V-ZUG Magnum 2 60i eco User manual

Installation instructions
Magnum 2 60i eco | Jumbo 60i | Iglu 60i
Refrigerator and freezer

Contents
1 General safety information................................... 2
2 Putting into operation............................................ 2
2.1 Transporting the appliance....................................... 2
2.2 Installing the appliance............................................. 2
2.3 Appliance dimensions.............................................. 3
2.4 Recess dimensions.................................................. 3
2.5 Unit door................................................................... 4
2.6 Ventilation of the kitchen unit.................................... 4
2.7 Changing over door hinges...................................... 4
2.8 Installing the appliance in the recess........................ 5
2.9 Disposing of packaging............................................ 5
2.10 Connecting the appliance......................................... 5
Illustrated installation instructions...................... 7
Thank you for choosing one of our products. Your appliance
meets the highest of demands and is very easy to use.
However, please take time to read this user guide. It will help
you become familiar with your appliance so you fully enjoy it
and avoid faults.
Please follow the safety notes.
Changes
The text, images and details reflect the technical features of the
appliance at the time of print. They are subject to changes
brought about by further development.
Scope of application
The product range (model number) matches the first digits on
the rating plate. This user guide applies to:
Model Product range Unit system
Jumbo 60i 51078 Euro 60
Magnum 2 60i eco 51076 Euro 60
Model Product range Unit system
Iglu 60i 51077 Euro 60
Sections that apply to certain models only are marked with an
asterix (*).
Instructions for action are marked with a , the results of
action are marked with a .
1 General safety information
-Only install, connect and dispose of the appli-
ance according to the instructions. Take
particular note of “Recess dimensions” (see 2.4)
and “Ventilation of the kitchen unit” (see 2.6) .
-The socket must be easily accessible so that
the appliance can be quickly disconnected
from the supply in an emergency. It must be
outside the area of the rear of the appliance.
DANGER identifies a situation involving direct
danger which, if not obviated, may
result in death or severe bodily
injury.
WARNING identifies a dangerous situation
which, if not obviated, may result in
death or severe bodily injury.
CAUTION identifies a dangerous situation
which, if not obviated, may result in
minor or medium bodily injury.
NOTICE identifies a dangerous situation
which, if not obviated, may result in
damage to property.
Note identifies useful information and tips.
2 Putting into operation
2.1 Transporting the appliance
CAUTION
Risk of injury and danger of damage as a result of incorrect
transport!
uTransport the appliance in a packed condition.
uTransport the appliance upright.
uDo not transport the appliance without assistance.
2.2 Installing the appliance
WARNING
Risk of fire due to short circuit!
If the mains cable/connector of the appliance or of another
appliance touch the rear of the appliance, the mains cable/
connector may be damaged by the appliance vibrations,
leading to a short circuit.
uStand the appliance so that it is not touched by connectors
or main cables.
uDo not plug the appliance or any others into sockets located
near the rear of the appliance.
WARNING
Fire hazard due to dampness!
If live parts or the mains lead become damp this may cause
short circuits.
uThe appliance is designed for use in enclosed areas. Do not
operate the appliance outdoors or in areas where it is
exposed to splash water or damp conditions.
uOnly use the appliance when it is installed.
WARNING
Fire hazard due to refrigerant!
The refrigerant R 600a is environmentally friendly but flam-
mable. Escaping refrigerant may ignite.
uDo not damage the piping of the refrigeration circuit.
WARNING
Fire hazard and danger of damage!
uDo not place appliances emitting heat e.g. microwaves,
toasters etc. on the appliance!
NOTICE
Risk of damage.
An incorrect Side-by-Side- (SBS) assembly leads to conden-
sate between the appliances. Assemble the V-Zug appliances
as follows:
uInstall the freezer next to the refrigerator.
General safety information
2 * Depending on model and options

NOTICE
Risk of damage due to condensation!
When stacking multiple appliances there is a risk of conden-
sation damage.
uDo not stack refrigerators or freezers.
WARNING
Blocked ventilation openings pose a risk of fire and damage!
uAlways keep the ventilation openings clear. Always ensure
that the appliance is properly ventilated!
qIn the event that the appliance is damaged, contact the
supplier immediately before connecting to the mains.
qThe floor at the site must be flat and level.
qDo not install the appliance in a location where it is exposed
to direct radiation of the sun, next to a cooker, heater and
similar.
qDo not install the appliance alone: it is best to work together
with two or more people.
qThe more R 600a refrigerant there is in the appliance, the
larger the room in which the appliance is standing needs to
be. In rooms that are too small, a flammable mix of gas and
air may be created if there is a leak. According to the EN 378
standard, every 11 g of R 600a refrigerant requires at least
1 m3 space in the room for the appliance. The amount of
refrigerant in your appliance is on the type plate inside the
appliance.
qIf the appliance is installed in a very damp environment,
condensed water may form on the outside of the appliance.
Always make sure that there is good ventilation - both at air
inlet and outlet - at the site of installation.
After installation:
uRemove protective films, adhesive tapes and transport lock
parts etc.
Note
uClean the appliance (see Operating Instructions,
Chapter "Cleaning the appliance").
2.3 Appliance dimensions
Fig. 1
A (mm) B (mm) C (mm)
Magnum 2 60i eco, Jumbo
60i, Iglu 60i 559 544 1770
2.4 Recess dimensions
The appliance is built-in and therefore completely enclosed by
a kitchen unit. The kitchen unit concerned must be built exactly
to the prescribed dimensions and allow for sufficient ventilation,
both at air inlet and outlet, to ensure proper appliance opera-
tion.
Fig. 2
D
(mm)
E
(mm)
F (mm) G
(mm)
H
(mm)
J
(mm)
Magnum
2 60i
eco,
Jumbo
60i, Iglu
60i
1772
—
1788
560
—
570
min.
550,
recom-
mended:
560
min.
500
min.
40
max.
19
The specified energy consumption applies to a unit depth of
560 mm. The appliance will work properly at a unit depth of 550
mm, but at a slightly higher energy consumption.
uIn the case of Side-by-Side installa-
tion, two appliances next to one
another, build the appliances into
separate kitchen units.
uCheck the wall thickness of the adjoining cabinets: it must
be min. 16 mm thick.
uOnly install the appliance in robust, stable kitchen units.
Secure the units against tipping.
uAlign the kitchen unit using a spirit level and marking square
and if necessary compensate with shims.
uEnsure that the floor and walls of the unit are at right angles
to one another.
Putting into operation
* Depending on model and options 3

2.5 Unit door
-One door is required for the kitchen unit.
-The door must be minimum 16 mm and maximum 19 mm
thick.
-There must be a gap of minimum 3 mm width between the
door and the unit door located above it (if one exists).
-The width of the unit door depends on the style of the
kitchen and the gap size between the door panels of the
cabinet. Generally, there should remain a vertical gap of
3 mm between the unit doors.
-If other cabinets are present, the top edge of the unit door
should be on a level with the doors of the adjoining units.
-The unit door must be planar and mounted stress-free.
NOTICE
Risk of damage from over-heavy unit door!
If the unit door is too heavy, damage to the hinges and resulting
impairment of function cannot be excluded.
uBefore mounting the unit door, make sure that the door does
not exceed the approved unit door weight.
Appliance model Maximum cabinet
door weight (kg)
Magnum 2 60i eco, Jumbo 60i,
Iglu 60i 26
2.6 Ventilation of the kitchen unit
Fig. 3
-There must be an effective ventilation shaft of at least
200 cm2 per appliance at the air inlet
Fig. 3 (A) and outlet
Fig. 3 (B) vent.
-The principle applies that the larger the ventilation shaft, the
more energy-saving the operation of the appliance.
-The depth of the ventilation shaft at the back of the cabinet
must be min. 40 mm.
Fig. 4
-The upper ventilation shaft can either be positioned directly
above the appliance with an optional ventilation grille
Fig. 4 (C) , close to the ceiling above the unit Fig. 4 (D) or as
an air outlet opening in a false ceiling Fig. 4 (E) .
2.7 Changing over door hinges
NOTICE
Risk of damage due to condensation and colliding doors!
If you are installing V-Zug Side-by-Side (SBS) appliances
next to each other:
uInstall the appliances so that the doors open outwards.
Switch the door hinges, if necessary.
CAUTION
Risk of injury if soft stop contracts!
uCarefully remove the soft stop mechanism.
CAUTION
Risk of injury if hinges fold!
uLeave hinges open.
WARNING
Risk of injury due to the door dropping out!
If the fastening parts are not screwed into place firmly enough,
the door may drop out. This may lead to severe injuries. What is
more, the door may not close and therefore the appliance may
fail to cool properly.
uScrew the hinges and the ball journal of the soft stop mecha-
nism firmly into place, with 4 Nm.
uScrew the holder of the soft stop mechanism firmly into
place, with at least 3 Nm.
uCheck all of the screws and retighten if necessary.
Note
The door hinges can only be changed over if there is sufficient
space towards the top to pull out the hinge mounting bracket
and to mount it again on the other side. This is generally not the
case after installation in the recess.
uChange the hinges over before the appliance is installed in
the recess.
There is a risk of injury during this stage! Please
observe the safety instructions!
The instructions apply to several models. Only carry
out this step if it is relevant for your appliance.
Putting into operation
4 * Depending on model and options

Choose between the alternatives given.
Loosen the screws only, do not undo them all the way.
Check the screws and tighten if necessary.
uWhile changing over the door hinges, observe the safety
instructions above and also the information in the symbols
key.
Change the hinges over as shown at the end
of the book.
2.8 Installing the appliance in the
recess
WARNING
Fire hazard from short-circuiting!
uWhen pushing the appliance into the recess, take care not to
crush, jam or damage the mains power cable.
uDo not operate the appliance with a defective mains power
cable.
NOTICE
Risk of damaging the hinges!
If when being pushed the appliance is held by the door, the
hinges could be damaged.
uWhen pushing or otherwise moving the appliance, always
hold it by the main body.
For installation in the recess, the following accessories
are available from Customer Service:
Kit to limit the door opening angle to
90°
Set for fitting split furniture front
panels
Set with covers for concealed hinges
There is a risk of injury during this stage! Please
observe the safety instructions!
The instructions apply to several models. Only carry
out this step if the appliance is equipped with the
corresponding feature.
Choose between the alternatives given.
Loosen the screws only, do not undo them all the way.
Check the screws and tighten if necessary.
uPlease take note of the information in the symbols key
during installation.
Install the appliance in the recess as shown at
the end of the booklet.
2.9 Disposing of packaging
WARNING
Danger of suffocation due to packing material and plastic film!
uDo not allow children to play with packing material.
The packaging is made of recyclable materials:
-corrugated board/cardboard
-expanded polystyrene parts
-polythene bags and sheets
-polypropylene straps
-nailed wooden frame with polyethylene panel*
uTake the packaging material to an official collecting point.
2.10 Connecting the appliance
NOTICE
Failure to connect properly
Damage to the electronics.
uDo not use a standalone inverter.
uDo not use an energy saving plug.
WARNING
Failure to connect properly
Fire hazard.
uDo not use an extension cable.
uDo not use distributor blocks.
The type of current (alternating current) and voltage at the
installation site have to conform with the data on the type plate
(see Appliance at a glance).
The socket must be properly earthed and fused. The tripping
current for the fuse must be between 10 A and 16 A.
The socket must be easily accessible so that the appliance can
be quickly disconnected from the supply in an emergency. It
must be outside the area of the rear of the appliance.
uCheck the electrical connection.
uPlug in the power plug.
Putting into operation
* Depending on model and options 5

6 * Depending on model and options

7

8 * Depending on model and options

9

10 * Depending on model and options

11

12 * Depending on model and options

13

14 * Depending on model and options

15

240518 7088021-00
1043971–R02
V-ZUG AG, Industriestrasse 66, CH-6302 Zug
Tel. [phone], Fax[phone]
inf[email protected], www.vzug.com
