Vanco HDWIRKIT User manual

HDMI® WIRELESS
EXTENDER/
RECEIVER
Vanco Part Number:
HDWIRKIT
HDWIR-RX
Technical Support
www.vanco1.com • [email protected] • 800-626-6445

www.vanco1.com 800-626-6445 2
1. Do not expose this unit to water, moisture,
or excessive humidity.
2. Do not install or place this unit in a built-in
cabinet, or other conned space without
adequate ventilation.
3. To prevent risk of electrical shock or re
hazard, due to overheating, do not obstruct
unit’s ventilation openings.
4. Do not install near any source of heat,
including other units that may produce heat.
5. Do not place unit near ames.
6. Only clean unit with a dry cloth.
7. Unplug unit during lightening storms, or
when not used for an extended period
of time. A surge protector is strongly
recommended.
8. Protect the power cord from being walked
on or pinched, particularly at the plugs.
9. Use unit only with accessories specied by
the manufacturer.
10. Refer all servicing to qualied personnel.
CAUTION
HDMI is a very complex technology requiring continuous authentication of the signal and the same
video resolution and audio settings on all electronic equipment in the system. When there are multiple
sources and displays, the video resolution and audio setting on all connected units must be adjusted
to correspond with that of the display having the lowest video and audio capability.
WARNING
DEAR CUSTOMER
Thank you for purchasing this product.
For optimum performance and safety, please
read these instructions carefully before
connecting, operating or adjusting this product.
Please keep this manual for future reference.
This product is 100% inspected and tested in the United States
to verify HDMI performance parameters.

www.vanco1.com 800-626-6445 3
FEATURES
The Vanco HDWIRKIT/RX extends HDMI signals wirelessly from a source to a display up to
131ft/40m using wireless technology. There are no cables that are required between the
transmitter and receiver which makes for a clean and easy installation, especially where cabling
is difcult or impossible to run. Using a 5GHz operation frequency, the HDWIRKIT Transmitter
and Receiver do not require line of site transmission, the wireless signal will travel through most
obstacles with no issues. Out of the box, the HDWIRKIT works as a point to point conguration,
however also supports having multiple sets on the same site (up to 10) and one to multiple (1 TX
to up to 4 RX) displays using HDWIR-RX receivers (sold separately). A great solution for splitting
a single source signal wirelessly. Also features dual band IR call back to control the source from
any display location connected. With the ability of sending HDMI signals wirelessly, whether point
to point or splitting to multiple displays, the HDWIRKIT and optional HDWIR-RX are easy solutions
where running cable is an issue.
HDMI® WIRELESS EXTENDER/RECEIVER
Part # HDWIRKIT (transmitter and receiver)
Part # HDWIR-RX (receiver only)
• Extends HDMI signals wirelessly up to 131ft/40m
• Transmits up to 1080p HD video and audio
• Kit includes both Transmitter and Receiver for point to point application
• Able to split wireless HDMI signals to up to 4 displays (additional HDWIR-RX receivers sold separately)
• Multiple kits able to be installed in one application without interference
• Perfect solution where cabling cannot be run such as a mantle or outdoor application
• IR pass-through to control source from display location wirelessly
• Wireless 5 GHz frequency
• No line of sight installation required, wireless signal will pass through most obstacles
• Easy manual front panel or IR setup for multiple units
• Dimensions: 5.25” W x 0.75” H x 3” D

www.vanco1.com 800-626-6445 4
PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the shipping carton:
• Wireless Transmitter (HDWIRKIT only)
• Wireless Receiver
• 5V/2A Power Supply
• IR Blaster (TX)
• IR Receiver (RX)
• IR Remote Control
• Product Manual
SPECIFICATIONS
Power Supply ............................................................ Voltage/Current: DC5V/2A; Power consumption
TX<7W, RX< 5W
HDMI Compliance ...................................................... HDMI 1.3
HDCP Compliance...................................................... HDCP 1.2
HDMI Resolutions Supported ...................................... 480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
Supports Audio Formats............................................. L/R stereo audio
Maximum Transfer Rate ............................................. 10.2 Gbps
Input and Output TMDS signal..................................... 0.5 ~ 1.5Vp-p(TMDS)
Input and Output DDC signal ....................................... 5Vp-p(TTL)
IR Remote Control ..................................................... Supports IR callback (RX->TX); 20-60KHz frequency
Transmission Method ................................................. 5G Wireless Transmission
Latency..................................................................... 120ms
Electrostatic Protection.............................................. 1a Contact discharge level 3; 1b Air discharge level
3; Standard: IEC61000-4-2
Operating Temperature............................................... 32~122 Fahrenheit
Storage Temperature ................................................. 14~158 Fahrenheit
Humidity (no condensation) ......................................... 0~90%
Dimensions ............................................................... 5.25” W x 0.75” H x 3” D (each unit)
Material.................................................................... Iron alloy material + crystal panel
Processing Technology................................................ Sandblasting
Color ........................................................................ Black
Weight ..................................................................... TX: 0.68 lbs; RX: 0.68 lbs

www.vanco1.com 800-626-6445 5
PANEL DESCRIPTIONS
1. Antennas
2. RF Channels (Selectable 0-9 to “marry” to Receiving unit; or to split to multiple HDWIR-RX receivers)
3. Channel Toggle Switch (will change RF Channels 0-9 sequentially)
4. IR Sensor (for included remote to change to RF channels remotely)
5. Reset Button
6. DC 5V Power Supply Port
7. HDMI INPUT (Connect to an HDMI source)
8. Signal Status Indicator (Solid Green for successful signal when connected to source)
9. Syncing Status (Blinking Green when connected to Receiving unit; Solid Green will appear if no connection
to Receiver)
10. HDMI OUT (Loop-out, able to use as a splitter to connect to a local display such as a control room display)
11. IR OUT (Connect included IR Blaster (TX) and place near or at source for IR control)
1
6
TRANSMITTER
78
9
10
1
5
11
2
34

www.vanco1.com 800-626-6445 6
PANEL DESCRIPTIONS
RECEIVER
1. Antennas
2. RF Channels (Selectable 0-9 to “marry” to Transmitting unit; other Receivers can be set to the same RF
channel to split signal)
3. Channel Toggle Switch (will change RF Channels 0-9 sequentially)
4. IR Sensor (for included remote to change to RF channels remotely)
5. Reset Button
6. DC 5V Power Supply Port
7. Signal Status Indicator (Solid Green for successful signal when connected to source)
8. Syncing Status (Blinking Green when connected to Receiving unit; Solid Green will appear if no connection
to Receiver)
9. HDMI OUTPUT (Connect to an HDMI display)
10. IR IN (Connect included IR Receiver (RX) and place near or at display for IR control)
1
67810
1
235
4
9

www.vanco1.com 800-626-6445 7
CONNECT AND OPERATE
1. Connect HDMI cable from a source into the HDMI IN port of the TRANSMITTER
2. OPTIONAL: Connect the provided IR BLASTER into the IR OUT port of the TRANSMITTER
3. OPTIONAL: Connect HDMI Cable to the HDMI OUT port to loop-out to a local display such as a control
room display
4. Connect an HDMI cable from the HDMI OUT port of the RECEIVER to a display or sink device
5. OPTIONAL: Connect the provided IR RECEIVER into the IR IN port of the RECEIVER
6. Connect both power supplies to the TRANSMITTER and RECEIVER using the provided power supplies,
TRANSMITTER rst, followed by RECEIVER
7. Using the manual toggle buttons on the units or the provided IR remote control, select any available
channel; the TRANSMITTER and RECEIVER MUST be on the same channel (if using multiple kits, set each
kit to different channels to avoid signal interference)
NOTE: If there is no signal on startup, press the RESET button on the TX and/or RX.
NOTE: Transmission distance may differ based on certain environmental factors such as other wireless signals
that can interfere with transmission. Solid core walls, brick, or glass can signicantly shorten the range at
higher resolutions.

www.vanco1.com 800-626-6445 8
IR PASS-THROUGH
The IR system allows you to control the source that is connected to the extender unit, from the display. There
are two important things to note when setting up the IR system:
1. The IR Receiver (IR RX) is always what you point your remote at to send an IR signal. This pigtail is
placed at the display for controlling the source.
2. The IR Blaster (IR TX) is what sends the IR signal to what you are intending to control. This pigtail is
placed at the source; either pointed at the source, or placed on the front panel of the source (see below
for placement tips).
IR BLASTER (TX)
To control the source: plug IR Blaster into IR OUT port of TRANSMITTER; place blaster in front of the IR eye of
the source.
Note: Placement of the IR Blaster is important and can result in the IR system not working if improperly
placed.
• First, locate the IR eye or window on the source
• If placing the IR blaster right on the front panel of the source, do not stick right on top of the IR eye or
IR window. The IR signal cannot travel through the double-sided tape on the Blaster. Instead place the
blaster on either side, or on the top or bottom of the IR eye or window, with the tip of the blaster facing
the IR eye or window. See below for illustration of where IR signal shoots from on IR Blaster:
IR BLASTER (TX)

www.vanco1.com 800-626-6445 9
IR RECEIVER (RX)
• To control the source: Plug IR Receiver into IR IN port of RECEIVER; place receiver at or near display.
• Note: Due to possible differences in 3rd party IR cables, please use the IR cables that came with the
product.
IR RECEIVER (RX)

www.vanco1.com 800-626-6445 10
SAFETY AND NOTICE
The HDWIRKIT/HDWIR-RX has been tested for conformance to safety regulations and requirements, and has
been certied for international use. However, like all electronic equipment, the HDWIRKIT/HDWIR-RX should
be used with care. Please read and follow the safety instructions to protect yourself from possible injury and
to minimize the risk of damage to the unit.
• Follow all instructions and warnings marked on this unit.
• Do not attempt to service this unit yourself, except where explained in this manual.
• Provide proper ventilation and air circulation and do not use near water.
• Keep objects that might damage the device and assure that the placement of this unit is on a stable surface.
• Use only the power adapter and power cords and connection cables designed for this unit.
• Do not use liquid or aerosol cleaners to clean this unit.
• Always unplug the power to the device before cleaning.
TROUBLE-SHOOTING
1. If the display has “waiting for connection” on the bottom right hand corner:
Check to see if the power supply of the transmitter and receiver are well connected and that the power
indicator lights are ON
2. If the display states, “Please check the TX input signal...”
First check to see if there input is properly connected and powered on. Next try to connect the signal source
directly to the display device to see if there is a signal output from the source device or change the signal
source.
3. If the display is not stable:
• Try moving the position of the transmitter and receiver and make sure the range of the device has not
been exceeded.
• Hit the “RESET” button on the RX rst, followed by the TX. Please allow time to sink before trying the TX
RESET button
• Remove power and HDMI form both sides, reconnect the HDMI cables FIRST, then power after
• Look to remove other wireless signal that may be disrupting the transmission
