VARO PowerPlus GardenPro POWXG90425 User manual
POWXG90425 EN
Copyright © 2018 VARO P a g e | 1www.varo.com
1APPLIANCE .....................................................................................3
2DESCRIPTION (FIG. A) ...................................................................3
3PACKAGE CONTENT LIST.............................................................3
4ADDITIONAL SAFETY INSTRUCTIONS FOR HIGH-PRESSURE
CLEANERS ......................................................................................4
4.1 Mains power connection ........................................................................................5
4.2Water connection....................................................................................................5
4.3 Safety devices.........................................................................................................5
5ASSEMBLY......................................................................................5
5.1 Assembly of the gun (Fig. 1) ..................................................................................5
5.2 Assembly of storage hook and gun holder (Fig. 2)...............................................5
6OPERATION.....................................................................................5
6.1 Connection of garden hose (Fig. 3) .......................................................................5
6.2 Mounting of high pressure hose (Fig. 4) ...............................................................6
6.3 Mounting of lance and nozzle ................................................................................6
6.4 Water connection....................................................................................................6
6.5 Start/stop of the machine .......................................................................................6
6.6 Adjustable nozzle (Fig. 6).......................................................................................7
6.7 Rotate The Gun (Fig. 7)...........................................................................................7
6.8 Patio Cleaner...........................................................................................................7
6.9 Detergent dispenser (Fig 8 & 9)..............................................................................7
6.10 Detergent rate (Fig 10)............................................................................................7
6.11 Pipe cleaning set.....................................................................................................7
7TECHNICAL DATA..........................................................................7
8NOISE...............................................................................................8
9MAINTENANCE AND CLEANING...................................................8
9.1 Cleaning of inlet filter .............................................................................................8
9.2 Cleaning of air vents...............................................................................................8
9.3 Greasing of couplings ............................................................................................8
10 STORAGE ........................................................................................8
POWXG90425 EN
Copyright © 2018 VARO P a g e | 3www.varo.com
HIGH PRESSURE WASHER 2500W
POWXG90425
1 APPLIANCE
Your high pressure cleaner has been designed for outdoors cleaning. Cleaning of: machines,
vehicles, structures, tools, facades, terraces, gardening tools,…
UWAGA! Proszę dla własnego bezpieczeństwa przeczytać ten podręcznik
oraz ogólną instrukcję zasad bezpiecznego użytkowania przed
zastosowaniem urządzenia. Elektronarzędzie należy przekazywać innym
osobom wyłącznie z niniejszym podręcznikiem.
2 DESCRIPTION (FIG. A)
1. Water inlet coupling
2. Storage hook
3. Water outlet
4. Switch
5. Trolley handle
6. Gun holder
7. High pressure hose
8. Trigger gun
9. Trigger lock
10. Lance
11. Adjustable Nozzle
12. Hose lock button Gun
13. Detergent rate knob
14. Patio Cleaner
15. Turbo nozzle
16. Detergent dispenser
17. Pipe cleaning set 10m
18. Special connector for pipe cleaning
set
19. Brush
20. Lance extension 330m
3 PACKAGE CONTENT LIST
▪Remove all packing materials
▪Remove remaining packaging and transit supports (if existing)
▪Check the completeness of the packing content
▪Check the appliance, the power cord, the power plug and all accessories for transportation
damages.
▪Keep the packaging materials as far as possible till the end of the warranty period. Dispose
it into your local waste disposal system afterwards.
WARNING Packing materials are no toys! Children must not play with
plastic bags! Danger of suffocation!
1x high pressure washer
1x trigger
1x extended lance for gun
1x adjustable nozzle
1x water inlet connector
1x 8m pressure hose
1x manual
1x patio cleaner
1x turbo nozzle
1x cleaning needle
1 x Pipe cleaning set 10m
1 x special connector for pipe cleaning set
1 x Brush
When parts are missing or damaged, please contact your dealer.
POWXG90425 EN
Copyright © 2018 VARO P a g e | 4www.varo.com
4 ADDITIONAL SAFETY INSTRUCTIONS FOR HIGH-PRESSURE
CLEANERS
▪The appliance is designed solely for outdoor private use and NOT for commercial use.
Please keep it away from heat, direct sunlight, moisture and rain, frost and sharp edges.
▪Do not let people who have not been trained in the use of a high pressure washer nor read
the instruction manual operate the machine!
▪High pressure cleaners shall not be used by children or untrained personnel.
▪Children should be supervised to ensure that they do not play with the appliance.
▪Before starting up your machine please check it carefully for any defects. If you find any,
do not start up your machine and contact your local distributor.
▪Check especially the insulation of the electric cable should be faultless and without any
cracks. If the electric cable is damaged, an authorized local service centre should replace
it.
WARNING: High pressure jets can be dangerous if subject to misuse. The
jet must not be directed at persons, live electrical equipment or the
appliance itself.
WARNING: Do not use the appliance within range of persons unless they
wear protective clothing.
▪Do not direct the jet against yourself or others in order to clean clothes or foot-wear.
▪Hold the spray lance firmly with both hands.
▪The operator and anyone in the immediate vicinity of the site of cleaning should take
action to protect them from being struck by debris dislodged during operation.
▪Wear goggles and protection clothes during operation.
▪Disconnect from electrical power supply before carrying out user maintenance.
▪To ensure appliance safety, use only original spare parts from the manufacturer or
approved by the manufacturer.
▪Do not use the appliance if a supply cord or important parts of appliance are damaged,
e.g. safety device, high pressure hose and trigger gun.
▪Do not use the appliance with wet hands. If the appliance is humid or wet, unplug it
immediately. Do not put it in water.
▪Tires and tire valves may be damaged by the high-pressure jet and then burst.
▪Never use the machine in an environment where there could be a danger of explosion.
▪It is not allowed to clean asbestos- containing surfaces with high pressure.
▪This high pressure washer must not be used at temperatures below 0°C
WARNING: High pressure hoses, fittings and couplings are important for
the safety of the appliance. Use only hoses, fittings and couplings
recommended by the manufacturer.
WARNING: Inadequate extension cables can be dangerous. Cables on reels
should always be completely unwinded to prevent the cable from
overheating.
▪If an extension cable is used, the plug and the socket must be waterproof and comply with
the below-mentioned requirements for length and cable dimensions.
1.0 mm² max. 12.5 m
1.5 mm² max. 20 m
POWXG90425 EN
Copyright © 2018 VARO P a g e | 5www.varo.com
▪If the electric cable is damaged, it must be replaced by the manufacturer or his service
agent or similarly qualified person in order to avoid a hazard.
4.1 Mains power connection
The following should be observed when connecting the high pressure washer to the electric
installation:
▪The electric supply connection shall be made by a qualified electrician and comply with
IEC 60364-1
▪It is recommended that the electric supply to this appliance should include either a residual
current device that will interrupt the supply if the leakage current to earth exceeds 30 mA
for 30 ms.
4.2 Water connection
▪Connection to the public mains according to regulations.
▪Inlet hose can be connected to the water mains with a max. inlet pressure of 12 bars.
This high pressure washer is in Europe only allowed to be connected with the
drinking water mains, when an appropriate mains backflow preventer has been
installed, Type BA according to EN 1717. The length of the hose between the
backflow preventer and the high pressure washer must be at least 10 metres to
absorb possible pressure peaks (min diameter ½ inch).
▪Operation by suction (for example from a rainwater vessel) is carried out without backflow
preventer.
▪As soon as water has flown through the BA valve, this water is not considered to be
drinking water any more.
IMPORTANT! Only use water without any impurities. If there is a risk of
sand particles in the inlet water (i.e. from your own well), an additional filter
should be mounted.
4.3 Safety devices
▪The unloader valve can reduce pressure if it exceeds pre-set values.
▪Locking device on trigger gun (9): The trigger gun (8) features a locking device (9). When
the knob is activated, the trigger gun (8) cannot be operated.
▪A thermal sensor protects the motor against overloading. The machine will restart after a
few minutes when the thermal sensor has cooled.
5 ASSEMBLY
This section will explain in details how to make you high pressure washer ready for use.
5.1 Assembly of the gun (Fig. 1)
▪Insert the adjustable spray nozzle(K) into the gun. Push and turn the adjustable nozzle
clockwise onto the gun(J) until hand tight to lock it in place. When the pieces are joined
properly, you cannot separate the two components by pulling straight out on the
adjustable nozzle. All attachments must be inserted into the gun for proper use.
5.2 Assembly of storage hook and gun holder (Fig. 2)
Slide the storage hook into the holder on the right side
Slide the gun holder into the holder on the left side
6 OPERATION
6.1 Connection of garden hose (Fig. 3)
▪Before attaching the water inlet connector to the pressure washer remove the plastic cap.
