4 hole single lever bath shower mixer
3 hole single lever bath shower mixer
Installation & maintenance instructions
Please leave these instructions with the customer

Important - please read
General installation
27
Operation
Maintenance
Please read these instructions carefully before starting installation and keep for future
reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and ttings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing (UK:BS6700) Regulations.
We strongly recommend that you use a qualied and registered plumber.
These ttings are mixing devices and therefore water supplies must be reasonably
balanced.
Where connections are made to the mains cold water supply, WRC approved single
check valves must be tted to both hot and cold inlets. This is a stated requirement of
Water Supply (Water Fittings) Regulations 1999 Schedule 2, Section 6 G15.13.2
Before making any inlet pipe connections, all supply pipes MUST be thoroughly
ushed to remove debris. Failure to do so could result in damage or low ow from the
mixer unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 4 G13.1
The tting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Care of the taps
Our products are nished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the
event of a problem occurring.
Shower/spout lever - diverts
the ow of water to either the
shower or the spout.
Moving the mixer lever
upwards/downwards will
increase/decrease the ow of
water.
Moving the mixer lever from
right to left will increase the
water temperature.
Removing the shower hose.
Should you need to replace the shower
hose, unscrew the base ring from the
base shroud, remove the plastic sleeve
and pull the shower hose through the
connecting tube from underneath the
unit. Remove the shower hose from the
exible hose coming from the diverter.
Fitting a new shower hose.
Place a rubber washer into the nut end of
the new hose and connect to the exible
pipe. Push the cone end of the hose up
through the connecting tube, clip on the
plastic sleeve and screw the base ring
back onto the base shroud.
Finally connect the new hose to the
handset.
Base
shroud
Base
ring
Plastic sleeve
Shower
hose

6
Dimensions
3
Operating Specications
Operating Pressure:
Minimum operating pressure 3 bar
Maximum operating pressure 5 bar
Installation - shower (and optional spout)
Rubber
washer
Nut
Flexible pipe
Connecting
tube
Shower
hose
Base
shroud
Base
ring
Washer
Hand set
Position the spout in place , and from the
underside slide on the rubber washer,
and then the washer/nut. Tighten the
nut to clamp on the spout.
CAUTION: Do not over tighten the nut.
Connect the spout to the diverter using
the large exible pipe.
Rubber
washer
Washer
Nut
Remove the nut, washer and rubber
washer from the connecting tube. Push
the shower hose and connecting tube
down through the hole, make sure the
seal is in position in the bottom of the
base shroud. From the underside slide
on the rubber washer, metal washer and
then the nut. Tighten the nut to clamp on
the cover plate.
CAUTION: Do not over tighten the nut.
Place a rubber washer into the nut end
of the shower hose and screw onto the
exible pipe coming from the diverter.
Place the rubber washer into the cone
end of the hose and screw to the handset.
Flexible pipe
35mm
48mm
55mm
45mm
42mm
55mm
38mm
65mm
180mm
110mm 57mm
110mm
20mm
90mm
5mm
36mm
Spout
Shower
hose

4
Installation - diverter valve
5
Installation - tap
Rubber
washer
Metal
washer
Cold inlet
Control
handle
Cover ring
Cover
Rubber
washer
Metal
washer
Nut
Valve
Screw the nut onto the valve body,
slide on the metal washer and rubber
washer, push the valve up through the
hole in the unit.
Slide the cover ring over the valve
making sure that the seal is in place on
the underside. Screw the cover onto the
valve. From the underside tighten the
nut to secure the valve in place.
CAUTION: Do not over tighten the nut
as this might damage the unit.
Carefully push the control handle onto
the splines of the valve and secure
using the hexagonal screw, replace the
screw cover.
Connect the valve to the tap, spout and
handset using the exible connectors.
Flexible pipe
outlet to
handset
Flexible pipe
inlet from
tap
Nut
Hot inlet
Flexible pipe
outlet to
spout
Cover
plug
Hexagonal
screw
Before installing your new mixer, ush
through the pipework to ensure removal
of debris, turn o the water supply.
Place the mixer in position.
From the underside slide the metal
washer and then the rubber washer over
the threaded connection and screw into
the back hole of the mixer. Tighten the
nut to clamp the mixer to the unit.
CAUTION: Do not over tighten the nut
as this may damage the unit.
Screw the exible pipes to the mixer.
Connect the water supply to the
inlet pipes. The hot water should be
connected to the left hand pipe and
cold to the right.
Connect the back outlet pipe to the
diverter using a exible pipe.
Control
handle
Threaded
connection
Outlet
Flexible
pipe to the
diverter
