Ⅰ. INTRODUCTION
Thank you for using our product! This product is designed for indoor and outdoor use. It is
suitable for disco, stage, building and other decorating places. As the high power LED Wall
Wash Light, this product can be operated as a single unit or in multiple units for large
applications. Direct input of DMX512 signal to unit to allow it can be controlled by any
DMX512 controller. Powerful internal programs and friendly and convenient operation
interface allow customers to program freely to any different lighting project requirements
for installation or shows.
This high power LED wall wash light has got the nice sculpt, efficient, save electricity and
durable. The light is small, but very brightness and stable. Please read this manual carefully
and completely. For technical reference in future, please keep it well. This user manual
contains all installation and operation information of this LED Wall Wash Light, it’s very
useful for user to install and operate the light. Please strictly abide by the relevant
instruction for the installation and operation.
This light meets the following criteria:
GB7000.1-2007/IEC60598-1:2003
GB7000.217-2008/IEC60598-2-17:1984+A2:1990
Once receiving the fixture, please open the carton board box carefully, and check the
contents to ensure that all parts are presents, and have received the products in a good
condition. Notify the shipper immediately and retain packing material for inspection if the
products or any parts appear damaged from shipping or the carton itself shows, sign of
mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box
01

USER MANUAL
24PCS OUTDOOR LED WALL WASH LIGHT
and packing. Please check the packing list as below:
LED Wall Wash Light-------- 1pc
User Manual ----------------- 1pc
Ⅱ. SAFETY WARNING
Every person involved with the installation, operation and maintenance of this device has to
know:
1). This product must be installed by a qualified professional;
2). This product left the place of manufacture in perfect condition. In order to maintain this
condition and for safe operation, the user must always follow the instructions and safety
warnings described in this user manual;
3). Manufacturer will not with responsibility for those operations not according to this
Instruction.
Ⅲ. OPERATION ATTENTION
·Do not connect power cable of other electric products with this unit;
·Do not connect DMX512 Signal cable of other electric products with this unit;
·Always make sure that you are connecting to the proper voltage, and that the line voltage
you are connecting to is not higher than that stated on the decal or rear panel of the fixture;
·Always ground (earth) the fixture electrically;
·During long periods of non-use, disconnect the unit’s main power;
·Do not attempt to operate this unit if the power cord has been frayed or broken;
·There are no user serviceable parts inside the unit. Do not open the housing or attempt
any repairs yourself;
·Maximum ambient temperature (Ta) is 35°C. Do not operate fixture at temperatures
higher than this;
·The surface temperature of the light can reach to 65° C, cool down at least before you
operate the light;
·The minimum distance between light-output and the illuminated surface must be more
than 1 meters. Keep all combustible materials (for example fabric, wood, paper) at least 0.5
meters away from the fixture;
·Avoid looking directly into the light source (especially those who suffer from epileptic
fits);
·Always mount this unit in safe and stable matter;
·When suspending the fixture above ground level, verify that the structure can hold at
least 10 times the weight of all installed devices;
·Verify that all external covers and rigging hardware are securely fastened and use an
approved means of secondary attachment such as a safety cable;
·Block access below the work area whenever installing or removing the fixture.
·Avoiding hit the Light when you are move or install the light;
·If the exterior cord of the fixture is damaged, it must be replaced by manufactory, agent
or a qualified technician.
ⅣPRODUCT MAIN FEATURES
6 DMX channel mode optional, with digital tube display and four control buttons;
DMX-512, Master/slave control mode;
IP65 rating;
With strobe function;
Long LED lifespan can reach to 50,000hours;
High efficiency, electricity saving, low heat;
Standard DMX-512 communication protocol;
03
02

USER MANUAL
24PCS OUTDOOR LED WALL WASH LIGHT
Easy for power connection.
ⅤINSTALLATION INSTRUCTION
Before plug-in the power, please make sure the voltage, frequency of the light are
correspond to the power. And ensure the grounding line of the light working reliable.
You can distinguish the different power cords as below:
Color of the Power Cord
Connection
Brown
Live line
Blue
Neutral/Null line
Yellow green
Earth line
1. Signal Connection
This light provide 3 pins cannon seats, Pin1 for signal ground, Pin2 for signal-, Pin3 for
signal+.
DMX-IN DMX-OUT
The controller, light and light will be connected by 3 pins signal cables one by one.
You can connect the output of the controller with input of the first light, and connect the
output of the first light with the input of the second light in the DMX control mode, and so
on one by one. And please connect the output of the last light with the terminal seat. You
can don’t need the controller and circuit terminal seat in the master/slave controller mode.
You can use one 120Ω& 0.25W resistance to insert into and weld the pin2 & pin3 of one
male cannon plug to make the circuit terminal seat. The circuit terminal seat can avoid
DMX-512 signal reflex and interference effectively.
If the output of your controller is using 5 pins cannon seat, please use 5pins into 3pins
signal change cable.
2. Installation Method
The light can be placed on the solid plane places, then loosen the screw on both sides of the
handles to adjust the right project angle. Please pay attention the places are
non-flammable.
Install the clamp into the hole of the handle, and hang it on the truss then. You can
adjust the right project angle through the screw of the both sides of the light. It’s
important that you have to use one or more protection measures to prevent the light will
fall, such as the safety rope. You can buy the clamps and safety ropes from our
-6-
DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT
DMX Controller Circuit Terminal Seat
05
03
05
04

USER MANUAL
24PCS OUTDOOR LED WALL WASH LIGHT
company.
ⅥOPERATION OF THE CONTROL PANEL
1. Basic using:
MENU: Main menu change
UP: Scroll up the menu items or browse increasing parameters
DOWN: Scroll down the menu items or browse diminishing parameters
ENTER: Confirm/Save/Access submenu
2. Operate step:
Step 1 : Press MENU to previous menu, then could choose MENU
Step 2 : Press UP or DOWN , then revise setting
Step 3 : Press ENTER to sub-menu
Step 4: Press ENTER to save or confirm
3. Menu Navigation
NO.
LED Display
Functions
1
A001
DMX address for 8 Channels(001-512)
2
D001
DMX address for 4 Channels(001-512)
3
Cc00
Seven color jumping Speed from 01 to 99 You can control
speed through the "UP" and ”Down”
4
Cp00
Seven color slowly Speed from 01 to 99 You can control speed
through the "UP" and "Down"
5
De00
RGB Color mixing Speed from 01 to 99 Seven color changing
controlled by voice active!
6
R000
Red, (000—255) You can Dim the Red color through the
key ”UP” And "DOWN"
7
G000
Green, (000—255) You can Dim the Green color through the
key ”UP” And "DOWN"
8
B000
Blue, (000—255) You can Dim the Blue color through the
key ”UP” And "DOWN"
9
W000
White, (000—255) You can Dim the White color through the
key ”UP” And "DOWN"
Ⅶ. DMX CHANNEL CHART
8 DMX Channels
CH
Function
DMX
Value
Description
1
General dimmer
0-255
R,G,B,W general linear dimmer, from
dark to brightness
2
General strobe
0-255
R,G,B,W general strobe, from slow to
fast
3
Function choose
0-50
51-100
101-150
151-200
201-255
8 DMX channel
Jump change
Fade change
Pulse change
Sound active
4
Function speed
0-255
Function speed, from slow to fast
07
06

USER MANUAL
24PCS OUTDOOR LED WALL WASH LIGHT
5
Red dimmer
0-255
Red linear dimmer, from dark to
brightness
6
Green dimmer
0-255
Green linear dimmer, from dark to
brightness
7
Blue dimmer
0-255
Blue linear dimmer, from dark to
brightness
8
White dimmer
0-255
White linear dimmer, from dark to
brightness
4 DMX Channels
CH
Function
DMX
Value
Description
1
Red dimmer
0-255
Red linear dimmer, from dark to
brightness
2
Green dimmer
0-255
Green linear dimmer, from dark to
brightness
3
Blue dimmer
0-255
Blue linear dimmer, from dark to
brightness
4
White dimmer
0-255
White linear dimmer, from dark to
brightness
Ⅷ. TECHNICAL SPECIFICATION
·Input voltage: AC90~240V, 50/60Hz
·Power consumption: 100W
·Light source: 24pcs 3W RGB 3in1 LEDs
·LED lifespan: 50,000hours
·Beam angle: 25degree
·Housing material: dia-casting aluminum
·IP rating: IP65
·Grey scale: 4096degree
·Working temperature: -25centigrade~+45centigrade
·Effect: 0~100% dimmer, strobe, color change, color fade, running effect
·Control mode: DMX mode, Auto mode, Master/slave mode, sound active
·DMX Channel: 8CH
