Vantech P3051S User manual

Part # QUANTITY
D102 1
P131/P132S 2
A416S 4
P013S 4
A286-65S 2
G313 4
Z286 4
A20 4
Warehouse Use Only
Part #: P3051S
Dimensions: 8” X 8” X 66” (Telescopic)
Weight: ???
S

PRODUCT INFO
Part #: P3051S
System: P3000
Material: Aluminum
Fitment: Pickup (Drilling Required)
Color: Silver
REQUIRED TOOLS
9/16” Wrench
Marker
MARKER
3/16” Allen Key Wrench
7/32” Allen Key Wrench

PART # DESCRIPTION QTY ITEM
ITEM NOT DRAWN TO SCALE
S101 3/8” SINGLE SLIDER (LENGTH 1”) 4
S103 3/8” DOUBLE SLIDER 3” 4
B080 3/8” X 1 1/2” HEX BOLT 8
B167 5/16” X 1 1/2” COUNTERSUNK BOLT 4
B177 3/8” X 3/4” COUNTERSUNK BOLT 8
N003 3/8” NUT 24
N015 5/16” KNOB SMALL 4
W008 5/16” X 3/4” WASHER 4
W013 3/8” X 3/4” WASHER 32
W023 3/8” LOCK WASHER 24
P131 ADJUSTABLE” UPRIGHT L 2
P132 ADJUSTABLE” UPRIGHT R 2
A416 ADAPTOR PLATE 4
P013 ANGLED BRACE 4
A286-65 3” X 1.5” X 65” CROSS BAR 2
G313 2” X 13” GASKET 4
Z286 A286 ENDCAPS 4
A20 ADJUSTABLE LADDER GUIDE 4

SECURE BOLTS
G313
B177
A416
A416
G313
B167
N015
W008
B177
Press to
adjust
Press to
adjust

S101
S101
A286
S103
S103
Z286
Do not secure hardware
S101
S103
W013
W023
N003

W013
S101
W023
P013
N003
-After adjusting the cross bar and uprights to align correctly
and centered tightly secure all hardware.
A20
MARKER
MARKER
MARKER
MARKER
N003
W023
W013
W013
B080
