V2 WES-BASE User manual

WES-BASE
IL n. 332
EDIZ. 09/03/2011
V2 S.p.A.
Corso Principi di Piemonte, 65/67
12035 RACCONIGI (CN) ITALY
tel. [phone] - fax [phone]
[email protected] - www.v2home.com
SISTEMA PER IL CONTROLLO VIA RADIO DELLE
COSTE DI SICUREZZA
RADIO CONTROL SYSTEM FOR SAFETY EDGES
SYSTÈME POUR LE CONTRÔLE PAR RADIO DES
BARRES PALPEUSES DE SÉCURITÉ
SISTEMA PARA EL CONTROL VÍA RADIO DE LAS
BANDAS DE SEGURIDAD
SISTEMA PARA O CONTROLO VIA RÁDIO DAS
COSTAS DE SEGURANÇA
FUNK-STEUERSYSTEM FÜR SIC ER EITSRIPPEN
SYSTEEM VOOR DE CONTROLE VAN
VEILIG EIDSLIJSTEN VIA RADIO
I
GB
F
E
P
D
NL

ENGLIS
7
IMPORTANT INFORMATION
For any installation problem please contact our Customer
Serviceat the number +39-0172.812411 operating Monday to
Fridayfrom 8:30 to 12:30 and from 14:00 to 18:00
V2 reserves the right to make modifications to the product
without any prior warning; furthermore, the company
declines all responsibility for damages to people or property
resulting from improper use or incorrect installation.
Read the following instruction manual thoroughly
prior to proceeding with installation and programming of
the system.
• This instruction manual is intended solely for use by technical
staff, qualified in the field of installation of automation devices
• None of the information contained in the manual is of interest
or use to end users.
• All maintenance or programming operations should be
conducted exclusively by qualified staff.
The installation, testing and commissioning of door and gate
automation devices should be performed by qualified and skilled
personnel, who must assume responsibility for setting up the
tests envisaged depending on the risks present; and verify
compliance in accordance with legal and regulatory requirements.
• V2 accepts no responsibility for injuries and damage resulting
from improper use of the product; other than that described in
this manual.
• Packing materials must be disposed of in full compliance with
local regulations.
DECLARATION OF CONFORMITY
The undersigned representing the following manufacturer:
V2 S.p.A.
Corso Principi di Piemonte 65, Racconigi (CN), ITALY
herein declares that the product WES
is in compliance with the provisions of the following community
directives (including all applicable amendments)
99/5/CE
Directive regarding radio equipment and telecommunication
terminal equipment and reciprocal recognition of their conformity
98/37/CE
concerning the harmonisation of legislation from member states
regarding machinery
and that the technical standards indicated below have been applied:
EN 301 489-3: 2002
Electromagnetic compatibility and questions relating to the
radiofrequency spectrum (ERM); electromagnetic compatibility
(EMC) standards for radio equipment and services.
Part 3: specific conditions for short range devices (SRD) operating
between the frequencies of 9 k z and 40 G z.
EN 300 328-1: 2001
Electromagnetic and radio spectrum compatibility (ERM);
Broadband transmission systems. Data transmission equipment
operating in the ISM band at 2.4 G z using broad spectrum
modulation techniques.
EN 12978 : 2003
Industrial, commercial and garage doors and gates - Safety devices
for motorised doors and gates - Test methods and requirements
Racconigi, 12/10/2009
V2 S.p.A. Legal Representative
Cosimo De Falco
TEC NICAL INFORMATION
DESCRIPTION
WES (Wireless Edge System) is the new V2 system allowing safety
edges to be controlled by radio.
The system consists of a base unit connected directly to the
control unit, and one or more sensors (up to 8 per base unit)
connected to the safety edges.
The base unit is powered from the control unit and constantly
monitors the status of the sensors connected.
Up to a maximum of 8 sensors may be connected to each base
unit.
The system is compatible with standard safety edges with NC
breakers, resistive safety edges (8k2).
The system is compatible with all control unit models.
System operation
The system operates independently of the status of the control
unit. The relay corresponding to each sensor unit is kept closed if
no edges are activated.
If an edge is pressed, the relay opens, signalling the anomaly to
the control unit.
The base unit communicates with each sensor every 15 seconds,
so as to verify their presence and function.
Base
Power supply: 12 / 24 Vdc-ac
Input power: 0,75 W
Dimensions: 125x56x23 mm
Operating temperature: -20/+60 °C
Outputs (relay switch): 2 edge alarms
1 low battery warning
Number of sensors: until 8
Number of radio channels: 16

ENGLIS
8
BASE UNIT INSTALLATION
PLEASE NOTE: The device should only be installed after having disconnected the power supply for the control unit to
which the WES base unit is connected.
1. Install the base unit near the control unit; fix the casing using the specific fixing lugs A
2. Open the cover by unscrewing the 6 screws. Use one or two grommets Bto allow the control unit connecting cable(s) to pass through
3. Connect the power supply to the POWER terminals. If using a DC supply, connect the positive pole to the POWER+ terminal and the
ground or common wire to the photocell transmitter power supply POWER- terminal
4. Connect the COM terminal to the control unit common (earth) inputs
5. Connect the (relay) outputs to the control unit inputs relating to the desired alarms:
- Outputs OUT1 and OUT2 (breaker NC) open in the case of activation of one of the edges associated with UNIT 1 and UNIT 2*
respectively.
- The BAT LOW output (breaker NC) opens when a sensor indicates the low battery status
* PLEASE NOTE: UNIT 1 and UNIT 2 are used to manage 2 edge units in different modes. If the control unit has two separate inputs for
safety edges, connect UNIT 1 (OUT1) to one input and UNIT 2 (OUT2) to the other, then program the control unit with the desired logics.
If the control unit has only one input for edges, use output OUT 1 only.
6. Connect the START terminal to the photocell transmitter power supply terminal.
7. Power up the control unit and ensure that the green LED for the base unit is flashing normally after a few seconds. If the red LED
remains on, this means the base has already been configured; it is necessary to delete the old configuration (see the section on
RESETTING T E BASE UNIT CONFIGURATION)
PLEASE NOTE: when the device is powered up, up to 15 seconds may be required before the connection with all sensors is
re-established. The system is ready for use when the LEDs for all the sensors are flashing at the scanning frequency set.

ENGLIS
9
TERMINAL BOARD CONNECTIONS 쩚쩚쩚쩚쩛쩛OUT1
COM
OUT2
COM
BAT LOW
COM
A DEVICE WIT LOW BATTERY - - A
BATTERIES OK
NO EDGE ACTIVATED CCC
EDGE 1 ACTIVATED A C C
EDGE 2 ACTIVATED C A C
C – contact closed
A – contact open
BASE UNIT CONTROL UNIT
POWER+
POWER-
System power - positive pole (12 / 24 Vdc-ac)
System power – accessory supply COMMON
COM Common safety input
OUT1 Unit 1 edge input
OUT2 Unit 2 edge input
BAT LOW Can be used to indicate low battery level
START Photocell TX supply
BASE UNIT ELECTRICAL CONNECTIONS
DIP-SWITC ES
The device has 8 DIP-SWITC ES allowing the factory settings to be modified.
Mechanical or resistive edges
DIP-SWITC FUNCTION
1 - 2 RESERVED – leave as OFF
3 - 4 - 5 - 6 The various combinations of these DIP switches allows 1 of the 16 radio channels to be selected
7RESERVED – leave as OFF
8Activates the procedure for configuring the edge radio/Test channel

ENGLIS
10
RADIO C ANNEL CONFIGURATION
When the network is not configured, the base unit monitors the 16 possible radio channels and registers activity present in the
environment; for establishment of a new network, it is appropriate to select a channel on which there is low radio activity, in order to
avoid interference.
Set dip-switch 8 to ON: the green and red LEDs indicate the quality of the channel selected:
- red LED: unusable channel
- green LED: single flash - medium quality
double flash – good quality
triple flash – best channel
Alter dip-switches 3 to 6 in order to change the radio channel until the best channel is identified.
PLEASE NOTE: Once the channel is selected, return dip-switch 8 to OFF
PLEASE NOTE: The channel cannot be modified after the network has been configured.
If dip-switches 3 to 6 are altered with the network configured, the red LED will emit a series of flashes in fours.
RESET BASE UNIT CONFIGURATION
To delete the configuration of a base, it is necessary to press and hold the PROG button on the base unit until the red LED starts to flash.
Then release the button and repeat the radio channel configuration.
ASSOCIATING T E SENSOR WIT T E BASE
During association, the sensor communicates the installed configuration to the base.
NOTE: if a sensor is not connected to any edge, it cannot be associated with a base.
CAUTION: make sure edges are connected properly to the sensors prior to proceeding.
When association is complete, it is no longer possible to alter the sensor connections.
Install the sensors by following the instructions attached to the product, then proceed as follows:
To associate an edge with unit 1, proceed as follows:
1. Press the PROG button on the base unit once: the ALARM LED emits single flashes
2. Press and hold the sensor SET button until LED L3 flashes intensely and regularly, then release the button.
3. The base automatically exits acquisition mode and the sensor starts to transmit with a period of 15 seconds
To associate an edge with unit 2, proceed as follows:
1. Press the PROG button on the base unit twice: the ALARM LED emits dual flashes
2. Press and hold the sensor SET button until LED L3 flashes intensely and regularly, then release the button.
3. The base automatically exits acquisition mode and the sensor starts to transmit with a period of 15 seconds
To associate an edge with both units, proceed as follows:
1. Press the PROG button on the base unit 3 times: the ALARM LED emits triple flashes
2. Press and hold the sensor SET button until LED L3 flashes intensely and regularly, then release the button.
3. The base automatically exits acquisition mode and the sensor starts to transmit with a period of 15 seconds
PLEASE NOTE: Association must be completed within 15 seconds, otherwise the base unit exits acquisition mode.
4. On completion, close the sensor casing and tighten the screws once more.
5. Repeat the operation for the other sensors in the network. When all the sensors have been installed and associated,
close the base unit casing.
EDGE TESTING
Activate the base unit testing method by setting dip-switch 8 to ON. Press the edge to verify that:
1. the LED on the sensor remains fixed and on
2. the red (OUT1/OUT2) LED on the base unit comes on
3. The control unit recognises the alarm on the input where the output from the u
PLEASE NOTE: Remember to return dip-switch 8 to OFF on completion of the test.

ENGLIS
11
LED SIGNALS ON T E BASE UNIT
CONDITION GREEN LED (RADIO) RED LED (ALARM) LED OUT 1 LED OUT 2 LED BAT LOW
DIP-SWITC 8 OFF
NETWORK NOT
CONFIGURED
•Flashes slowly • Off •Off •Off •Off
NETWORK
CONFIGURED
•A brief flash with
every message
received (with just
one sensor, the
period is 15 sec.)
•Fixed on if there is no
connection with a sensor
•Series of 4 flashes if the
network channel does
not correspond with
dip switch 3-6
•On when output
OUT1 is activated
(sensor alarm
associated with
unit 1)
•On when output
OUT2 is activated
(sensor alarm
associated with
unit 2)
•On when the LOW
BAT output is
activated (one of
the sensors has a
flat battery)
NETWORK
CONFIGURATION
ONGOING
•A brief flash with
every message
received
•Slow flashing until
at least one sensor is
inserted in the
network
•One, two or three
flashes, depending on
the unit being
configured (button
pressed once, twice or
three times)
•Slow flashing during
network deletion (button
pressed and held down)
•Off •Off •Off
CONDITION GREEN LED (RADIO) RED LED (ALARM) LED OUT 1 LED OUT 2 LED BAT LOW
DIP-SWITC 8 ON
NETWORK NOT
CONFIGURED
• Channel quality
1.Channels where maximum quality has been
measured: green LED flashes 3 times
2.Channels with near maximum quality:
green LED flashes twice
3.Channels with above-average quality:
green LED flashes once
4.Channels with below-average quality:
red LED flashes once
5.Channels with minimal quality:
red LED flashes 3 times
•Off •Off •Off
NETWORK
CONFIGURED
•Fixed •Fixed on if there is no
connection with a sensor
•Series of 4 flashes if the
network channel does
not correspond with
dip switch 3-6
•On when output
OUT1 is activated
(sensor alarm
associated
with unit 1)
•On when output
OUT2 is activated
(sensor alarm
associated
with unit 2)
•On when the LOW
BAT output is
activated (one of
the sensors has a
flat battery)

ENGLIS
12
FAULT FINDING PROCEDURE
Conduct fault-finding with the system off (door closed).
PLEASE NOTE: Remember to set dip-switch 8 to OFF on completion of the procedure.
STEP Action Test Diagnosis
1. Open the base cover and observe
the red LED Is the LOW BAT LED on? A sensor has a low battery; find the sensor with the flashing LED
2. Is the ALARM LED on and fixed?
Communication problems between the sensors
and the base. Find the sensor with the LED off or
flashing very faintly
3. Set dip switch 8 to ON:
the ALARM LED initially comes on
Are the three OUT1, OUT2 and BAT
LOW LEDs off?
The system is operating normally. If the control
unit does not show that the edge input has been
closed, there is a connection problem (broken
wire)
4. Observe the LED for a sensor Is the LED on and fixed? The sensor detects that the edge has been
activated; connection problem or faulty edge
5. Operate the edge Does the LED on the sensor come
on?
The sensor does not detect the status of the
edge; connection problem or faulty edge
6. -Does the control unit indicate the
edge input is closed?
Connection problems between the control unit
and the base (short circuit)
7. Repeat steps 4, 5 and 6 for each
sensor Are all sensors operating normally?
A non-existent sensor is included in the network.
It is necessary to delete the network and repeat
assignment of the sensors
