Vapormed Mighty Plus MEDIC User manual

INSTRUCTIONS FOR USE
Read carefully before using the device
and save these instructions.

2
Table of Contents.......................................................................................Page
1 MIGHTY+MEDIC .......................................................................................5
1.1 Scope of Delivery.........................................................................5
1.2 Functional Elements...................................................................6
1.3 Cooling Unit...................................................................................7
1.4 Operating life .................................................................................7
1.5 Service............................................................................................7
2 For your Safety .......................................................................................... 8
2.1 Explanation of Symbols MIGHTY+MEDIC ............................8
2.2 Explanation of Symbols of the USB Charger.........................9
2.3 Legend.......................................................................................... 10
2.4 Basic Rules.................................................................................. 10
2.5 Safety Recommendations .......................................................11
2.5.1 Risk of Injury due to electric Shock ........................11
2.5.2 Danger of Injury due to Burning/Vapors .............. 12
2.5.3 Risk of Injury due to various Causes..................... 12
3 Intended Use, Side Effects, Contraindications ............................ 13
3.1 Intended Use............................................................................... 13
3.2 Side Effects................................................................................. 13
3.3 Contraindications...................................................................... 13
4 Important Information about Cannabinoids ................................14
5 Commissioning and Operation........................................................... 15
5.1 Storage and Transport Conditions........................................ 15
5.2 Unpacking ................................................................................... 15
5.3 Operating Conditions ............................................................... 15
5.4 Battery ......................................................................................... 16
5.4.1 Basic Explanation of the
Battery Charge Display ............................................. 16
5.4.2 Charging the Battery ................................................. 16
5.4.3 Explanation of the Battery Charge Display
during Charging
(depending on the Charger used) .......................... 16
5.4.3.1 Charging with the USB Charger ............. 16
5.4.3.2 Quick Charge
(if supported by the Charger) ................. 16
5.4.3.3 Charging with a low Power Charger ......17
5.4.4 End of the Charging Process....................................17
5.5 Mains Operation
(only possible with USB-C Supercharger)............................17
5.6 Herb Mill....................................................................................... 18
INSTRUCTIONS FOR USE ENGLISH

3
INSTRUCTIONS FOR USE ENGLISH
Table of Contents ...................................................................................... Page
5.7 Dosing Capsule (for single Use) and Magazine ..................18
5.7.1 Filling the Dosing Capsule with the Aid of
the Magazine Cap .......................................................18
5.7.2 Filling the Magazine with Dosing Capsules..........19
5.7.3 Inserting the Dosing Capsule into the
Filling Chamber............................................................19
5.8 Heating Up ................................................................................. 20
5.8.1 Display .......................................................................... 20
5.8.2 Default Settings ......................................................... 21
5.8.3 Switching on................................................................ 20
5.8.4 Base Temperature...................................................... 20
5.8.5 Booster Temperature................................................ 20
5.8.6 Superbooster Temperature..................................... 21
5.8.7 Celsius/Fahrenheit .................................................... 21
5.8.8 Reset to Default Settings ........................................ 22
5.9 Inhalation..................................................................................... 22
5.10 End of Inhalation........................................................................ 22
5.11 Disposal of the Dosing Capsules........................................... 23
5.12 Automatic Switching Off ......................................................... 23
5.13 Storage ........................................................................................ 23
6 Cleaning/Hygiene .................................................................................. 24
6.1 Mouthpiece................................................................................. 24
6.2 Cooling Unit ................................................................................ 24
6.2.1 Disassembling the Cooling Unit ............................. 24
6.2.2 Cleaning the Cooling Unit and
Filling Chamber Screen ............................................ 26
6.2.2.1 Cleaning the Cooling Unit and
the Filling Chamber Screen with
rinsing Water............................................... 26
6.2.2.2 Cleaning the Cooling Unit and
the Filling Chamber Screen with
Isopropyl Alcohol....................................... 26
6.2.3 Check the Cooling Unit Parts and
the Filling Chamber Screen ..................................... 27
6.2.4 Assembling the Cooling Unit................................... 27
6.3 Filling Chamber.......................................................................... 28
6.3.1 Cleaning the Filling Chamber .................................. 28
6.3.2 Removing the Screen................................................ 28
6.3.3 Installing the Screen.................................................. 28

4
INSTRUCTIONS FOR USE ENGLISH
Table of Contents....................................................................................... Page
6.4 Cleaning the Vaporizer, the USB Charger
and the USB-C Cable ................................................................ 28
6.5 Cleaning the Herb Mill and
Magazin for Dosing Capsules ................................................ 29
7 Optional Accessories ............................................................................ 30
8 Faults.......................................................................................................... 31
8.1 Possible Faults / Troubleshooting ........................................ 31
8.2 Disposal ....................................................................................... 31
9 TechnicalSpecications ..................................................................... 32
9.1 MIGHTY+MEDIC Vaporizer.................................................... 32
9.2 USB Charger ............................................................................... 32
9.3 Technical Requirements for suitable Chargers ................. 32
9.4 Information on Electromagnetic Compatibility ................. 32
10 Compliance with legal and normative Requirements ................. 33
11 Warranty, Liability, Copyright.............................................................. 34
11.1 Warranty ...................................................................................... 34
11.2 Liability ........................................................................................ 34
11.3 Copyright..................................................................................... 34

5
1 MIGHTY+ MEDIC
1.1 Scope of Delivery
1 MIGHTY+MEDIC Vaporizer
2 1 pc. USB Charger
3 1 pc. USB-C Cable
(USB Type C to USB Type A Plug)
4 3 pcs. Normal Screen, small
3 pcs. Coarse Screen, small
5 3 pcs. Base Seal Ring, small
61 pc. Magazine with
8 Dosing Capsules
7 1 pc. Herb Mill
81 pc. Cleaning Brush
9 1 pc. Instructions for Use
4
1
6
5
9
8
3
2
7

6
1 MIGHTY+MEDIC
1.2 Functional Elements
9
10
4
3
5
1
2
11
6
7
8
1 Filling Chamber
2 Mouthpiece
3 Actual Temperature Display
4 Plus Temperature Button
5 USB-C Charging Socket
6 Set Temperature Display
7 Battery Charging Display
8 Filling Chamber Tool
9 ON/OFF Switch
10 Minus Temperature Button
11 Cooling Unit

7
1.4 Operating life
The MIGHTY+ MEDIC Vaporizer has an average expected operating life of:
approx. 1,000 operating hours
approx. 5 years
The batteries have an average expected operating life of
approx. 500 operating hours
approx. 2 years
1.5 Service
XIn case of incomplete delivery, technical problems, questions about the
device and its disposal, replacement of the batteries and in warranty ca-
ses please contact our Service Center:
Storz & Bickel GmbH
Service Center
In Grubenäcker 5-9
78532 Tuttlingen, Germany
Tel.: [phone] · e-mail: [e-mail]
XFor service requests, start an RMA (Return Merchandise Authorization)
process via our homepage: www.vapormed.com/rma.
1
3
2
8
7
6
5
4
1Cap Lock
2Mouthpiece
3Mouthpiece Seal Ring
4Cooling Unit Cap
5Base Seal Ring (small)
6Cooling Unit Base
7Screen (coarse Mesh width)
8Base Seal Ring (large)
1.3 Cooling Unit
1 MIGHTY+MEDIC

2.1 Explanation of Symbols MIGHTY+MEDIC
The Vaporizer is protected by an angle of 15° against dropping
water (IP 22). The Vaporizer should nevertheless be protected
against moisture and rain. Do not use in the bathroom or above
water.
EU conformity symbol: A 4-digit number after the CE marking
indicates that a notied body is involved in the conformity
assessment procedure.
0123
REF Symbol for order number - followed by the order number of the
corresponding medical product (or part)
Safety tested and production monitored by TUEV SUED accor-
ding to IEC 60601-1, CAN/CSA C22.2 No. 60601-1 and ANSI/
AAMIES 60601-1.
Safety Category II device
Please follow these instructions carefully!
(according to IEC 60601)
Symbol for the manufacturer - the manufacturer‘s name and
address are next to the symbol
The medical product was introduced after 13 August 2005. The
product may not be disposed of in normal household waste. The
X on the trash can indicates the necessity of disposing of this
product separately. The Vaporizer contains a built-in rechargeab-
le lithium-ion battery that must be discharged before disposal.
Symbol for serial number - followed by the serial number of the
medical product
ON/OFF Switch
IP 22
Caution! Hot surfaces!
Do not touch metal parts!
8
2 FOR YOUR SAFETY

Temperature limits of ambient temperature
Application Part Type BF
The class “BF” (Body Float) applies to medical devices
(application parts) that come into direct contact with the patient.
UL Recognized Component Mark: This symbol indicates that the
corresponding devices are listed by UL.
Safety Category II device
Air pressure limitation
Intermittent operation
INT:
7 on/30 off
Humidity limitation
2.2 Explanation of Symbols of the USB Charger
Interference may occur in the vicinity of equipment marked
with the following symbol.
Safety tested and production monitored by TUEV SUED
according to EN 60335-1.
Protect from direct sunlight.
Protect against moisture and humidity.
9
2 FOR YOUR SAFETY

Restriction on the use of certain hazardous substances in
electrical and electronic equipment
Eciency Level 6
Eciency of USB Charger
Symbol for FCC declaration of conformity
(electromagnetic interference approval in the USA)
DC (direct current)
10
2.3 Legend
Bullet points
XOperating instructions
ÖResult
2.4 Basic Rules
XThese Instructions for Use must be kept for future reference. They are
an integral part of the Vaporizer and must be made available to the user.
XDownload the current version of the Instructions for Use from
www.vapormed.com.
XRead these instructions carefully and completely before operating the
Vaporizer, USB Charger and USB-C Cable.
XAlways follow the instructions in these Instructions for Use when using
and servicing the device.
XThe Vaporizer is not intended for use with children and adolescents un-
der 18 years of age. Adults may use the Vaporizer in accordance with the
instructions for use or a physician‘s instructions.
XIf the user is suffering from respiratory tract or lung disease, the device
may only be used after consultation and with the consent of the treating
physician. Depending on their density, the vapors may irritate the respira-
tory tract and lungs, which may cause coughing.
XDo not operate the Vaporizer unattended.
XStore and use the Vaporizer, USB Charger and USB-C Cable only at
a sufficient distance from heat sources (oven, stove, fireplace, etc.)
and in a dry place where the ambient temperature cannot drop below
+5 °C (+41 °F).
2 FOR YOUR SAFETY

11
2 FOR YOUR SAFETY
XDo not expose Vaporizer and USB Charger to extreme uctuations in
ambient temperature. Condensation humidity could interfere with the
functionality.
XUse of accessories, transducers and cables other than those specied or
provided by the manufacturer of this equipment could result in increased
electromagnetic emissions or decreased electromagnetic immunity of
this equipment and result in improper operation.
XOnly use original Storz & Bickel accessories and spare parts.
XDo not use the Vaporizer, USB Charger and USB-C Cable improperly, in-
correctly or unreasonably, as the manufacturer accepts no responsibility
for any damage resulting from this.
2.5 Safety Recommendations
2.5.1 Risk of Injury due to electric Shock
XThe Vaporizer, USB Charger and USB-C Cable must be switched off and dis-
connected from the power supply after use, before any maintenance work
and during thunderstorms.
XMake sure that the USB-C Cable is not damaged by bending, crushing
or pulling.
XDo not use multiple sockets and/or extension cables. Where absolute-
ly necessary, use only products with a quality certificate (e.g. UL, IMQ,
VDE, +S, etc.) if the stated power value exceeds the power requirements
(A=Ampere) of the connected devices.
XDo not use the Vaporizer, USB Charger and USB-C Cable if they are dam-
aged. Repairs may only be carried out by our Service Center. Attempting
to repair damage yourself will invalidate the warranty. Our Service Center
will replace a defective USB Charger or USB-C Cable.
XThe Vaporizer, USB Charger and USB-C Cable must not be exposed to
moisture and humidity.
XKeep the Vaporizer, USB Charger and USB-C Cable away from pets (e.g.
rodents) and pests.
XDo not use the Vaporizer, USB Charger and USB-C Cable in a potentially
explosive or flammable atmosphere.
XThe Vaporizer is radio interference suppressed according to DIN EN
60601-1-2. Radiation-emitting devices (e.g. mobile phones) should not
be operated in the immediate vicinity of the Vaporizer. In case of doubt,
please consult qualied personnel. This spark suppression/EMC is only
valid in connection with our certied Chargers.

12
2 FOR YOUR SAFETY
2.5.2 Danger of Injury due to Burning / Vapors
XDo not touch hot surfaces of the Vaporizer (Filling Chamber) during oper-
ation and the cooling phase.
XOnly use the Vaporizer with the Cooling Unit attached.
XPlace the hot Vaporizer only on a solid and heat-resistant surface and
make sure that it is not covered.
XDo not use the Vaporizer and USB Charger near inflammable objects
such as curtains, tablecloths or paper.
XDo not close, cover or obstruct the openings of the Vaporizer during op-
eration and the cooling phase.
XBefore switching on the Vaporizer, ensure that all vapors, e.g. from flam-
mable cleaning agents and disinfectants, have evaporated.
2.5.3 Risk of Injury due to various Causes
XA medical examination must always be carried out before treating ill-
nesses.
XBe careful that small parts of the Vaporizer are not swallowed.
XBe aware of the danger of strangulation through the USB-C Cable.
XMonitor your symptoms (e.g., cough, shortness of breath, chest pain)
during or after the usage and promptly seek medical attention if you have
concerns about your health.

13
3.1 Intended Use
The Vaporizer is intended for vaporizing and then inhaling cannabinoids from
hemp owers (cannabis os).
The goal is the application of the active ingredients in the human body via the
alveoli for the appropriate medical indication.
It is suitable for the temporary inhalative application of cannabinoids pre-
scribed by a physician for use at home, in a hospital, or doctor‘s oce.
3.2 Side Effects
There are no known side effects from using the device.
There are no contraindications specic to the device.
3.3 Contraindications
However, if the user is suffering from respiratory tract or lung disease, the de-
vice may only be used after consultation and with the consent of the treating
physician. Depending on the density, the vapors can irritate the respiratory
tract and lungs, which can lead to coughing ts.
3 INTENDED USE, SIDE EFFECTS,
CONTRAINDICATIONS

14
4 IMPORTANT INFORMATION ABOUT
CANNIBOIDS
The Vaporizer ensures the highly effective, safe, and fast-acting application
of cannabinoids.
At a certain dosage, cannabis can have a psychotropic (mind-altering) effect.
Thus, there is a potential for abuse, which governments in nearly all countries
of the world counteract with corresponding laws.
XOnly use hemp owers (Cannabis os) prescribed by a doctor and availa-
ble from a pharmacy. Otherwise, there is a risk of conict with the law.
XAsk your doctor, pharmacist or, if necessary, the responsible authorities
for information about the current legal situation at your place of resi-
dence.
Currently, patients in practically all countries, which allow the use of hemp
owers for medical purposes, get a prescription of a certain amount of dried
hemp owers. These hemp owers are delivered either as whole pieces or
already ground and have to be portioned and weight out by the patient ac-
cording to the doctor‘s directive. In case the hemp owers are not ground,
they have to be ground with the included Herb Mill rst.
Cannabinoids vaporize at temperatures over 180 °C (356 °F) and then form
an aerosol with an average droplet size (MMAD) of 0.64 µm (micrometer) that
can be inhaled and respired. The droplets are absorbed in the alveoli and enter
the bloodstream (systemic absorption).
XIf you have any questions about the medical use of cannabinoids or can-
nabis, contact your doctor, pharmacist or the manufacturers of medical
hemp owers (Cannabis os).
XYou can nd more information about cannabinoids on our homepage:
www.vapormed.com.

15
5 COMMISSIONING AND OPERATION
Ambient temperature:
-20 °C to +60 °C (-4 °F to +140 °F)
+60 °C
- 20 °C
15% - 90% Relative humidity of ambient air:
15% to 90%
700hPa - 1060hPa Atmospheric pressure:
700 hPa to 1060 hPa
5.1 Storage and Transport Conditions
5.2 Unpacking
XCheck the Vaporizer for completeness using Chapter 1.1 “Scope of Delivery”,
page 5.
XClean the Mouthpiece according to the instructions in Chapter 6.1 “Mouth-
piece”, page 24 before rst use.
XCheck the Vaporizer, USB Charger and USB-C Cable for externally visible
damage.
5.3 Operating Conditions
Ambient conditions in which the specied aerosol characteristics are guar-
anteed:
Ambient temperature:
+5 °C to +35 °C (+41 °F to +95 °F)
+35 °C
+ 5 °C
15% - 90% Relative humidity of ambient air:
15% to 90%
700hPa - 1060hPa Atmospheric pressure:
700 hPa to 1060 hPa

16
5 COMMISSIONING AND OPERATION
NOTICE
Loss of warranty /
Damage to property if the battery is replaced independently
Damage to the Vaporizer due to improper opening.
• Have the battery replaced exclusively by our Service Center
5.4 Battery
5.4.1 Basic Explanation of the Battery Charge Display
full battery: display of all six charging status fields
battery almost empty: Slowly flashing battery frame
The battery charge of the new product has a level of up to 80%.
5.4.2 Charging the Battery
XFully charge the battery before rst use.
XConnect the Vaporizer to a USB Charger or computer using the USB-C
Cable supplied.
5.4.3 Explanation of the Battery Charge Display during Charging
(depending on the Charger used)
XComply with Chapter 9.3 “Technical Requirements for suitable Chargers,”
page 32 regarding various chargers.
5.4.3.1 Charging with the USB Charger
XConnect the Vaporizer to the USB Charger.
ÖVibration and lighting up of the display.
ÖAscending flashing charge status fields.
ÖAs soon as the battery is fully charged, all six charge status fields are
visible.
5.4.3.2 Quick Charge (if supported by the Charger)

17
XConnect the Vaporizer to the USB-C Supercharger.
ÖVibration and lighting up of the display.
ÖAscending quickly flashing charge status fields.
ÖAs soon as the battery is fully charged, all six charge status elds are
visible.
ÖIf the connected charger also supports pass-through operation, “dct” ap-
pears on the second line of the display for three seconds after connection
(see Chapter 5.5 “Mains Operation”,page 17).
5.4.3.3 Charging with a low Power Charger
5 COMMISSIONING AND OPERATION
XConnect the Vaporizer to the USB Charger.
ÖVibration and lighting up of the display.
ÖDisplay indication in the second line: “SLO”.
XUse a more powerful charger.
5.4.4 End of Charging Process
XWhen the charging process is nished, rst disconnect the USB-C Cable
from the mains supply and then from the Vaporizer.
5.5 Mains Operation (only possible with USB-C Supercharger)
When using the optionally available USB-C Supercharger, the Vaporizer can
also be operated with a completely discharged battery.
ÖIrrespective of whether the Vaporizer is switched on or off, “dct” is shown
on the second line of the display for three seconds after connecting the
USB-C Supercharger.
ÖThe battery is not charged during this.
ÖThe Vaporizer switches off when the mains supply is disconnected if the
battery is completely discharged.

18
5 COMMISSIONING AND OPERATION
5.6 Herb Mill
XStore hemp flowers in the refrigerator or freezer, as cooled or frozen
hemp flowers are the easiest to crush.
XPlace an approximately hazelnut-sized
quantity of hemp owers between the
two mill bowls of the Herb Mill.
XClose the Herb Mill.
XTurn the Herb Mill back and forth 4-5
times.
5.7.1 Filling the Dosing Capsule with the Aid of the Magazine Cap
XUnscrew the Magazine Cap counter-
clockwise.
XPlace the Magazine Cap on the open
Dosing Capsule.
XPush 50 - 150 mg crushed hemp ow-
ers through the central opening of the
Magazine Cap into the Dosing Capsule.
XClose the Dosing Capsule with its cap.
5.7 Dosing Capsules (for single Use) and Magazine
XFilled Dosing Capsules can be stored in
the Magazine.

19
5.7.2 Filling the Magazine with Dosing Capsules
XInsert lled Dosing Capsules into the
Magazine.
XScrew the magazine cap on clockwise.
5 COMMISSIONING AND OPERATION
XUnscrew the Cooling Unit from the
Vaporizer by turning it 90° counter-
clockwise.
5.7.3 Inserting the Dosing Capsule into the Filling Chamber
XInsert the Dosing Capsule into the
Filling Chamber with the cap facing
upwards.
XScrew the Cooling Unit onto the Va-
porizer by turning 90° clockwise.

20
5 COMMISSIONING AND OPERATION
5.8 Heating Up
5.8.1 Display
1Actual Temperature Display
2Plus Temperature Button
3Battery Charge Display
4Minus Temperature Button
5Set Temperature Display
2
1
4
5
3
5.8.2 Default Settings
The Vaporizer offers three factory preset temperature levels:
Basic temperature: 180 °C (356 °F)
Booster temperature offset: +15 °C (+27 °F)
(relative to the basic temperature) corresponds to 195 °C (383 °F)
Superbooster temperature offset: +15 °C (+27 °F)
(relative to the booster temperature) corresponds to 210 °C (410 °F)
XBasic temperature and booster temperature can be changed individually,
whereas the superbooster temperature is xed.
XStart inhalation at 180 °C (356 °F).
XIf one temperature level is no longer sucient, change to the next level
as described below.
5.8.3 Switching on
XPress the orange ON/OFF switch for at least half a second.
ÖVibration and lighting up of the display.
ÖThe display indicates the heating process by showing the set and actual
temperatures. This can take up to two minutes.
ÖA double vibration signal indicates that the basic temperature has been
reached.
5.8.4 Base Temperature
XSwitch on the Vaporizer.
XPress the plus or minus button.
ÖPermanent change of temperature setting between 40 °C and 210 °C
(104 °F and 410 °F).
