Vantage Hearth VV-SA300K-GSK2 User manual

The product is a voice GSM home / commercial burglar alarm system,
combined with advanced GSM digital signal processing technology and GSM
wireless mobile intelligent control function. It is highly integrated with digital
voice, wireless coding, remote control of home appliances, SMS recognition
and other technologies. When the system alarms, it can send messages &
alarm with voice prompt. Stable, reliable, safe, and user-friendly
manipulation. The six LED lights on the host can indicate the alarm zones.
Can connect with PIR, door contacts, smoke detectors, gas detectors,
emergency buttons and other accessories. Widely used in houses, factories,
schools, shops, stores, offices, villas, etc.
Chapter 1 Introduction
1.1 System Introduction
Chapter 1 Introduction
(1)
■Strong GSM wireless signal & voice prompts, easy to operate.
■The host has 6 zones, 4 zones wireless/wired optional, 2 zones wireless
only. There are 5 types optional in each zone, normal zone, stay zone,
intelligent zone, emergency zone and closed zone.
■Two groups of auto arm/disarm settings available; each group can choose
activated days of a week to realize the intelligent automatic control.
■With GPRS networking function, the host state can be uploaded to the
networking alarm center; the host can also be controlled through APP.
■It can be connected with a large-scale center machine and is compatible
with the international contact ID protocol for alarm networking.
■The password is divided into the system password and the user password.
Enter the system password to use all the functions of the host. Enter the
user password to use the functions except system settings.
■Phone (cell phone) or SMS can remote control system settings of hosts.
■The host can be set and controlled by APP, supporting IOS/Android.
■6 groups of phone alarm phone number, 3 groups of SMS alarm number.
External AC power outage information will be informed to 9 groups of
number.
■10 seconds customized automatic message recording can be heard in the
phone when there is alarm. Together with built-in artificial voice, the user
can know the location and the zone no..
■With remote monitoring & propaganda function, users can change
arm/disarm state of the host by remote calls or text messages.
■A group of wireless signal linkage alarm output to remote control
■Using quad-band GSM / GPRS module.
1.2 Features

Chapter 1 Introduction
(2)

■A group of wired alarm signal linkage, users can customize the output
 mode to remote control them.
■Users can remote control 5 smart sockets via phone calls or SMS.
■Wireless accessories adding & fast and easy code matching, the host is
compatible with 1527 and millions of groups coding. It can add 50 remote
controls and 50 detectors.
■Built-in rechargeable high-capacity battery as standby battery when
power off. After power failure the host will automatically alarm .
Chapter 2 Instruction
Chapter 2 Instruction
Arm state is used when users want to activate all detectors, for example
users go out from home. When there is anything (theft, fire, gas leaks, etc)
that activate detectors, the system will immediately alarm. Short press【 】
on the back of the host to switch the state among arm, stay home, and
disarm. In arm state, the light of arm state will be long lit.
Remote control operation: press [arm] of the remote control once.
2.1 Arm
Stay Home is used when users want to activate part of detectors, for
example, when the user is at home, he/she wants to activate the sensors
outdoors, but to deactivate the sensors indoors. In this situation, users can
change the state to stay home to activate indoor sensors and deactivate
outdoor sensors.
Stay Home function needs to be set. Users need to set the zone type of
indoor sensors to stay zone to use this function. Press【 】on the back of
the host to change the state. When the host is in stay home state, the light of
arm state will flash.
Remote control operation: press [stay home] of the remote control once.
2.2 Stay Home
Disarm is used to stop the alarm or make the host in non-alert state. Trigger
detectors in disarm state, the host won't alarm (except the detectors in
emergency zone and emergency button on remote controls). Press【】on
the back of the host to disarm the host. When the host is in disarm state, the
light of arm state will extinguish.
Remote control operation: press [disarm] of the remote control once.

2.3 Disarm

(3)
Chapter 2 Instruction
When an emergency occurs, press the emergency key on the remote control
to make the host alarm.
2.4 Emergency
Disarm Arm
Stay Home Emergency
The host should be installed in the center of the monitoring area to achieve
the best receiving signal range of all wireless detectors. Avoid installing the
host near large metal objects, household appliances with high frequency
interference, barriers such as reinforced concrete walls and fire doors.
2.5 Installation
Host front view:
123456
Host back view:
Anti-tamper switch
SIM slot
Wired signal linkage
Wired zone
Power output terminals
Power su ppl y
hole
Siren h ole

(4)
Chapter 2 Instruction
Host side view:
Host back view:
34 5 612V
GND
COM
NO
Light bulb
220V AC
Wired door s ens or
Wired Infrare d sen sor
Siren
Power supp ly
SetArm/Disa rm
Tra nsm it
2.6 Prompt
Explanation
Function Prompt
Built-in speaker
Voice prompt
"Beep" once
"Beep" twice
"Dong" once
Key pressing prompt/adding same remote
controls or detectors again/quit the adding state
Voice prompts for each function and status
Mistake
Add accessories successfully
Arm light
Extinguish
Long lit
Fast flash
Slow flash
The host is in disarm state
The host is in away arm state or recording state
The host is in stay home state
The host is in delay arm state
Zone light
Light of a zone
flashes
Lights of six
zones stay lit
Light of a zone
stay lit
The host is in remote control adding state or in the
selection state of siren in 0 zone
The zone is in delay alarm state
The zone alarms or enter a signal selection state
GSM signal light
Fast flashing
Flash every
second
Flash every 3
seconds
GPRS network is normal working state
GSM signal is weak or without SIM card insertion
GSM signal and SIM card work normally

(5)
Chapter 3 System Settings
Chapter 3 System Settings
3.1 First Power On
According to the installation method, insert SIM card into SIM card slot on the
back of the host. Then plug the adapter output into the power hole or long
press【 】on the side of the host. The host will appear voice prompt
"Welcome"; then the host begins to search GSM network with GSM signal
light flashing every second. When GSM network is normal, GSM signal light
flashes every 3 seconds to prompt that GSM network and SIM card work
normally. If the GSM signal light is blinking constantly, it means there is no
SIM card or SIM card doesn't work.
3.2 Alarm Message Recording
When the host dials the preset number during alarm, it will play the
prerecorded sound recording. The method to set the recording: long press
【 】for 3 seconds, the host will beep once, and the arm indicator light will
be on; there will be the voice prompting "recording", then users can record
their voice. Recording should be concise, such as "This is XXX, my house
was illegally intruded, please help." The host will automatically record for 10
seconds and then will automatically quit the recording state. Short press
【 】to quit the recording state in advance.
3.3 Add Remote Controls
Short press【 】，when the indicator lights of six zone stay lit with voice
prompt "add remote control", the host has entered the adding state of remote
controls.
Trigger remote controls. If the host beeps twice with voice prompt "add
successfully", remote controls are added successfully; if the host beeps
once, the remote control has been added to the host before. When in adding
state, short press【 】to go back，and short press【 】to quit the adding
state (all indicator lights extinguish). The host can add 50 remote controls at
most.
3.4 Delete Remote Controls
Short press【 】,when the indicator lights of six zone stay lit with voice
prompt "add remote control", the host has entered the adding state of remote
controls. Long press【 】for 3s, after the host beeps twice and all the
indicator lights extinguish, all the remote controls are deleted.

(6)
Chapter 3 System Settings
3.5 Add Detectors
Short press【 】,indicator lights of six zones will stay lit to prompt that the
host enters remote control adding state. Press【 】again, the indicator light
of zone 1 will be lit to prompt that the host enters the adding state of zone 1.
Then trigger detectors, if the host beeps twice with the voice prompt "add
successfully", the detector has been added into zone 1 successfully; if the
host beeps once, the detector has already been added into the host before.
Then short press【 】once to enter the adding state of zone 2 with the
lightened zone 2 indicator light. Short press【 】to enter the adding state of
zone 3,4,5,6. When the host is in the adding state of zone 6, short press
【 】,the host will beep twice and all the indicator light will extinguish,
which means the host has exited the adding state.
Note: When in adding state, press【 】to go back, and press【 】to quit
the adding state. If a zone is in adding state, its indicator light will be lit. The
host can add 50 detectors at most. 50 detectors can be added to the same
zone or six zones separately.
3.6 Delete Detectors
Delete detectors in zone 1:short press【 】twice, the indicator light of zone
1 will be on. Long press【 】for 3s, when the host beeps twice, all the
detectors in zone 1 are deleted.
Delete detectors in zone 2:short press【 】3 times, the indicator light of
zone 2 will be on. Long press【 】for 3s, when the host beeps twice, all the
detectors in zone 2 are deleted.
Delete detectors in zone 3:short press【 】4 times, the indicator light of
zone 3 will be on. Long press【 】for 3s, when the host beeps twice, all the
detectors in zone 3 are deleted.
Delete detectors in zone 4:short press【 】5 times, the indicator light of
zone 4 will be on. Long press【 】for 3s, when the host beeps twice, all the
detectors in zone 4 are deleted.
Delete detectors in zone 5:short press【 】6 times, the indicator light of
zone 5 will be on. Long press【 】for 3s, when the host beeps twice, all the
detectors in zone 5 are deleted.
Delete detectors in zone 6:short press【 】7 times, the indicator light of
zone 6 will be on. Long press【 】for 3s, when the host beeps twice, all the
detectors in zone 6 are deleted.

(7)
Chapter 3 System Settings
3.7 Program Wireless Strobe Siren, Smart Socket and Alarm
Linkage Switch
Short press【 】to enter signal transmitting state. Short press【 】to
transmit signals, and short press【 】to quit the state. When the host is in
signal transmitting state, there are 7 kinds of signal can be selected:
Zone 0
Zone 1-5
Zone 6
Wireless strobe siren signal
Smart socket signal
Alarm linkage signal
Smart socket Strobe siren
3.7.1 Program Siren
1. Long press [SET] on the siren for 3 seconds.
2. Short press 【 】on the host. All lights will be on at the same time with
voice prompt "0", showing signal 0 is in control.
3. Short press 【 】on the host. The host will send a signal to the siren. If
programmed successfully, the host will beep twice.
4. Short press [SET] on the siren to exit the programming status.
After programming, short press【 】on the host to activate the siren with
voice prompt "0 on". Short press it again to inactivate it with voice prompt "0
off"

(8)
Chapter 3 System Settings
Corresponding reaction of the siren to the host:

Beep twice
Host Siren
Alarm Alarm
Arm Beep once
Disarm
3.7.2 Program Smart Socket
1. Long press the smart socket for 5 seconds
2. Short press 【 】on the host. All lights will be on at the same time with
voiceprompt "0", showing signal 0 is in control. Short press 【 】again to
control signal 1. Zone1 indicator light will be on with voice prompt "1".
3. Short press 【 】on the host to send a signal. If programmed
successfully, the light of smart socket will flash once.
When the host is in signal control status, short press【 】to switch on or off
of the smart socket. For example, signal 3 is in control. Short press 【 】to
switch on/ off the socket with voice prompt "3 on/ off". When the signal is not
in control, the socket cannot be controlled by any button (except SMS
settings).
3.7.3 Program Wireless Alarm Linkage Relay
1.Make signal 1 in control.
2.Short press【 】five times to control signal 6.
3. Short press【 】to send a signal. If programmed successfully, the light of
wireless alarm linkage relay will flash once. Short press【 】then to exit
status of sending signals and the host will beep twice with all lights off (For
details, please refer to the manual of smart socket).
When signal 6 is in control, short press 【 】to close the relay with voice
prompt "6 on"; short press it again to open it with voice prompt "6 off".
When the host raises the alarm, the wireless alarm linkage relay in Zone 6
will close automatically. Ant it will be opened when the host disarms.
Notice: 1-6 groups all are smart sockets. The sixth group is the wireless
alarm linkage relay as well. It will close or open automatically along with the
status of alarm. 1 -5 groups of smart sockets are switched on/ off manually.

(7)
Chapter3󴘐SystemSettings
3.8 Command List for Remote Setting by Phone
Remote setting by phone is available.
For example, changing the voice alarm number of the first group to
13899998888 by method below:
1. Call the host's number.
2. Enter the system password (factory default is 123456).
3. Input "#" and the host will speak "Set", showing the remote setting is
available.
4. Input "8113899998888#" and then set the host according to the command
list below.
5. Press "*" to exit.
1. Set a voice alarm number
Steps:
【8】+【1-6】+【number】
+【#】
[1-6] refer to the first group to the sixth group of
voice alarm numbers.
Method:
1. Call the host's number.
2. Enter the system password (factory default is
123456).
3. Input "#" and the host will speak "Set", showing
the remote setting is available.
4. Input "8113812345678#". If set successfully, the
host will speak "Set successfully".
5. Press "*" to exit.
Notice:
When user input a number for remote setting, the
host will speak the number. If it speaks incorrectly,
the setting is incorrect.
In the case of an extension number, number input
step should be "8113812345678 + * + extension
number". One * means 1 second interval while two *
means 2 seconds interval.
(9)
2. Delete a voice alarm
number
Steps:
【8】+【1-6】+【#】
Example: delete the first group of voice alarm
number
Method:
Call, enter remote setting status, then input "81 #".
Steps:
【9】+【1-3】+【number】
+【#】
3. Set a SMS alarm number The host will send messages to the three groups
of SMS alarm numbers.
Example:set 13812345678 as the first group SMS
alarm number.
Method:Call, enter remote setting status, then
input "9113812345678 #".
Chapter 3 System Settings
Steps:
【9】+【1-3】+【#】
4. Delete a SMS alarm
number
Example:delete the first group SMS alarm number.
Method:Call, enter remote setting status, then
input "91#".
