Vacon CXL User manual

VACON CX/CXL/CXS
FREQUENCY CONVERTERS
Profibus DP
Fieldbus
Option Board
USER'S MANUAL
Subject to changes without notice
F O R S M O O T H C O N T R O L

VACON CX Profibus user’s manual Page 2
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
INDEX
1. GENERAL.......................................................................................................................................................3
2. SPECIFICATIONS ..........................................................................................................................................4
2.1 General.......................................................................................................................................................4
2.2 Profibus cable.............................................................................................................................................4
3. PROFIBUS DP................................................................................................................................................6
3.1 General.......................................................................................................................................................6
3.2 Profiles........................................................................................................................................................6
4. INSTALLATION..............................................................................................................................................7
5. CONNECTIONS..............................................................................................................................................9
5.1 Board layout................................................................................................................................................9
5.2 Profibus connections..................................................................................................................................9
5.3 I/O-control connections.............................................................................................................................10
6. COMMISSIONING.........................................................................................................................................11
7. PROFIBUS-VACON CX INTERFACE..........................................................................................................12
7.1 General.....................................................................................................................................................12
7.2 PPO-types ................................................................................................................................................12
7.3 Process Data............................................................................................................................................15
7.3.1 Control Word....................................................................................................................................15
7.3.2 Status Word.....................................................................................................................................16
7.3.3 State Machine..................................................................................................................................16
7.3.4 Speed Reference.............................................................................................................................17
7.3.5 Actual Value.....................................................................................................................................18
7.3.6 PD1-PD4..........................................................................................................................................18
7.4 Parameter Data ........................................................................................................................................19
7.4.1 Actual Values...................................................................................................................................19
7.4.2 Parameter Read and Write..............................................................................................................20
7.4.3 Fault Code .......................................................................................................................................20
8. FAULT TRACKING......................................................................................................................................21
9. TYPE FILES..................................................................................................................................................22
9.1 GSD-file....................................................................................................................................................22
APPENDIX A.........................................................................................................................................................23
Board layout........................................................................................................................................................23
Profibus connections..........................................................................................................................................23
APPENDIX B.........................................................................................................................................................24
APPENDIX C: INSTALLATION............................................................................................................................26
Installation of Profibus DP in Vacon CXS drives................................................................................................26

VACON CX Profibus user’s manual Page 3
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
1. GENERAL
Vacon frequency converters can be connected to the Profibus DP by using a Fieldbus board. The
converter can then be controlled, monitored and programmed from the Host system.
The used I/O can also be extended with the Fieldbus board:
• 4 digital inputs (standard signals)
• 4 digital outputs (2 standard signal)
• 1 relay output (standard signal)
• Thermistor input (can be directly connected to the motor thermistors for overtemperature trip)
• Encoder input
The Profibus fieldbus board can be installed inside the frequency converter as instructed in this manual.
Note that the installation procedure is different for CX/CXL (board CX202OPT) and CXS frequency
converters (CX210OPT).
The control connections are isolated from the mains potential and the I/O ground is connected to the
frame of the device via a 1 MΩresistor and 4.7 nF capacitor*. The control I/O ground can also be
connected directly to the frame by changing the position of the jumper X9 (GND ON/OFF) to ON-
position. Digital inputs are also isolated from the I/O ground.
NOTE !
Internal components and circuit boards (except for the isolated I/O terminals) are at mains
potential when the frequency converter is connected to the mains. This voltage is extremely
dangerous and may cause death or severe injury if you come into contact with it.
The control I/O terminals are isolated from the mains potential, but the I/O:s (if jumper X9 is in
OFF-position) may have dangerous voltage connected even if the power is off on the
frequency converter.
* Default value = X9 is GND OFF- position)

VACON CX Profibus user’s manual Page 4
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
2. SPECIFICATIONS
2.1 General
Profibus DP - Interface 9-pin DSUB connector (female)
connections Transfer method RS-485, Half duplex
Transfer cable Twisted pair (1 pair and shield)
Electrical isolation 500 V DC
I/O -control Digital input (4 pcs) 24 V: “0” ≤10 V, “1” ≥18 V, Ri= 5 kΩ
connections Digital output (4 pcs) Open collector output, 50 mA/48 V
Relay output (1 pcs) Max.switching voltage: 300 V DC, 250 V AC
Max.switching load: 8 A / 24 V DC
0,4 A / 300 V AV
2 kVA / 250 V DC
Max.continuous load: 2 A rms
Thermistor input (1 pcs) Rtrip = 4.7 kΩ
Encoder input (3 pcs) 24 V: “0” ≤10 V, “1” ≥18 V, Ri= 3.3 kΩ
5 V : “0” ≤2 V, “1” ≥3 V, Ri= 330 Ω
Aux. voltage 24 V (±20%), max 50 mA
Safety Fulfils EN50178 standard
Communication mode Profibus DP
PPO types 1
2
3
4
Communication parameters
- Address
- Baud Rate 1 to 127
9.6 kBaud to 12 MBaud
Table 2-1. Profibus communication data
2.2 Profibus cable
Profibus devices are connected in a bus structure. Up to 32 stations (master or slaves) can be
connected in one segment. The bus is terminated by an active bus terminator at the beginning and end
of each segment (see figure 2-1). To ensure error-free operation, both bus terminations must always be
powered. When more than 32 stations are used, repeaters (line amplifiers) must be used to connect the
individual bus segments.
The maximum cable length depends on the transmission speed and cable type (see table 2-4). The
specified cable length can be increased by the use of repeaters. The use of more than 3 repeaters in
series is not recommended.

VACON CX Profibus user’s manual Page 5
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
Parameter Line A Line B
Impedance
Capacity
Resistance
Wire gauge
Conductor area
135 ... 165 Ω
(3 to 20 Mhz)
< 30 pF/m
< 110 Ω/ km
> 0,64 mm
> 0,34 mm2
100 ... 130 Ω
( f > 100kHz)
< 60 pF/m
-
> 0,53 mm
> 0,22 mm2
Table 2-2 Line Parameter
Baud rate (kbit/s) 9.6 19.2 93.75 187.5 500 1500 3000-12000
Length line A (m) 1200 1200 1200 1000 400 200 100
Length line B (m) 1200 1200 1200 600 200 - -
Table 2-3 Line length for different transmission speeds
Following cables can be used (e.g):
Belden Profibus Data Cable 3079A
Olflex Profibus Cable 21702xx
Siemens SINEC L2 LAN cable for profibus 6XV1 830-0AH10
Cabling Bus Termination
RxD/TxD-P
(
3
)
DGND
(
5
)
RxD/TxD-N
(
8
)
VP
(
6
)
(
3
)
RxD/TxD-P
(
5
)
DGND
(
8
)
RxD/TxD-N
(
6
)
VP
Shielding
Protective
ground Protective
ground
Station 2
Station 1
RxD/TxD-P
(
3
)
DGND
(
5
)
RxD/TxD-N
(
8
)
VP
(
6
)
Data Line
Data Line
390 Ω
390 Ω
220 Ω
Figure 2-1 Cabling and bus termination

VACON CX Profibus user’s manual Page 6
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
3. PROFIBUS DP
3.1 General
PROFIBUS is a vendor-independent, open fieldbus standard for a wide range of applications in
manufacturing, process and building automation. Vendor independence and openness are guaranteed
by the PROFIBUS standard EN 50 170. With PROFIBUS, devices of different manufacturers can
communicate without special interface adjustments. PROFIBUS can be used for both high-speed time
critical data transmission and extensive complex communication tasks. The PROFIBUS family consists
of three compatible versions.
PROFIBUS-DP
Optimized for high speed and inexpensive hookup, this PROFIBUS version is designed
especially for communication between automation control systems and distributed I/O at the
device level. PROFIBUS-DP can be used to replace parallel signal transmission with 24 V or 0
to 20 mA.
PROFIBUS-PA
PROFIBUS-PA is designed especially for process automation. It permits sensors and actuators
to be connected on one common bus line even in intrinsically-safe areas. PROFIBUS-PA
permits data communication and power over the bus using a 2-wire technology according to the
international standard IEC 1158-2.
PROFIBUS-FMS
PROFIBUS-FMS is the general-purpose solution for communication tasks at the cell level.
Powerful FMS services open up a wide range of applications and provide great flexibility.
PROFIBUS-FMS can also be used for extensive and complex communication tasks.
PROFIBUS specifies the technical and functional characteristics of a serial fieldbus system with which
decentralized digital controllers can be networked together from the field level to the cell level.
PROFIBUS distinguishes between master devices and slave devices.
Master devices determine the data communication on the bus. A master can send messages without an
external request when it holds the bus access rights (the token). Masters are also called active stations
in the PROFIBUS protocol.
Slave devices are peripheral devices. Typical slave devices include input/output devices, valves, drives
and measuring transmitters. They do not have bus access rights and they can only acknowledge
received messages or send messages to the master when requested to do so. Slaves are also called
passive stations.
3.2 Profiles
The PROFIBUS-DP protocol defines how user data are to be transmitted between the stations over the
bus. User data are not evaluated by the PROFIBUS-DP transmission protocol. The meaning is
specified in the profiles. In addition, the profiles specify how PROFIBUS-DP is to be used in the
application area. The following PROFIBUS-DP profile is used in VACON CX Profibus fieldbus board.
Variable-Speed Drive Profile (3.071)
Leading manufacturers of drive technology have jointly defined the PROFIDRIVE profile. The profile
specifies how the drives are to be parameterized and how the setpoints and actual values are to be
transmitted. This enables drives from different vendors to be exchanged. The profile contains necessary
specifications for speed control and positioning. It specifies the basic drive functions while leaving
sufficient freedom for application-specific expansions and further developments. The profile describes
the mapping of the application functions for DP or FMS.

VACON CX Profibus user’s manual Page 7
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
4. INSTALLATION
NOTE! These instructions apply if you have received the Profibus board for Vacon CX or CXL
drives (CX202OPT) as an accessory. Otherwise the board has already been installed for you at
the factory.
Instructions for the installation of Profibus option board for Vacon CXS drives (CX210OPT) you
will find in Appendix C.
Before doing any commissioning, carefully read the safety instructions in the "Vacon CX/CXL/CXS
frequency converter, User's manual" chapter “SAFETY”. Check that you have received all the Fieldbus
board parts: Fieldbus board, plastic board, power cable (black terminal), data cable (blue terminal) and
earthing screw.
Fieldbus board can be installed in the place reserved for an option board inside the frequency converter
(see figure 4-1).
A Remove the control panel and jumper X4 from the control board (1).
B Connect the power cable to control board terminal X5 (2) and the data cable to terminal X14
(3). The power cable can also be connected to terminal X6, if the power cable from the
power board is connected to terminal X5.
C Bend the data cable into an "S-curve" as far as possible from the power board transformer
(4) before you place the plastic board above the control board.
D Remove the protection foil of the plastic board and place the plastic board on the control
board, remember the right position of the plastic board (5).
E Install the Fieldbus board above the plastic board by the larger holes and push it downward
so that the narrow part of the hole in the board fits the cut on the sleeve. Check that the
installation is stable. If you have difficulties placing the plastic board and the Fieldbus board,
slightly bend the regulator A4 (6) and capacitor C59 (7) of the control board.
F Connect the power cable to terminal X6 of the Fieldbus board (8) and the data cable to the
terminal X14 (9).
G Install the jumper which you removed from the terminal X4 of the control board, on the
terminal X9 of the Fieldbus board (10) in ON or OFF position.
H If the package includes the cable cover (11), fasten it into position as shown in figure 4-1.
I Install the earthing screw (12).
J After this install the control panel and connect the needed control signals.
KIf you use a 5 V encoder input, install the jumpers on terminal X15 (see figure 5-1) of the
Fieldbus board (one jumper on the two upper pins and the other on the two lower).

VACON CX Profibus user’s manual Page 8
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
Plastic board
Control board
11
7
4
6
3
8
9
12
10
21
5
Figure 4-1. Fieldbus board installed onto the control board
Fieldbus board

VACON CX Profibus user’s manual Page 9
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
5. CONNECTIONS (CX202OPT)
(For the board layout and connections of the small Profibus DP board, Vacon CX210OPT, see
Appendix A)
5.1 Board layout
Terminals:
X1 I/O - terminals
X10 Digital Output terminal
X3 Digital Output terminal
X7 Relay Output terminal
X4 Thermistor input
X15 Encoder input selection
X5 Screw terminal to Profibus DP
X9 Connection of control I/O ground:
ON - Directly to the frame of the
device
OFF- To the frame of the
device via RC filter
X17 Connection of control Fieldbus
cable shield:
ON - Directly to the frame of the
device
OFF- To the frame of the
device via RC filter
Diagnostic LED:
H1 Data Exchange state for Profibus DP, Red. The red LED goes out when
communication is established
H1 led is active when Fieldbus board is not ready to exchange data
H3 Supply Voltage, Green.
H3 led is active if the Fieldbus board has supply voltage.
5.2 Profibus connections
Screw Connector connector X5: (Terminal resistors not included in the package)
Signal Connector X5
Description
Shield X5-241 Cable shield
VP X5-242 Supply voltage of the terminating resistance
RxD/TxD-P X5-243 Receive/Transmission data positive (B)
RxD/TxD-N X5-244 Receive/Transmission data negative (A)
DGND X5-245 Data Ground
Table 5-1. X5 screw connector terminals
Note! If Vacon is the last device then the bus termination must be set. Install the resistors to the screw
terminal (see table 5-1)
X1
H3
X5
X15
H1
X7
X4
X10
X3
Figure 5-1. Fieldbus board
390 Ω
220 Ω
390 Ω
Termination for
the last node

VACON CX Profibus user’s manual Page 10
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
5.3 I/O-control connections
Terminal Signal Description
201…205 Not used
206 +24 V Control voltage output Voltage for switches, etc. max. 0.05 A
207 GND I/O ground Ground for reference and controls
208 COME Common for DIE1-DIE4 Connect to GND or +24 V
209 DIE1 Programmable:
External fault
OR
Selection of active control
source
Contact open = no fault
Contact closed = fault
Contact open = VACON IO-terminal
Contact closed = Fieldbus
210 DIE2 Run disable Contact open = start of motor enabled
Contact closed = start of motor disabled
211 DIE3 Acceler. / Decel. time
selection Contact open = time 1 selected Contact closed = time 2 selected
212 DIE4 Jogging speed selection Contact open = no action
Contact closed = jogging speed
213 Not Used
214 DIE6A+
215 DIE6A-
Pulse input A
(differential input)
216 DIE7B+
217 DIE7B-
Pulse input B
(differential input) 90 degrees phase shift compared to pulse input A
218 DOE1 Encoder direction output
219 DOE2 Encoder divider 1/64 output
220 Not Used
221 TI+
222 TI-
Thermistor input
225 RO4/1
226 RO4/2
Relay output 4, FAULT
231 DOE3 Open collector output 3 READY
232 GND I/O ground Ground for reference and controls
233 DOE4 Open collector output 4 RUN
234 GND I/O ground Ground for reference and controls
Figure 5-2. Control connections
NOTE! Thermistor input (Terminals 221 and 222) must be shorted if not used
READY= ON, when mains voltage has been applied and VACON CX is ready to operate
RUN = ON, when the motor is running
FAULT = ON, if a fault occurs
Enco-
der
Signal from
motor thermistor

VACON CX Profibus user’s manual Page 11
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
6. COMMISSIONING
READ FIRST THE COMMISSIONING OF THE FREQUENCY CONVERTER IN VACON CX/CXL/CXS
FREQUENCY CONVERTER USER'S MANUAL (CHAPTER 8.)
Commissioning of the Fieldbus board:
Check that Multi-purpose Control Application II (or e.g. Fieldbus Application) is selected.
- Parameter P0.1 = 0
For further information about use of parameters, see Vacon CX/CXL/CXS User's Manual, Chapter 7.
Start-up test:
FREQUENCY CONVERTER APPLICATION
1. Check that the control panel is not the active control source.
(See Vacon CX/CXL/CXS frequency converter User's manual, Chapter 7.)
2. Set parameter “Fieldbus control select” to value 1(On).
MASTER SOFTWARE
1. Set Control Word value to 0hex.
2. Set Control Word value to 47Fhex.
3. Frequency converter status is RUN
4. Set Reference value to 5000 (=50,00%).
5. The Actual value is 5000 and the frequency converter output frequency is 25,00 Hz
6. Set Control Word value to 7Dhex.
7. Frequency converter status is STOP
If Status Word bit 3 = 1 Status of frequency converter is FAULT.

VACON CX Profibus user’s manual Page 12
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
7. PROFIBUS-VACON CX INTERFACE
Features of the Profibus-Vacon CX interface:
• Direct control of Vacon CX ( e.g. Run, Stop, Direction, Speed reference, Fault reset)
• Full access to all Vacon CX parameters
• Monitor Vacon CX status (e.g. Output frequency, Output current, Fault code ..)
7.1 General
Data transfer between Profibus DP master and slave takes place via the Input/Output data field. The
master writes to slave’s Output data and the slave answers by sending the contents of its Input data to
the master. The contents of Input /Output data is defined in a device profile, PROFIDRIVE is the device
profile for frequency converters.
The Vacon CX frequency converter can be controlled by Profibus DP master using PPO-types defined
in PROFIDRIVE (see next chapter). When fieldbus has been selected as the frequency converter’s
active control place, the frequency converter’s operation can be controlled from the Profibus DP master.
Whether or not the active control place is fieldbus, the frequency converter can be monitored and its
parameters can be set by the Profibus DP master.
7.2 PPO-types
PPOs (Parameter/Process Data Object)are communication objects in PROFIBUS DP. PPOs in VACON
CX:
Parameter Field Process Data Field
ID IND VALUE CW
SW
REF
ACT
PD1 PD2 PD3 PD4
PPO1
PPO2
PPO3
PPO4
Byte
ID Parameter type and number
IND Parameter subindex
VALUE Parameter value
CW Control Word
SW Status Word
REF Reference Value
ACT Actual Value
PD Process Data

VACON CX Profibus user’s manual Page 13
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
ID
ID byte1 ID byte2
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Request/Response type SM Parameter Number
SM: Spontaneous bit (not used)
Request/Response types
Request Function Response Function
0 No request 0 No response
1 Read parameter value (word) 1 Parameter value ready (word)
2 Write parameter value (word) 7 Request rejected (+fault code)
Fault Number (if response = 7)
Fault Number Description
0 Illegal Parameter
1 Parameter is read only ( e.g. actual values)
2 Parameter value is out of limits
17 Request temporarily rejected (e.g. can be changed only for STOP state)
18 Other fault
101 Unknown request type
Example1, (PPO1 mode):
Read parameter number 102 (Par 1.2).
Start frequency converter and set speed reference 50,00%.
Command Master - Slave:
ID 1066 hex 1 - Read parameter value
066 - Parameter 102 (= Maximum frequency )
IND 0000 hex 0000 - No meaning
VALUE 0000 0000 hex 0000 0000 - No meaning
CW 047F hex 04 7F- Start command (see chapter control word and state machine)
REF 1388 hex Speed ref. 50,00% (= 25,00 Hz if parameter min. frequency 0 Hz and
max. frequency 50 Hz)
PPO1 frame:
10 66 00 00 00 00 00 00 04 7F 13 88

VACON CX Profibus user’s manual Page 14
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
Answer Slave - Master:
ID 1066 hex 1 - Parameter value ready
066 - Parameter 102 (= Maximum frequency )
IND 0000 hex 0000 - No meaning
VALUE 0000 0032 hex 0000 0032 - Parameter value = 32hex ( 50 Hz)
SW 0000 hex 0000 - frequency converter status (see chapter status word and state
machine)
ACT 0000 hex Current speed 0,00% (= 0,00 Hz if parameter min. frequency 0 Hz
and max. frequency 50 Hz)
PPO1 frame:
10 66 00 00 00 00 00 32 00 00 00 00
Example 2, (PPO1 mode):
Write to parameter number 701 (Par 7.1) value 2.
Keep Run mode on and Send speed reference 75,00%.
Command Master - Slave:
ID 22BD hex 2 - Write parameter value
2BD - Parameter 701 (= Response to reference fault )
IND 0000 hex 0000 - No meaning
VALUE 0000 0002 hex 0000 0002 - Parameter value
CW 047F hex 04 7F- Start command (see chapter control word and state machine)
REF 1D4C hex Speed ref. 75,00% (= 37,50 Hz if parameter min. frequency 0 Hz and
max. frequency 50 Hz)
PPO1 frame:
22 BD 00 00 00 00 00 02 04 7F 1D 4C
Answer Slave - Master:
ID 12BD hex 1 - Parameter value ready
2BD - Parameter 701 (= Response to reference fault )
IND 0000 hex 0000 - No meaning
VALUE 0000 0032 hex 0000 0032 - Parameter value = 32HEX ( 50 Hz)
SW 0337 hex 0337- frequency converter status (see chapter status word and state
machine)
ACT 09C4 hex Current speed 25,00% (= 12,50 Hz if parameter min. frequency 0 Hz
and max. frequency 50 Hz)
PPO1 frame:
12 BD 00 00 00 00 00 00 03 37 09 C4

VACON CX Profibus user’s manual Page 15
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
7.3 Process Data
Direct control of Vacon CX ( e.g. Run, Stop, Direction, Speed reference, Fault reset) and frequency
converter status (e.g. Output frequency, Output current, Fault code ..) can be handled by using PPO
types 1 to 4.
Fieldbus Board VACON CX
P PROCESS DATA Parameters
R Out
p
ut
OControl Word
FReference
I PD1 Variables
B PD2
U PD3
S PD4
A
ctive Fault Code
D
P
M RUN/STOP
A DIRECTION
S FAULT RESET
T
E Frequency Reference
R (Frequency Reference 2)
In
p
ut CONTROL SOURCE
Status Word READY STATE
Actual Value RUN STATE
PD1 DIRECTION STATE
PD2 FAULT STATE
PD3
PD4 Output Frequency
7.3.1 Control Word
The Control command for the state machine (see figure 7.1). The state machine describes the device
status and the possible control sequence of the frequency converter.
The control word is composed of 16 bits that have the following meanings:
Bit Description
Value = 0 Value = 1
0 STOP 1 (by ramp) ON 1
1 STOP 2 (by coast) ON 2
2 STOP 3 (by ramp) ON 3
3 RUN DISABLE ENABLE
4 No Action START
5 No Action START
6 No Action START
7 No Action FAULT RESET (0 -> 1)
8 No Action No Action
9 No Action No Action

VACON CX Profibus user’s manual Page 16
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
10 Disable Profibus control Enable Profibus control
11 Not used Not used
12 Not used Not used
13 Not used Not used
14 Not used Not used
15 Not used Not used
7.3.2 Status Word
Information about the status of the device and messages is indicated in the status word.
The status word is composed of 16 bits that have the following meanings:
Bit Description
Value = 0 Value = 1
0 Not Ready (initial) READY
1 Not Ready READY
2 DISABLE ENABLE
3 NO FAULT FAULT ACTIVE
4 STOP 2 OFF STOP 2 ON
5 STOP 3 OFF STOP 3 ON
6 START ENABLE START DISABLE
7 No Warning Warning
8 Reference ≠Actual value Reference = Actual value
9 Fieldbus control OFF Fieldbus control ON
10 Not used Not used
11 Not used Not used
12 FC stopped Running
13 Not used Not used
14 Not used Not used
15 Not used Not used
7.3.3 State Machine
The state machine describes the device status and the possible control sequence of the frequency
converter. The state transitions can be generated by using “control word” parameter. The “status word”
parameter indicates the current status of the state machine. The modes INIT, STOP, RUN and FAULT
(see figure 7-1) correspond to the actual mode of the Frequency converter.
DISABLE (Bit6=1) is one value of the “status word”.
Bit0=0 is one value of the “control word”.

VACON CX Profibus user’s manual Page 17
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
7.3.4 Speed Reference
Speed reference of the frequency converter. The range is -10000... 10000, percentage of frequency
area between set minimum and maximum frequency.
-10000 = 100,00 % (Direction reverse)
0 = 0,00 % (Direction forward)
10000 = 100,00 % (Direction forward)
DISABLE
INIT Bit6=1
Reset fault
Bit7=0
xxxx x1xx xxxx x110
Bit7=1
Bit0=0
Fault
Bit0=1
Bit3=1
Bit4=1, Bit5=1, Bit6=1
Power ON
READY 1
STOP Bit0=1
READY 2
STOP Bit1=1
ENABLE
STOP Bit2=1
RUNNING
RUN
NOT READY
STOP Bit6=0
Bit0=0
FAULT ACTIVE
FAULT Bit3=1
Bit1=0
STOP 2
STOP by coast
Bit4=0
Bit2=0
STOP 3
STOP by ramp
Bit5=0
Bit0=0
STOP 1
STOP by ramp
Bit1=0
Bit3=0
RUN DISABLE
STOP Bit2=0
Figure 7-1. States of the device control

VACON CX Profibus user’s manual Page 18
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
7.3.5 Actual Value
Actual value of the motor. The range is -10000... 10000, percentage of frequency area between set
minimum and maximum frequency.
-10000 = 100,00 % (Direction reverse)
0 = 0,00 % (Direction forward)
10000 = 100,00 % (Direction forward)
7.3.6 PD1-PD4
The master can read the frequency converter’s actual values using process data variables. There are
four process data variables and each of them can be selected to show one of the monitoring page
variables or active fault code. Selection can be done in two different ways:
By master: Parameter 916.1 PD1
916.2 PD2
916.3 PD3
916.4 PD4
By control panel: Parameter Process Data 1 PD1
ProcessData2 PD2
ProcessData3 PD3
ProcessData4 PD4
Set the number of the variable to be monitored (see table 7-1) or number 99 for the active fault code to
the value of the parameter.
1 Output Frequency
2 Motor Speed
.
.
.
22 Fieldbus status
99 Active fault code
PD1 PD2 PD3 PD4
Profibus DP master
VACON CX
Selector
Parameter
Figure 7-2. Control of Process Data

VACON CX Profibus user’s manual Page 19
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
7.4 Parameter Data
Fieldbus Board VACON CX
P PARAMETERS Parameters
R Out
p
ut
OParameter ID
FParameter Index
I Parameter Value Variables
B In
p
ut
U Parameter ID
S Parameter Index
Parameter Value
A
ctive Fault Code
D
P
M
A
S
T
E
R
The Vacon variables and fault codes can be read and parameters can be read and written using PPO
types 1 and 2.
7.4.1 Actual Values
Actual Values can be read by using the parameter read function.
Profibus parameter numbers according to monitored item numbers are as follows.
Parameter number Vacon variable
1 n1
2 n2
. .
. .
98 n98
Number Data name Step Unit Description
V1 Output frequency 0,01 Hz Frequency to the motor
V2 Motor speed 1 rpm Calculated motor speed
V3 Motor current 0,1 A Measured motor current
V4 Motor torque 1 % Calculated actual torque/nominal torque of the unit
V5 Motor power 1 % Calculated actual power/nominal power of the unit
V6 Motor voltage 1 V Calculated motor voltage
V7 DC-link voltage 1 V Measured DC-link voltage
V8 Temperature 1 °C Temperature of the heat sink

VACON CX Profibus user’s manual Page 20
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone [phone] Fax: [phone]
V9 Operating day counter DD.dd Operating days 1), not resetable
V10 Operating hours, "trip
counter” HH.hh Operating hours 2), can be reset with program-button
#3
V11 MW-hours 0,001 MWh Total amount of MW-hours, not resettable
V12 MW-hours, "trip counter" 0,001 MWh MW-hours, can be reset with programmable button
#4
V13 Voltage/analogue input 0,01 V Voltage of the terminal Uin+ (control board)
V14 Current/analogue input 0,01 mA Current of terminals Iin+ and Iin- (control board)
V15 Digital input status, gr. A 0 = Open Input, 1 = Closed Input (Active)
V16 Digital input status, gr. B 0 = Open Input, 1 = Closed Input (Active)
V17 Digital and relay output
status 0 = Open Input, 1 = Closed Input (Active)
V18 Control program Version number of the control software
V19 Unit nominal power 0,1 kW Shows the power size of the unit
V20 Motor temperature rise 1 % 100% = temperature of motor has risen to nominal
value
Table 7-1 Monitored Items
1) DD = full days, dd = decimal part of a day
2) HH = full hours, hh = decimal part of an hour
For Special Actual Values see Appendix B.
7.4.2 Parameter Read and Write
The Vacon variables and parameters can be read and written using the Parameter Read/Write function.
Profibus parameters according to parameter numbers are as follows.
Parameter
Number Vacon parameter group Vacon parameter number
101 - 199 Group 1 1 - 99
201 - 299 Group 2 1 - 99
. .
. .
801 - 899 Group 8 1 - 99
901 - 999 Profibus DP parameter
1001 - 1099 Group 9 1 - 99
. .
. .
1901 - 1999 Group 18 1 - 99
Numbering of the parameter as well as parameter ranges and steps can be found in the application
manual in question. The parameter value should be given without decimals. The Profibus DP
parameter group can be set by the Profibus DP master only, not on the VACON CX control panel.
7.4.3 Fault Code
When a fault is active, fault codes can be read using the Parameter Read function. Profibus parameter
number according to the fault code is as follows.
Parameter number Vacon variable
99 Active fault code
List and description of the fault codes are in VACON CX/CXL/CXS USER’S MANUAL
