Valcom VMT-1 User manual

Issue 0
1 947993
Shorting
Jumper
HI Z Out
600-OHM
Input
HI Z Out
SHLD CT
Shorting
Jumper in
Normal
Position
HI Z Out
600-OHM
Input
HI Z Out
Shield
600-OHM Balanced
Line Input
To Aux. Input
of Amplifier
Phono
Plug
Phono
Plug
OR
N
O
R
M
M
I
C
SHLD CT
VMT-1
INPUT MATCHING TRANSFORMER
CONNECTIONS
The VMT-1 matches 500-600 Ohm lines to either
a high impedance input or output of an amplifier.
It may be used to connect audio page ports of
telephone systems to most 70 Volt amplifiers.
The VMT-1 provides an impedance match
between a 500-600 Ohm balanced line and
auxiliary high impedance input or 25 Volt output
of an amplifier.
Figure 1
Connection to an auxiliary input of an amplifier is
made using a standard phono patch cable or
screw terminals. Connection to a 500-600 Ohm
input is made to screw terminals. A shorting
jumper is available when the unit is used to
connect a high impedance output to the
microphone input of an amplifier.
DIMENSIONS/WEIGHT
•1.75" H x 3.75" W x 1.25" D
(4.45cm H x 9.53cm W x 3.2cm D)
•0.5 lbs. (.23 kg)
Figure 2 shows the VMT-1 used to
connect a 600 Ohm balanced line to the auxiliary
input of a commercial 70 Volt amplifier. If the
amplifier uses phone jacks for auxiliary input
connections a patch cable with male phono ends
may be used for the connection. Shielded single
conductor wiring is used when the amplifier is
equipped with screw terminal connections.
Figure 2 Input Matching Ttransformer
To connect a 600 Ohm line to a ¼
microphone input of an amplifier move the
shorting jumper to the lower 2 header pins on the
unit. The connection the amplifier may be made
using a standard patch cable with phono plugs
and a ¼” male/phono jack adapter.

2 947933
Shorting
Jumper
In M ic .
Position
HI Z Out
600-OHM
Input
HI Z Out
Shield
600-OHM Balanced
Line Input
To M ic. Input
of Amplifier
Phono
Plug
Phono
Plug
OR
Switchcraft 343 or Equiv.
Female Phono to ¼” Male
N
O
R
M
M
I
C
SHLD CT
FIGURE 3: Connection to Microphone Input
Connect 25V speaker line common to HIZ
Shld. screw terminal. Connect other side of 25V line
to the remaining HIZ out screw terminal. Connect
500/600 balanced line to VMT-1 screw terminals
Designated 600 Ohm Input. Shorting jumper should
be in norm. position
Shorting
Jumper
Norm.
Position
HI Z Out 600-OHM
Input
HI Z Out
SHLD
To 600 Ohm
Balanced
Input
To 25V Output
of Amplifier
Amplifier
Com.
25 V
Term.
CT
TECHNICAL ASSISTANCE
When trouble is reported, verify the unit is
properly connected and there are no broken
connections leading to this unit. Ascertain
volume control is turned up.
Assistance in troubleshooting is available from
the factory. When calling, you should have a
VOM, a test set and call from the job site. Call
[phone] and press 1 for Technical
Support or visit our website at
http://www.valcom.com.
Valcom equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating company
name, address, phone number, contact person
and the nature of the problem. Send the unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
FIGURE 4: Match 25V Speaker Line to
600/500 Ohm Input
