Valhalla TY-M2005S/L User manual

pg. 1
INSTRUCTIONS:
(TY-M2005S/L)
 Inspect product for shipping damage or manufacturing defects. If product is damaged, please
contact us immediately at [email protected]om. Do not discard packaging.
REQUIRED FOR INSTALL:
 7/32” Hex Key
 5/32” Hex Key
 1/2” Wrench
 T30 Torx Driver
IN THE BOX:
 1x M.A.P.S. Base Panel
 1x M.A.P.S. Extension
 1x Joining Plate
 2x Mounting Brackets
 1x Support Bracket
 3x 3/8-16 Bolts
 3x 3/8” Washers
 3x 3/8-16 T-Nuts
 10x 1/4-20 Bolts
 10x 1/4" Washers
 1 x 5/16-18 Carriage Bolt
 1 x 5/16-18 Lock Nut
INSTALLATION:
1. Attach Joining plate to base panel using ¼-
20 Screws and washers. Leave screws
loose.

pg. 2
2. Join base panel and extension together
using ¼-20 screws and washers. Align
panels together so sides are flush and
there is no gap between panels. Firmly
tighten all six screws.
3. Thread T-Nuts to back of brackets using 3/8-16” bolts and washers. Orient T-Nuts as shown in
picture.
4. Prepare Truck for Installation:
a. Remove top 3 screws from
storage box frame using T30 Torx
Driver.
b. Remove caps from end of cargo
rail.

pg. 3
5. Attach mounting hardware to
cargo rail.
a. Slide remaining T-Nut
into middle of rail.
Flat side of T-Nut
should face outward.
This will be used
later.
b. Slide bracket
assemblies from step
3 into front and rear
ends of rail. Loosely
Tighten bolts so
brackets can still
move freely.
6. Place Panel in Truck. Panel should sit flush
to brackets. Align holes in bottom of panel
to holes in storage box frame. Once
aligned, thread Torx bolts through panel
and into storage box frame. Leave bolts
loose.
7. Bolt MAPS Panel to brackets front and rear using 1/4-20 screws and washers. Tighten bolts to
remove play, but still allow easy adjustment.

pg. 4
8. Align panel so storage box bolts are centered in slots and adjust brackets so they are vertical and
completely engaged into cargo rail. Once aligned, firmly tighten all bolts.
9. Install center support bracket. Bracket should be forward of seem between base panel and
extension.
a. Thread bracket onto loose T-Nut in cargo rail using 3/8-16 bolt and washer.
b. Align square hole in bracket with first square hole forward of panel joint.
c. Bolt bracket to panel using 5/16-18 carriage bolt and lock nut.
NOTE: Bracket can be mounted in any of the 3 square holes forward of the joint to avoid
interference with other accessories mounted to rail.
10. Check all bolts are tight. Installation is complete.
