Variscite DART-SD410 User manual

DART-SD410 based on Qualcomm Snapdragon 410
Evaluation Kit Quick Start Guide
123456
11
23
13
1514 17
12
18 19
21
16
25
8 7
9
10
24
20
22
Features:
1. 5V DC In Jack (J18)
2. USB Debug (J21)
3. Microphone Jack (J16)
4. Headset Jack (J15)
5. Gigabit Ethernet Jack (J22)
6. USB Device (J20)
7. Dual USB Host (J14)
8. Speaker connector placeholder (J19)
9. LVDS Header (J11)
10. 24bit LVDS expansion placeholder (12)
11. HDMI (J9)
12. UART0 Header (J7)
13. Capacitive Touch (J4)
14. I2C/SPI Header (J5)
15. GPIO/I2S Header (J8)
16. JTAG Header (J6)
17. Camera Board PCB Connector (J10) –
Interfaces with VAR-EXT-CB410
18. micro SD Card slot (J3)
19. RTC Battery Holder (JBT1)
20. Back Button (SW8)
21. Boot select switch (SW3)
22. Home Button (SW5)
23. USB Boot switch (SW7)
24. Power Button (SW9)
25. On/Off switch (SW10)
Evaluation kit initial Setup
1. Carefully remove the 7” LCD and
VAR-SD410CustomBoard board from the
package.
2. Plug the supplied USBtypeAtomicroBcable
between the USB debug connector (J21) and
a PC USB port. Wait for USB device
enumeration and driver installation.
3. Connect the supplied 5V DC power supply to
5V DC In Jack (J18).
4. PowerOntheboardbyOn/Offswitch (SW10).
5. The Board will boot into preloaded OS.
Downloaded from Arrow.com.

P/N VSS0113B
DART-SD410 based on Qualcomm Snapdragon 410
Evaluation Kit Quick Start Guide
Setting the Host PC for Debug
1. Download any PC terminal program.
Variscite suggests using Putty
2. Set PC terminal parameters as follows:
- Baud Rate: 115200
- Data bits: 8
- Stop bits: 1
- Parity: None
- Flow Control: None
Preparing images
1. The Package includes a microSD card which
contains a recovery SD Card image for
installing OS and recovery.
The image can also be downloaded from
Variscite FTP site.
Booting and OS Burning
1. Insert included SD Cart into SD Card
slot (J3).
2. Set Boot select switch (SW3) to the ON
position in order to boot from SD Card.
3. Plug a USB type A to micro B cable
between the USB Debug connector (J21)
and a PC USB port.
4. Power ON the VAR-SD410CustomBoard
By plugging the wall adapter power
connector into the 5V power jack (J18) and
to a 120VAC~240VAC power source.
5. The system will read the image from
external SD card and boot into Debian
Release.
6. Navigate to /media/linaro/OSes/Android or
to /media/linaro/OSes/Debian folder on the
SOM using PC terminal program.
7. Execute update.sh script by running
./update.sh
This will flash the OS to the On SOM
eMMC.
8. Wait till Done message appear.
9. Power off the VAR-SD410CustomBoard.
10. Set Boot select switch (SW3) to the OFF
position to boot from the On SOM eMMC.
11. Power ON the VAR-SD410CustomBoard
12. Boot messages are printed in the PC’s
terminal window and the flashed OS will
start.
13. For additional instructions follow:
https://variwiki.com/index.php?title=DART-
SD410_Android_Getting_Started
Additional Support Links
oWiki pages:
https://variwiki.com/index.php?title=Main_P
age
oVariscite Customers Portal:
https://varisciteportal.axosoft.com/login
oVAR-DVK-SD410:
https://www.variscite.com/product/evaluatio
n-kits/dart-sd410-kits/
oDART-SD410:
https://www.variscite.com/product/system-
on-module-som/cortex-a53-krait/dart-sd410-
qualcomm-snapdragon-410/
oVAR-SD410CustomBoard:
https://www.variscite.com/product/single-
board-computers/var-sd410customboard/
Thank you for purchasing Variscite’s
product.
For additional assistance please
contact: [e-mail]
