Vansco Pro Series User manual

Adhesive control requires a VANSCO PRO…
pro series
DIGI-TRACK
Speed Compensating, Distance Based
Electronic Adhesive Control System
Features…
- Two Independently
programmable Patterns
- Two separate
Outputs
- Selectable Stitch
option for each Pattern
- Automatic Latch-on
- 24 VDC Output
- Four Program storage
capacity in Non-Volatile Memory
- No battery back-up required
- 20 character by two line LCD Display Window
- On-screen Status Line
- Input and Output test routines simplify Installation and maintenance
- Program Security (“Access Code”) to protect Programs
- Single Cycle, Repeat Cycle, and No Pattern Cycle Modes of Operation
- Optional cable assemblies and optional plug-in connector kits for Outputs
VanSco Products-The Gluing Equipment Innovators
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
E-mail: [e-mail] • URL: www.vansco.com

Specifications…
Power: 115 VAC 50 or 60 Hz
INPUTS Sensor: 12 VDC current sinking (open
collector)
DC Output: 24 VDC, 1.5 amp total
Outputs Power for Sensor(s): 12 VDC, 0.250 amp total
Enclosure: 8” wide x 10” high x 4” deep
DIMENSIONS: Mounting Holes (4): 7” x 10.625,” 0.025 dia
Weight: approximately 11 pounds
PRO SERIES DIGI-TRACK
RESPONSE TIME:
From TRIGGER SIGNAL to start of PATTERN
CYCLE: Less than 1 millisecond
TOTAL RESPONSE TIME
PRO SERIES DIGI-TRACK response time plus
INPUT DEVICE response time
OUTPUT RESOLUTION:
+/- 0.1 inch from programmed START and STOP
settings
PATTERN RESOLUTION:
0.1 inch
MAXIMUM PATTERN
LENGTH:
99.9 inches
MAXIMUM OFFSET:
99.9 inches
STITCH ON/OFF LENGTH:
24.9 inches (maximum)
FLOW:
0-100 scale, no dimensions
LOW SPEED CUT OFF
(LSCO):
0-250 ft/min, 1 ft/min resolution
ON-DELAY, OFF-DELAY:
(speed compensation)
0-50.00 ms, 0.25 ms resolution
VanSco Products-The Gluing Equipment Innovators
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
E-mail: [e-mail] • URL: www.vansco.com

How It Works…
The PRO SERIES DIGI-TRACK requires two
inputs in order to function: A trigger signal to
start a pattern cycle, and a speed tracker
signal to provide product speed and distance
information. The triggering device (photo
sensor or limit switch) is mounted so that it will
detect the edge of a product at a point up
stream in the direction of product travel before
the application point. The speed tracker is
mounted so that its measuring wheel will
contact a part of the product or the parent
machine (such as a belt or
pulley) that will cause it to
rotate one complete
revolution per foot of
product travel.
On power-up, the PRO
SERIES DIGI-TRACK
performs an internal
diagnostic and reset routine,
which initializes the
hardware and insures that
the software is operating
successful completion of this routine, the PRO
SERIES DIGI-TRACK is ready to operate.
Pressing the run/stop button on the control
panel will put the PRO SERIES DIGI-TRACK in
run Mode, which allows a trigger signal to
begin a pattern cycle.
properly. On Y. Each pattern has
he PRO SERIES DIGI-TRACK constantly
selected by an operator. These corrections are
When a pattern cycle is started, the PRO
SERIES DIGI-TRACK begins counting pulses
received from the speed tracker. The pulses
measure the distance traveled. When the
pulse count corresponds to the “start at”
distance of a pattern (either or both pattern X
and pattern Y), the output selected for the
pattern is turned on. When the pulse count
corresponds to the “stop at” distance of a
pattern, the output is turned off. The pattern
cycle is completed when both pattern X and Y
have reached their “stop at” distance settings.
If the Repeat Cycle operation was selected, the
pattern cycle will start again, and continue to
repeat as long as the trigger signal is active. If
the no pattern cycle mode was selected,
patterns are not active; when a trigger signal is
received, the outputs will turn on and remain
on until the trigger signal is removed.
An offset value can be entered for both Pattern
X and Pattern Y. If
entered, this value is
added to both the “start
at” and “stop at” distances
to determine the pattern
turn on and turn of
distances. Stitch, if
selected, will superimpose
repeating on and off cycles
determined by stitch on
length and stitch off length
on Pattern X and Pattern
separate stitch enable and
length settings. Either pattern can be directed
to one, both, or neither output A and B. In
addition, either or both outputs A and B can be
disabled from the control panel.
T
monitors its speed and compares it to the
operator selected low speed cut off (lsco)
setting. If machine speed drops below lsco,
both outputs A and B are disabled until the
speed increases to above the lsco speed.
Turn-on speed and turn-off speed correction
factors are continuously generated during
DIGI-TRACK operation, based on the product
speed as sensed by the Speed Tracker, and the
values selected for on-delay and off-delay

applied to Pattern X and Pattern Y at the start signal. Increases and decreases in pressure
of each Pattern Cycle in order to maintain the
correct pattern length and position even if the
product speed varies.
During each pattern cycle, a servo signal is uto and manual operation may be selected
calculated based on product speed as sensed
by the speed tracker and the volume gain
selected by the operator. This signal is sent to
a servo controlled pump or servo controlled
fluid pressure regulator which raises and
lowers fluid pressure in direct proportion to the
increase and decrease the flow (volume) of
fluid. This results in a constant deposit of
adhesive even if machine speed varies.
A
for the servo signal. Auto functions as just
described. In manual, the servo signal is fixed
at a setting corresponding to the programmed
volume gain value, and will not vary as
machine speed varies.

The Vansco PRO SERIES Digi-Track….
…is a microproc system. It can
be used in any process, which requires precise accurate pattern placement at varying product
IES DIGI-TRACK incorporates two independently programmable patterns, X and Y,
hich can be directed singly or in combination to two outputs, A and B. Thus, single line, multiple
RACK includes routines to store and retrieve four different programs. A
ariable low speed cut off (lsco) to prevent flooding on the machine shut-down, adjustable speed
attern X and Y which rapidly cycles the
utput signal on and off. The result is dots or short lines rather than a continuous long line.
with a
rotective cover which also prevents unauthorized adjustment and tampering. The operator interface
y
indow is moved to view program variables such as pattern lengths. When the desired information
tines or procedures are
the job fast! Prewired electrical quick
essor driven, speed-compensating, distance based, electronic control
,
speeds, but it was specifically developed to control the output from valves used in adhesive
application systems. Examples of applications where the PRO SERIES DIGI-TRACK could be used
include business forms, collating, labeling, cartooning, and bag making. There are many other
applications.
The PRO SER
w
line, and the familiar “Pattern-Skip-Pattern” applications can easily be accomplished. In addition to
single cycle operation, a repeat cycle operating mode is provided which continues pattern cycle
output as long as the trigger signal is active, and a no pattern cycle operating mode for continuos
applications is available.
The PRO SERIES DIGI-T
v
modulated fluid volume, and variable start and stop compensation for a wide range of electric valves
are all standard features. Routines for testing the inputs and outputs, configuring for installation and
setup, and an access code security system are also provided.
An operator selectable stitch may be superimposed on both p
o
All controls and displays, except the power switch, are mounted inside a rugged enclosure
p
includes a sealed membrane switch control panel and a twenty character, two line display window.
Data entry is “thumb-wheel switch” simple. Using direction buttons on the control panel, the displa
w
is displayed, new data can easily be entered using data keys if required.
Engineered to “hook up and run”, no confusing hidden set up rou
required to get the PRO SERIES DIGI-TRACK on
connects for the TRIGGER INPUT DEVICE, SPEED TRACKER, and SERVO (and optionally
available for the OUTPUTS) mean trouble free installation and reliable operation.
VanSco Products-The Gluing Equipment Innovators
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
E-mail: [e-mail] • URL: www.vansco.com

A functional PRO SERIES DIGI-TRACK Installation should include at least
ne each of the following items:o
PRO SERIES CONTROLLER
45-20-21 Pro Series Digi-Track
DRIVER BOARD(S)
(One 95-06-38 DC Driver Board is included
95-06-38 Driver Board, DC
95-02-19 Driver Board, H/S Actuator
with the controller)
SPEED TRACKER 95-03-02 Speed Tracker, 1200 ppr
TRIGGER INPUT DEVICE
Photo Sensors and other electronic s
Mechanical Limit Switches
95-01-93 Reflective Phot
95-01-94 Photo Sensor Rec
Assembly
95-01-91 Reflective Photo Sensor Assembly, H/S
95-01-92 Fiber Optic
(appropriate Driver Boards required)
40-40-00 Applicator Valve Actuator
40-40-10 Applicator Valve Actuator
(Requires 95-06-38 Driver Board)
41-0X-XX Air Electric Control Assemb
(Requires 95-06-38 Driver Board)
20-02-05 VanSco Adhesive Pump, Basic SERV
REQUIRED (optional)
78-XX-XX Output Kits
95-02-40 9-wire Quick
95-02-43 9-wire Plug Kit
95-02-41 3-wire Quick Connect Kit
95-02-42 3-wire Plug Kit
r PHONE, FAX, or WRITE:
ensing devices, current
sinking (open collector)
o Sensor Assembly
eiver and Transmitter
Photo Sensor Assembly, H/S
ONE OR MORE SOLENOIDS OR
VALVES (Requires 95-02-19 Driver Board)
lies (DC)
ADHESIVE SUPPLY O Control
20-01-XX Fluid Pressure SERVO Regulator Assembly
CONNECTORS AND
CONNECTING CABLES AS 95-XX-XX Cable Assemblies
Connect Kit
For more information contact your local VanSco distributor,
o
2652 Lashbrook Avenue, South El Monte, California 91733
[phone] FAX [phone]

Y: STITCH OFF
0 TO 25“
Y: PAT TO OUT
A, B, Both, Neither
Y: OFF DELAY
0 to 50 ms
Y: ON DELAY
0 to 50 ms
Y: STITCH?
YES or NO
VOLUME GAIN
0 to 100
Change values while in RUN or
STOP mode, above this line.
Change values while in STOP
mode only, below this line.
YES
Y: OFFSET
0 to 99.9“
LSCO
000 TO 250
Y: START AT
0 to 99.9“
TEST OUTPUT A
ON or OFF
ALT ACCESS CODE
CURRENT CODE=???
TEST OUTPUT B
ON or OFF
VOLUME GAIN
0 to 100
CYCLE MODE:
SINGLE, REPEAT, NO PAT
Y: STOP AT
0 to 99.9“
TEST TRIGGER
ON or OFF
TRIGGER INPUT
NORMALLY OPEN/CLOSED
VOLUME MODE
AUTO or MANUAL
ACTIVE
A, B, Both
X: STITCH OFF
0 TO 25“
X: PAT TO OUT
A, B, Both, Neither
X: OFF DELAY
0 to 50 ms
X: ON DELAY
0 to 50 ms
X: STITCH?
YES or NO
YES
X: OFFSET
0 to 99.9“
X: START AT
0 to 99.9“
X: STOP AT
0 to 99.9“
X: PATTERN
Y: PATTERN
TEST
INPUT/OUTPUT
ERASE PROGRAM
1 to 4
SELECT PROG
1 to 4
STORED
PROGRAMS
DIGI-TRACK
SET UP
CONSTANTS
OUTPUT
SELECTION
X: STITCH OFF
0 TO 25“
Y: STITCH ON
0 TO 25“
VANSCO PRO SERIES
DIGI-TRACK Speed Compensating Control System
FLOW CHART
VANSCO
2652 LASHBROOK AVE
SOUTH EL MONTE, CA 91733
626-448-7611 FAX [phone]

95-03-04 SPEED TRACKER COMPONENT PARTS
4
910111213
17
1
15
16
3
8
14
7
5
6
2
PIN 1 = + VOLTAGE
PIN 2 = COMMON
PIN 3 = SIGNAL
ITEM PART NO. QTY DESCRIPTION
1 92-79-08 1 Top Clamp Half
2 92-79-10 1 Swing Arm
3 92-79-06 3 1/4" Dia. X 1" Pin
4 95-06-39 1 Encoder Assembly 1200 PPR
5 95-06-60 1 Measuring Wheel
6 90-06-12 2 1/4-20 X 1/4 Flat Head Screw
7 90-06-78 4 6-32 X 3/8 Flat Head Screw
8 95-06-62 1 Side Plate
ITEM PART NO. QTY DESCRIPTION
9 92-79-00 1 Adjustment Lock
10 92-79-01 1 Adjustment Nut
11 90-03-06 1 Spring
12 92-79-03 1 Spring Retainer
13 92-79-04 1 Teflon Washer
14 92-79-05 1 Swing Bolt
15 92-79-09 1 1/4"-20 X 20mm Adj. Lever
16 90-07-59 1 1/4" S.S. Flat Washer
17 92-79-07 1 Bottom Clamp Half
Distributed By:
GCC1000
VanSco Products-The Gluing Equipment Innovators
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
E-mail: [e-mail] • URL: www.vansco.com
TECHNICAL DATA
INPUT:
12VDC, 0.1A
PULSES PER SHAFT ROTATION:
1200
SHAFT DIAMETER:
.375 Inches
SHAFT ROTATION:
Bi-directional
MEASURING WHEEL CIRCUMFERENCE:
12 Inches
OPERATING LIFE:
89,000 Hours (average)
TYPICAL SYSTEM DIAGRAM
79-03-16
(BRACKET ONLY)
3-WIRE CABLE ASSEMBLY
PRO SERIES
DIGI-TRACT USE
95-02-70 5 FEET
95-02-69 10 FEET
95-02-68 15 FEET
PRO SERIES
MICRO-TRACK USE
95-08-77 10 FEET
95-08-80 20 FEET
PRO SERIES
CONTROLLER
(ORDERED SEPARATELY)

Speed Tracker Installation 95-03-04
SPEED TRACKER WHEEL
FOLDER/GLUER BELT
CORRECT WRONG WRONG
Figure 1
Installing the Speed Tracker on the Belt of a Folder/Gluer
Speed Tracker Installation
Install the Vansco Speed Tracker to a Folder/Gluer as shown in the example (Figure 1) above.
Mount the Speed Tracker so that the wheel is on the center of the belt and positioned close to but
not pressed against the opposing wheel for best traction.
VanSco Products-The Gluing Equipment Innovators
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
E-mail: [e-mail] • URL: www.vansco.com

95-01-91 95-01-92 95-01-93 95-01-94
PHOTO SENSORS
SPECIFICATIONS
SUPPLY VOLTAGE: +10VDC to +30VDC (10%
maximum ripple), at less than 25mA.
OUTPUT CONFIGURATION: current sinking (NPN)
open-collector transistor.
OUTPUT RATING: 150mA maximum each output at
25°C, derated to 100mA at 70°C. Output leakage
less than 1 microamp (off-state).
OUTPUT PROTECTION: protected against false
pulse on power-up, inductive load transients, power
supply polarity reversal, and continuous overload or
short-circuit of outputs.
OPERATING TEMPERATURE RANGE: -20° to
+70°C (-4° to +158°F).
ADJUSTMENTS: LIGHT/DARK OPERATE select
switch, and 15-turn slotted brass screw GAIN
(sensitivity) adjustment potentiometer (clutched at
both ends of travel). Both controls located on rear
panel of sensor and protected by a gasketed, clear
acrylic cover on the 95-01-91 and 95-01-92 models
only.
INDICATOR LED: an alignment indicating device
system lights a rear-panel mounted red LED indicator
whenever the sensor sees a "light" condition, with a
superimposed pulse rate proportional to the light
signal strength (the stronger the signal, the faster the
pulse rate).
CABLE: PVC-jacketed 3-conductor cable (6' length)
standard.
How To Order
PART No. DESCRIPTION RESPONSE TIME
95-01-91 Reflective Photo Sensor H/S 1 millisecond
95-01-92 Reflective Photo Sensor, Fiber Optic, H/S 1 millisecond
95-01-93 Reflective Photo Sensor 2.5 milliseconds "on"; 1.25 milliseconds "off"
95-01-94 Emitter/Receiver Photo Sensor 3 milliseconds
VanSco Products-The Gluing Equipment Innovators
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
URL: www.vansco.com • E-mail: [e-mail]

95-01-91 95-01-92 95-01-93 95-01-94
DIMENSIONS & COMPONENT PARTS
ITEM No. PART No. DESCRIPTION
1 95-02-42 3-Wire Plug Kit
2 95-06-16 Circular Plug, 4-Pin
3 95-06-22 Barrel Socket, 20-24 Ga.
4 95-06-18 Strain Relief
ITEM No. PART No. DESCRIPTION
5 95-08-42 Fiber Optic
6 95-07-35 Swivel Mount
7 95-07-34 Bracket
8 95-06-24 Barrel Socket, 14 Ga.
WIRING NOTES:
1. Pin 4 in Circular Plug is not used.
2. Wiring for 95-01-91, 95-01-92 and 95-01-93:
Pin 1-Brown ... +10 to +30VDC
Pin 2-Blue ... Common
Pin 3-*White ... Signal
*(Black 95-01-93 only)
3. Wiring for 95-01-94:
Pin 1-Brown from Emitter and Receiver ... +10 to +30VDC
Pin 2-Blue from Emitter and Receiver ... Common
Pin 3-White from Receiver ... Signal
4. Barrel Socket used in 95-01-94: Pin 1 & 2 uses
95-06-24; Pin 3 uses Barrel Socket 95-06-22.
GBR199
INTERNATIONAL HEADQUARTERS
2652 Lashbrook Avenue • South El Monte, CA 91733 • 626-448-7611 • Fax [phone]
Sales and service offices world wide
