V-ZUG Magnum 2 60i eco User manual

Installation instructions
Magnum 2 60i eco | Jumbo 60i | Iglu 60i | Ideal 60i
Refrigerator and freezer

Contents
1 General safety information................................... 2
2 Transporting the appliance................................... 2
3 Installing the appliance......................................... 2
4 Appliance dimensions........................................... 3
5 Recess dimensions............................................... 3
6 Unit door................................................................. 4
7 Ventilation of the kitchen unit............................... 4
8 Changing over door hinges.................................. 4
9 Water connection*.................................................. 5
10 Installing the appliance in the recess.................. 6
11 Disposing of packaging........................................ 6
12 Connecting the appliance..................................... 6
Illustrated installation instructions...................... 8
Thank you for choosing one of our products. Your appliance
meets the highest of demands and is very easy to use.
However, please take time to read this document. It will help
you become familiar with your appliance so you fully enjoy it
and avoid faults.
Please follow the safety notes.
Changes
The text, images and details reflect the technical features of the
appliance at the time of print. They are subject to changes
brought about by further development.
Sections that apply to certain models only are marked with an
asterix (*).
Instructions are marked with a and results are marked
with a .
Scope of application
The product range (model number) matches the first digits on
the rating plate. This document applies to:
Model Product range Unit system
Jumbo 60i 51078 Euro 60
Magnum 2 60i eco 51076 Euro 60
Model Product range Unit system
Iglu 60i 51077 Euro 60
Model Product range Unit system
Ideal 60i 51090 Euro 60
1 General safety information
-Only install, connect and dispose of the appli-
ance according to the instructions. Take
particular note of “Recess dimensions”
(see 5 Recess dimensions) and “Ventilation of the
kitchen unit” (see 7 Ventilation of the kitchen unit) .
-The socket must be easily accessible so that
the appliance can be quickly disconnected
from the supply in an emergency. It must be
outside the area of the rear of the appliance.
DANGER identifies a situation involving direct
danger which, if not obviated, may
result in death or severe bodily
injury.
WARNING identifies a dangerous situation
which, if not obviated, may result in
death or severe bodily injury.
CAUTION identifies a dangerous situation
which, if not obviated, may result in
minor or medium bodily injury.
NOTICE identifies a dangerous situation
which, if not obviated, may result in
damage to property.
Note identifies useful information and tips.
2 Transporting the appliance
CAUTION
Risk of injury and danger of damage as a result of incorrect
transport!
uTransport the appliance in a packed condition.
uTransport the appliance upright.
uDo not transport the appliance without assistance.
3 Installing the appliance
WARNING
Risk of fire due to short circuit!
If the mains cable/connector of the appliance or of another
appliance touch the rear of the appliance, the mains cable/
connector may be damaged by the appliance vibrations,
leading to a short circuit.
uStand the appliance so that it is not touched by connectors
or main cables.
uDo not plug the appliance or any others into sockets located
near the rear of the appliance.
WARNING
Fire hazard due to dampness!
If live parts or the mains lead become damp this may cause
short circuits.
uThe appliance is designed for use in enclosed areas. Do not
operate the appliance outdoors or in areas where it is
exposed to splash water or damp conditions.
uOnly use the appliance when it is installed.
WARNING
Fire hazard due to refrigerant!
The coolant used is eco-friendly but also flammable. Any
leaking coolant may ignite.
uDo not damage the piping of the refrigeration circuit.
WARNING
Fire hazard and danger of damage!
uDo not place appliances emitting heat e.g. microwaves,
toasters etc. on the appliance!
General safety information
2 * Depending on model and options

Note
The bags at the rear of the appliance are important for proper
operation. Their contents are nontoxic and nonhazardous.*
uDo not remove the bags!
NOTICE
Risk of damage.
An incorrect Side-by-Side- (SBS) assembly leads to conden-
sate between the appliances. Assemble the V-Zug appliances
as follows:
uInstall the freezer next to the refrigerator.
WARNING
Blocked ventilation openings pose a risk of fire and damage!
uAlways keep the ventilation openings clear. Always ensure
that the appliance is properly ventilated!
qIn the event that the appliance is damaged, contact the
supplier immediately before connecting to the mains.
qThe floor at the site must be flat and level.
qDo not install the appliance in a location where it is exposed
to direct radiation of the sun, next to a cooker, heater and
similar.
qDo not install the appliance alone: it is best to work together
with two or more people.
qThe more coolant there is in the appliance, the larger the
room in which the appliance is installed must be. If the room
is too small, any leak may create a flammable mixture of gas
and air. For each 8 g of coolant the installation space must
be at least 1 m3. Information on the coolant is on the model
plate inside the appliance.
qIf the appliance is installed in a very damp environment,
condensed water may form on the outside of the appliance.
Always make sure that there is good ventilation - both at air
inlet and outlet - at the site of installation.
If the transport lock is inserted on the door:
uPull off red transport lock.
If the transport lock is screwed onto the door:
uUnscrew red transport lock.
Close the freed retaining hole
with plugs (60).
After installation:
uRemove protective films, adhesive tapes and transport lock
parts etc.
Note
uClean the appliance (see Operating Instructions,
Chapter "Cleaning the appliance").
4 Appliance dimensions
Fig. 1
A (mm) B (mm) C (mm)
Magnum 2 60i eco, Jumbo
60i, Iglu 60i 559 544 1770
Ideal 60i 559 544 872
5 Recess dimensions
The appliance is built-in and therefore completely enclosed by
a kitchen unit. The kitchen unit concerned must be built exactly
to the prescribed dimensions and allow for sufficient ventilation,
both at air inlet and outlet, to ensure proper appliance opera-
tion.
Fig. 2
Appliance dimensions
* Depending on model and options 3

D
(mm)
E
(mm)
F (mm) G
(mm)
H
(mm)
Magnum
2 60i
eco,
Jumbo
60i, Iglu
60i
1772
—
1788
560
—
570
min.
550,
recom-
mended:
560
min.
500
max.
19
Ideal 60i
874
—
890
560
—
570
min.
550,
recom-
mended:
560
min.
500
max.
19
The specified energy consumption applies to a unit depth of
560 mm. The appliance will work properly at a unit depth of 550
mm, but at a slightly higher energy consumption.
uIn the case of Side-by-Side installa-
tion, two appliances next to one
another, build the appliances into
separate kitchen units.*
*
uCheck the wall thickness of the adjoining cabinets: it must
be min. 16 mm thick.
uOnly install the appliance in robust, stable kitchen units.
Secure the units against tipping.
uAlign the kitchen unit using a spirit level and marking square
and if necessary compensate with shims.
uEnsure that the floor and walls of the unit are at right angles
to one another.
6 Unit door
-One door is required for the kitchen unit.
-The door must be minimum 16 mm and maximum 19 mm
thick.
-There must be a gap of minimum 3 mm width between the
door and the unit door located above it (if one exists).
-The width of the unit door depends on the style of the
kitchen and the gap size between the door panels of the
cabinet. Generally, there should remain a vertical gap of
3 mm between the unit doors.
-If other cabinets are present, the top edge of the unit door
should be on a level with the doors of the adjoining units.
-The unit door must be planar and mounted stress-free.
NOTICE
Risk of damage from over-heavy unit door!
If the unit door is too heavy, damage to the hinges and resulting
impairment of function cannot be excluded.
uBefore mounting the unit door, make sure that the door does
not exceed the approved unit door weight.
Appliance model Maximum cabinet
door weight (kg)
Magnum 2 60i eco, Jumbo 60i,
Iglu 60i 26
Ideal 60i 16
7 Ventilation of the kitchen unit
Fig. 3
-There must be an effective ventilation shaft of at least
200 cm2 per appliance at the air inlet
Fig. 3 (A) and outlet
Fig. 3 (B) vent.
-The principle applies that the larger the ventilation shaft, the
more energy-saving the operation of the appliance.
Fig. 4
-The upper ventilation shaft can either be positioned directly
above the appliance with an optional ventilation grille
Fig. 4 (C) , close to the ceiling above the unit Fig. 4 (D) or as
an air outlet opening in a false ceiling Fig. 4 (E) .
8 Changing over door hinges
NOTICE
Risk of damage due to condensation and colliding doors!
If you are installing V-Zug Side-by-Side (SBS) appliances
next to each other:
uInstall the appliances so that the doors open outwards.
Switch the door hinges, if necessary.
Unit door
4 * Depending on model and options

CAUTION
Risk of injury if soft stop contracts!
uCarefully remove the soft stop mechanism.
CAUTION
Risk of injury if hinges fold!
uLeave hinges open.
WARNING
Risk of injury due to the door dropping out!
If the fastening parts are not screwed into place firmly enough,
the door may drop out. This may lead to severe injuries. What is
more, the door may not close and therefore the appliance may
fail to cool properly.
uScrew the hinges and the ball journal of the soft stop mecha-
nism firmly into place, with 4 Nm.
uScrew the holder of the soft stop mechanism firmly into
place, with at least 3 Nm.
uCheck all of the screws and retighten if necessary.
Note
The door hinges can only be changed over if there is sufficient
space towards the top to pull out the hinge mounting bracket
and to mount it again on the other side. This is generally not the
case after installation in the recess.
uChange the hinges over before the appliance is installed in
the recess.
There is a risk of injury during this stage! Please
observe the safety instructions!
The instructions apply to several models. Only carry
out this step if it is relevant for your appliance.
Choose between the alternatives given.
Loosen the screws only, do not undo them all the way.
Check the screws and tighten if necessary.
uWhile changing over the door hinges, observe the safety
instructions above and also the information in the symbols
key.
Change the hinges over as shown at the end
of the book.
9 Water connection*
WARNING
Danger of electric shock!
uDisconnect the appliance by unplugging it before you
connect it to the water line.
uShut off the water supply before you connect the water feed
lines of the IceMaker.
uThe connection to the drinking water system may be carried
out only by a qualified gas fitter and plumber.
WARNING
Risk of poisoning!
uThe water quality has to comply with the drinking water ordi-
nance of the respective country (e.g. 98/8
uConnect to the drinking water supply only.
uThe IceMaker serves exclusively for making ice cubes in
household quantities and has to be operated with water suit-
able for the purpose.
Fig. 5
- The water pressure must be between 0.15 MPa and
0.6 MPa (1.5 bar - 6 bar).
- The water must be connected to the appliance via a cold
water pipe that can withstand the operating pressure and
complies with hygiene standards.
Use the stainless steel hose supplied (length 1.5 m). Do not
reuse old hoses. A 3 m hose is available as an optional
extra. This must be professionally installed.
A filter with a seal is located in the hose connector.
- A stopcock must be provided between the hose line and the
domestic water connection to cut off the water supply if
necessary.
- The stopcock must be located outside the back of the appli-
ance and be within easy reach so that the appliance can be
inserted as deeply as possible and the stopcock can be
turned off quickly. Stick to the clearances.
- All devices and equipment used to supply water must
comply with the regulations in force in the respective
country.
- Do not damage or kink the water supply line during installa-
tion.
Fig. 6
The solenoid is located at the bottom on the back of the appli-
ance. It has a metric R3/4 connecting thread.
Connecting the stainless steel hose:
uConnect the connector without the filter to the solenoid.
uConnect the connector with the integrated filter to the stop-
cock.
uFix the stainless steel hose to the housing with the guide
clip.
uTurn the water supply stopcock on and check the
whole water system for leaks.
Before using for the first time:
uHave the domestic water pipe bled professio-
nally.
Water connection*
* Depending on model and options 5

NOTICE
Malfunction of the water intake!*
If the water intake is shut off during operation but the IceMaker
remains in operation, the water intake pipe may ice up.
uSwitch off the IceMaker if the water supply is interrupted
(e.g. holiday).
10 Installing the appliance in the
recess
WARNING
Fire hazard from short-circuiting!
uWhen pushing the appliance into the recess, take care not to
crush, jam or damage the mains power cable.
uDo not operate the appliance with a defective mains power
cable.
NOTICE
Risk of damaging the hinges!
If when being pushed the appliance is held by the door, the
hinges could be damaged.
uWhen pushing or otherwise moving the appliance, always
hold it by the main body.
For installation in the recess, the following accessories are
available from Customer Service:
Kit to limit the door opening angle to
90°
Set for fitting split furniture front
panels
Set with covers for concealed hinges
There is a risk of injury during this stage! Please
observe the safety instructions!
The instructions apply to several models. Only carry
out this step if the appliance is equipped with the
corresponding feature.
Choose between the alternatives given.
Loosen the screws only, do not undo them all the way.
Check the screws and tighten if necessary.
uPlease take note of the information in the symbols key
during installation.
Install the appliance in the recess as shown at
the end of the booklet.
11 Disposing of packaging
WARNING
Danger of suffocation due to packing material and plastic film!
uDo not allow children to play with packing material.
The packaging is made of recyclable materials:
-corrugated board/cardboard
-expanded polystyrene parts
-polythene bags and sheets
-polypropylene straps
-nailed wooden frame with polyethylene panel*
uTake the packaging material to an official collecting point.
12 Connecting the appliance
NOTICE
Failure to connect properly
Damage to the electronics.
uDo not use a standalone inverter.
uDo not use an energy saving plug.
WARNING
Failure to connect properly
Fire hazard.
uDo not use an extension cable.
uDo not use distributor blocks.
The type of current (alternating current) and voltage at the
installation site have to conform with the data on the type plate .
The socket must be properly earthed and fused. The tripping
current for the fuse must be between 10 A and 16 A.
The socket must be easily accessible so that the appliance can
be quickly disconnected from the supply in an emergency. It
must be outside the area of the rear of the appliance.
uCheck the electrical connection.
uPlug in the power plug.
Installing the appliance in the recess
6 * Depending on model and options

* Depending on model and options 7

8 * Depending on model and options

* Depending on model and options 9

10 * Depending on model and options

* Depending on model and options 11

12 * Depending on model and options

* Depending on model and options 13

14 * Depending on model and options

* Depending on model and options 15

20191127 7088233-00
1043971–R04
V-ZUG AG, Industriestrasse 66, CH-6302 Zug
Tel. [phone], Fax [phone]
inf[email protected], www.vzug.com
