Vais Technology SoundLinQ3 SL3sat User manual

Owner’s Manual
www.vaistech.com
Copyright (C) 2003-2014 VAIS Technology Feb 12, 2014
Bluetooth Interface Adapter
for iOS, Android, and other devices
with Bluetooth Streaming capabilities.

DO NOT DISASSEMBLE OR ALTER
Doing so may result in an accident, fire or electric shock.
Do not block your view
Do not mount product or any added audio and/or video equipment where it can block your view through the windshield or
your view of dashboard indicators and displays.
Do not block the airbag
Do not mount product or any added audio and/or video equipment where it can obstruct the operation of the safety device
such as the airbag.
Distraction warning
Do not let product or any added audio and/or video equipment to distract you while you are driving.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY TERMINAL
DO NOT SPLICE INTO ELECTRICAL CABLES
Never cut away cable insulation to supply power to other equipment. Doing so will exceed the current carrying capacity of
the wire and result in fire or electric shock .
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING OBJECTS
Cables or wiring that obstruct or get caught on the places such as the steering wheel, shift lever, brake pedals, etc. can be
extremely hazardous.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST
Moisture or dust may result in product failure.
HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS
The wiring and installation of this product requires special technical skills and experience.
USE ONLY SPECIFIED ACCESSORY PARTS
Use of other than specified parts may damage product internally.
FOLLOW THE OPERATIONAL AND INSTALLATION MANUALS.
YOU SHOULD READ AND FAMILIARIZE YOURSELF THOROUGHLY WITH THE FOLLOWING INFORMATION PRIOR
TO INSTALLING AND USING THIS UNIT. IN ADDITION, YOU MUST CAREFULLY READ AND FOLLOW THE
INSTALLATION SCHEMATICS/INSTRUCTIONS FOR THE PRODUCT AND THE VEHICLE IN WHICH IT IS BEING
INSTALLED. FAILURE TO FOLLOW INSTALLATION INSTRUCTIONS MAY DAMAGE THE PRODUCT AND THE
VEHICLE, WILL VOID THE PRODUCT WARRANTY, MAY VOID THE VEHICLE WARRANTY
CHECK YOUR LOCAL LAWS
Some States/Provinces or other governmental jurisdictions (such as cities) may have laws that prohibit the operation of a
video screen within the sight of the Driver. If you have purchased such a product, you should use the product only in
locations where it is legal to do so, and if you do use the product, set up the screen so it is only visible to passengers.
TROUBLESHOOTING
Should this product fail to operate properly, please contact your Dealer or our Customer Service Department at
[email protected].
Before starting any installation work , you must wait 90 seconds after turning the ignition switch to the LOCK position and disconnecting the negative (-) terminal
from the battery. The supplemental restraint system (airbag) is equipped with a backup power source. If installation work is started less 90 seconds after
disconnection of the negative (-)battery terminal, the SRS may deploy. When the negative (-) terminal cable is disconnected from the battery the clock and audio
systems memory will be erased. Before starting installation work make a record of the clock and audio systems memory settings. When installation is complete,
reset the clock and audio systems to their previous settings . Power tilt, power telescopic steering column, front power seats, power mirrors, and power shoulder
belt anchorage are equipped with a memory function .The rear power seat is not equipped with a memory function. e and they can make a record of the memory
contents, rear power seat is not equipped with the memory function. When installation is complete, it is necessary to readjust the features to their previous settings
Never use a backup power supply (such as another battery) during installation work to avoid losing these memory settings.
WARNING
!
CAUTION
!
Before You Start 2

Before You Start 3
IMPORTANT
i
(1) After a delay of five seconds, this product will automatically bypass the automobile manufacturer's
on-screen warnings concerning use of the onboard navigation system.
These warnings are: ”Caution, Drive safely and obey traffic rules. Watching this screen while vehicle is
in motion can lead to a serious accident. Make selections only while stopped. Some map data may be
incorrect. Read safety instructions in Navigation Manual.”
(2) PLEASE PRE-NOTIFY EVERY DRIVER OF THIS VEHICLE OF THE CONTENT OF
THE AUTOMOBILE MANUFACTURER'S WARNING.
(3) IF YOU PREFER THAT THIS PRODUCT NOT ELIMINATE THE FOREGOING
WARNINGS, YOU MAY DISABLE THIS FEATURE BY FOLLOWING THE
INSTRUCTIONS IN THIS OWNER'S MANUAL, OR REFER TO INSTRUCTIONS
AVAILABLE ON THE MANUFACTURER'S WEBSITE .WWW.VAISTECH.COM
Important Please Read!
! !
!The iPod/iPhone is charging as long as it’s connected to the unit and the vehicle’s ignition is “ON” or in the “Acc”
position. The head unit does not have to be “ON”.
!The iPod/iPhone automatically turns ON when you turn the ignition key into the “ON” or “Acc” position.
!The iPod/iPhone automatically turns OFF when the vehicle’s ignition key is turned OFF. (The iPod/iPhone is paused
and goes into Sleep mode after some period of inactivity).
!iPod/iPhone interface mode is displayed in the same way as a factory CD-changer, MiniDisc-changer or CD-MP3
Changer.
!The iPod/iPhone has NOT been designed to withstand automotive temperature extremes. You may damage
your iPod/iPhone If you leave it inside the vehicle on a hot or cold day. For further information please
refer to the iPod/iPhone specifications.
!VAIS Technology accepts no responsibility for loss of data on the iPod/iPhone, even if that data is lost while
using this unit
IMPORTANT
i
!WE STRONGLY RECOMMEND THAT YOU ORGANIZE YOUR SONGS INTO PLAYLISTS FOR PROPER
OPERATION OF THIS UNIT.
To avoid improper track number/text information display (Do NOT place more then 99 songs into single
playlist for CD changer emulation and 999 songs for MD/CD-MP3 changer emulation)
IF IPOD DOES NOT HAVE PLAYLISTS/SONGS IT MAY CAUSE UNPREDICTABLE OUTCOME AND IMPROPER
OPERATION OF THE UNIT.
EMPTY PLAYLISTS WILL CAUSE UNIT TO SEARCH FOR NEXT PLAYLIST WITH SONGS IN IT.
RECOMMENDATIONS
!We recommend that you set the iPod Equalizer to be “OFF”.
!We recommend that you set “Sound Check” on the iPod to “ON” (if applicable).
About iPod Settings
i
About iPod Operation
i

SoundLinQ3
20-pin Audio Harness (36”)
Connections 4
Connecting SoundLinQ3
Mode
Programming
switch
Audio
Harness
Service
Port
SoundLinQ3
12-pin Audio Harness (36”)
SoundLinQ3
Interface Adapter
Model SL3B
USB Port
(Charging ONLY)
Bluetooth
Module

Connections 5
Head Unit (Radio Receiver)
Factory Audio
harness
Plug into
Head Unit
(connector “A”)
AA
To SoundLinQ3
Connection diagram used for all 2001-2009 Lexus vehicles
Connecting SoundLinQ3 to head unit using 20-pin Y-harness
Head Unit (Radio Receiver)
Connection diagram used for most 2004-2012 Toyota vehicles and
for most 2004-2009 Lexus vehicles (excluding Lexus SC430)
Connecting SoundLinQ3 to head unit using 12-pin Y-harness
BB
Factory Audio
harness
(if present)
Plug into
Head Unit
(connector “B”)
20-pin connector
12-pin connector
CAUTION
!
Toyota head units
20-pin connector
IS NOT COMPATIBLE
with SoundLinQ3
Audio Harness
used for Lexus vehicles
To Un-plug any connector do NOT pull it by the wires.
WARNING
!
Lexus GX 470 Radio Receiver shown as an example.
Locate connector “A” (20-pin connector) on your Radio.
Connector location on the Radio may be
different from shown above.
Lexus GX 470 Radio Receiver shown as an example.
Locate connector “B” (12-pin connector) on your Radio.
Connector location on the Radio may be
different from shown above.
SoundLinQ3
20-pin Audio Harness (36”)
To SoundLinQ3
SoundLinQ3
12-pin Audio Harness (36”)

12
ON
12
ON
12
ON
12
ON
Installation
We strongly recommend that you install the unit in easily accessible location. So you can later upgrade the
unit or re-program it in case of incorrect programming.
IMPORTANT
i
@Gain access to the back of you vehicle’s Head Unit.
@Find the same port as our Y-Harness (see “Connecting SoundLinQ3 to head unit”)
@Disconnect the existing connector and plug in our Y-Harness connector into this port, then plug female end of Audio
Harness to the plug in for your factory connector. Audio harness female connector is not used in some vehicles,
in this case isolate unused plug to prevent accidental shortage to vehicle body.
@Plug the other end of Audio Harness into designated port on SoundLinQ3.
@Connect iPod cable as shown in the”Connecting SoundLinQ3” picture.
@Setup proper Emulation Mode for this unit (see “Emulation Mode Selection”)
@Turn the car on and check SoundLinQ3 functionality and (especially Text capability) before the final assembly.
@Make sure your iPod has at least two playlists, in order for this unit to operate properly.
@Please mount this unit in easy accessible location for upgrading and re-programming purposes.
@Secure the Head Unit in its original position.
Installation
Emulation Mode Selection
MD Changer Emulation Mode programming steps:
@Properly install this unit.
@Put both programming switches in “DOWN” position.
@Put ignition switch into “ACC” position.
@Wait for long beep followed by a few short beeps. This take up to one minute.
@Return programming switches into their default position (both switches “UP”).
Wait up to 30 seconds until confirmation beep.
@Put ignition switch into the “OFF” position. Wait at least 10 seconds.
@Put ignition switch into the “ACC” or “ON” position.
@Check SoundLinQ3 for functionality, especially TEXT capabilities.
CD Changer Emulation Mode programming steps:
@Properly install this unit.
@Put “Right” programming switch in the “DOWN” position.
@Put ignition switch into the “ACC” position.
@Wait for long beep followed by a few short beeps. This may take up to one minute.
@Return programming switches into their default position (both switches “UP”).
Wait up to 30 seconds until confirmation beep.
@Put ignition switch into the“OFF” position. Wait at least 10 seconds.
@Put ignition switch into the “ACC” or “ON” position.
@Check SoundLinQ3 for functionality, especially TEXT capabilities.
!Improper Emulation Mode setting may cause this unit to be unrecognized by head unit.
!CD or MD Changer Emulation Mode Programming MUST BE DONE in order for the unit to find proper address
location in the vehicle Audio/Video network.
IMPORTANT
i
6
Both switches
“DOWN”
Ignition into
“ACC” or “ON”
position Both switches
“UP”
Ignition into
“OFF” position
up to 30 sec Confirmation beep
(Red LED blinks)
Ignition into
“ACC” or “ON”
position Both switches
“UP”
Ignition into
“OFF” position
up to 30 sec Confirmation beep
(Red LED blinks)
Right switch
“DOWN”
Confirmation beep
(Red LED blinks)
Confirmation beep
(Red LED blinks)
up to 10 sec
up to 10 sec

12
ON
12
ON
Installation 7
CD-MP3 Emulation Mode Selection (CD-MP3 emulation)
CD-MP3 Emulation Mode programming steps:
@Properly install this unit.
@Put “Left” programming switch in “DOWN” position.
@Put ignition switch into the “ACC” position.
@Wait for long beep followed by a few short beeps. This may take up to one minute.
@Return programming switches into their default position (both switches “UP”).
Wait up to 30 seconds until confirmation beep.
@Put ignition switch into the “OFF” position. Wait at least 10 seconds.
@Put ignition switch into “ACC” or “ON” position.
@Check SoundLinQ for functionality, especially TEXT capabilities.
“Hard” Velcro Fastener
Carpet or car chassis
SoundLinQ3
“Soft” Velcro Fastener
Mounting unit using Velcro fasteners
!Velcro Fasteners are not included
!VAIS Technology strongly recomand to ground unit to the car chassis for best results
NOTE
Ignition into
“ACC” or “ON”
position Both switches
“UP”
Ignition into
“OFF” position
up to 30 sec Confirmation beep
(Red LED blinks)
Left switch
“DOWN” Confirmation beep
(Red LED blinks)
up to 10 sec

8
Bluetooth Connection
Connecting Android Device to SL3B
Connecting iPod, iPhone, iPad to SL3B
Other devices may have other requirements.
Refer to the Bluetooth device's user manual for device specific requirements.
@On the Home screen, press the Menu key.
@Touch Settings
@Touch Wireless & networks
@Touch Bluetooth to turn it On
@Touch Bluetooth settings
@Touch Scan for devices (make sure your headset is in pairing mode).
@Your phone scans for available Bluetooth devices (SL3B:XX:XX)
@Touch the Bluetooth device (SL3B:XX:XX) to select it
@Touch the device name again to connect to it.
@From the home screen, tap Settings.
@Tap Bluetooth.
@Pair with Bluetooth
@Tap the Bluetooth toggle to enable the feature if it is not already active.
@The handset automatically searches for available Bluetooth devices.
@Tap the preferred Bluetooth device (SL3B:XX:XX).
@Pair with Bluetooth
@The Bluetooth device is now paired.
NOTE:
SL3B automatically connects to the last connected device. In case SL3B does not connect, you can force
connection by activating and then deactivating “SCAN” button on the factory radio.

9
Activate / Deactivate “I Agree” Automatic Bypass Function
@Put your device in Simple Mode by rapidly pressing the [SCAN] button 8 times (MUST BE DONE within 1-2 seconds).
@Push DISC REPEAT button to hear a long beep to toggle the “I Agree” Automatic Bypass Function ON and OFF.
(For vehicles not equipped with DISC REPEAT as a physical button, push and hold the REPEAT button until you hear a
long beep to toggle the “I Agree” Automatic Bypass Function ON and OFF.
IMPORTANT
i
(1) After a delay of five seconds, this product will automatically bypass the automobile
manufacturer's on-screen warnings concerning use of the onboard navigation system.
These warnings are: ”Caution, Drive safely and obey traffic rules. Watching this screen
while vehicle is in motion can lead to a serious accident. Make selections only while
stopped. Some map data may be incorrect. Read safety instructions in Navigation
Manual.”
(2) PLEASE PRE-NOTIFY EVERY DRIVER OF THIS VEHICLE OF THE
CONTENT OF THE AUTOMOBILE MANUFACTURER'S WARNING.
(3) IF YOU PREFER THAT THIS PRODUCT NOT ELIMINATE THE
FOREGOING WARNINGS, YOU MAY DISABLE THIS FEATURE BY
FOLLOWING THE INSTRUCTIONS IN THIS OWNER'S MANUAL, OR
REFER TO INSTRUCTIONS AVAILABLE ON THE MANUFACTURER'S
WEBSITE .WWW.VAISTECH.COM
Important Please Read!
! !
Special Feature

10
Head Unit Controls
Radio Integrated into Navigation System
CD-Text support
CD changer emulation
For Radio Receiver with LCD
For Radio Integrated into Navigation System
Control of connected Bluetooth Streaming Device is done through your head unit or the steering wheel controls (explained
below).
Functionality Description
Radio Integrated into Navigation System
Direct disc selection
MAY NOT be available for all vehicle model.
Applicable for iOS integration ONLY.
Song Title, Artist Name
or Album Name
(see “DISC SCAN” function)
MD-TEXT
MD changer emulation
For Radio Receiver with LCD
For Radio Integrated into Navigation System
Playlist Title
Head Unit:
To switch between the unit sources you need to use “DISC” or “CD” button on the radio
(Diagram below assumes factory CD changer is present).
Steering Wheel control:
To switch between the unit and radio you need to use the “MODE” button on the steering wheel control.
(Diagram below assumes following sources are present).
CD CD1 CD CD1
SL3B
CD MD1 CD MD1
SL3B
OR
AM FM1 FM2 TAPE CD CD1
Select desired source by pressing DISC button on the head unit or MODE on the steering wheel control.
(See diagram below)
Source Selection
SL3B SL3B
SL3B
CD/MD Changer Emulation
This unit can be programmed in CD changer emulation mode , MD changer emulation mode and CD-MP3 Emulation.
Please see attached chart to determine which emulation mode is compatible with your vehicle.

10
iOS Devices controls
TRACK+ TRACK-
and
Select the desired track
(Maximum number of tracks is 99 for CD changer Emulation mode, 999 for MD changer Emulation mode).
You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button.
The track will change after a brief pause when you stop pressing the button.
NOTE: If a playlist only contains one track, the [TRACK+] / [TRACK-] buttons will not function.
DISC+ DISC-
and
Select the desired playlist (Maximum number of playlists is 99).
You can fast switch through playlists by repeatedly pressing the [DISC+] / [DISC-] button.
The new playlist will start after a brief pause when you stop pressing the button.
NOTE: If there are no songs in a playlist the unit will jump to the next playlist.
RPT
Activates iPod “Repeat One” function
RAND
Activates iPod “Shuffle” function.
NOTE: Shuffle all songs in the active playlist. iPod starts playing songs from your entire playlist in random order,
skipping audiobooks.
DISC RPT
Activates iPod “Repeat All” function.
NOTE: Repeats all songs in active playlist.
DISC RAND
Select the desired track title display mode. You can choose between Song Title, Artist Name, or Album Name.
Note: Track Title information can ONLY be displayed on Radio LCD or Navigation screen that support CD or MD
changers with CD-Text or MD-Text.
SCROLL UP SCROLL DOWN
and
Fast Forward/Rewind the song
NOTE: For vehicle not equipped with [DISC+] and [DISC-] buttons, if “DISC SCAN”
function is active use [SCROLL UP] and [SCROLL DOWN] as [DISC+] and [DISC-]
to select the desired playlist
NOTE: if “ SCAN” function is active use [SCROLL UP] and [SCROLL DOWN]
as “TRACK +10” and “TRACK -10” to select the desired song
DISC SCAN
SCAN
NOTE: if “ SCAN” and “DISC SCAN” function are active use [SCROLL UP] and
[SCROLL DOWN] as “TRACK +50” and “TRACK -50” to select the desired song
DISC SCAN SCAN
Displayed Errors (available only as a TEXT message)
CD/MD Changer Emulation
iPod/iPhone (as a Bluetooth Device) is not connected to SL3B
Check BT Device
11
iOS Devices controls
TRACK+ TRACK-
and
Select the desired track
(Maximum number of tracks is 99 for CD changer Emulation mode, 999 for MD changer Emulation mode).
You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button.
The track will change after a brief pause when you stop pressing the button.
NOTE: If a playlist only contains one track, the [TRACK+] / [TRACK-] buttons will not function.
DISC+ DISC-
and
Select the desired playlist (Maximum number of playlists is 99).
You can fast switch through playlists by repeatedly pressing the [DISC+] / [DISC-] button.
The new playlist will start after a brief pause when you stop pressing the button.
NOTE: If there are no songs in a playlist the unit will jump to the next playlist.
RPT
Activates iPod “Repeat One” function
RAND
Activates iPod “Shuffle” function.
NOTE: Shuffle all songs in the active playlist. iPod starts playing songs from your entire playlist in random order,
skipping audiobooks.
DISC RPT
Activates iPod “Repeat All” function.
NOTE: Repeats all songs in active playlist.
DISC RAND
SCROLL UP SCROLL DOWN
and
Fast Forward/Rewind the song
NOTE: For vehicle not equipped with [DISC+] and [DISC-] buttons, if “DISC SCAN”
function is active use [SCROLL UP] and [SCROLL DOWN] as [DISC+] and [DISC-]
to select the desired playlist
NOTE: if “ SCAN” function is active use [SCROLL UP] and [SCROLL DOWN]
as “TRACK +10” and “TRACK -10” to select the desired song
DISC SCAN
SCAN
NOTE: if “ SCAN” and “DISC SCAN” function are active use [SCROLL UP] and
[SCROLL DOWN] as “TRACK +50” and “TRACK -50” to select the desired song
DISC SCAN SCAN
Displayed Errors (available only as a TEXT message)
CD/MD Changer Emulation
iPod/iPhone (as a Bluetooth Device) is not connected to SL3B.
Check BT Device
NOTE: Folder/Disc Title information may not display properly if song selected directly from the iOS device.
Some applications may not refresh Folder/Disc Title when the song changes.
NOTE:
SL3B automatically connects to the last connected device. In case SL3B does not connect, you can force
connection by activating and then deactivating “SCAN” button on the factory radio.

12
Android Devices controls
TRACK+ TRACK-
and
Select the desired track
(Maximum number of tracks is 99 for CD changer Emulation mode, 999 for MD changer Emulation mode).
You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button.
The track will change after a brief pause when you stop pressing the button.
NOTE: Some devices/applications may not display track information correctly.
RPT
Activates “Repeat One” function
RAND
Activates “Shuffle” function.
NOTE: Shuffle all songs in the current category selection.
DISC RPT
Activates “Repeat All” function.
NOTE: Repeats all songs in current category selection.
DISC RAND
Select the desired track title display mode. You can choose between Song Title, Artist Name, or Album Name.
Note: Track Title information can ONLY be displayed on Radio LCD or Navigation screen that support CD or MD
changers with CD-Text or MD-Text.
Displayed Errors (available only as a TEXT message)
CD/MD Changer Emulation
Android (as a Bluetooth Device) is not connected to SL3B.
Check BT Device
NOTE: This functionality must be supported by selected application.
NOTE: This functionality must be supported by selected application.
NOTE: This functionality must be supported by selected application.
NOTE: Functionality such as track information display and controls must be supported by connected device and
selected application.
NOTE:
SL3B automatically connects to the last connected device. In case SL3B does not connect, you can force
connection by activating and then deactivating “SCAN” button on the factory radio.

CD-MP3 changer emulation
For Radio Integrated into Navigation System
(5th Generation Navigation System)
Control of connected Bluetooth Streaming Device is done through your head unit or the steering wheel controls (explained
below).
Functionality Description
Head Unit:
To switch between the unit sources you need to use “DISC” or “CD” button on the radio
(Diagram below assumes factory CD changer is present).
Steering Wheel control:
To switch between the unit and radio you need to use the “MODE” button on the steering wheel control.
(Diagram below assumes following sources are present).
CD CDC1 CD CDC1 CDC1 CDC2 CDC1 CDC2
OR
AM FM1 FM2 TAPE CD CD1
Select desired source by pressing DISC button on the head unit or MODE on the steering wheel control.
(See diagram below)
Source Selection
13
Head Unit Controls
CD-MP3 Changer Emulation
6 disc CD-changer
Disc 1 - Playlist
Disc 2 - Artist
Disc 3 - Album
Disc 4 - Genre
Disc 5 - Audiobook
Disc 6 - Podcast
This unit can be programmed in CD changer emulation mode , MD changer emulation mode and CD-MP3 Emulation.
Please see attached chart to determine which emulation mode is compatible with your vehicle.
List Of Folders (List of Albums) List Of Files (List of songs in selected Album)
List of folders represent either list of Playlists, Artists, Albums, Genres, Audiobooks, or Podcasts, depending on your “Browsing mode”
selection.
“Browsing mode” selection:
Disc 1 - Playlists, Disc 2 - Artists, Disc 3 - Albums, Disc 4 - Genres, Disc 5 - Audiobooks, Disc 6 - Podcasts.
List of files represent list of songs in each of the folder category.
This functionality is available for all 5th Gen Navigation system.
Please note all Toyota vehicles except for Prius, do not have a list of files and folders display available on the screen due to Radio limitation.
Please also see “Activate / Deactivate ‘Disc Switching Fix’ Function”
!
SL3B
SL3B
SL3B
SL3B SL3B
This functionality applicable for iOS integration ONLY.

14
TRACK+ TRACK-
and
Select the desired track
(Maximum number of tracks is 999 for CD-MP3 changer Emulation mode).
You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button.
The track will change after a brief pause when you stop pressing the button.
NOTE: If a playlist only contains one track, the [TRACK+] / [TRACK-] buttons will not function.
FOLDER+ FOLDER-
and
Select the desired playlist (Maximum number of playlists is 999).
You can fast switch through playlists by repeatedly pressing the [FOLDER+] / [FOLDER-] button.
The new playlist will start after a brief pause when you stop pressing the button.
NOTE: If there are no songs in a playlist the unit will jump to the next playlist.
RPT
Activates iPod “Repeat One” function
RAND
The RAND button activates the playlist randomizer function. All tracks in the current playlist will be placed into a new,
random order. The currently selected track will be renumbered to Track 1, and all subsequent tracks will be random
selections from the playlist. After activating the playlist randomizer, the displayed track number does not map to the
physical track number in the playlist, but rather to the new, randomized order.
NOTE: Shuffle all songs in the active playlist. iPod starts playing songs from your entire playlist in random order,
skipping audiobooks.
FOLDER RPT
Press and hold the RPT button to activate playlist repeat. This mode will cause the current playlist to start over with
the first track after the last track has been played, instead of moving on to the next playlist.
NOTE: Repeats all songs in active playlist.
Displayed Errors (available only as a TEXT message)
SCROLL UP SCROLL DOWN
and
Fast Forward/Rewind the song
NOTE: For vehicle not equipped with [DISC+] and [DISC-] buttons, if “SCAN” function is active use
[SCROLL UP] and [SCROLL DOWN] as [DISC+] and [DISC-] to select the desired playlist (in this case [DISC+] and
[DISC-] will work as a [FOLDER+] and [FOLDER-])
DETAIL
Pressing the DETAIL button will bring up details on the current track. It will display Album Title, Track Title, and Artist.
Genre is not supported and will always be blank.
NOTE: You can switch tracks while in DETAIL view, but it will not display the current track number.
FOLDER LIST
The FOLDER button will bring up a new display that allows you to scroll through the playlists and tracks on your iPod
device. [Folder Up] or [Folder Down] will scroll through playlists, wile [File Up] or [File Down] will scroll through tracks.
If a playlist contains a large number of songs, it may take some time for the data to be transferred to the head unit.
This can cause the scroll buttons to become unresponsive during rapid scrolling, until data has been loaded from the iPod.
NOTE: Some vehicles' head units do not support the Folder/File display function. In this case when you press FOLDER
you will see a blank display in the Folder and File lists.
iOS Device controls
CD-MP3 Changer Emulation
iPod/iPhone (as a Bluetooth Device) is not connected to SL3B
Check BT Device iPod/iPhone (as a Bluetooth Device) is not connected to SL3B. Check BT Device
NOTE: Folder/Disc Title information may not display properly if song selected directly from the iOS device.
Some applications may not refresh Folder/Disc Title when the song changes.
NOTE:
SL3B automatically connects to the last connected device. In case SL3B does not connect, you can force
connection by activating and then deactivating “SCAN” button on the factory radio.

15
DETAIL
Pressing the DETAIL button will bring up details on the current track. It will display Album Title, Track Title, and Artist.
Genre is not supported and will always be blank.
NOTE: You can switch tracks while in DETAIL view, but it will not display the current track number.
FOLDER LIST
Information displayed in Folders/Files list does not correspond to current selection.
NOTE: Some vehicles' head units do not support the Folder/File display function. In this case when you press FOLDER
you will see a blank display in the Folder and File lists.
Android Device controls
CD-MP3 Changer Emulation
NOTE: Functionality such as track information display and controls must be supported by connected device and
selected application.
TRACK+ TRACK-
and
Select the desired track
(Maximum number of tracks is 99 for CD changer Emulation mode, 999 for MD changer Emulation mode).
You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button.
The track will change after a brief pause when you stop pressing the button.
NOTE: Some devices/applications may not display track information correctly.
RPT
Activates “Repeat One” function
RAND
Activates “Shuffle” function.
NOTE: Shuffle all songs in the current category selection.
DISC RPT
Activates “Repeat All” function.
NOTE: Repeats all songs in current category selection.
Displayed Errors (available only as a TEXT message)
Android (as a Bluetooth Device) is not connected to SL3B.
Check BT Device
NOTE: This functionality must be supported by selected application.
NOTE: This functionality must be supported by selected application.
NOTE: This functionality must be supported by selected application.
NOTE:
SL3B automatically connects to the last connected device. In case SL3B does not connect, you can force
connection by activating and then deactivating “SCAN” button on the factory radio.

16
Additional iOS Features
Internet Radio / Third party Music Players
Support for iOS 5.1+ devices
TRACK+ TRACK-
and
Select the desired track
NOTE: Functionality of [TRACK+] / [TRACK-] buttons are available only if iOS application supports it.
FOLDER+ FOLDER-
and
Will exit currently played Application and return to “built-in” iPod Player.
DISC+ DISC-
and
CD/MD Changer Emulation
CD-MP3 Changer Emulation
IMPORTANT
i
To play Internet Radio or Third party Music Player applications (iOS 5.1+ device required):
1. Connect iPod/iPhone.
2. Let the iPod/iPhone “built-in” player to start playing.
3. Start Internet Radio/Third party Music Player application
4. Text information (Artist Name and Song Title) will appear on the nav display/radio LCD.
List of files” and “List of folders” will not display correct information.
NOTE: Some applications require manually select “Play”.
For CD-MP3 Emulation “
Will exit currently played Application and return to “built-in” iPod Player.

17
Enable/Disable “Settings mode”- press the [SCAN] button 8 times (MUST BE DONE within 1-2 seconds).
You will hear a long beep.
Sound Level Adjustment
NOTE: Remember, a high sound level may result in noticeable sound distortion.
@Enable “Settings mode”
@Start playing desired song by pressing the [Play/Pause] button on the connected BT Audio Device
@Activate “SCAN” function on the head unit
@Set the desired volume on the head unit
@While “SCAN” is active use [SCROLL UP] to increase volume and [SCROLL DOWN] to decrease volume.
@Sound level [01..10] will be displayed as Seconds on the head unit.
@Deactivate “SCAN” function
@Disable “Settings mode”
Settings Mode
Additional controls
Activate / Deactivate “Disc Switching Fix” Function
@Put your device in Settings Mode by rapidly pressing the [SCAN] button 8 times (MUST BE DONE within 1-2
seconds).
@Push DISC RANDOM button to hear a long beep to toggle the “Disc Switching Fix” Function ON and OFF. (For
vehicles not equipped with DISC RANDOM as a physical button, push and hold the REPEAT button until you hear a
long beep to toggle the “Disc Switching Fix” Function ON and OFF.
@Disable “Settings mode”
Activate / Deactivate “I Agree” Automatic Bypass Function
@Put your device in Settings Mode by rapidly pressing the [SCAN] button 8 times (MUST BE DONE within 1-2
seconds).
@Push DISC REPEAT button to hear a long beep to toggle the “I Agree” Automatic Bypass Function ON and OFF.
(For vehicles not equipped with DISC REPEAT as a physical button, push and hold the REPEAT button until you hear
a long beep to toggle the “I Agree” Automatic Bypass Function ON and OFF.
IMPORTANT
i
(1) After a delay of five seconds, this product will automatically bypass the automobile
manufacturer's on-screen warnings concerning use of the onboard navigation system.
These warnings are: ”Caution, Drive safely and obey traffic rules. Watching this screen while
vehicle is in motion can lead to a serious accident. Make selections only while stopped. Some
map data may be incorrect. Read safety instructions in Navigation Manual.”
(2) PLEASE PRE-NOTIFY EVERY DRIVER OF THIS VEHICLE OF THE
CONTENT OF THE AUTOMOBILE MANUFACTURER'S WARNING.
(3) IF YOU PREFER THAT THIS PRODUCT NOT ELIMINATE THE FOREGOING
WARNINGS, YOU MAY DISABLE THIS FEATURE BY FOLLOWING THE
INSTRUCTIONS IN THIS OWNER'S MANUAL, OR REFER TO INSTRUCTIONS
AVAILABLE ON THE MANUFACTURER'S WEBSITE .WWW.VAISTECH.COM
Important Please Read!
! !
“Disc switching Fix” has been designed to avoid a Radio malfunctioning in some vehicles while navigating through disc
selection. SL3B comes with this feature activated by default, and it can causes screen to go black for 0.5 sec -1.5 sec in
between disc selection. It doesn't have to be ON for all vehicles. Users are welcome to turn this feature OFF to determine
wether or not it actually needs to be ON or OFF for their vehicles.

LICENSING AGREEMENT, DISCLAIMERS AND LIMITED
WARRANTY
VAIS TECHNOLOGY, LLC
18
LICENSE AGREEMENT
for U.S.A. (hereinafter referred to as ‘PRODUCT’) and its related software
For Most Toyota/Lexus Vehicles 2001-2009; (hereinafter collectiv ely referred to as ‘PRODUCTS’). THIS IS A LEGAL AGREEMENT
BETWEEN YOU, AS THE END USER, AND VAIS TECHNOLOGY, LLC (“VAIS”). PLEASE CAREFULLY READ THE TERMS AND
CONDITIONS OF THIS AGREEMENT BEFORE USING THE VAIS PRODUCTS. BY USING THE VAIS PRODUCTS AND SOFTWARE
INSTALLED ON THE VAIS PRODUCTS, YOU ARE AGREEING TO BE BOUND BY THE TERMS OF THIS AGREEMENT. THE AUDIO
INTERFACE CONTROLLER AND THE AUDIO VIDEO INTERFACE CONTROLLER ARE ESSENTIALLY THE BRIDGE BETWEEN A
VEHICLE, ITS EQUIPMENT, AND ANY ‘AFTER-MARKET’ EQUI PMENT SUBSEQUENTLY ADDED TO THE VEHICLE BY THE END-
USER. THE EQUIPMENT SOLD TO YOU, THE END USER, IF PROPERLY INSTALLE D. IS A RESETTABLE TECHNOLOGY, WHICH
WILL, UNDER NORMAL CIRCUMSTANCES, AUTOMATICALLY DISCONNECT IN THE EVENT OF ANY MALFUNCTION. SINCE VAIS
DOES NOT INSTALL THIS EQUIPMENT, VAIS DISCLAIMS AN Y LIABILITY FOR IMPROPER INSTALLATION OF THE VAIS
TECHNOLOGY OR THE ‘AFTER-MARKET’ EQUIPMENT (INPUTS). FURTHER, THE ‘END USER’ ACKNOWLEDGES THAT THE
PRODUCT AND ITS SOFTWARE ARE NOT INHERENTLY DANGEROUS AND DO NO T PROVIDE ANY INHERENT RISKS AND
THEREFORE POTENTIAL DAMAGES TO THE END-USER, OTHER THAN ‘Fitness for its Purpose’. Some radio receiver models may
cause you to experience some technical difficulties, if the product does not operate properly please contact technical department promptly at
[email protected].
1. GRANT OF LICENSE
VAIS grants to you a non-transferable, non-exclusive license to use the PRODUCT and its software installed on the VAIS product (the
“PRODUCTS”) and the related documentation solely for your own personal use or for internal use by your business, only on such VAIS
PRODUCTS. You shall not copy, reverse engineer, translate, port, modify or make derivative works of the Software contained in t he
PRODUCT. You shall not loan, rent , disclose, publish, sell, assign, lease, sublicense, market or otherwise transfer the Software in the
PRODUCT or use it in any manner not expressly authorized by this agreement. You shall not derive or attempt to derive the source code or
structure of all or any portion of the Software in the PRODUCT by reverse engineering, disassembly, recompilation, or any other means. You
shall not use the Software in the PRODUCT to operate a service bureau or for any other use involving the processing of data for other
persons or entities. VAIS and its licensor(s) shall retain all copyright, trade secret, patent and other proprietary ownership rights to the
Software in the PRODUCT. The PRODUCTS are Copyrighted/ Patented and/or at various stages of Pending and may not be copied, even
if modified or merged with other products. You shall not alter or remove any copyright notice or proprietary legend contained in or on the
PRODUCTS. You may transfer all of your license rights in the Software or the PRODUCT, the related documentation and a copy of this
License Agreement And Warranty to another party, provided that the party reads and agrees to accept the terms and conditions of this
License Agreement And Warranty.
2. OPERATIONAL WARNING AND SAFETY INSTRUCTIONS.
IMPORTANT NOTICE: YOU SHOULD READ AND FAMI LIARIZE YOURSELF THOROUGHLY
WITH THE FOLLOWING INFORMATION PRIOR TO INSTALLING AND USING THE –
SoundLinQ3 (SL3i), (SL3x), (Sl3s), (SL3B) and its related software (THE “PRODUCTS”).
IN ADDITION, YOU MUST CAREFULLY READ AND FOLLOW THE INSTALLATION
SCHEMATICS/INSTRUCTIONS FOR THE PRODUCT AND THE VEHICLE IN WHICH IT IS
BEING INSTALLED. FAILURE TO FOLLOW INSTALLATION INSTRUCTIONS MAY DAMAGE
THE PRODUCT AND THE VEHICLE AND WILL VOID THE PRODUCT WARRANTY AND MAY
VOID THE VEHICLE WARRANTY. (A copy of the installation schematics is included with
the Product and can also be found on the VAIS TECHNOLOGY website at
www.vaistech.com.)
FAILURE TO ABIDE BY THESE OPERATIONAL WARNINGS AND SAFETY INSTRUCTIONS
COULD RESULT IN SERIOUS BODILY INJURY OR DEATH. IN ADDITION, FAILURE TO
FOLLOW THESE INSTRUCTIONS MAY VOID THE PRODUCT WARRANTY AND COULD
BECOME A BASIS FOR LIABILITY ON THE PA RT OF THE VEHICLE OPERATOR IN THE
EVENT OF AN ACCIDENT WHICH RESULTS IN INJURY TO PERSONS OR PROPERTY.
UNDER NO CIRCUMSTANCES WILL VAIS OR ITS IMMEDIATE AGENTS OR PRINCIPALS,
BE LIABLE, FOR DAMAGES INCURRED TO THE PRODUCTS, THE VEHICLE OR ITS
PASSENGERS, OR OTHER THIRD-PARTIES AS A RESULT OF FAILURE TO FOLLOW
VAIS’S INSTALLATION INSTRUCTIONS.
VAIS TECHNOLOGY- SoundLinQ3 (SL3i),(SL3x),(SL3s),(SL3B)

A COPY OF THE ‘OPERATIONAL WARNINGS AND SAFETY INSTRUCTIONS’ IS TO BE KEPT
WITH THE VEHICLE AT ALL TIMES.
3.DISCLAIMER AND LIMITATION OF WARRANTIES .
(A) EXCEPT AS OTHERWISE CONTAINED HEREIN , the PRODUCTS and related documentation are provided to you, “AS IS”. IN NO
EVENT SHALL VAIS BE LIABLE FOR ANY DAMAGES, CLAIM OR LOSS INCURRED BY YOU (INCLUDING WITHOUT LIMITATION,
COMPENSATORY, INCIDENTAL, INDIRECT , SPECIAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES, LOST PROFITS, LOST
SALES OR BUSINESS, EXPENDITURES, INVESTMENTS, OR COMMITMENTS IN CONNECTION WITH ANY BUSINESS, LOSS OF
ANY GOODWILL, OR DAMAGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE
PRODUCTS TO THE VAIS SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE OF
THE PRODUCT, BUS FARES, CAR RENTALS OR OTHER COSTS RELATED TO THE CARE AND CUSTODY OF THE PRODUCT. THE
TERM ‘CONSEQUENTIAL DAMAGES’ REFERS TO THE COST OF REPAIRING OR REPLACING OTHER PROPERTY, WHICH IS
DAMAGED WHEN THIS PRODUCT DOES NOT WORK PROPERLY.) RESULTING FROM THE USE OR INABILITY TO USE THE
PRODUCTS, INCLUDING ANY DAMAGES INCURRED DUE TO THE NEGLIGENT OPERATION OF A MOTOR VEHICLE, IN
CONJUNCTION WITH THE USE OF SAID PRODUCTS. THE END-USER ACKNOWLEDGES ITS RESPONSIBILITY FOR THE USE OF
THE PRODUCT. THE ADDITION OF VAIS PRODUCTS AND ANY AFTER-MARKET EQUIPMENT MAY ENHANCE THE VALUE OF A
VEHICLE OR CAUSE A THIRD-PARTY TO ILLEGALLY ATTEMPT TO REMOVE THE PRODUCTS AND AFTER-MARKET EQUIPMENT.
VAIS DISCLAIMS ANY LIABILITY RELATE D TO SUCH THEFT AND POTENTIAL DAMAGE TO PROPERTY.IT IS THE END-USERS
RESPONSIBILITY TO PROTECT ITS OWN PROPERTY.
THE END-USER FURTHER ACKNOWLEDGES THAT THE OPERATIO N OF A MOTOR VEHICLE IS AN INHERENTLY DANGEROUS
ACTIVITY, AND BY ITS USE OF VAIS’S PRODUCTS, ACKNOWLEDG ES THAT THE PRODUCTS ARE REMOTELY RELATED TO SAID
MOTOR VEHICLE OPERATION, AND THUS ANY DAMAGES CAUSED TO THE DRIVER OF THE VEHICLE, THE VEHICLE ITSELF OR
ANY THIRD-PARTY AND ITS PROPERTY IS NO T THE RESPONSIBILITY OF VAIS, ITS AGENTS OR ITS PRINCIPALS AND IS THE
SOLE RESPONSIBILITY OF THE DRIVER OF SAID VEHICLE.
YOU, THE END-USER, OR ANY OTHER DRIVER OF THE VEHICLE, IS SOLELY RESPONS IBLE FOR THE SAFE OPERATION OF THE
VEHICLE AND THE SAFETY OF BOTH YOU AND THE PASSENGERS . FOR SAFETY PURPOSES, THE PRODUCT SHOULD NOT BE
USED FOR THE DRIVER’S ENTERTAINMENT, WHILE THE VEHICLE IS BEING DRIVEN. SUCH USE COULD BE A DISTRACTION TO
THE DRIVER, WHICH COULD CAUSE AN ACCIDENT LEADING TO SER IOUS INJURY OR DEATH. IF YOU, THE END-USER ALLOW
ANOTHER PERSON TO USE THE VEHICLE, IT IS YOUR RESPONSIBILITY TO THOROUGHLY BRIEF THAT OTHER USER, ON THE
SAFETY REQUIREMENTS FOR OPERATING THE VEHICLE AND THE PR ODUCTS INSTALLED THEREIN.
(B) SAID DISCLAIMERS SHALL APPLY TO THE USE OF SAID PR ODUCTS, EVEN IF VAIS HAS BEEN INFORMED OF, KNEW OF, OR
SHOULD HAVE KNOWN OF THE LIKELIHOOD OF SUCH DAMAGES. THIS LIMITATION APPLIES TO ALL CAUSES OF ACTION IN THE
AGGREGATE, INCLUDING WITHOUT LIMITATION: BREACH OF CONTRACT, BREACH OF WARRANTY, NEGLIGENCE, STRICT
LIABILITY, MISREPRESENTATION AND OTHER TORTS. IF VAIS’S WARRANTY DISCLAIMER OR LIMITATION OF LIABILITY SET
FORTH IN THIS AGREEMENT SHALL, OR FOR ANY REASON WHATSOEVER, BE HELD UNENFORCEABLE OR INAPPLICABLE, YOU
AND ANY OTHER END USER AGREE THAT VAI S’S LIABILITY SHALL NOT EXCEED (50%) OF THE PRICE PAID FOR THE ENCLOSED
VAIS PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not
apply to you. This Warranty Disclaimer and Limitation of Liability shall not be applicable to the extent that any federal, state or local law,
which cannot be preempted, prohibits any provision of this Warranty.
(C) Some States/Provinces or other governmental jurisdictions (such as cities) may have laws that prohibit the operation of a video screen
within the sight of the Driver. If you have purchased such a product, you should use the product only in locations where it is legal to do so,
and if you do use the product, set up the screen only where it may be visible to passengers only. Although VAIS strongly recomm ends that
Products not be used while the vehicle is in motion, it is your responsibility to determine whether the product can be used in any given
location. Any use of the PRODUCTS where it is illegal to do so, may be used against you as evidence of negligence in the event of an auto
accident or other traffic infraction.
4. THIRTY (30)- DAY MONEY BACK WARRANTY ONLY IF PURCHASED DIRECT FROM
VAIS.
Any Product purchased directly from VAIS, referencing a Return Authorization Number (RAN) during the Thirty-(30) day period following
shipment by VAIS, may be returned for a full refund of the purchase price actually paid, only if you have received damaged, def ective or
incorrectly shipped merchandise. The RAN number may be obtained from VAIS’s Customer Suppor t at [phone], and is valid for
only thirty- (30) days from its issuance. Said RAN must be noted on the outside of the returned PRODUCTS’ packaging. The PRODUCTS
must be returned in its original packaging, intact, without any evidence of tampering with the PRODUCTS or physical damage caused by the
Customer (End-User).
WE WOULD STRONGLY RECOMMEND THAT THE ITEM BE SHIPPED INSURED, SINCE THE RISK OF LOSS DURING SHIPPING IS
WITH THE END-USER. Re-stocking Fees may apply. Damage Fees if deemed caused by the End-User may apply. SHIPPING AND
HANDLING OF THE END-USER IS NOT REFUNDABLE AND MUST BE PREPAID, FOR THIS WARRANTY TO BE APPLICABLE. END-
USER SHALL ASSUME ALL RISK OF LOSS FOR THE SHIPPING OF THE PRODUCTS TO VAIS. PLEASE ALLOW UP TO EIGHT (8)
WEEKS FOR VAIS TO CREDIT YOUR ACCOUNT .
19

5. LIMITED WARRANTY.
VAIS warrants that the PRODUCTS will be free from defects in materials and workmanship for a period of ONE (1) YEAR from the
date of purchase. VAIS’S sole obligation under this warranty is to repair or replace at VAIS'S option, any PRODUCTS that VAIS
shall have determined to be defective. Any replacement of parts, shall at the option of VAIS
and at no additional charge to the end-
user, be new or rebuilt/re-engineered replacement parts. Any replacement of PRODUCTS shall be with new or remanufactured
equivalent PRODUCTS. The End-User is responsible for all shipping costs to VAIS, in connection with warranty service. VAIS will
not be liable for any defects arising out of any modification of the PRODUCTS, or misuse, neglect, improper installation not in
accordance with the specifications provided byVAIS, or if the product is used in violation of any applicable local, state or federal laws. It is
the End Users responsibility to ascertain the existence and applicability of any local laws to the operation of the PRODUCTS, in any location
where the PRODUCTS are being used. other causes beyond Seller's reasonable control.
A. WHO PERFORMS VAIS TECHNOLOGY'S WARRANTY COMPLIANCE.
VAIS Technology’s professional technical depar tment will perform VAIS warranty obligations.
B. WHAT YOU MUST DO.
To obtain warranty performance, you must take the PRODUCTS, or deliver the PRODUCTS freight prepaid, to a VAIS Technology
Authorized Service Center. If shipped, the PRODUCTS must be packaged so that it is protected from possible shipping damage. VAIS
Technology will ship the PRODUCTS to you when warranty performance is completed. VAIS Technology will pay for shipping the
PRODUCTS to you, if the product was repaired under the warranty and the Product was received by the Service Center during the warranty
period, in which case the Product will be returned to you freight prepaid by VAIS. You must present to the Service Center, or include with
your shipment, a dealer's bill of sale, or other original evidence, showing the date and place of purchase and describing the Product
purchased to establish warranty eligibility. Be sure to include your return address and a written description of the problem and a daytime
telephone number where you can be reached should the need arise.
SHIP TO: VAIS Technology
13792 Compark Blvd., Unit #125
Englewood, CO
80112
ATTENTION: SERVICE DEPARTMENT
For your own protection, you should obtain a proof of delivery receipt. Return shipping (that is, shipping back to the customer following repair
or replacement), will be paid by the Seller unless repair or replacement is determined not to be covered by the warranty.
C. WHAT THE WARRANTY DOES NOT COVER . VAIS shall have no liability or obligation to Purchaser with respect to any
PRODUCTS requiring service during the warranty period which is subjected to any of the following: abuse, improper operation, negligence,
accident, modification, improper connections, failure of the end-user to follow the operating procedures outlined both herein, and in any
user's manual, attempted repair by non-qualified personnel, Company or Association; operation of the Product outside of the pub lished
environmental and electrical parameters, or if such Product's original identification (trademark, serial number) markings have been defaced,
altered, or removed. VAIS excludes from warranty coverage Products which have not been sold by VAIS or an Authorized VAIS Deale r to
the Purchaser. VAIS also excludes from warranty coverage Products sold outside of the United States. All wires and connectors
furnished with, or as part of the PRODUCTS is furnished “AS IS” (i.e., without any warranty of any kind), except where expressly
provided otherwise in any documentation or license agreement furnished with the PRODUCTS.
Other Items Not covered Pursuant to this Warranty:
1. Damage occurring during shipment of the product to VAIS for repair (claims must be presented to the carrier);
2. Any cost or expense related to the removal or reinstallation of the product;
3. Any Products which have been adjusted, altered or modified without VAIS’s consent;
4. Any Products that has been determined to contain an excessive amount of dust or dirt and any product that contains any
other contaminants including liquid or foreign objects.
REPAIR OR REPLACEMENT AS PROV IDED IN THIS WARRANTY IS THE PURCHASER'S EXCLUSIVE WARRANTY REMEDY.
IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR
PURPOSE, SHALL NOT EXTEND BEYOND THE DURATION OF THE APPLICABLE PARTS WARRANTY PERIOD AND NO PERSON,
COMPANY OR ASSOCIATION (INCLUDING AUTHORI ZED DEALERS) IS AUTHORIZED TO ASSUME FOR VAIS ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE OF THE PRODUCT.
D. ALL WARRANTIES EXPRESS OR IMPLIED, ARE HEREBY DISCLAIMED BY VAIS, AND ANY SUCH WARRANTY IS DEEMED
VOID, IN THE EVENT THE END-USER ATTEMPTS TO MODIFY THE PRODUCT OR PRODUCTS IN ANY WAY.
In addition, some states, do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusion may not apply to you. This warranty gives you specific legal rights and you
may have other rights, which may vary, from state to state. THE ABOVE WARRANTY TERMS AND CONDITIONS ARE VALID ONLY IN
THE U.S.A.
IMPORTANT STEPS TO SAFEGUARD YOUR DATA AND PROPERTY :
Be sure to remove all third-party after market equipment, options, alterations, and attachments not warranted by VAIS Technolog y before
sending the Product to VAIS for warranty service. VAIS IS NOT LIABLE FOR ANY LOSS OR DAMAGE TO THESE ITEMS.
20
