VADO AXCES AX-VAL-137-CP Instruction Manual

This instruction booklet covers model:
AX-VAL-137-CP
Version 1, 1-8-19
VADO
Wedmore Road, Cheddar,
Somerset, England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail] BATH FILLER
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
VALA

23
Please read these instructions carefully before starting installation and keep for
future reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and fittings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing Regulations.
To be installed in accordance with BS EN806.
We strongly recommend that you use a qualified and registered plumber.
General installation
Operating Specifications
Important - please read
Operating Pressure
Minimum operating pressure 0.5 bar
Maximum operating pressure 5 bar
This fitting is a mixing device and therefore water supplies should be reasonably
balanced.
When installed, the fitting must comply with the requirements of the Water Supply
(Water Fittings) Regulations 1999 and Scottish Byelaws 2004.
For further information, contact the Water Regulations department of your local water
supplier (see the WRAS website www.wras.co.uk for details) or the Water Regulations
Advisory Scheme by email ([e-mail]) or telephone: [phone].
Before making any inlet pipe connections, all supply pipes MUST be thoroughly flushed
to remove debris. Failure to do so could result in damage or low flow from the mixer
unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 13.
The fitting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Contents of Packaging
Installation guide &
User manual
Mixer with 2 O-rings
Fixing Kit
Nuts x 2
BATH FILLER
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
VALA
Rubber washers x 2

4 5
Dimensions
93mm
3/4"
162mm
115mm
180mm
½"
Installation - Quick guide
1
23
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
3
4
2
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
3
4
x 2 x 2
1

6 7
Installation Operation
Cold
Hot
Hot tap - moving the tap lever to the left will increase the flow of water.
Cold tap - moving the tap lever to the right will increase the flow of water.
Before installing your new mixer, flush through the pipe work to ensure removal of
debris, turn off the water supply.
Make sure that the base seals are in position in the bottom of the mixer body.
Position the mixer on the bath. From the underside of the bath fit the rubber
washers and nuts. Tighten the nuts to clamp the mixer to the bath.
CAUTION: Do not over tighten the nuts as this may damage the bath.
Connect the water supply to the inlet pipes. The hot water should be connected to
the left hand pipe.
Cold
control
handle
Hot
control
handle
Rubber
washer
O-ring
Nut
Rubber
washer
Nut
O-ring

8 9
NotesCleaning instructions
The electroplating on this product is finished to the highest standard. Due care needs
to be taken to ensure the appearance is retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of all aggressive/corrosive cleaning products i.e. powders and liquids.
If these instructions are not followed, this may invalidate your guarantee in the event
of a problem occurring.

11
