VacuBlend Action User manual

User manual
This product is for home use only. Usage in commercial or industrial environments is prohibited.
Read this manual carefully before use and keep it where you can find easily.
Do read “Important Safeguards” before using the product.
Your original purchase receipt is the proof for product warranty, keep it well.
The product design and functionality are subject to change without notice
1.
2.
3.
4.
5.
01 Part names and components 02 Important safeguards before use
03 How to use the VacuBlend 04 Cleaning and maintenance
05 Check before reporting trouble 06 Warranty and contact

2
Part Names and Components
Technical Specifications
Model name: Action
Rated Operating Time: Less than 1 minute
Dimensions: 200(W) X 220(D) X 448(H)
Weight: 3.4kg
Rated Power Consumption: 960 W
Max. vacuum level: -80 Kpa
What's in the box
1 Set of Vacuum Blender
1 Sub Vacuum Container
1 User Manual
1 spare vacuum valve
Vacuum Body
(Main Body)
Power Plug
Auto Button
Main Body
Vacuum Valve
Vacuum Valve
Blender Container Lid
Vacuum Container
Speed Control Dial
Vacuum Button
Pulse Button
Power Button
Support
Vacuum Cap
01

3
Vacuum Container Components Sub Vacuum Container Components
Vacuum Valve Vacuum Valve
Container Lid
Container Packing
Backflow
Prevention
Cap
Container
Blade Body
Disassembly Device
Lid for Blender
Container
Upper Packing
Side Packing
Backflow
Prevention
Cap
Blender
Container
Blade Body Packing
Hexa-Blade (Blade)
Blade Body
When disassembling or assembling the vacuum
container for washing ALWAYS:
You can do this by turning them counter
clockwise and assemble them by turning them
clockwise (refer to section 04 for details).
ŸDisassemble the backflow prevention cap
ŸDisassemble the blade body
※

4
Use a proper outlet for the electric capacity of the product. Do not connect or disconnect the plug by the
cord; do so by the plug. It can cause fire, electric shock, or electric leakage.
Do not bend, tie, or pull the power cord by force. It can cause electric shock or fire.
Clean any dirt on the power plug. Do not touch or connect the power cord with wet hands. It can cause
electric shock.
Do not disassemble or remodel the product or press the safety device by force in order to start the
product. It can cause trouble, fire, electric shock or injury.
Do not place the product in a hot and humid area or near an electric heater or inflammable substances.
It can cause fire, electric shock, or other safety accidents.
Do not wash the main body in water. Do not use dish washer or dish dryer for the main body. It can cause
trouble, fire, or electric shock. Remove dirt using dampened dry cloth.
Do not use the product longer than 60 seconds continuously. When using it multiple times, do not use it
more than 2 times within 30 minutes. It can cause damage to the product. The motor will stop automatically
when the safety device (temperature sensor) is activated to prevent the motor's overheating. This is not a defect.
Cool down the motor for at least 30 minutes and then try again.
Do not put hot water (40°C or hotter) on the materials. Be careful if hot liquid is poured into the blender
as it can be ejected out of the appliance due to sudden steaming. It may cause damage or injury to the
product.
Do not open the vacuum cap or move the product in use. After use, turn off the power and open the
vacuum cap after the knife comes to a complete stop. It can cause injury or damage.
Always operate the product on a flat, hard and dry surface. Do not place the product on an unstable
place where it might fall easily. Do not put place the product on a rug or cushion. It can cause electric
shock or an accident.
Do not idle the blender while the vacuum container is empty. For ice and solid materials, peel off and break
into pieces to use with other materials containing moisture (Refer to section 03). It can cause damage or fire.
This appliance CANNOT be used by children under the age of 8 years. Children aged 8 and above and
persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge can use the
product if they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Important safeguards before use
WARNING
02

5
The safety related information in the following is intended to prevent unpredicted danger or damage by guiding you to use
the product safely and properly.
The safety related cautions for this product comply with certified technical standards and the electric safety standards.
Read the descriptions carefully and follow the instructions to avoid danger.
The following symbols are used to remind the user of the matters and operations that can lead to danger.
※
※
※
※
WARNING Refers to the case where the noncompliance with instructions can lead to serious injury or death.
CAUTION Refers to the case where the noncompliance with instructions can lead to light injury or product damage.
When you open or close the vacuum cap, do not use excessive force, and make sure the vacuum
container does not bump into vacuum cap. It can cause breakage.
Do not apply extreme shock to the product or drop the product. It can cause trouble and problems with
safety.
Do not clean the product with paint thinner, benzene, or insecticide. It can damage the appearance through
discoloration or exfoliation.
When disassembling the blade body for washing, take cautions to avoid injury by the sharp blade. (Wear
protective gear).
If the product generates a strange sound or an odor while in use, pull out the power plug immediately
and contact customer support center. If you run the blender at a high RPM, it can produce a slight smell due
to the friction of the motor. However, this is not a defect.
Disconnect power plug when the product is not in use, or to store or wash the product. If the supply cord
is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
Use the product for designated uses only (do not use the product for kneading, mincing, pulverizing, or for
dried food materials). Do not put the product and its parts into boiling water or a microwave. It may cause
damage or injury.
Do not put a finger or metal spoon in the vacuum container. It can cause injury and product damage.
After blending, separate the container only after the blade comes to a complete stop. Wash the blade and
container immediately and store it after it is completely dry. If not, it can become the cause of foul odor,
bacterial propagation, and corrosion.
After each use, the container lid must be washed for next use (refer to section 04). If the expanding bubble
or food material goes into the backflow prevention cap on the container lid, it can cause trouble.
Do not use the exclusive container and designated parts with other devices or undesignated parts. It can
cause breakage.
After vacuuming, keep the food in the refrigerator (never in the freezer). The vacuum does not sterilize the
foods. Take cautions when storing food.
Do not use carbonated beverages, large frozen foods, or sticky foods, etc.). It can cause injury or breakage.
Take cautions to make sure the food material does not go into the safety device. It can cause injury or
breakage.
Keep the maximum or the minimum volume for each type of material (refer to section 03). It can cause
breakage. Maximum level for smoothies to blend (MAX 1,000ml), Maximum level for milky fluids to blend (MAX
750ml), Minimum level for materials to blend (400ml).
When disposing used appliances as waste, follow designated disposal procedures.
CAUTION

6
How to use the VacuBlend
Open the blender container lid, put an appropriate
amount of materials, and close the lid (Refer to
section 03, item 15 for volume of materials).
Match the bump on the container's pouring
section and the bump on the lid. (If not, the
vacuum may not work).
1.
Turn the vacuum container clockwise until the
handle comes to the “Lock” position on the front
side.
3.
※
Check if the vacuum container and vacuum cap
are connected properly.
If the vacuum container is
not set properly, all lamps on
the front side will flicker with
the buzzer sound while the
blender is in use. Press the
power button to cancel the
buzzer and check whether
the container is set properly.
5.
※
Press the power button to turn on the blender and
use the required function to prepare the materials.
All lamps on the front side
will be on when the
container is set properly and
is ready. Check before use!
6.
Completely close the vacuum cap that you had
opened to the left.
4.
Open the vacuum cap of the blender's main body
to the left and turn the container until its handle
comes to the “Open” position to set it on the main
body.
2.
Like it simple? Go to: www.vacublend.com and watch the video.
03

7
AUTO
LOW HIGH
VACUUM
PUSH
PULSE
LOWLOW


※

※
Turning on the power
Connect the power plug of the main body to 220V outlet, press the
power button to turn on the lamps on the control panel with the
signal sound. Lamps will turn on partially when the vacuum container
is not set properly or when the vacuum cap is not closed properly.
The blender function will not operate when the lamp is not on.
Even when the power is off, a small amount of electricity is flowing through
the product.
This switch puts power on suspend, but does not completely turn it off.
7.
If an error occurs without the operation being complete, the problem
may be due to lose seal. Tap the top of the vacuum valve in the main
part when the vacuum starts.
LOW HIGH
PULSE
PUSH
LOW HIGH
PULSE
PUSH
※
※
Speed Control
Turn the speed control dial clockwise to start the blender. The
blending speed increases by the ratio of turning the dial, and
decreases to a stop when the dial is turned the other way around.
(Lamp will flicker at various rates depending on the blending speed).
The blender will stop when you press Pulse button while controlling the
speed.
It will operate for a fixed period of time and stop automatically.
8.
PUSH
AUTO
LOW HIGH
VACUUM
PULSE
※
Vacuum
When you press the vacuum button, it will automatically reach the
automatically set vacuum pressure. The lamp will flick during
vacuum action, and it will stop when you press the button again.
When an error occurs, the vacuum and pulse lamps will flicker
simultaneously with the buzzer sound, and this will be cancelled when you
press the power button again. Check the connection between vacuum
container and main body and the vacuum valve for trouble.
10.
PUSH
AUTO
LOW HIGH
VACUUM
PULSE
※
Auto
When you press auto button, it will automatically carry out vacuum,
pulse, and blend functions in respective order and also automatically
stop without additional control of the user.
Lamps will flicker when the blender is running and stop when you
press the auto button again.
When an error occurs, the vacuum and pulse lamps will flicker
simultaneously with the buzzer sound, and this will be cancelled when you
press the power button again. Check the connection between vacuum
container and main body and the vacuum valve for trouble.
11.
PUSH
AUTO
LOW HIGH
VACUUM
PULSE
(Dial's lamp will flicker at a fast rate).
Pulse
When you press the pulse button on the speed control dial, the
blender will instantly run at full power.
9.

8
Release of Vacuum (2 steps)
When you want to remove the vacuum
container after vacuum blending, you must
first open the vacuum valve on the top to
release the vacuum, after this you can
open the vacuum cap and separate the
container. On the vacuum container you
must also release vacuum by opening the
vacuum valve on the top of the lid.
12.
Sub Vacuum Container (Storage Container)
You can keep blended juice or other foods in vacuum using the storage container to keep them fresh for a
long time (Vacuum delays oxidation but does not sterilize the contents. Keep them refrigerated and consume
them as soon as possible). Some food products, including fruits, emit gas. In such case it may seem that the
vacuum container does not preserve food well, even when in fact, it is well sealed.
13.
Maximum Level
Do not exceed the maximum level for each substance indicated by the scale on the container. Bubbles or
fluids getting into the vacuum pump can cause a malfunction.
14.
Powdered Materials / Dry Materials
Powdered materials shall be completely dissolved in water or beverage for use, and dry materials shall not
be used by themselves.
16.
m l
M AX
1250
1000
750
500
Limit for
Milk / Soymilk
Foods with
Milk / Soymilk
Only
Milk / Soymilk
Minimum Level
All materials must be inserted above the minimum (MIN) level indicated by the scale on the container.
If not, the blade will idle and will not be able to crush the materials, and this can lead to a malfunction or a
performance problem.
15.
If the material is too large or too thick, the contents might not be blended well. In this case, add liquid such as water or milk.
If you put ingredients over the reference mark of the container, expanded content may suck in to the backflow prevention
cap during vacuum and cause malfunction of the vacuum pump. Please make sure to stop the operation before reaching
the backflow prevention cap.
Maximum level to blend (MAX)
Maximum level for smoothies (1,000ml)
Maximum level for products containing milk and soymilk (750ml)
Minimum level for materials to blend (400ml)
Maximum level for ice cream insertion (400ml)
How to Insert your ingredients
※
※
Ice and Solid Materials
Ice and solid materials shall not be used by themselves; break into small pieces and insert in the following
order.
17.
Liquid such as water or beverage Watery or soft materials Ice or solid materialsLight materials
① → ② → ③ → ④
How to use
the Vacublend
(continued)
Before using the product make sure that the blade body is inserted
all the way into the connecting part of the container. When loosely
assembled, the contents may pour out and cause malfunction.
※
You can easily assemble/disassemble the blade by using the
footlid of the Sub Vaccum container. I has a double function as a
tool for better grip.
※
03

9
Cleaning and maintenance
Make sure the components such as packing and backflow prevention cap are not missing when
reassembling them after washing.
※
OPEN CLOSE
Blades are sharp. Take cautions to avoid injury. (Wear protective gear).
Washing Blade Body
Blade body is not waterproof. Do not put it directly into
the water. Wash only the blades using the brush under
running water in order to prevent corrosion and remove
moisture completely. If there is dirt on the bottom of the
blade body, clean it with soft cloth or kitchen cloth.
2.
※
Washing Lid
After each use, wash the lid and remove moisture, for next
use. If a large quantity of blended materials spattered on it,
separate and wash the backflow prevention cap on the
container lid and dry it well before use. If the vacuum valve is
spattered with food, it can block the vacuum passage and
cause trouble. Take cautions to avoid trouble. In case the valve
is spattered with food, separate and wash the vacuum valve
and dry it well before use.
3.
Assembly and Disassembly of Backflow Prevention Cap
Turn it counter clockwise as in the picture on the right to disassemble
and clockwise to assemble.
※
Assembly and Disassembly of Vacuum Valve
Pull up as in the picture on the right to disassemble and press down
to assemble.
※
Storing after Cleaning
When storing after washing, completely wipe and dry the product and store it in
a well-ventilated place away from heat or direct sunlight.
5.
Other Cautions
You must turn off and unplug the product before cleaning or storing the product.
6.
Rough and sharp tools such as steel wool or steel brush can damage the product to cause leakage of materials or
vacuum failure. Do not use such tools. For the risk of fire, never use benzene, paint thinner, and wax.
※
Cleaning Main Body
Clean the main body using a small amount of neutral detergent mixed in warm water and
soft cloth or kitchen cloth.
4.
Do not sprinkle water or other liquid agents on the main body or do not put the main body into
water. It can cause fire or electric shock.
※
If the water gets inside the main body, dry it thoroughly before use.
※
Cautions for Disassembling and Cleaning Blade
Blades are sharp. Take cautions to avoid injury. Using the blade disassembly device as in
the picture on the right, turn it counter clockwise to disassemble and clockwise to assemble.
Cleaning Container
To wash the container and the blade, fill half of the container with water, assemble
it to the main body, and run for 15 seconds to wash the remnants caught in the
blades easily. Do not operate the product with foaming detergent in it (The foam
can cause product damage).
1.
※
04

Please Check before Reporting Trouble
When you experience the following symptoms while using the product, check again.
You may be able to resolve the issue yourself.
※
When the error occurs, turn off the power, unplug the product, and then take action.
※
AUTO
LOW HIGH
VACUUM
PUSH
PULSE
Error Action
Auto Error
Vacuum Error
Safety Device
Error
Auto and
Pulse
Beep - Beep - Beep - Beep - Beep
(5 times)
Beep - Beep - Beep - Beep - Beep
(5 times)
Beep - Beep - Beep - Beep - Beep
(5 times)
Vacuum and
Pulse
All
Lamps Buzzer Sound
Buzzer / Lamp Reaction to Errors
For following symptoms Take following measures
It is not working at all
It stops while in use
Check whether the earth leakage breaker is down or whether the power cord is unplugged.
Check whether the vacuum container is set on the main body properly or whether the
vacuum cap is closed properly.
Materials not pulverized
well
Did you put too much or too little materials? Refer to how to feed food materials in section 3.
Check operating voltage. This product is exclusively for AC 220V.
Materials are leaking Check whether the vacuum container is set on the main body properly and whether the
container's lid or blade body are connected to the container properly.
Check whether the container's lid or blade packing is damaged and if it is, then contact
your retailer or customer service center.
Vacuum is not working Check whether the vacuum container components such as packing and backflow
prevention cap are assembled properly.
Check whether the container's lid is contaminated. If it is, clean it according to the
descriptions in section 4.
Check if the container cover seal is in correct position and press the vacuum valve on the
vacuum cap of the main body as it starts vacuuming (see section 3, the top of the right page).
Check whether the earth leakage breaker is down or whether the power cord is unplugged.
Did you use the product continuously for a long time? When the motor overheats, it is
designed to stop automatically for safety and run again when it cools down.
Cool down the motor fully for 30 minutes and try again.
Check whether materials are caught in the blades.
Check whether the vacuum cap is open or whether the vacuum container is loosened
from the main body.
05
10

11
Warranty and contact
06
You can register your purchase on the website of Versapers. http://versapers.com/warranty. Your
warranty is executed at the local distributor where you have purchased the product.
Please always keep your invoice or receipt as original proof of purchase in case of making a claim on
the warranty. We certify that your Vacublend vacuum blender is warranted by Versapers to be free from
defects in material construction and workmanship.
All parts are warranted for two (2) years from the date of purchase to the original purchaser.
This warranty does not apply to damages caused by accident, misuse, abuse, commercial use,
alteration, failure to follow the operating instructions in this manual, or damage caused by parts or
service unauthorized by Versapers.
Damages caused by transportation must be claimed with the carrier. Versapers disclaims all
responsibilities for consequential damages from incidental losses caused by use of this appliance. If
service should be necessary, please contact our local Customer Care Center for technical support.
Manufacturer :
Versapers
De Steeg 10
9473 TT De Groeve
The Netherlands
You have bought a VacuBlend and thus you now belong to the leading group of health innovators. In the
nutritional field, you show that you only want the best for yourself and your family. By nourishing your
knowledge about the healthiest food trends and tools, you have managed to find us.
We think it's super cool that VacuBlend has got a place in your life. All the super healthy juices,
smoothies and soups that you will make with it, will bring you mentally and physically feel better.
For me personally VacuBlend is the newest baby in our mission to make the world a little healthier every
day. Of course we will do our best to inspire as much as possible with creative recipes and applications,
enabling you as our health ambassador to further inspire the people in your environment. Together, we
have made a new step in our juice revolution. Yeah!
Welcome to the brand new world of vacuum blending.
With healthy regards,
Joost
Founding father Versapers
Congratulations!

A Dutch brand, made in South Korea
VB_ACT_V1.0_EN
www.versapers.com
DISCOVER WHAT
80% LESS
DOES FOR YOUR
SMOOTHIE
OXYGEN
