basket
11 Spray arms
11
10
7
4
9
4
10
5
12
6
8
9
2
3
1

… Your appliance
12
Operating and display elements
Programme selection buttons
Digital display
Programme and indicator symbols with indicator lights
1Programme selection with indicator light
2Energy saver with indicator light
3Wash upper basket only with indicator light
4Delayed start
5End of programme with indicator light
6Display for:
䡲Programme duration/Programme time remaining
䡲Delayed start
䡲Childproof lock
䡲Wash temperature (during the «Cleaning» phase)
䡲Hints and trouble-shooting
7Display for:
Daily wash Pre-wash
Quick wash/Glass care Normal/Standard
Fondue/Raclette Hygiene
Intensive
8Display for:
Salt refill indicator
Rinse aid refill indicator
3in1 detergent indicator
123645
78

… Your appliance
13
Indicator lights
Indicator lights flash
Select programme(s) or function(s).
Indicator light for «End of programme» flashes
The programme has finished.
Indicator lights are illuminated
Programme(s) or function(s) is (are) active.
Indicator lights are not illuminated
Programme(s) or function(s) is (are) inactive.

14
Programme overview
Programme/Symbol Type of soiling
Daily wash
For normal soiling. Not suitable for burned-on or dried-on food.
Quick wash/Glass For light soiling, aperitif dishware and coffee cups. Not suitable
for slowly dissolving tabs.
Fondue/Raclette For heavy soiling and burned-on food, especially cheese (fondue
and raclette pans), casserole and gratin dishes.
Intensive For heavily soiling. Particularly suitable for dried-on starchy food
(e.g. rice, mashed potato, etc.).
Pre-wash To prevent food drying on if intending to start a wash programme
later.
Normal/Standard
Declaration programme for heavy soiling.
Hygiene For sanitizing the appliance and the water outlet. Where hygiene
requirements are high (e.g. for baby bottles, cutting boards, etc.),
items can be cleaned at a higher temperature. Clean the filters
before starting the hygiene programme.

… Programme overview
15
Programme sequence/Consumption data
Pre-
wash Cleaning Intermedi- ate wash
Rinse
aid Drying Dura- tion Water Energy
Yes 55 °C Yes 65 °C Yes 1h10 14 l 1.1 kWh
No 45 °C Yes 60 °C Yes 0h45 12 l 0.9 kWh
Yes 65 °C Yes 65 °C Yes 2h25 19 l 1.6 kWh
35 °C 65 °C Yes 65 °C Yes 1h30 23 l 1.55 kWh
Yes No No No No 0h07 4 l 0.05 kWh
No Yes Yes 65 °C Yes 1h55 12 l 1.05 kWh
60 °C 70 °C Yes 70 °C Yes 1h30 14 l 1.3 kWh

… Programme overview
16
Additional functions
In addition to the main programmes, two additional functions «Wash upper
basket only» and/or «Delayed start» may be selected.
The «Energy saver» function can only be selected in combination with the
/ / and programmes.
Function/Symbol Use
Energy saver Reduces the wash temperature at the «Cleaning» stage of the pro-
gramme by 5 °C, reducing energy consumption by about 10 % and pro-
viding gentle washing for glassware. Ideal for dishes which are lightly
soiled with low starch or low protein food.
Wash upper
basket only
Uses only the upper spray arm for washing. Load the upper basket only.
Delayed start
The wash programme can be delayed by between one hour and maxi-
mum 24 hours. The previous delayed start time will be shown.
Using the «Energy saver» and «Wash upper basket only» functions
shortens the duration of a programme.

… Programme overview
17
Fondue/Raclette programme
Uses
䡲Removes cheese which tends to stubbornly stick to fondue and raclette
pans and dishes.
䡲Removes food burned on to gratin dishes.
䡲Can be used to clean all other dishes.
Tips for best results
䡲Fondue pans made of enamelled metal or stoneware may be cleaned in
the appliance.
APlace the fondue pan 1facing downwards
so that the water can drain away.
Fondue pans made of earthenware (red-brown colour) should not be
washed in the appliance as these absorb water.
Fondue pans with a large opening in the handle are suitable for wash-
ing in the appliance.
1

… Programme overview
18
ALoad raclette dishes in the upper
basket as shown in the diagram.
Add about a tablespoon of detergent to the pre-rinsing compartment
in addition to the detergent in the detergent dispenser. This will im-
prove the wash results for heavily burned-on food.
Use an aluminium heat distribution plate between the burner and the
fondue pan to protect the fondue pan and to help prevent food from
burning on.
The appliance cannot, however, remove very heavily burned-on food
completely.

19
User settings
You can change certain user settings to suit your own preferences. Settings
can only be changed when there is no programme running. The procedure is
the same for all settings.
To access the configuration mode
AHold the button depressed for 5 seconds.
– appears in the digital display.
APress the button repeatedly to see the various settings.
APress the button to change the configuration.
– Any changes are taken over automatically and must not be confirmed.
To exit the configuration mode
APress the button repeatedly until the digital display goes out.
If no buttons are pressed within 15 seconds, the display goes out. The
new settings are saved.

… User settings
20
3in1 detergent
The setting adapts the wash programmes for 3in1 detergent in an opti-
mal way.
䡲3in1 products can generally only be used up to a certain water hardness.
When the or refill indicators light up, the appliance needs to be re-
filled with regeneration salt or rinse aid.
䡲The duration of very short programmes is extended because 3in1 deter-
gent takes longer to dissolve.
䡲The drying phase is also extended slightly.
Configuring the appliance for 3in1 detergent
AHold the button depressed for 5 seconds (to enter the configuration
mode).
APress the button 1×.
– appears in the digital display for 3in1 detergent OFF (factory
setting).
APress the button to change the setting.
– appears in the digital display for 3in1 detergent ON.
– The indicator light illuminates.
ATo exit the configuration mode, press the button repeatedly until the
digital display goes out.
