Vaisala TacMet MAWS201M Guide

M212018EN-B
Spare Part Guide
Vaisala TacMetâTactical Meteorological
Observation System
MAWS201M

PUBLISHED BY
Vaisala Oyj
Vanha Nurmijärventie 21, FI-01670 Vantaa, Finland
P.O. Box 26, FI-00421 Helsinki, Finland
[phone]
Visit our Internet pages at www.vaisala.com.
© Vaisala 2020
No part of this document may be reproduced,
published or publicly displayed in any form or by
any means, electronic or mechanical (including
photocopying), nor may its contents be modified,
translated, adapted, sold or disclosed to a third
party without prior written permission of the
copyright holder. Translated documents and
translated portions of multilingual documents are
based on the original English versions. In
ambiguous cases, the English versions are
applicable, not the translations.
The contents of this document are subject to
change without prior notice.
Local rules and regulations may vary and they
shall take precedence over the information
contained in this document. Vaisala makes no
representations on this document’s compliance
with the local rules and regulations applicable at
any given time, and hereby disclaims any and all
responsibilities related thereto.
This document does not create any legally
binding obligations for Vaisala towards customers
or end users. All legally binding obligations and
agreements are included exclusively in the
applicable supply contract or the General
Conditions of Sale and General Conditions of
Service of Vaisala.
This product contains software developed by
Vaisala or third parties. Use of the software is
governed by license terms and conditions
included in the applicable supply contract or, in
the absence of separate license terms and
conditions, by the General License Conditions of
Vaisala Group.
This product may contain open source software
(OSS) components. In the event this product
contains OSS components, then such OSS is
governed by the terms and conditions of the
applicable OSS licenses, and you are bound by the
terms and conditions of such licenses in
connection with your use and distribution of the
OSS in this product. Applicable OSS licenses are
included in the product itself or provided to you
on any other applicable media, depending on
each individual product and the product items
delivered to you.

Table of contents
1. About this document.......................................................................................5
1.1 Version information.............................................................................................5
1.2 Related manuals.................................................................................................. 5
1.3 Documentation conventions..............................................................................6
1.4 Trademarks...........................................................................................................6
2. Overview............................................................................................................... 7
2.1 Scope.....................................................................................................................7
2.2 MAWS201M layout and cable codes..................................................................8
2.3 MAWS201M Basic System...................................................................................9
2.4 MAWS201M Enhancement 2.............................................................................. 11
2.5 MAWS201M radio modem options...................................................................13
3. Combined Wind Sensor WMS302M.........................................................15
3.1 WMS302M spare parts...................................................................................... 15
4. Telescopic mast assembly QM30154-MEKASP....................................17
4.1 QM30154-MEKASP spare parts........................................................................ 17
5. Sensor arm assembly QMA102M and HUMICAP
Humidity and Temperature Probe HMP155........................................... 19
5.1 QMA102M spare parts....................................................................................... 19
5.2 HMP155 spare parts............................................................................................21
6. Power Distribution Unit QPD101............................................................... 22
6.1 QPD101 spare parts........................................................................................... 22
7. Tripod assembly QMASSY201M................................................................ 24
7.1 QMASSY201M spare parts................................................................................24
7.2 QMASSY201M fasteners................................................................................... 26
8. Handheld Terminal QMD102M................................................................... 29
8.1 QMD102M spare parts...................................................................................... 29
9. TacMet laptop TACLAP-PCR......................................................................30
9.1 TACLAP‑PCR spare parts.................................................................................30
10. Suunto Global Compass MC-2/360G...................................................... 31
10.1 MC‑2/360G spare parts.....................................................................................31
11. Ground and foot peg set QMY103MSP.................................................. 32
11.1 QMY103MSP spare parts.................................................................................. 32
12. Present Weather Detector PWD22M...................................................... 33
12.1 PWD22M spare parts........................................................................................33
13. Lightning Detector SA20M‑MT................................................................. 34
13.1 SA20M-MT spare parts.....................................................................................34
14. Power Supply Module QMP202SP...........................................................36
14.1 QMP202SP spare parts.................................................................................... 36
15. Ceilometer CL31M........................................................................................... 37
15.1 CL31M spare parts............................................................................................. 37
16. Radio modem set SAT400AWS............................................................... 40
16.1 SAT400AWS spare parts.................................................................................40
Table of contents
1

17. Radio modem set SAT400PC....................................................................42
17.1 SAT400PC spare parts.....................................................................................42
18. Spare part sets................................................................................................ 44
18.1 Spare part set 260073 for transit cases.........................................................44
18.2 Spare part set 260075 for transit cases.........................................................45
18.3 Spare part set 260076 for transit cases.........................................................46
18.4 Spare part set ASM212813 for tripod leg hinge............................................. 47
18.5 Spare part set 238485SP for tripod................................................................47
18.6 O‑ring set 240575SP for Alden cable connectors........................................ 49
18.7 Spare part set QMY105M................................................................................. 49
19. Maintenance parts list.................................................................................... 51
Warranty.............................................................................................................53
Technical support.............................................................................................53
Recycling............................................................................................................53
MAWS201M Spare Part Guide M212018EN-B
2

List of figures
Figure 1 MAWS201M layout and cable codes.............................................................. 8
Figure 2 MAWS201M with Basic System equipment, main components............. 9
Figure 3 MAWS201M with Enhancement 2, main components.............................. 11
Figure 4 MAWS201M radio modem options................................................................13
Figure 5 WMS302M main parts...................................................................................... 15
Figure 6 QM30154-MEKASP main parts.......................................................................17
Figure 7 QMA102M sensor arm assembly....................................................................19
Figure 8 HMP155 probe with DTR502........................................................................... 21
Figure 9 QPD101 main parts and cable options.........................................................22
Figure 10 QMASSY201M main parts............................................................................... 24
Figure 11 Fasteners used in attaching tripod leg to logger enclosure.................26
Figure 12 Fasteners used in attaching tripod leg to tripod foot.............................27
Figure 13 Fasteners used in attaching tripod center to leg.....................................28
Figure 14 Handheld Terminal QMD102M.......................................................................29
Figure 15 TacMet laptop TACLAP-PCR..........................................................................30
Figure 16 Global Compass MC‑2/360G..........................................................................31
Figure 17 QMY103MSP main parts..................................................................................32
Figure 18 PWD22M main parts........................................................................................ 33
Figure 19 Lightning Detector SA20M‑MT.....................................................................34
Figure 20 QMP202SP main parts.................................................................................... 36
Figure 21 CL31M main parts..............................................................................................37
Figure 22 CL31M replaceable parts inside the enclosure..........................................38
Figure 23 SAT400AWS main parts.................................................................................40
Figure 24 SAT400PC main parts.....................................................................................42
Figure 25 260073 parts..................................................................................................... 44
Figure 26 260075 parts......................................................................................................45
Figure 27 260076 parts..................................................................................................... 46
Figure 28 ASM212813 parts............................................................................................... 47
Figure 29 238485SP parts.................................................................................................47
Figure 30 Fastener options for tripod leg types 1 and 2 (included in
238485SP)..........................................................................................................48
Figure 31 240575SP parts.................................................................................................49
List of figures
3

List of tables
Table 1 Document version (English)...............................................................................5
Table 2 Related manuals.................................................................................................... 5
Table 3 MAWS201M maintenance levels........................................................................7
Table 4 Main components of MAWS201M Basic System...........................................9
Table 5 Main components of MAWS201M Enhancement 2......................................11
Table 6 MAWS201M radio modem options..................................................................14
Table 7 Available WMS302M spare parts.................................................................... 16
Table 8 Available QM30154-MEKASP spare parts..................................................... 18
Table 9 Available QMA102M spare parts.....................................................................20
Table 10 Available HMP155 spare parts.......................................................................... 21
Table 11 Available QPD101 spare parts.......................................................................... 22
Table 12 Available QMASSY201M spare parts..............................................................25
Table 13 Available QMD102M spare parts.....................................................................29
Table 14 Available TACLAP‑PCR spare parts...............................................................30
Table 15 Available MC‑2/360G spare parts...................................................................31
Table 16 Available QMY103MSP spare parts................................................................ 32
Table 17 Available PWD22M spare parts.......................................................................33
Table 18 Available SA20M-MT spare parts................................................................... 34
Table 19 Available QMP202SP spare parts...................................................................36
Table 20 Available CL31M spare parts............................................................................ 38
Table 21 Available SAT400AWS spare parts...............................................................40
Table 22 Available SAT400PC spare parts................................................................... 43
Table 23 Spare part set 260073 for transit cases.......................................................44
Table 24 Spare part set 260075 for transit cases....................................................... 45
Table 25 Spare part set 260076 for transit cases.......................................................46
Table 26 Fixing screw set ASM212813 for tripog leg hinge.......................................47
Table 27 Spare part set 238485SP for tripod...............................................................47
Table 28 O‑ring set 240575SP for Alden cable connectors.....................................49
Table 29 Spare part set QMY105M..................................................................................49
Table 30 Available spare parts for maintenance tasks............................................... 51
MAWS201M Spare Part Guide M212018EN-B
4

1. About this document
1.1 Version information
This document provides information on the spare parts available for Vaisala TacMetâ
Tactical Meteorological Observation System MAWS201M.
Table 1 Document version (English)
Document code Date Description
M212018EN-B July 2020 Several NSN codes have been added.
The order code for antenna storage bag (26224) has been corrected.
The order code for protective canvas for QMP202 (DRW246329) has
been added.
The following spare part sets have been added:
• Support bar set and fasteners for the tripod
• Wheels and toggle latches for transit cases
• Fixing screw set for tripod leg hinge
M212018EN-A June 2018 First version.
1.2 Related manuals
Table 2 Related manuals
Document code Name
M010082EN Vaisala HydroMet™Automatic Weather Station MAWS201 User Guide
M212018EN Vaisala TacMet â Tactical Meteorological Observation System MAWS201M Spare Part Guide
M210375EN Vaisala Combined Wind Sensor WMS301 and WMS302 User’s Guide
M210912EN Vaisala HUMICAP â Humidity and Temperature Probe HMP155 User's Guide
M211095EN Vaisala WINDCAP â Ultrasonic Wind Sensor Series WMT700 User Guide
M210543EN Vaisala Present Weather Detector PWD22/52 User's Guide
M211355EN Vaisala Ceilometer CL31M User's Guide
M211109EN Vaisala AviMet â Wind Panel Display WID511 User Guide
M211773EN Vaisala AviMet â Wind Panel Display WID511 for TacMet MAWS Technical Reference
M211658EN Vaisala Data Panel Display WID512 User Guide
M211635EN Vaisala TacMet â Weather Station AviMet â Display AWW105 User Guide
M210842EN Vaisala AviMet â Synoptic Observations Software SYNOP User Guide
Chapter 1 – About this document
5

Document code Name
-Labkotec LID-3300IP Ice Detector Installation and Operating Instructions
1.3 Documentation conventions
Warning alerts you to a serious hazard. If you do not read and follow
instructions carefully at this point, there is a risk of injury or even death.
WARNING!
Caution warns you of a potential hazard. If you do not read and follow
instructions carefully at this point, the product could be damaged or important data
could be lost.
CAUTION!
Note highlights important information on using the product.
Tip gives information for using the product more eciently.
Lists tools needed to perform the task.
Indicates that you need to take some notes during the task.
1.4 Trademarks
Vaisalaâ, AviMetâ, BAROCAPâ, HUMICAPâ, and TacMetâare registered trademarks of
Vaisala Oyj.
All other product or company names that may be mentioned in this publication are trade
names, trademarks, or registered trademarks of their respective owners.
MAWS201M Spare Part Guide M212018EN-B
6

2. Overview
2.1 Scope
This document provides illustrated spare part lists for Vaisala TacMet Weather Station
MAWS201M. The information on the available spare parts is listed separately for each of the
main components.
The spare parts lists contain the following information:
• Vaisala product code: refer to this code when ordering parts from Vaisala
• Common name of the spare part
• NSN: NATO Stock Number
• Maintenance level: See Table 3 (page 7)
• Quantity of the parts in the system
The spare part lists in this document cover the basic MAWS201M system and
Enhancement 2: Present Weather Sensors. For more information on MAWS201M, see
Vaisala TacMet
â Tactical Meteorological Observation System MAWS201M User Guide.
Depending on the complexity of the maintenance task associated with the spare part, a
spare part can be intended for either user-level maintenance (field maintenance) or
maintenance crew use. The maintenance level is defined in the spare parts lists.
Table 3 MAWS201M maintenance levels
User crew level Maintenance crew level
Level 1 Level 2
Field maintenance actions Sustainment maintenance actions
On-system O-system
Plug and play Disassemble/Assemble
Fewer tools required Wide variety of tools in use
Replace Repair
Some cases may require factory maintenance (level 3).
Chapter 2 – Overview
7

2.2 MAWS201M layout and cable codes
The following figure shows the layout and cabling of MAWS201M equipped (in addition to
basic system equipment) with the present weather detector PWD22M, ceilometer CL31M,
and TACLAP‑PCR.
QM30154-MEKA
CBL210328 1)
ZZ45113
QMP202
CBL210104-5M
ZZ45123
PWD22M
220598
CL31M
CT45298
(data)
CT45300
(power)
ZZ45202,
5 m (16 ft 5 in)
TACLAP-PCR
AviMet AWW105 software
QMR101M
QMA102M
HMP155
D2AB11A0AHA1A0A
2245110 1)
CBL210084
REIM707771
QPD101
CBL210127
grounding cable
CBL210104-5M
CBL210103-5M
ZZ45121-IP67
US plug
EU plug
ZZ45114, 22.5 m (73 ft 10 in)
QMASSY201M incl.
- Logger tube
- Tripod
- Solar panel
QMD102M
WMS302M
1) Part of the next level assembly.
Figure 1 MAWS201M layout and cable codes
The following cables are available for the SATEL radio option:
• DRW243363 (computer end)
• DRW243368 (weather station end)
For more information about cables ZZ45202 and ZZ45114, see MAWS201M Basic System
(page 9).
MAWS201M Spare Part Guide M212018EN-B
8

2.3 MAWS201M Basic System
1
3a
4
5
3
3b
3c
5b
5c
5d
7
5a
6
2
5e
8
Figure 2 MAWS201M with Basic System equipment, main components
Table 4 Main components of MAWS201M Basic System
Number
in figure
Code Component name and link NSN code
– – MAWS201M Basic System 6660‑22‑309‑2921
1 WMS302M Combined Wind Sensor, see WMS302M spare parts
(page 15).
6660-99-378-7075
Chapter 2 – Overview
9

Number
in figure
Code Component name and link NSN code
2 QM30154-
MEKASP
Telescopic mast assembly, see QM30154-MEKASP spare
parts (page 17).
5985-58-000-6687
3 QMA102M Sensor arm assembly, see QMA102M spare parts
(page 19).
6660-99-147-5309
3a QMR101M Rain Gauge, see QMA102M spare parts (page 19). 6660-01-507-5716
3b DTR502 Radiation shield, see QMA102M spare parts (page 19). –
3c HMP155D2AB11
A0A0A1A0A
HUMICAP Humidity and Temperature Probe HMP155 with
cable for MAWS201M (inside DTR502 radiation shield),
see HMP155 spare parts (page 21).
6660-58-000-2016
4 QPD101 Power Distribution Unit, see QPD101 spare parts
(page 22).
6150-01-504-7741
5 QMASSY201M Tripod assembly with QME101M, QTR102, and QMP201,
see QMASSY201M spare parts (page 24).
–
5a QM30206SP Telescope legs assembly, see QMASSY201M spare parts
(page 24).
6660-01-625-4088
5b QME101M-
MEKA
Enclosure for MAWS201M, QME101M without QML data
logger, see QMASSY201M spare parts (page 24).
5999-58-000-6686
5c QML201T QML data logger for MAWS201M (inside QME101M
enclosure), see QMASSY201M spare parts (page 24).
5998-01-541-9243
5d QMP201 Solar/Mains Power Supply Unit, see QMASSY201M spare
parts (page 24).
6117-99-167-4873
5e QTR102SP Transit case for basic system, tripod, see QMASSY201M
spare parts (page 24).
8145-99-665-5093
6 QMD102M Handheld Terminal, see QMD102M spare parts
(page 29).
7025-58-000-8661
7 TACLAP-PCR AviMet computer, see TACLAP‑PCR spare parts
(page 30).
–
8 QTR101SP Transit case for basic system sensors 8145-99-836-3970
– 19772 Suunto Global Compass MC‑2/360G, see MC‑2/360G
spare parts (page 31).
6605‑25‑149‑1938
– QMY103MSP Set of ground and foot pegs with bag, see QMY103MSP
spare parts (page 32).
5975-13-118-8037
– ZZ45202 Computer – MAWS201M cable 6150-99-215-1114
– ZZ45114 Landline cable for the computer and handheld terminal 5995-99-616-1511
MAWS201M Spare Part Guide M212018EN-B
10

2.4 MAWS201M Enhancement 2
2
1
3
5
4
Figure 3 MAWS201M with Enhancement 2, main components
Table 5 Main components of MAWS201M Enhancement 2
Number
in figure
Code Component name and link NSN code
– ENCH1 MAWS201M Enhancement 2 6625‑58‑001‑3723
1 PWD22M Present Weather Detector, see
PWD22M spare parts (page 33).
6660‑17‑118‑6142 1
2 QMP202 Power Supply Module, see QMP202SP
spare parts (page 36).
6130‑22‑309‑2926
Chapter 2 – Overview
11

Number
in figure
Code Component name and link NSN code
3 CL31M-C Portable Ceilometer, see CL31M spare
parts (page 37).
6660‑22‑309‑2925
4 QTR104 / QTR104SP Transit case for portable ceilometer 6660‑01‑504‑5577
5 QTR105 / QTR105SP Transit case for PWD22M and QMP202 6660‑01‑504‑5578
MAWS201M Spare Part Guide M212018EN-B
12

2.5 MAWS201M radio modem options
1a
1b
2a
2b
Figure 4 MAWS201M radio modem options
Chapter 2 – Overview
13

Table 6 MAWS201M radio modem options
Numbe
r in
figure
Code Component name and link
1 SAT400AWS Radio modem set, see SAT400AWS spare parts (page 40).
1a SAT400ASET UHF antenna assembly
1b 23503 SATELLINE-EASy UHF radio modem
2 SAT400PC Radio modem set, see SAT400PC spare parts (page 42).
2a SAT400ASET UHF antenna assembly
2b 23503 SATELLINE-EASy UHF radio modem
MAWS201M Spare Part Guide M212018EN-B
14

3. Combined Wind Sensor
WMS302M
3.1 WMS302M spare parts
1
2
3
4
5
Figure 5 WMS302M main parts
Chapter 3 – Combined Wind Sensor WMS302M
15

Table 7 Available WMS302M spare parts
Number in
figure
Order code Common name NSN code Maint.
level
Pcs in
system
– WMS302M Combined Wind Sensor,
MAWS201M
6660-99-378-7075 1 1
1 WA45233SP Cup wheel assembly – 2 1
2 WA45232SP Anemometer bearings
assembly
3110-15-157-5101 2 1
3 WA35370 Vane assembly – 2 1
4 – WMS302M fastener screw
M4×4 DIN914 A4
– – 1
5 25160WA Set of vane spares (ball
bearing, O‑rings, retainer ring)
3110-15-157-5100 2 –
MAWS201M Spare Part Guide M212018EN-B
16

4. Telescopic mast assembly
QM30154-MEKASP
4.1 QM30154-MEKASP spare parts
1
2
Figure 6 QM30154-MEKASP main parts
Chapter 4 – Telescopic mast assembly QM30154-MEKASP
17

Table 8 Available QM30154-MEKASP spare parts
Number in
figure
Order code Common name NSN code Maint.
level
Pcs in
system
– QM30154-
MEKASP
Telescopic mast assembly 5985-58-000-6687 1 1
1 QM40155 Protecting cover – 1 1
2 ZZ45113 Wind cable 6150-01-564-3398 1 1
MAWS201M Spare Part Guide M212018EN-B
18
