Vahle SLS Quick guide

TRANSLATION OF THE ORIGINAL GERMAN
OPERATING INSTRUCTIONS
SLS
BATTERY CHARGING CONTACTS
INSTALLATION MANUAL
MAINTENANCE MANUAL
SYSTEM MANUAL
EN-V 1.01

TABLE OF CONTENTS 0
TABLE OF CONTENTS
1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.1 About these instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.2 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.3 Copyright protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.4 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.5 Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.6 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.6.1 Warranty terms and conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..6
2.3 General risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..7
2.3.1 Danger from electrical energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.4 Responsibilities of the operating company . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.5 Personnel requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.5.1 Qualifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.6 Personal protective equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7 Safety devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.8 Conduct in case of danger or accident . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.9 Signage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3Technicaldata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4 Layout and function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4.1 Brief system description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4.2 Assembly overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.1 Safety instructions for commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.2 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5.2.1 Hanger preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5.2.2 Preassembling the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5.2.3 Assembling the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5.2.4 Mounting more rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2.5 Finalize assembly system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2.6 Connection Feed terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.2.7 Installing current collector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
6 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
6.1 Safety information about repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
6.2 Rail maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
6.3 Current collector maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
7 Transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
7.1 Safety instructions for transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
7.2 Transport inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30


TABLE OF CONTENTS 1
7.3 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
8 Disassembly and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
8.1 Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
8.2 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33


GENERAL 2
1 GENERAL
1.1 About these instructions
1.2 Symbols
Safety instructions in this manual are identified by symbols. Each safety instruction begins with a signal word
that indicates the severity of the hazard. The various types of warnings and safety instructions and their struc-
ture are explained below.
DANGER!
The source of the hazard is described here.
This combination of a symbol and a signal word indicates an immediately dangerous
situation that will result in death or serious injury unless avoided.
►The actions to prevent the hazard are identified here.
DANGER!
The source of an electrical hazard is described here.
This combination of a symbol and a signal word indicates an immediately dangerous
situation related to electricity that will result in death or serious injury unless avoided.
►The actions to prevent the hazard are identified here.
WARNING!
The source of the hazard is described here.
This combination of a symbol and a signal word indicates a potentially dangerous sit-
uation that may result in death or serious injury unless avoided.
►The actions to prevent the hazard are identified here.
CAUTION!
The source of the hazard is described here.
This combination of a symbol and a signal word indicates a potentially dangerous sit-
uation that may result in light or moderate injury unless avoided.
►The actions to prevent the hazard are identified here.
NOTICE!
The source of the hazard is described here.
This combination of a symbol and a signal word indicates a potentially dangerous sit-
uation that may result in property or environmental damage unless avoided.
►The actions to prevent the hazard are identified here.


GENERAL 3
NOTICE!
This indicates a reference to another place in this text or another document.
This combination of a symbol and a signal word indicates a reference to another place
in this text or in a different document.
►The places in the text or references to other documents are identified here.
TIPS AND RECOMMENDATIONS!
►Simple tips and recommendations from our long years of experience are provided
here.
1.3 Copyright protection
The contents of this manual are protected by copyright. Their use is permitted within the scope of the use of
the installation. No further use is permitted without the written permission of the manufacturer. This manual
may not be copied, given to any third party, reproduced in any form or by any means, including, but not limited
to, exploitation and / or communication of the contents without the written permission of the manufacturer,
except for internal purposes.


GENERAL 4
1.4 Disclaimer
The information in this document has been compiled in consideration of applicable standards and regulations,
accepted rules of engineering, as well as our years of knowledge and experience.
The manufacturer shall not be liable for damages resulting from:
•Failure to observe the technical documentation
•Uses other than the intended use
•Use by personnel without the required training
•Unauthorized modifications or technical changes
•Use of non-approved spare parts or accessories
The actual scope of delivery may vary from the descriptions and images in this document in case of custom
versions, the selection of additional order options, or due to latest technical changes.
The obligations agreed in the supply contract, the general terms and conditions and the terms and conditions
of delivery, and the laws and regulations applicable at the time the contract was signed all apply.
We reserve the right to make technical changes to improve the usability and for further development.
1.5 Customer service
Paul Vahle GmbH & Co. KG
Westicker Str. 52
Tel: [phone]
Fax: [phone]
59174 Kamen, GERMANY
Email: [e-mail]
Web: http://www.vahle.de
Country of origin: Germany


GENERAL 5
1.6 Warranty
1.6.1 Warranty terms and conditions
The information in this document has been compiled in consideration of applicable standards and regulations,
accepted rules of engineering, as well as our accumulated years of knowledge and experience.
The warranty period and the scope of the warranty are defined in the terms of the contract and the general
terms and conditions of delivery of Vahle GmbH & Co. KG.
Our general terms of warranty and delivery are published on our website. www.vahle.de
WARNING!
No liability in case of unauthorized changes, modifications, or accessories!
Changes or modifications to the delivered product require the permission of the man-
ufacturer. Genuine spare parts and manufacturer-approved accessories provide safe-
ty. The use of non-approved parts voids any liability of the manufacturer.
►Always consult the manufacturer first!
The warranty immediately expires if one or several of the following situations arise(s):
•If the product is modified without permission from Vahle.
•If the operator independently performs repairs during the warranty period or has repairs performed by
third parties.
•If the product has been handled or maintained inappropriately.
•If parts are used that are not original parts approved by Vahle.
•If the information in this documentation is not observed.


SAFETY INSTRUCTIONS 6

2 SAFETY INSTRUCTIONS
2.1 Safety
This section gives an overview of all important safety aspects relating to the protection of personnel as well as
the safe use and fault-free operation. Other, task-specific safety instructions can be found in the sections on
the individual phases of the product's life.
DANGER!
Failure to observe the safety instructions may result in risks to life and health!
2.2 Intended use
Intended use
The charge contacts are intended for charging moving shuttles which travel over the bar with the built-in cur-
rent collector.
•Ambient temperature: - 30°C to +55°C
•Air humidity: r.F. 95% (non-condensing)
•Travel speed: max. 4.0 m/s
•Voltage: 0 to 48 VDC
•max. current load: 100 A (140 A at 50 % ED)
•Automatic disconnection of the charging current by the power supply units when moving up and down to
the charging contacts
•exclusively for indoor systems
•Length of the charging contact standard 4 m. Longer charging contacts on request
Foreseeable misapplication
•Incorrect installation
•Insufficient air gap in relation to surrounding, possibly conductive parts
•Insufficient maintenance
•Temperature range exceeded


SAFETY INSTRUCTIONS 7

2.3 General risks
The following section describes residual risks that arise even if the product is used as intended. Observe the
safety instructions listed here in the other sections of these instructions to reduce the risk of injuries or dam-
age to property and equipment and to avoid dangerous situations.
Do not change or modify the system inappropriately!
WARNING!
Risk of death from improper replacement or removal!
Errors during the removal or replacement of components may cause life-threatening
situations or significant property damage
►Observe the safety instructions before beginning any removal work.


SAFETY INSTRUCTIONS 8

2.3.1 Danger from electrical energy
Perform the following safety work according to VDE 0105-100 (this work must be carried out by a qualified elec-
trician, see chapter: "2 security").
Activate
The required separation distances must be established.
Secure against restart
During work, a prohibition sign must be attached reliably on switching handles or drives of switches, control
units, pressure and sensing devices, safety parts, circuit breakers that have been used to unlock a system part
or that can be used to connect electricity. If this is not possible, then the clearly associated prohibition sign
must be nearby. Existing mechanical interlocking devices against restart must be used for manually operated
switches.
Determine absence of voltage
Absence of voltage is to be determined at or as close as possible to the work site at all pins. Absence of voltage
must be checked with a voltage tester immediately before and after use.
Grounding and short-circuiting
Parts on which work will be performed at the work place must first be grounded and then short circuited.
Grounding and short-circuiting must be visible from the workplace. Deviating from the above, it is permitted to
ground and short-circuit near the work place if this is required due to local conditions or for safety reasons.
Devices for grounding and short-circuiting must always first be connected with the grounding system or the
ground electrode and afterwards with the parts to be grounded. Grounding and short circuiting may be waived
in certain low-voltage systems (see VDE 0100-100).
Cover adjacent, live parts or isolate them
Before starting work, check whether it is appropriate to make adjacent parts voltage-free.
DANGER!
Danger of death due to electrical current!
Contact with live parts can result in life-threating injuries.
►Make sure that the relevant components are not live or under voltage, and that
there is no unauthorized approximation.
