Valor RetroFire RF24DN Installation instructions
© 2010 Miles Industries Ltd. All rights reserved.
Manufactured by
British Columbia, Canada
www.valorreplaces.com
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNING
!
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNING
!
4000607-16
2
For purchasing a Valor Retrore. Your new radiant gas heater is a technical appliance
that must be installed by a qualied dealer. Each Retrore is fully tested during the
production process for your safety and comfort.
Your unit has been professionally installed by:
Dealer Name _______________________________________
Phone Number ______________________________________
.
The information contained in this installation manual is believed to be correct at the time of printing.
Miles Industries Ltd. reserves the right to change or modify any information or specications without
notice. Miles Industries Ltd. grants no warranty, implied or stated, for the installation or maintenance
of your heater, and assumes no responsibility for any consequential damage(s).
Do not put
furniture or other objects
in this space in front of
the replace:
36” (0.9 m)
Fireplace
Hearth
3
Table of Contents
= Updated content
◊
◊
◊
◊
◊
◊
4
Safety and Warning Information
Children and adults should be to the hazards
of high surface temperature and should to
avoid burns or clothing ignition.
should be
when they are in the same room as
the appliance. Toddlers, young children and others
may be susceptible to
. A physical barrier is recommended if there
are at risk individuals in the house. To restrict access
to a replace or stove,
to keep toddlers, young children and
other at risk individuals out of the room and away from
hot surfaces.
place furniture or any other combustible
household objects within 36” of the replace front.
and all instructions carefully
before starting the installation.
these installation instructions may result in possible re
hazard and will void the warranty.
Prior to the rst ring of the replace, the
Owner’s Information section of this manual.
this appliance if any part has been under
water. Immediately, a qualied service technician
to inspect the unit and to replace any part of the control
system and any gas control that has been under water.
Installation and repair should be by a
qualied service person. The appliance and venting
system should be before initial use and at
least annually by a professional service person. More
frequent cleaning may be required due to excessive
lint from carpeting, bedding, etc. It is that
the unit’s control compartment, burner, and circulating
air passageways to provide for
adequate combustion and ventilation air.
Always the appliance clear and free from
combustible materials, gasoline, and other ammable
vapors and liquids.
the ow of combustion and
ventilation air. Keep the front of the appliance
of all obstacles and materials for servicing and proper
operation.
Due to the high temperature, the appliance should be
out of trafc areas and away from furniture
and draperies. Clothing or ammable material
on or near the appliance.
This unit MUST be used with a vent system as
described in this installation manual. vent
system or components .
This gas replace and vent assembly be vented
directly to the outside and be attached
to a chimney serving a separate solid fuel burning
appliance. Each gas appliance a separate
vent system. Common vent systems are .
the external vent cap on a regular basis to
make sure that no debris, plants, trees, shrubs are
interfering with the air ow.
The glass door assembly be in place and sealed
before the unit can be placed into safe operation.
this appliance with the glass door
removed, cracked, or broken. Replacement of the glass
door should be performed by a licensed or qualied
service person. strike or slam the glass door.
The glass door assembly be replaced
as a complete unit, as supplied by the replace
manufacturer. material may be used.
abrasive cleaners on the glass door
assembly. to clean the glass door
when it is hot.
the gas before servicing this appliance.
It is recommended that a qualied service technician
perform an appliance check-up at the beginning of each
heating season.
Any safety screen or guard removed for servicing
before operating this appliance.
not to put any decorating objects
sensitive to heat to close above or around the replace
as it gets very hot when operating.
use this heater as a temporary source of heat
during construction.
This appliance is a
. It must not be used for any other purposes
such as drying clothes, etc.
Fuels
used in gas, wood-burning or oil red appliances,
and the products of combustion of such fuels, contain
chemicals known to the State of California to cause
cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6.
5
Specications
This appliance is intended for installation
This appliance is certied to ANSI Z21.88-2009 /
CSA 2.33-2009 American National Standard / CSA
Standard for Vented Gas Fireplace Heaters for use in
Canada and the USA and to CGA 2.17-91 High Altitude
Standard in Canada. This appliance is for direct vent
installation terminating at the roof only.
is for use with Natural Gas only.
is for use with LPG only.
Conversion between fuels may only be done using the
approved conversion kits listed in the section Options.
This appliance complies with CSA P4.1-09 Testing
method for measuring annual replace efciencies.
The installation must conform to local codes or, in the
absence of local codes with the National Fuel Gas
Code, ANSI Z223.1 or the Canadian Installation Code
CAN/CGA-B149. Only qualied licensed or trained
personnel should install this appliance.
This appliance, when installed , must be electrically
grounded in accordance with local codes, or in the
absence of local codes, with the National Electrical
Code, ANSI/NFPA 70 or the Canadian Electrical Code,
CSA C22.1.
Input ratings are shown in BTU per hour and are
certied without deration for elevations up to 4,500 feet
(1,370 m) above sea level.
For elevations above 4,500 feet (1,370 m) in USA,
installations must be in accordance with the current
ANSI Z223.1 and/or local codes having jurisdiction.
In Canada, please consult provincial and/or local
authorities having jurisdiction for installations at
elevations above 4,500 feet (1,370 m).
Safety and Warning Information
When operating your new replace for the rst time,
some vapors may be released due to the burning of
curing compounds used in the manufacture of the
appliance. They may cause a slight odor and could
cause the ames to be the full height of the rebox, or
even slightly higher, for the rst few hours of operation.
It is also possible that these vapors could set off any
smoke detection alarms in the immediate vicinity.
These vapors are quite normal on new appliances. We
recommend opening a window to vent the room. After
a few hours use, the vapors will have disappeared and
the ames will be at their normal height.
Natural Propane
0-4,500 feet*
24,000 24,000
10,500 10,500
3.95 9.5
5.0 11.0
10.5 14.0
82-580 92-260
51 30
6
Dimensions
17-1/4”
Min. 12”
Max 14”
24”
1”
4-1/2”
1-3/4”
24”
1-1/4”
18-3/4”
16-1/2”
19-1/4”
12-1/2”
13-3/4”
Min. 12”
Max 14” 3-1/4”
3” dia.
Inlet
Gas Inlet
3/8” NPT Female
Gas Inlet
3/8” NPT Female
3” dia.
Exh
Front Face of
Cast Fret
Control Valve
Location
Fret
Mounting
Brackets
(removeable)
Optional Fan
Speed Control
Location
(this side at front)
Control Valve
Optional
Cast
Fret
Adjustable
Convection
Baffle
Levelling
Feet
Side View
Front View
Top View
The diagram shows minimum dimensions required to
install the RF24. Cavities having a combination of all
the minimum dimensions shown, although possible,
may prove to be difcult installations.
24-1/2”
8”
25-1/2”
27”
10” 11”
RA24TB Fret (Black) 1225VFB Ventana Fret (Black)
RA24CV Fret (Vintage Iron) RA24AV Fret (Vintage Iron)
Optional Frets
24-3/8”
7-5/8”
18”
17”
19-1/2”
25-1/2”
14”
Height to Smoke Curtain
Minimum Cavity
7
Vent Congurations
10’
15’
20’
25’
30’
35’
40’
4’6”
5’0”
5’6”
6’0”
6’6”
7’0”
7’6”
8’0”
9’0”
10’0”
8’6”
9’6”
3” Liners
3” min. Bend
Radius
Vertical Vent Height
Allowable Horizontal Offset
10’ min. - 40‘ max.
559CLT
Co-Linear Terminal
See
Chart
559CLT
Termination
3” Inlet & Exhaust
Collars (exhaust collar
is slighthly longer)
10”
10”
The RF24 is certied for use with approved 3” diameter
exible venting installed into an approved existing solid
fuel burning masonry or factory built chimney system.
The venting system must terminate vertically at the
roof using an approved termination cap. Both inlet and
exhaust liners must be run continuously from appliance
to roof termination.
Where possible, avoid joints in ex pipe. If joints
are required, use only connectors approved by the
manufacturer of the ex pipe. Field fabricated joints are
not allowed.
Any generic 3” diameter exible venting
is acceptable. See list of
the approved venting components on page 22 of this
manual.
Failure to position the parts in
accordance with these diagrams or
failure to use only parts specically
approved with this appliance
may result in property damage or
personal injury.
8
Vent Termination
The RF24 is approved for . Two 3” diameter liners
are required from top to bottom. The vent liners must be connected to the proper collars
(intake and exhaust) or the unit will not operate properly. The method of ashing will
depend on whether the liners are installed into a rectangular masonry or round factory-built
solid-fuel burning chimney.
. The integrity of the air-cooled
function of factory-built chimney systems must be maintained when installing terminations.
Firebox Installation
Co-Linear Terminal and Square Flashing Kit are
recommended—see list of approved venting accessories on page 22.
Cut ashing kit to size. Allow extra around perimeter for drip edge to
be formed on site. Seal ashing to top of chimney using sealant (not
supplied). Fasten terminal to ashing using sheet metal screws as
shown.
559SFK Flashing
(cut to required
size and form
drip edge on site)
559CLT Terminal
Fasten to Flashing
with Sheet Metal
Screws (3 locations)
2 - 3” Flex Liners
18”
18”
The 559CLT terminal is designed to t existing 7” or 8” diameter factory-built round chimneys without requiring
additional ashing. Ensure the installation of the terminal seals off the top of the chimney space to avoid convective
air loss. The diagrams below show a typical terminal installation for an 8” diameter air-cooled chimney system.
Existing Air-Cooled Chimney
(Factory-Built Fireplaces)
Remove Top
Portion of
Terminal
Maintain Air-Cooled
Function of Existing
Chimney System
Install 2 - 3” dia.
Flex Liners
Identify
which
Liner is
Exhaust
EXH.
Connect Liners to
Corresponding
Collar on Terminal
using Sheet Metal
Screws (longer
collar is exhaust
collar)
EXH
7-5/8” dia.
10” dia.
10” 11”
559CLT
Fasten Terminal
to Flashing
(3 locations)
Ensure Flashing
Remains over
Air-Cooled
Openings
559CLT Termination
Ensure Exhaust
Portion of Chimney
is Sealed at Top
9
Vent Termination
The venting system for this appliance is considered to be a Special Venting System. The rule in the Installation
Code CAN/CGA–B149 requiring a minimum vent height of 2 feet above any portion of a building within 10 feet does
not, therefore, apply.
Overhang
should not
extend beyond
vent if within
48” of termination
cap
Horizontal
overhang
Vertical
wall
Min. 24”
(unvented sot)
Min. 36”
(vented sot)
Termination
cap
Min.
18”
Storm
collar
Roof
ashing
‘H’
Flat to 7/12 1’
over 7/12 to 8/12 1.5’
over 8/12 to 9/12 2’
over 9/12 to 10/12 2.5’
over 10/12 to 11/12 3.25’
over 11/12 to 12/12 4’
over 12/12 to 14/12 5’
10
Existing Fireplace Preparation
A few points must be considered before inserting the RF24 into an existing replace cavity. Generally, no
modications are allowed to the existing replace that will compromise the integrity of the existing replace.
Components that are bolted or screwed on such as dampers or bafes may be removed to accommodate the
installation of the RF24 engine.
. Check with local authorities if in doubt.
Have the chimney swept and the replace cavity including ash dumps and clean-outs cleaned before installing the
RF24 heater and vent liners. Any creosote or soot residue remaining in the replace cavity, chimney, or clean-out
may cause odors or stains once the RF24 insert is installed. Consult with chimney sweep for information on how
best to clean.
Factory-built, zero-clearance replaces will require the damper to be removed in order to install the vent liners.
These dampers are usually bolted into place. Dampers in masonry replaces must be xed open and may remain in
place.
Some replaces (particularly factory-built) have a raised curb at the front edge to retain ashes. Check the
dimensions carefully to ensure the RF24 engine will t behind any raised curb (some curbs may be removed
separately from the refractory base). The fret retainers allow for some vertical adjustment of the cast iron fret should
the fret need to sit on top of the curb, otherwise the fret will need to be eliminated or adequate room provided behind
the curb.
Plan the routing of the gas line before proceeding. Utilize the existing hole for the gas line. If the factory-built
replace has no access hole, carefully drill an access hole of 1.5 inch (38 mm) or less through the lower sides or
bottom of the rebox. The access hole must be plugged with non-combustible insulation after the gas supply line
has been installed. See General Dimension drawing for detailed location of gas inlet. Also, take into consideration
whether or not a fan or shut-off valve will interfere when planning routing of the gas line.
prior to installing the RF24 insert. Existing wire re screens
may remain in place or new ones may be added. The RF24 has been tested and approved to operate with wire re
screens in the closed or open positions.
Combustible mantel clearances must conform to those required for the original solid-fuel replace into which the
RF24 is being installed.
It may be desirable, for visual reasons, to paint the existing refractory liners in black to blend in with the RF24 insert
once installed.
Attach the “This replace has been converted...” label to the existing replace using screws or other mechanical
means and store any removed parts in back of the existing replace for future use.
11
Supply Gas
• It’s preferable to rough-in the gas line at this point before proceeding with the rebox installation.
• The gas supply inlet connection is a 3/8” NPT female connector. For detailed location of this connector, see
drawing in section Dimensions. If a circulating fan or isolating valve is to be installed, adjust the routing of the gas
line to suit.
• Use only new black iron or steel pipes or copper tubing if acceptable—check local codes. Note that in USA,
copper tubing must be internally tinned for protection against sulfur compounds.
• Unions in gas lines should be of ground joint type.
• The gas supply line must be sized and installed to provide a supply of gas sufcient to meet the maximum
demand of the appliance without undue loss of pressure.
• Sealant used must be resistant to the action of all gas constituents including LP gas. Sealant should be applied
lightly to male threads to ensure excess sealant does not enter gas lines.
• The supply line should include a manual shut-off valve and union to allow the appliance to be disconnected for
servicing.
• Pressure test the supply line for leaks.
• The appliance and its individual shut-off valve must be disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in excess of ½ psig (3.5 kPa).
• The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½ psig
(3.5 kPa).
• Failure to either disconnect or isolate the appliance during
pressure testing may result in regulator or valve damage.
Consult your dealer in this case.
• The minimum supply pressure is given in the section
Specications of this manual.
• All piping and connections must be tested for leaks after
installation or servicing. All leaks must be corrected
immediately.
• When testing for leaks:
• Make sure that the appliance is turned off.
• Open the manual shut-off valve.
• Test for leaks by applying a liquid detergent or soap
solution to all joints. Bubbles forming indicate a gas leak.
• Correct any leak detected immediately.
• The pressure test tapping locations are shown in gure above.
A built-in non-adjustable regulator controls the burner manifold pressure. The correct pressure range is shown in
the table in section Specications of this manual. The pressure check should be made with the burner alight and
at its highest setting. See Lighting Instructions section for full operating details.
Inlet Pipe
Manifold Pressure
Test Tap Supply Pressure
Test Tap
Loosen screw to check
(tighten afterwards)
Pressure Test Tappings
12
Vent Liner Rough-in
Rough-in the two 3” diameter vent liners into existing chimney system being careful not to tear or damage the
liners in the process. It may be easier to install both liners at the same time rather than one at a time. Leave plenty
of liner at the bottom end if the Heater will be connected while on the hearth (see diagram). When connecting the
liner in this manner so the slack liner can be lifted after the insert
is in place (see separate section for top termination).
Two 3” dia.
Aluminum Liners
EXH.
Appliance Preparation
• Unpack appliance.
• Remove window.
• Remove log pack from rebox.
• Strip rebox down by removing:
• Burner Module (10 screws),
• Support Legs (2 screws per leg)
(required when inserting into
small replaces only)
Remove
Burner
Module
(10 screws)
Remove
Support Legs
(2 screws/leg)
Spring-loaded
Fastening Studs (2)
1/4 Turn
The size of the existing replace cavity will affect the method of installation. Smaller replaces, particularly factory-
built zero-clearance replaces will require the RF24 rebox to be disassembled then reassembled inside the
replace. Plan your particular installation accordingly.
13
Firebox Installation
Reach Through Front
to Connect Liners
Reach Through
Top or Sides
to Connect Liners
Gear Clamps
Trim liners if necessary and connect to the rebox either while the rebox is on the hearth or with the rebox in the
cavity. Use gear clamps provided to connect the liners to the rebox. If the liners are connected with the rebox on
the hearth, it will be necessary to pull the slack liner up from the top of the chimney after the rebox is installed.
With the rebox recessed behind the smoke curtain of the existing replace, raise the rebox and place the
individual support legs under the rebox. Placing a temporary shim under the rebox, such as a 2” x 4”, may help
while positioning the support legs. Tabs are provided on the support legs to help position them. Fasten the support
legs at the points indicated by the arrows using the bolts provided (2 per side).
Thread thumbscrews
into Support Leg.
Raise left hand side of firebox
and slip LH Support Leg
Under. Fasten with 2 bolts
as indicated.
Thread thumbscrews
into Support Leg.
Raise right side of firebox
and slip RH Support Leg
Under. Fasten with 2 bolts
as indicated.
14
Firebox Installation
Reinstall the burner module using the 10 screws removed previously. Note: The upper bafe may be removed to
gain more room for the screwdriver to install the rear screws.
Reinstall Burner
Module
(10 screws)
Edge Fits Into
Cleat at Back
Remove Top Baffle
(2 screws)
(to provide space for a screwdriver)
Remove Top Baffle (optional)
The backside of each support leg has a leveling bolt. If necessary, adjust the level of the rebox in the hearth.
Leveling
bolt
Front View
Side View
Fret bracket
Leg
Leveling bolt
BackFront
Leveling
bolt
Connect the gas line to the burner module. Check for leaks, purge the line, and test-re the unit before installing the
window or proceeding with the remainder of the install—see section Lighting Instructions.
Edge Fits Into
Cleat at Back
Reinstall Top Baffle
(2 screws)
15
Ceramic Fuel Bed Installation
Install the ceramic brick liner taking care not to damage them as the material is fragile. The top rounded edges of
the side panels should face inwards and the front edge bevelled. Place the side brick panels at against the side of
the rebox up high and slide downward into place behind the front return edge on the rebox.
Side Brick Behind
Firebox Return
Side Brick in front of Rear Brick
Rear Brick
Left
Brick
Rest Brick on
Rear Log Support
Rear Brick
Rear Brick
Left
Brick
Right
Brick
within the existing replace to allow ample space at front for the fret
and to allow convection air to ow under the smoke curtain of the existing replace. Position the top convection
bafe with the threaded studs pointing downwards into the slots at the top of the rebox. Slide the convection bafe
, angled down if possible, to force the air under the smoke curtain, and tighten the wing
nuts.
Convection Baffle
Wingnuts (2)
Start wingnuts on studs. Slide
Convection Baffle into slots.
Adjust Baffle Forward to Touch
Back of Smoke Curtain of
Existing Fireplace. Tighten
Wingnuts.
Firebox Installation
16
Ceramic Fuel Bed Installation
Carefully remove the ceramic logs from the packaging taking care not to damage them. Install the logs as described
below. The position of
the logs is critical to insure the good performance of the appliance
Rear Log Touches
Front Log Here
Right Log
Locating Pins
Place Font Log onto locating
Pins at Each End
NG ONLY: Drop Rear Log into place
behind front log retainers.
LPG ONLY:
Drop Rear Log into
place centered side-
to-side against back
support so the log
sits more vertical.
Front Log locating pins
L/H Log Locating Pins
Place Middle Cross Log
Across Gap in Front Log
Place R/H Cross Log
Onto Locating Pins
Place L/H Cross Log
Onto Locating Pins
17
Remote Control Installation
1. Connect the wiring harness to the receiver box, by
pushing the wire connector on to the receiver circuit
board. The plug will only go on one way so please
ensure that the wires are pointing up and slot in the
board is in line with the tab on the wiring harness
plug.
2. Connect wires as shown. Please note that the “L”
connectors are different sizes, the smaller one ts
to the lower connection and the larger one the top
connection on the top left hand side of the valve.
The other two wire connectors can be tted to either
terminal located to the left of the ame control
button.
3. Remove the remote control receiver lid.
4. Fit four AA 1.5 V alkaline batteries.
5. Place the remote control receiver on the base of
the replace beside the valve.
6. Fit the 9 V alkaline battery to the handset
transmitter.
Remote Receiver
Receiver GV34 Valve
Push-on
Connector
Window Retting and Checking
Hook the window over the top edge of the rebox, and
fasten the bottom two spring loaded bolts by pushing
in and turning 90 degrees. Check that the window
moves freely against the spring by pulling out at the
bottom. If broken, the window may only be replaced as
a complete unit as supplied by the manufacturer.
Cast Iron Fret Installation
Check that Window
Moves Freely After
Reinstallation
Spring Loaded
Fastening Studs (2)
1/4 Turn
a screwdriver or other metallic object
to remove the batteries from the receiver or the
handset! This could cause a short circuit to the
receiver.
18
Cast Iron Fret Installation
Screw 2 thumbscrews into sides of each support
leg if not done previously when support legs were
installed. Fit the slotted holes in the fret retainers over
the thumbscrews, push fret retainers downwards and
tighten screws.
Adjust screw heads on back of fret to the thickness of
the retainer bracket and drop the fret into place while
guiding the screw heads into the slots in the bracket.
Clip the ash pan cover onto the fret.
Drop Fret with Bolt
into Slotted Retainer
(fret adjusts up or down
to suit)
Note: The fret retainer brackets are designed to
maintain the required space in front of the window to
allow the window to move and relieve during a hard
start. It is very important to ensure this area in front
of the window is kept clear at all times.
Slip Fret Retainer
over thumbscrews
and tighten screws
Operation Check and Aeration Adjustment
Turn the replace up and down using the remote control to conrm
that the full range of inputs is achieved.
Light the re and allow to warm up for 10–15 minutes to evaluate
the ame picture. The burner is equipped with an adjustable air
shutter to control primary aeration. See gures below. The shutter is
factory-set at an aeration gap, which will give optimum performance
for the vast majority of installations. In a few unusual installations,
ame picture may be improved by adjusting the aeration. The need
for adjustment should be determined only by operating the appliance
with the ceramic fuel effects and window installed.
will cause the ame to appear more
transparent and blue making the ceramic fuel effects glow more.
will
cause the ames to appear
more yellow or orange making
the fuel effects glow less.
Too little aeration may result
in black carbon forming and
dropping into the rebox.
Air Shutter in
Open Position
Air Shutter in
Closed Position
Air Shutter
Air Shutter Retainer
Air Shutter Components
19
Owner’s Information
Safety and Warning
Information
For your safety, this appliance is tted with a ame
supervision device which will shut-off the gas supply
if, for any reason, the pilot ame goes out. This device
incorporates a xed probe, which senses the heat
from the pilot ame. If the probe is cool, the device will
prevent any gas ow unless the burner control knob is
kept pushed in at the PILOT position. See full lighting
instructions on page 23 of this manual.
It will be necessary to clean the glass periodically.
During startup, condensation, which is normal, forms
on the inside of the glass and causes dust, lint etc. to
cling to the glass surface. Initially paint, while curing,
may deposit a slight lm on the glass. We therefore
recommend that, during the rst few weeks of use,
the glass be cleaned two or three times with non-
abrasive common household cleaners and warm
water. Ammonia based cleaners should not be used.
Subsequently, the glass should be cleaned two or
three times a season depending on the circumstances.
Do not clean the glass while it is hot. Always securely
replace the window before lighting.
Cast Iron Fret Installation
Check that Window
Moves Freely After
Reinstallation
Spring Loaded
Fastening Studs (2)
1/4 Turn
Pilot Flame
Thermocouple
Probe must be
in Flame
Warranty
Card at the
back of this
manual.
Let the replace cool rst before cleaning it.
Your replace becomes very hot when operating.
Avoid placing decorating objects sensitive to heat
within 36 inches (0.9 m) around it.
Do not put
furniture or other objects
in this space in front of
the replace:
36” (0.9 m)
Fireplace
Hearth
Performance of LPG appliances may be affected by
the quality of commercial gas supplied in your area.
The window can be removed for cleaning by rotating
the two fastening studs at the bottom corners 90
degrees to release, and swinging the bottom of the
window unit outwards to unhook the top edge.
After retting
the window,
apply light
hand pressure
against the
window frame
sides to bed-
in the window
seal.
Dust, etc. can be brushed from the ceramic fuel effects
and rebox walls after removing the front unit and
opening the window. Dust etc. can also be removed
from the burner using a soft brush after removing the
ceramic fuel effects.
A periodic check of the pilot and burner ames should
be made. Check after the re has been on for at least
30 minutes. The pilot ame must cover the tip of the
thermocouple probe. The main burner ame pattern
will vary from appliance to appliance depending on the
type of installation and climatic conditions—see images
below.
The appliance area must always be kept clear and
free from combustible materials, gasoline and other
ammable vapors and liquids.
Inspect the vent terminal outdoors regularly to make
sure that, snow, leaves, bushes, trees, etc, do not
obstruct it.
Examine the vent system and terminal regularly. We
recommend annually.
20
Owner’s Information
All appliances use four 1.5 V AA alkaline batteries for
remote control receiver and the handset uses a 9 V
alkaline battery.
Batteries are accessible by removing the lid of the
remote control receiver. Batteries should last one to
two seasons, depending on usage. Removing batteries
in the off season will extend battery life. Should the
batteries loose power, the control may be operated by
manually turning the control knob at the valve.
If your appliance needs to be serviced, contact your
supplier quoting the model number. It will be helpful if
the appliance serial number can also be quoted. This is
on the rating plate, which is attached to the unit.
The repair parts are shown in the repair parts list.
Please always quote the part number and description
when requesting spare parts.
a screwdriver or other metallic object
to remove the batteries from the receiver or the
handset! This could cause a short circuit to the
receiver.
Remote Control Operation
Your replace remote control helps you get the comfort, convenience and aesthetics
you want from your gas replace. The remote controls your replace in different
ways.
BEFORE YOU BEGIN, please note that on this system, the settings
of time, temperature and automatic ON/OFF can only be programmed when the
function display is ashing. Be patient when programming as it can take a few
seconds to set.
The rst thing to do is to set the time.
1. With your thumb, hold down the and buttons until ashes.
Let go.
2. Note the digital clock on the bottom right hand corner. The ▲ button sets the
hour; the ▼ button sets the minutes. Set the time.
Note: You must start setting the time while the is ashing. If it stops ashing,
go back to 1.
3. The display shows °C/24-hour or °F/12-hour. To change the temperature/hour
display, press on the button while the display ashes.
4. Let go and wait until the ashing stops. The remote shows the time you set. It
also shows the current temperature.
Use this setting when you come in and want to enjoy a specic temperature.
1. Push the button until a number and ash. Let go.
2. While it is still ashing, push the ▲ and ▼ buttons to the temperature you want.
Let go.
Your replace will reach that temperature and the remote will check the temperature
every ve minutes, adjusting the amount of fuel needed to give you a steady, even heat.
This manual suits for next models
1
Table of contents
Other Valor Indoor Fireplace manuals
Valor
Valor Wellington User manual
Valor
Valor Portrait 530ILN/ILP Operating instructions
Valor
Valor 739IRN Installation instructions
Valor
Valor Vogue 1300ILN Operating instructions
Valor
Valor Sunfire Assembly instructions
Valor
Valor BR417 VA Assembly instructions
Valor
Valor 1700IN Operating instructions
Valor
Valor 1400MN User manual
Valor
Valor Black Beauty Radiant 340 User manual
Valor
Valor 1600IN Operating instructions
Valor
Valor SFFK01 User manual
Valor
Valor 700MN Planning guide
Valor
Valor DIMENSION ELECTRIC Series User manual
Valor
Valor 1500IN Operating instructions
Valor
Valor COSYFLAME TURBOCHIM 528 User manual
Valor
Valor PORTRAIT 530 Installation and operation manual
Valor
Valor 535XAN Installation instructions
Valor
Valor LX2 Series Operating instructions
Valor
Valor FIA BR650 VA User manual
Valor
Valor 737XN Installation instructions
Popular Indoor Fireplace manuals by other brands
M Design
M Design TRUE VISION RUSTICA M Instructions for installation
Heatilator
Heatilator BIR36-B owner's manual
Escea
Escea IB1100 Service manual
Regency
Regency U32E-NG5 Owners & installation manual
Ambifuego
Ambifuego KALIDO 73 Installation, user and servicing instructions
Hearth and Home Technologies
Hearth and Home Technologies Simplifyre SFE-35 Homeowner's installation & operating manual
kozy heat
kozy heat SP-41 LOG Installation and operation manual
Heatilator
Heatilator GDST5244I owner's manual
Desa
Desa VTGF33PRA OWNER'S OPERATION AND INSTALLATION MANUAL
Wamsler
Wamsler WO 109- 6F/A User instruction
Empire Comfort Systems
Empire Comfort Systems VFPC20in33N-1 Installation instructions and owner's manual
Paramount Fitness
Paramount Fitness BLT-999A-7 Instructions for use
Continental Fires
Continental Fires CF-E 40 Instructions for installation and use
Element
Element Modore 75H installation manual
Quadra-Fire
Quadra-Fire HUDBAY-FS owner's manual
GlammFire
GlammFire KIT Glamm 3D Plus 500 manual
Cast Tec
Cast Tec Integra Convector Plus Installation and user instructions
Mendota
Mendota AA-11-04050 Installation and operating instructions
