Val Controls IHP24-A User manual

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
1/58
USER MANUAL
Foundation Fieldbus
IHP24-A
IHP24-AF
IHP24-BF

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
2/58
Table of contents
1General.........................................................................................................................................3
1.1 Safety instructions................................................................................................................................ 3
2Purpose ........................................................................................................................................4
3Specifications...............................................................................................................................5
3.1 Electrical specifications for standard configuration............................................................................. 5
3.2 Power Ratings....................................................................................................................................... 5
3.2.1 FF –Fieldbus Connector.............................................................................................................. 6
3.2.2 Terminals..................................................................................................................................... 6
3.3 Additional IHP24 FF-Fieldbus Menu Function.................................................................................... 6
3.4 Additional IHP24 FF-Fieldbus Error Codes......................................................................................... 6
4FF - Fieldbus Function Blocks inside the Val Controls Device..............................................7
4.1 Transducer block.................................................................................................................................. 8
4.2 FF - Function blocks used in Default Setting....................................................................................... 9
4.3 FF –Other Function blocks available but not used in default setting................................................ 12
5Appendix –NI-FBUS Configurator Tool ...............................................................................15
5.1 DD File............................................................................................................................................... 15
5.2 Import DD Files.................................................................................................................................. 15
5.3 Upload data to NI-FBUS from the device.......................................................................................... 15
5.4 Changing Node ID from NI-FBUS .................................................................................................... 16
5.5 Modifying Device Tag name.............................................................................................................. 16
5.6 Modifying Block Tags names ............................................................................................................ 16
5.7 Factory Reset of the device. ............................................................................................................... 16
6Appendix –Function Blocks Description...............................................................................17
6.1 Appendix - Resource (RB2) Block..................................................................................................... 17
6.2 Appendix - Transducer Block (MTB)................................................................................................ 25
6.3 Appendix - Analogue Input Function Block (AI) .............................................................................. 34
6.4 Appendix - Analogue Output Function Block (AO).......................................................................... 44
6.5 Appendix - Discrete Input Function Block (DI)................................................................................. 51
6.6 Appendix - Discrete Output Function Block (DO) ............................................................................ 53
6.7 Appendix - PID Function Block (PID)............................................................................................... 55
7Trouble Guide...........................................................................................................................56
7.1 Check “Err Lock Result”.................................................................................................................... 56
8Important Issues .......................................................................................................................57
8.1 Limitation in use of Factory Reset in NI-FBUS................................................................................. 57
8.2 Always upload configuration before configuration............................................................................ 57
8.3 Don’t remove power when updating configuration............................................................................ 57
8.4 Don’t use the MTB Transducer block, in Function block Application .............................................. 57

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
3/58
1General
This manual covers software version:
Software ID: DHP-SW-009
Software Version: 1.06.04
Foundation Fieldbus software
Software ID: DHP-SW-013
Software Version: 1.00
DD file
Software ID: DHP-SW-011
Software Version: 1.00
1.1 Safety instructions
For a safe installation of a positioner, the following must be observed. The module must only be
installed by qualified personnel who are familiar with the national and international laws, directives
and standards that apply to this product as well as all instructions in this manual.
The information in this user manual is subject to changes without notice.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
4/58
2Purpose
It is the purpose of this document, to list specifications, protocol commands and functions in the
Foundation Fieldbus communication protocol in Val Controls products.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
5/58
3Specifications
3.1 Electrical specifications for standard configuration
FF-Fieldbus
Interface
FF-Fieldbus - H1 Device Class –Basic Device
Termination
No internal termination
Baud rate
31250 baud
Field bus ID (Node ID)
Node ID 17 –36 and 223 - 247
Software selectable
Default Node ID 247
Default Tag Name
“Val Controls” can be changed.
Execution Time
-AI 25 ms
-AO 31.25 ms
-DI 25 ms
-DO 25 ms
-PID 31.25 ms
-RATIO 31.25 ms
-BG 25 ms
-SC 25 ms
-ISEL 25 ms
-LLAG 25 ms
PD_TAG = Modbus_FF
Manufacture Id = 0x000105 hex - Microcyber Inc
Device Type = 0x1001 hex
DEV-Rev = 0x01 hex
DD-Rev=0x01 hex
CF-Rev = 0x01 hex
ITK-Rev = 5.00
DD-File - Tested on the following systems
-Emerson Delta V version 8.4.2
-Yokogawa Centum VPR 5.01
-Honeywell, Experion control system revision 400.2
3.2 Power Ratings
FF-Fieldbus –H1
Power Requirements: 9-32 V
Current Consumption: < 5mA

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
6/58
3.2.1 FF –Fieldbus Connector
FB-P
FB-N
FB-P
FB-N
1 32 4
3.2.2 Terminals
See the chart below to see how to connect to the terminals on the positioner.
1+3 and 2+4 is internally connected.
FF-Fieldbus
1. FB-P Receive/transmit data line, positive polarity
2. FB-N Receive/transmit data line, negative polarity
3. FB-P Receive/transmit data line, positive polarity
4. FB-N Receive/transmit data line, negative polarity
3.3 Additional IHP24 FF-Fieldbus Menu Function
Internally in IHP24 there is a hardware Foundation Fieldbus module. This module communicates
with the rest of the hardware in IHP24 via a local Modbus interface. This interface needs to run at a
fixed setup ID = 1, Baud rate = 38400, Parity = Even, Stop bits = 1. The communication settings
should always be set to these values.
It is important to set the Baud rate after an “Advanced Reset” of the IHP24.
Advanced menu Default Value Reset Description
6 Modbus Modbus configuration
1ID 1 1-247 A Change the Modbus node ID
2 Baudrate 57600 9600/38400/57600 A Change the baudrate
3 Parity Even None/Even/Odd A Change the parity
4 Stopbits 1 1-2 A Change the number of stopbits
3.4 Additional IHP24 FF-Fieldbus Error Codes
No. 801
Fieldbus_OutOfService
Description
Fieldbus AO block out of service. Mode Block is “OOS”
Set the Mode Block to “Auto” or “Cascade”
The device goes to its hardware fail position. All solenoids are de-energized.
Trouble shooting
Set the Device in In Service
Or check the Internal Modbus Menu parameter settings.
ID = 1, Baud rate = 38400, Parity = Even, Stop bits = 1.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
7/58
4FF - Fieldbus Function Blocks inside the Val Controls Device
This section contains the supported FF-Fieldbus commands.
The following FF-Fieldbus blocks are available:
•Resource Block (RB2)
•Modbus Transducer Block (MTB)
•Analogue Input Block (AI)
•Analogue Output Block (AO)
•Discrete Input Block (DI)
•Discrete Output Block (DO)
•PID Regulator (PID)
Resource (RB2)
Resources block, used to describe the characteristics of field devices, such as device name,
manufacturer, serial number. There is no input or output parameter for resource block.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
8/58
4.1 Transducer block
Transducer Block (MTB)
Analogue and Digital input and output parameters are stored in the MTB Transducer Block.
This block is the linking the Hardware and the Fieldbus Analogue and Discrete Input and Output
functions.
Values in this block should not be changed.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
9/58
4.2 FF - Function blocks used in Default Setting.
Analogue Input (AI)
Analog input function block, used to receive input data from the transducer blocks (MTB). Other
function blocks can then read the value from the “OUT” port.
In the Default setting:
The “OUT” contains the actual position signal from the Val Controls Device. Values 0.00 to
100.00%
Configuration
If you want to change the sensor input just change the CHANNEL register in the AI Block.
Block
Signal in
Device
OUT Value
Status
AI1
TM –Flow %
0.00% - 100.00%
Good / Bad
Error Handling
If the IHP24 status is “Ok”, FF-Fieldbus status on the AI channel goes to “Good”
If the IHP24 status is “Error”, FF-Fieldbus status on the AI channel goes to “Bad”

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
10/58
Analogue Output (AO)
Analog output function block, used to transmit output data to transducer block, acting on the
physical device.
In the Default setting:
In “Cascade Mode” the Val Controls Device gets its SP ( Setpoint ) from the “CAS_IN” Input.
Values of the “CAS_IN” should be in the range from “0.00% - 100.00%”
“OUT” contains the same value as “CAS_IN”
Configuration
Block
Signal in Val Controls
CAS_IN Values:
AO.OUT
SP –Flow %
0.00% - 100.00%

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
11/58
Fail position in Cascade Mode
If the Val Controls Device receives the status bad from the fieldbus, the device goes to its fail
position. The fail position is determined depending on configuration.
Example showing what will happen on the AO.OUT when one of the following errors occurs.
Fault Causes
•AO.CAS_IN.STATUS signal has status BAD
•Connection to SPUR is broken
Configuration
•AO.IO_OPTS, can be set to “0” (Disabled) or “Fault state to value”
•AO.FSTATE_VAL, the fail position 0.0% - 100.0%
Control Signal
•AO.CAS_IN –In cascade Mode
Output Signal
•AO.OUT –> Control signal SP-FLOW in Val Controls Device.
AO Block Mode - Cascade
AO.CAS_IN
value
(0.0-100.0%)
AO.CAS_IN
Status
SPUR
AO.IO_OPTS
(Fail function)
AO.FSTATE_VAL
(Fail position)
AO.OUT
Result
67.0%
Good
Connect
0
0.0%
67.0%
67.0%
Bad
Connect
0
0.0%
67.0%
67.0%
Good
Connect
Fault state to
value
0.0%
67.0%
67.0%
Bad
Connect
Fault state to
value
0.0%
0.0%
67.0%
Good
Broken
0
0.0%
67.0%
67.0%
Bad
Broken
0
0.0%
67.0%
67.0%
Good
Broken
Fault state to
value
0.0%
0.0%
67.0%
Bad
Broken
Fault state to
value
0.0%
0.0%
AO Block Mode - OOS
Fieldbus AO block out of service.
The device goes to its hardware fail position. All solenoids are de-energized.
Error Code 801 is logged.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
12/58
4.3 FF –Other Function blocks available but not used in default setting.
Discrete Input (DI)
Discrete input function block, used to receive input data of transducer blocks, and transmit it to
other function blocks.
Configuration
If you want to change the digital input just change the CHANNEL register in the DI Block.
Block
Signal in
Device
OUT_D Values:
Status
DI1
Note: No signals are available on any of the channels.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
13/58
Discrete Output (DO)
Discrete output function block, used to transmit discrete output data to transducer block.
Configuration
Block
Signal in Device
CAS_IN D Values:
Status
DO1
Note: No signals are available on any of the channels.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
14/58
PID (PID)
PID function block, is a position automatic control module. It zooms in or out for deviation and
accumulates. It includes a variety of functions, such as set-point adjustment, process parameters
(PV) filtering, feed forward and output tracking, etc.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
15/58
5Appendix –NI-FBUS Configurator Tool
5.1 DD File
NI-FBUS Configurator Rev 4 is a tool that can be used to configure the Fieldbus Interface used by
the Val Controls Device.
First you should be sure that the interface is installed in NI-FBUS.
5.2 Import DD Files
In windows
Select [National Instruments / NI-FBUS / Utilities / Interface Configuration Utility]
•If the Interface Configuration Utility will not start, stop the NI-FBUS process.
In windows go to “Task Manager”, and end the “nifb.exe” process.
On the start-up window
•Press Import DD/CFF
•Browse the location for the files, open 000105, open 1001, open 0101.ffo
•Press Ok, .. the DD files is imported successfully
•Browse the location for the files, open 000105, open 1001, open 010101.cff
•Press Ok, .. the DD files is imported successfully
Now start the NI-FBUS configurator
Select [National Instruments / NI-FBUS / NI-FBUS Configurator]
Now NI-FBUS is configured to recognise the Val Controls Fieldbus Device.
5.3 Upload data to NI-FBUS from the device.
First start the NI-FBUS Configurator if not already started. If the application dos not start, check
that to pc is connected to the Fieldbus Network.
In the network there should be a “ValControls” device.
•Click on ‘Device Tag Name’ in the tree window.
•In the menu select ‘Configure’.
•Choose ‘Upload Configuration.’
•Press ‘Yes’
•.. now its uploading data from the device to NI-FBUS Configurator.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
16/58
5.4 Changing Node ID from NI-FBUS
If you need to change the Fieldbus Node ID address then you should do it now.
•Click on ‘ValControls’ in the tree window.
•In the menu select ‘ValControls”.
•Choose ‘Set Address’.
•Press ‘Yes’ if you get a warning
•Now you can set the Address in between 17 –36 and 223 - 247
5.5 Modifying Device Tag name
If the default tag names “ValControls” conflicts with the other tag names in the network, they can
be modified with the NI-FBUS tool.
5.6 Modifying Block Tags names
If the default tag names “AI” .. “AO” conflicts with the other tag names in the network, they can be
modified with the NI-FBUS tool.
5.7 Factory Reset of the device.
Do not make a factory reset of the device, since it will reset all parameters in the MTB transducer
block and all TAG names and Node ID address.

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
17/58
6Appendix –Function Blocks Description
6.1 Appendix - Resource (RB2) Block
Resource (RB2) Block
Label / Name /
Handling
Group
Idx
rel.
Description / Format
ST_REV
[Others]
1
Length: 2 bytes
Read Only
Value: 0 –initial value
Description: The revision level of the static data
associated with the function block. The revision
value will be incremented each time a static
parameter value in the block is changed
TAG_DESC
[Process]
2
Length: 32 bytes
Value: “ “
Description: The user description of the intended
application of the block.
STRATEGY
[Others]
3
Length: 2 bytes
Value: 0
Description: The strategy field can be used to
identify grouping of block. This data is not
checked or processed by the block
ALERT_KEY
[Alarms]
4
Length: 1 byte
MODE_BLK
[Process]
[Diagnostic]
5
Length: 4 bytes
1:Target –Value: OOS
2:Actual –Value: OOS
3:Permitted –Value: Auto | OOS
4:Normal –Value: Auto
Description: The actual target permitted and
normal modes of the block.
Target: This is the mode requested by the
operator. Only one mode from those allowed by
the permitted mode parameter may be requested.
Actual: This is the current mode of the block
which may differ from the target based on
operating conditions. Its value is calculated as a
par of block execution
Permitted: Defines the modes which are allowed
for an interface of the block. The permitted mode

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
18/58
is configured based on application requirement.
BLOCK_ERR
[Diagnostic]
6
Length: 2 bytes
Description:
This parameter reflects the error associated with
the hardware or software components associated
with a block. It is a bit string so that multiple
errors may be shown.
RS_STATE
[Process]
7
Length: 1 bytes
Value: Standby
Description:
State of the function block application state
machine
TEST_RW
[Process]
8
Read Write
Value_1
Value_2
Value_3
Value_4
Value_5
Value_6
Value_7
Value_8
Value_9
Value_10
Value_11
Value_12
Value_13
Value_14
Value_15
Description:
Read/Write Test parameters –used only for
conformance testing
DD_RESSOURCE
[Others]
9
Length: 32 bytes
Read Only
Value: “ “
Description: String identifying the tag of the
resource which contains the Device Description
for this resource.
MANUFAC_ID
[Diagnostic]
10
Value: “0x000105” –Microcyber Inc
Length: 4 bytes
Read Only
Description:
Manufacturer identification number –used by an
interface device to locate the DD file for the

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
19/58
resource
DEV_TYPE
[Diagnostic]
11
Value: “0x1001” –NCS_MODBUS_FF
Length: 2 bytes
Read Only
Description:
Manufacturer’s model number associated with the
resource –used by the interface defines to locate
DD file for the resource
DEV_REV
[Diagnostic]
12
Value: “0x02”
Length: 1 bytes
Read Only
Description:
Manufacturer’s revision number associated with
the resource –used by the interface defines to
locate DD file for the resource
DD_REV
[Diagnostic]
13
Value: “0x01”
Length: 1 bytes
Read Only
Description:
Revision of the DD associated with the resource –
used by an interface device to locate the DD file
for the resource.
GRANT_DENY
[Options]
14
1: Length: 1 bytes
Read Write
2: Length 1 bytes
Read Write
Description: Option for controlling access of host
computers and local control panels to operating
tuning and alarm parameters of the block.
HARD_TYPES
[Process]
15
Length: 2 bytes
Read Write
Description: The types of hardware available as
channel numbers
RESTART
[Options]
16
Length: 1 bytes
Read Write
Allows a manual restart to be initiated. Several
degrees of restart are
possible, they are:
1: Run –Normal state when running
2: Restart Resource
3: Restart with Default –Set the parameters to

DHP-UM-013
Val Controls A/S •Limfjordsvej 3 •DK-6715 Esbjerg N •Tel. [phone] •Fax [phone]
[email protected] •www.valcontrols.com
Revision: 4
20/58
INITIAL VALUES.
4: Restart Processor –perform a warm start-up
Description: Allows a manual restart to be
initiated. Several degrees of restart are possible.
See above.
FEATURES
[Options]
17
Length: 2 bytes
Read Only
Description: Used to show supported resource
block options
FEATURES_SEL
[Options]
18
Length: 2 bytes
Read Write
Description: Used to select resource block options
CYCLE_TYPE
[Tuning]
19
Length: 2 bytes
Read Only
Description: Identifies the block execution
methods available for resource.
CYCLE_SEL
[Others]
20
Length: 2 bytes
Read Write
Value: 0x0000
Description: Used to select the block execution
methods for this resource.
MIN_CYCLE_T
[Process]
21
Length: 4 bytes
Read Only
Description: Time duration of the shortest cycle
interval of witch the resource is capable. 0
1/32mSek
MEMORY_SIZE
[Others]
22
Length: 2 bytes
Read Only
Value: 512 Kbyte
Description: Available configuration memory in
the empty resource. To be checked before
attempting a download
NV_CYCLE_T
[Process]
23
Length: 4 bytes
Read Only
Description: Interval between writing copies of
NV parameters to non-volatile memory. Zero
means Never. 0 1/32mSek
FREE_SPACE
[Diagnostic]
24
Length: 4 bytes
Read Only
