VARO CAW-07015 User manual

SAMSUNG POWERED WIFI PORTABLE SPEAKER
MODEL:CAW-07015
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE
OPERATION AND KEEP IT FOR FUTURE REFERENCE

IMPORTANT SAFETY INSTRUCTIONS
3

Accessories:
Specification
Power supply......................................................................................5V 2A
Speakers..................................................................................................................2 X 3 W
1 X 3.5mm Stereo AUX IN Cable
1 X Instruction Manual
1 X AC/USB Adapter
4
LOCATION OF CONTROLS
M
DC IN
TOP VIEW
FRONT VIEW
SIDE VIEW
1 2 3 4
5 6 7
8 9 10 11
1. Play/Pause (WiFi Pairing) Button
2. Previous (Volume Down) Button
3. Next (Volume Up) Button
4. Mode (Power On/Off) Button
5. WiFi Indicator
6. Bluetooth Indicator
7. AUX IN Indicator
8. Battery Indicator
9. Battery Indicator Button
10. AUX IN Jack
11. DC IN Jack
1 X Velvet Bag
Running Time..................................................................around 6 hours(with 50% volume)
Recharging Time...........................................................................................around 4 hours

Recharging
When the battery is in low level, the battery indicator will flash blue, the unit needed to be
recharged.
Battery Indicator
Battery Indicator Button
Uncover the rubber lid of AUX IN and DC IN jack,using the supplied Adapter to recharge
through the DC IN jack.
During playing, press the battery indicator button to display the battery level.
DC IN Jack
Battery Indicator
When the battery is recharging, the battery indicator will light up red. The red indicator will
turn blue after the unit is fully charged.
DC IN
5

BLUETOOTH OPERATION
Pairing the speaker with Bluetooth devices (phone or music device)
1. Press and hold the button to turn on the unit.
5. Once paired successfully, Bluetooth indicator will stop blinking.
6. If pairing is unsuccessful, turn off the speaker first and then re-pair following above steps.
M
2. Press the button repeatedly to turn to Bluetooth mode, the Bluetooth indicator on
M
front of the unit will light up and blink, now it is entering pairing mode.
3. Activate the Bluetooth function on your Bluetooth device (phone or music device). Please
refer to the manufacturer’s instructions of your device.
4. Once you have activated Bluetooth on your device, select the speaker “CAW-07015” from
the list of available Bluetooth devices.
7. Once you have paired the speaker with a device, the speaker will remember this device
and will pair automatically when the device’s Bluetooth is activated and in range.
8. If you want to pair it with a new device, press and hold the button to disconnect the
current pairing.
During playing:
A:Press the or button to skip to previous or next track.
B:Press the button to pause, press again to resume playing.
C:Press and hold the or button to decrease or increase the volume.
NOTE:
During playing, please do not insert the AUX IN cable into the AUX IN Jack, or it will switch
to AUX IN mode.
6

2. Press and hold the button to turn on the unit.
M
3. Press the button repeatedly to turn to AUX IN mode, the AUX IN indicator on
M
front of the unit will light up.
~ Insert the other end to the AUX IN jack on the side of unit.
1. Connected the external audio device to the unit by an
~ Insert one end to the Phone; Line Out or AUX Out Jack on the external audio device.
audio connection cable with 3.5mm
stereo mini jacks as:
DC IN
Mobile Phone
(Audio Connection Cable supplied)
To AUX IN jack on
the side of the unit
Connect to the Phones; AUX Out;
Line Out Jack of the external devices
(Such like MP3 Player; cell phones;
iPod/iPad ... etc)
AUX IN OPERATION
4. Play music as usual on your external device.
MP3
7

8
Install the APP and set the language of mobile phone to English.
Before connecting the mobile phone with the unit ,
please search "MUZO" player from network and download it,
or download the MUZO APP from APP store.
The APP icon will appear like the Fig.1 after successful installation. Fig. 1
PREPARATION
CONNECT THE MOBILE PHONE WITH THE UNIT
Turn on the WiFi on the mobile phone, then search the router (WiFi Source),
Press and hold the button to turn on the unit, the WiFi indicator will light up and blink.
Click MUZO icon to activate the MUZO player APP, it will start to search muzo system
for example, the router name is "JUNLAN", select "JUNLAN" from WiFi name list,
input the password (eg:12345678)to make successful connection.
automatically.
Follow the instruction to input the WiFi password (12345678) to log on same WiFi network.
Follow the instruction below to establish connection.
1. Press and hold the button on the unit and try to connect with mobile phone.
2.There will be voice tone from the unit instructing like:
" Searching for Wifi connection "
" Waiting for Wifi connection "
" Wifi connected "
Setup
successfully connected
device connected to JUNLAN network
current signal strength 59%
MUZO PLAYER
NOTE:Please make sure that there is no AUX IN cable plugged in AUX IN jack.
M

d the device which is already connected to the router
A. Connect phone to the same router as the devices.
B. Open the app, it will search all the devices.
dd the device which is not connected to the router
If you want to add other device which is not connected to the router,
you can follow the operations below:
1. Click “ + ” on DEVICE
LIST interface, you can add
the device according to the
steps;
2. After finished, the new
added device will appear in
the DEVICE LIST
9
Setup
Ad
A

After you first add the device, it will automatically instruct you
to rename the device, while if you want change the name of
the device, you can follow the instruction below:
Click the , and
rename the device:
Eg. Rename the
device as "Garden"
Guide of Using App Functions
1. Search
It can search the internet resource for you according to
your requirement, for example, input Lady Gaga and all
her songs on Internet will be found. As the pictures below:
For example, input
Lady Gaga and all
her songs,albums
on Internet will be
found.
10
Setup
Setting the password for the speakers
After naming the speakers, it will prompt you to set the password for speakers.
Set at least 8-digit password.
After setting password, other device will need password to connect the unit directly under
Rename the device
the condiction that it hadn't connected with WiFi source.

2. Favorites
2.1 Collect Songs in Favorites
The Favorite function allows you to freely collect your favorite songs,
you need not to look for the song among the internet resource again
1. Click the heart icon
in Playing interface to
collect this song in
Favorites
2.2 Manage the songs in Favorites
You can manage the songs in Favorites, remove or add it in
your customized song list.
Click the icon
on the right of the
song:
Guide of Using App Functions
11

3. My Music
3.1 Play local music
It can automatically
search the song in
local device, Eg,
your iPhone:
3.2 Home Music Share
If your PC is connecting
the same router with the
device, then the device
can automatically search
the songs in your
computer, you can
playback the song in
computer to the speakers.
Guide of Using App Functions
12

3.3 My Playlists
You can add or delete
the playlist.
3.4 Recently
1. It can collect the
songs you recently
listened;
2. It can manage the
playlists and preset it
to the speakers.
Guide of Using App Functions
13

3.4 Recently----Manage the playlists
You can choose the
song add it to a playlist
or just remove it.
3.4 Recently----Music preset
You can set the
Recently to Preset
Music. Eg Set channel
6 as Recently:
Guide of Using App Functions
14

4. TTpod
TTpod itself is a powerful,
free cell phone music
player software, with
hundreds of millions of
users. Click TTpod on the
main function control
interface, you can enjoy all
the high quality internet
music provided by it.
Guide of Using App Functions
15
5.
Online radio Tunein is
powerful, it can provide
a collection of tens of
millions of online radio
around the world, click
Tunein on the main
function control
interface: choose your
favorite programs, start
a wonderful radio trip.
eInTun

BAN
Guide of Using App Functions
16
6.
7.
DOU
DOUBAN FM can
provide personalized
music MHZ.
iHeartRadio is an Internet
radio platform owned by
iHeartMedia, Inc. Founded
in April 2008 as the website
iheartmusic.com,
iHeartRadio now aggregates
audio content from over
800 local iHeartMedia radio
stations across the United
States, as well as hundreds
of other stations and
various other media.
artRadioiHe

XIMALAYA is one
of the largest,
most complete
audio resource
platform in China.
Guide of Using App Functions
17
8.
LAYAXIMA
9. lti mode and solo mode
This APP can provide
the multi mode
function. Enter the
“DEVICE LIST” interface,
you can glance the
situation of all the
devices, like the song,
voice volume, voice
channel.
Mu

lti mode and solo mode
You can see a guide to
tell how to switch
between solo and
multi mode if you click:
After finished,
Multi mode will
be as this:
Guide of Using App Functions
18
10.
Mu
11. Cloud music preset
You can listen to your
preset online cloud
music playlist anytime
once you press the
corresponding key on
the device. Eg. Set
NEW in TTPOD as
channel 1: Click Preset
icon

12. Playlist management
12.1 Customize playlist
Open the app,
choose ”My Playlist”,
click “Edit”, you can
add multiple play
lists or delete the
one you don’t need.
You can also collect
songs in the play list.
Guide of Using App Functions
19
Click icon + to add new
playlist, Eg. Yoga:

You can also delete the
playlist:
Guide of Using App Functions
20
You can click icon
on the right of the
song list, collect it to
the playlist.
