vacuubrand VACUU-BUS User manual

Technology for Vacuum
Systems
Instructions for use
OI no.: 20901660Original instructions EN
USB VACUU·BUS®converter
for communication with
VACUU·BUS®-enabled devices
CommuniCation Kit

2 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Original instructions
Keep for further use!
This manual is only to be used and distributed in its complete and original form. It is strictly the user's responsibility to
carefully check the validity of this manual with respect to the product.
Thank you for purchasing this product from VACUUBRAND GMBH + CO KGVACUUBRAND GMBH + CO KG. You have chosen a modern and
technically high quality product.
Imprint
Manufacturer:
VACUUBRAND GMBH + CO KGVACUUBRAND GMBH + CO KG
Alfred‑Zippe‑Str. 4Alfred‑Zippe‑Str. 4
97877 Wertheim97877 Wertheim
GERMANYGERMANY
Phone:
Head ofce: [phone]‑0
Sales: [phone]‑5550
Service: [phone]‑5660
Fax: [phone]‑5555
Email: [email protected]
Web: www.vacuubrand.com

Contents
320901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
TABLE OF CONTENTS
1 Introduction 5
1.1 User information .................................5
1.2 Copyright ......................................5
1.3 Symbols and icons ...............................5
1.4 Disposal .......................................6
2 Product description 7
2.1 Communication Kit ...............................7
2.2 Connection examples.............................8
2.2.1 VACUU·PURE update.........................8
2.2.2 VACUU·BUS component update ................9
2.2.3 VACUU·PURE data transfer ...................11
3 Connection 13
3.1 Cable adapters, general ..........................13
3.2 VACUU·PURE .................................13
3.3 VACUU·BUS component .........................14
4 Service 15
5 Index 16

Contents
4 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920

520901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Introduction
11 IntroductionIntroduction
1.11.1 User informationUser information
This manual is part of your product. The illustrations and drawings
in this manual are only intended to facilitate comprehension. We
reserve the right to make technical changes in the course of
continuous product improvement. Only use the product if it is in
perfect working condition.
In addition, refer to the original instructions for the connected
devices.
1.21.2 CopyrightCopyright
The content of this manual is protected by copyright. Only copies
for internal use are allowed, e.g., for professional training.
© VACUUBRAND GMBH + CO KGVACUUBRAND GMBH + CO KG
1.31.3 Symbols andSymbols and iconsicons
This manual uses symbols and icons. Safety symbols indicate
specic risks associated with handling the product. Symbols and
icons are designed to help you identify risks more easily.
General mandatory sign. Disconnect power plug.
Electric/electronic devices must not be disposed of in
domestic waste at the end of their service life.
Refer to manual.
Graphic symbol for
connector.
Graphic symbol for
socket.
User information
Copyright
Meaning of
symbols

6 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Introduction
1.41.4 DisposalDisposal
NOTENOTE
Incorrect disposal of electronic components can
cause environmental pollution.
Used electronic devices contain harmful substances that
can cause damage to the environment or human health.
Disused electrical devices also contain valuable raw materials,
which can be recovered for reuse if the device is disposed of
correctly within the recycling process.
End users are legally obliged to take used electric and
electronic devices to a licensed collection point.
> Correctly dispose of all electronic scrap and electric
components at the end of their service life.
> Observe the national regulations regarding disposal and
environmental protection.

720901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Product description
22 Product descriptionProduct description
The Communication KitCommunication Kit is a set consisting of various cable
adapters intended for connecting VACUU·BUS components to a
terminal device.
The
Communication KitCommunication Kit is used for communication between a
terminal device, e.g., a PC, laptop, control panel, or PLC, and
VACUU·BUS-enabled devices. It can be used for rmware
updates, remote control, or remote monitoring.
2.12.1 Communication KitCommunication Kit
The Communication KitCommunication Kit consists of a USB VACUU·BUS
converter (1)(1), various cable adapters (3)(3) and (4)(4), and a
VACUU·BUS Y adapter (2)(2).
The cable adapter (3)(3) labeled is intended
solelyforcommunicatingwithandupdatingVACUU·PUREvacuum
pumps. The other cable adapter (4)(4) is intended for updating and
communicating with suitable VACUU·BUS components.
Components
2
4
2
3
1
1D-sub 9 pin RS-485 connector/USB adapter +
USB/USB extension cable (type A) + CD ROM with drivers
2VACUU·BUS Y adapter
3Cable adapter: VACUU·BUS socket/D-sub
only for VACUU·PURE
4Cable adapter: VACUU·BUS connector/D-sub
Intended use
Description of
components
Function
Description
Overview of
components

8 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Product description
Example
VACUU·PURE
update
Standard delivery
1x Communication Kit 20683230
1x Instructions for use 20901425
1x Original packaging ------
2.22.2 Connection examplesConnection examples
2.2.12.2.1 VACUU·PURE updateVACUU·PURE update
VACUU·PURE – rmware update
1
2 3
1VACUU·PURE vacuum pump
2Communication Kit with cable adapter for VACUU·BUS socket/
D-sub
3Laptop or PC
In the package

920901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Product description
Example
Vacuum sensor
update
Example
Vacuum pump
update
Description
Description
2.2.22.2.2 VACUU·BUS component updateVACUU·BUS component update
Vacuum sensor – rmware update
1 4
3
2
1Plug-in power supply 24 V
2VACUU·VIEW vacuum sensor
3Communication Kit with cable adapter for VACUU·BUS
connector/D-sub and Y adapter
4Laptop or PC
Vacuum pump – rmware update
1
4
3
2
1VACUU·BUS extension cable, optional
2Vacuum pump*
3Communication Kit with cable adapter for VACUU·BUS
connector/D-sub
4Laptop or PC
* Only VARIO select vacuum pumps with 8 cylinders.

10 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Product description
Example
VAC 24seven
control module
update
Example
VAC 24seven
pump module
update
Control module – control board rmware update
4
2
1
3
1VACUU·BUS extension cable, optional
2VAC 24seven control module
3Communication Kit with cable adapter for VACUU·BUS
connector/D-sub
4Laptop or PC
Pump module – single vacuum pump rmware update
4
2
1
3
1VACUU·BUS extension cable, optional
2VAC 24seven pump module
3Communication Kit with cable adapter for VACUU·BUS
connector/D-sub
4Laptop or PC
Description
Description

1120901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Product description
Example
Communication with
a single vacuum
pump
Example
Communication with
multiple vacuum
pumps
2.2.32.2.3 VACUU·PURE data transferVACUU·PURE data transfer
VACUU·PURE communication
2
1
3 4
2
1
3 4
65
Accessories for connecting multiple
vacuum pumps, see “Ordering“Ordering
information” on page 15information” on page 15
1VACUU·PURE vacuum pump
2VACUU·BUS extension cable, optional
3Communication Kit with cable adapter for VACUU·BUS socket/
D-sub
4Host computer, e.g., laptop or PC
5VACUU·BUS extension cable
6VACUU·BUS Y adapter
Description

12 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Product description

1320901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Connection
33 ConnectionConnection
3.13.1 Cable adapters, generalCable adapters, general
Connect cable adapters
1.1. Disconnect the device power plug or switch off the power
switch.
2.2. Connect all required components of the Communication Kit
as shown in the illustrations in chapter 2.2.
3.3. Connect the VACUU·BUS connector or socket to the
corresponding VACUU·BUS port on the device.
4.4. Connect the USB adapter to a free USB port on your terminal
device and, if required, install the driver software from the
enclosed CD ROM.
5.5. Refer to the manual of the VACUU·BUS component or your
laboratory software for how to install an update or establish
data transfer.
3.23.2 VACUU·PUREVACUU·PURE
The cable adapter labeled is intended
solely for VACUU·PURE vacuum pumps for updates and as a
Modbus RTU interface. Communication can only be established
with suitable software, e.g., LabVIEW, Modbus Poll, etc.
Cable adapter with VACUU·BUS socket
2 31
* VACUU PURE ONLY
1Cable adapter for VACUU·BUS socket/D-sub
2RS-485 / USB-A adapter
3USB-A extension cable
Example
View of installed
cable adapter

14 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Connection
3.33.3 VACUU·BUS componentVACUU·BUS component
The unmarked cable adapter is intended for suitable VACUU·BUS
components for updates and as a data transfer interface, e.g., for
reading out values.
Cable adapter with VACUU·BUS connector
2 31
1Cable adapter for VACUU·BUS connector/D-sub
2RS-485 / USB-A adapter
3USB-A extension cable
Example
View of installed
cable adapter

1520901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Service
44 ServiceService
Technical support
For technical assistance or in the event of an error, please con-
tact our Service Department1.
Updates
If an update is available for your device, you will be able to down-
load it from our homepage.
VACUUBRAND > Support > Software Updates
Ordering information
Product Order no.
Communication Kit 20683230
Accessories, optional Order no.
VACUU·BUS Y adapter 20612875
Extension cable VACUU·BUS, 0.5 m 20612875
Extension cable VACUU·BUS, 2 m 20612552
Extension cable VACUU·BUS, 10 m 22618493
Sources of supply
Purchase original accessories and original spare parts from a
subsidiary of VACUUBRAND GMBH + CO KGVACUUBRAND GMBH + CO KG or your local dis-
tributor.
>Information about our complete product range is available
in the current product catalog.
>Your local distributor or VACUUBRAND GMBH + CO KGVACUUBRAND GMBH + CO KG
sales ofce is available to assist you with orders, questions
on vacuum control and optimal accessories.
1 -> Phone: [phone], fax: [phone],
[email protected]
Ordering information

16 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920
Index
55 IndexIndex
C
Cable adapter .................................... 7
Communication Kit ............................ 7
Communication with a single vacuum
pump ................................................ 11
Communication with multiple vacuum
pumps .............................................. 11
Components ...................................... 7
Connect cable adapters ................... 13
Control module update .................... 10
Copyright ........................................... 5
D
Disposal ............................................. 6
F
Function ............................................. 7
I
Icons .................................................. 5
Intended use ...................................... 7
In the package ................................... 8
M
Mandatory sign .................................. 5
Meaning of symbols ........................... 5
O
Ordering information ........................ 15
Overview of components ................... 7
P
Product description ............................ 7
Pump module update ...................... 10
S
Sources of supply ............................ 15
Standard delivery ............................... 8
T
Technical support ............................. 15
U
Update available? ............................ 15
User information ................................ 5
V
Vacuum pump update ........................ 9
Vacuum sensor update ...................... 9
VACUU·PURE update ....................... 8
View of installed cable adapter .. 13, 14

1720901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920

18 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920

1920901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920

Manufacturer:
VACUUBRAND GMBH + CO KGVACUUBRAND GMBH + CO KG
Alfred‑Zippe‑Str. 4Alfred‑Zippe‑Str. 4
97877 Wertheim97877 Wertheim
GERMANYGERMANY
Phone:
Head ofce: [phone]‑0
Sales: [phone]‑5550
Service: [phone]‑5660
Fax: [phone]‑5555
Email: [email protected]
Web: www.vacuubrand.com
Version: 20901660_EN_VACUU·BUS-CommunicationKit_V2.0_070920 – TDD2 – © VACUUBRAND GMBH + CO KG – 2020
Technology for Vacuum
Systems
