VADO NOTION User manual

Guarantee
WHERE
INSPIRATION
FLOWS
NOTION
2 handle, 2 outlet thermostatic shower valve
1
5
y
e
a
r
g
u
a
r
a
n
t
e
e
User Guide
Keep for future reference
All VADO products come with a 2 year guarantee as standard. Within this guarantee period
VADO will provide replacement parts and any labour [SEE NOTE 1] needed to complete the
product repair.
This standard guarantee may be extended by registering your product to give up to a 15 year
guarantee period. Once registered:
VADO chromed brassware and stainless steel products have a 15 year guarantee
(2 years parts and labour plus 13 years parts only).
VADO Sensori SmartTouch and SmartDial products have a 5 year guarantee
(parts and labour).
VADO Identity and i-tech products have a 5 year guarantee (2 year parts and labour plus 3
years parts only).
All other VADO products have a 3 year guarantee (2 years parts and labour plus 1 year parts only)
[SEE NOTE 2].
Guarantee Conditions
Our products are guaranteed against manufacturing defects from the date of purchase until
the expiry of the relevant guarantee period shown above.
The guarantee is only valid if:
•The product has been installed, used and maintained in accordance with VADO’s
instructions and subjected to normal use only.
•The defect is not due to use of an unsuitable or inadequate water or power supply.
•The defect is not due to accident, misuse, neglect or incorrect/inappropriate repair (other
than by VADO or VADO authorised agents) or damage caused by foreign objects
or substances.
•The extended guarantee is only available if you have completed the Guarantee
Registration Process.
This can be done via the VADO website or via phone to our aftersales team.
Registration must be completed within 6 months from date of purchase.
Under the extended guarantee period VADO will, at its option, offer to supply any
replacement product (or component part) assessed to be defective [SEE NOTE 3].
The guarantee (whether standard or extended) is non-transferable to any subsequent owner.
All claims under the guarantee should be notified in the first instance to our Aftersales
department, contact details below, this must be done no later than the last day of the
relevant guarantee period.
All claims must be accompanied by proof of purchase (sales receipt or delivery note) from
an official VADO dealer.
The guarantee does not extend to any consequential loss or damage.
After repair or replacement, the relevant guarantee period will be calculated from the
original date of purchase.
VADO operates a policy of continuous product development and therefore reserves the right
to change the product, packaging and documentation specifications without notice. E&OE.
NOTES:
[1] Labour via our engineer network is only available in the UK. Attendance by a VADO
engineer or sub-contract engineer will be under our standard terms and conditions.
[2] VADO spare parts and shower hoses are under a parts only guarantee.
[3] VADO reserves the right to charge in advance for a product (or replacement part)
pending collection and investigation (at VADO expense) to confirm a defect is due to a
manufacturing issue.
If a defect is found the charge will be refunded or cancelled.
This guarantee is in addition to and does not affect your statutory rights as a consumer.
Tel: [phone]
Email: [e-mail]

Welcome
Thank you for choosing VADO
Our products can be found in some of the most prestigious
hotel, commercial and residential developments across the
world, therefore you can expect exceptional product quality and
outstanding customer service.
This product has passed through stringent quality assurance
processes coupled with demanding lifecycle mechanical testing
to ensure it reaches the exacting standards that allow us to
offer our premium 15 year guarantee.
We work to ensure our product designs are harmonious with
all sanitaryware, so when you choose VADO, your choice of
coordinating items is unlimited.
With VADO, you can really let your inspiration flow.
For any technical or operational queries please contact our
experienced aftersales team on 01934 745163.
2
Cleaning instructions:
The electroplating on this product is finished to the highest
standard. Due care needs to be taken to ensure the
appearance is retained.
We recommend cleaning all products with a soft damp cloth
ONLY and advise strongly against the use of all aggressive/
corrosive cleaning products i.e. powders and liquids. If
these instructions are not followed, this may invalidate your
guarantee in the event of a problem occurring.
3
VADO, Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel [phone] fax [phone]
[e-mail]
www.vado.com

Turning the flow control in the direction of the arrows
increases the flow of water to the outlets.
Operation - flow control
Handset
outlet
Outlet 1
Off
Outlet 1 &
Handset outlet
Handle in Off position
(handle mark at 12 o’clock)
4
Cold
Hot
Hot
Turning the temperature control handle in the direction of
the arrows increases/decreases the temperature
Operation - temperature control
Cold
5

6 7
Removing the Cartridge
1. Remove handle assemblies and faceplate allowing access to
the isolation points on the valve.
2. Screw down the isolation screws clockwise until you
feel resistance (taking care not to over tighten). Ensure the
thermostatic valve has been successfully isolated.
See page 9 for correct procedure.
3. Remove the screw, spline adaptor, connecting rod and stop
ring.
4. Unscrew and remove the securing nut.
5. Carefully pull out the thermostatic cartridge.
6. Clean filters by rinsing them under running water to remove
any debris.
7. If there is limescale deposits then it is recommended to
immerse the cartridge for a few minutes in 50% white vinegar
+ 50% hot water, brush the filters gently and then rinse under
running water to clean all particles. If this is not effective, a
replacement cartridge should be fitted.
Maintenance Maintenance
We advise that the below is carried out annually as failure to do
so may result in invalidation of warranty.
Shut off the water supply to both hot and cold inlets, before
commencing any maintenance work below.
See isolation procedure on page 9.
Thermostatic cartridge
This thermostatic valve is fitted with a single filtering facility.
Filters are fitted on the thermostatic cartridge. Depending on
the water quality, filters may become dirty, causing reduced
flow and inefficient working of the valve. To clean the filters, you
must first remove the cartridge from the housing.
Securing
nut
Stop ring
Connecting
rod
Screw
Spline
adaptor
Cartridge O-ring
O-ring
O-ring
Filter
Filter Grub screw
Locating
slot
Isolation
screws

8
Maintenance
8. Before reassembling the cartridge, clean its housing with
a wet cloth and grease the O-rings using a suitable silicone
grease, insert the thermostatic cartridge to the valve body
ensuring the grub screw is aligned with the slot.
9. Screw the securing nut on and tighten.
10. Place the temperature stop ring on the cartridge so the step
is located at 8 o’clock.
11. Place the connecting rod, spline adaptor and screw back
onto the cartridge.
12. Turn the water supply on via the isolating valves.
13. Check the water temperature to ensure correct
commissioning.
See page 15 of the installation instructions or Vado.com for
commissioning.
11. Replace handle assemblies and faceplate.
Step
Isolation procedure
IMPORTANT: Please see the below procedure for isolating this
thermostatic valve.
1. Remove handles/faceplate and trim parts allowing access to
the isolation points on the valve.
2. Screw down the isolation screws clockwise until you feel a
resistance (taking care not to over tighten).
3. Turn shower on to check isolation, please ensure that
your body/hands are not under the flow of water as there is a
potential for delivery of hot water.
4. Remove temperature stop ring (essential).
5. With shower in the on position, replace temperature handle
on thermostatic valve (ensure temperature stop ring has been
removed).
6. Turn temp handle fully anti clockwise until stop point is
reached and can be turned no further, please ensure that your
body/hands are not under the flow of water as there is potential
for delivery of hot water if isolation has been unsuccessful.
7. Turn temperature handle fully clockwise until resistance is
felt.
8. If there is no flow of water coming from the outlet during
both points 6 and 7 isolation has been successful, you may now
remove and maintain the cartridge.
9. If at any of the above points water continues to flow please
isolate at an alternative point within the system for both hot and
cold and repeat points 3-9.
Maintenance
9

Parts list:
10
Parts:
11
5
7
2
9
1
3
3
2 handle,2 outletthermostatic shower valve
TAB-148/2WO-NOT-CP
Keep for future reference
Installation Guide
NOTION
WHERE
INSPIRATION
FLOWS
NOTION
2handle, 2 outlet thermostatic shower valve
1
5
y
e
a
r
g
u
a
r
a
n
t
e
e
UserGuide
Keep for future reference
4
4
18
17 17
17
8
11
10
12
6
13 14 15
16
Item Code Quantity
1FL-802-33/2MX 1
2V-704-34S 1
3TAB-003A-FIL 1
4TAB-003A-FIL-HOUSING 1
5TAB-STOPRING 1
6TAB-NUT/TEMP-BRA 1
7TAB-NUT/FLOW-BRA 1
8TAB-DIV/EXTSPLINE-BR 1
9TAB-COG-BRA 1
10 TAB-1/FLOW-NOT-C/P 1
11 TAB-1/TEMP-NOT-C/P 1
12 TAB-DIV/COVERNUT-BRA 1
13 TAB-WO/SPIGOT-BRA 1
14 TAB-0024WO-NOT-CP 1
15 INS-HANDSET-C/P 1
16 SH-013-150-CP-LB 1
17 CEL-CON-3/4MX1/2F-BR 1
18 INSTALLATION GUIDE &
USER MANUAL 1
