Varytec Boostar 4 User manual

Manual
Splitter DMX Boostar 4

1. Safety instructions
................................
1.1.
For safe and efficient operation
2. Introduction
................................
3. Control................................
................................
4. Technical data
................................
1. Safety instructions
•This
device is suitable for indoor use (not outdoors) only.
•
All modifications to the device will void the warranty.
•
Repairs are to carry out by skilled personnel only.
•
Use only fuses of the same type and original parts as spare parts.
•
Protect the unit from rain and humidity to avoid fire and electric shocks.
•Make s
ure to unplug the power supply before opening the housing.
1.1.
For safe and efficient operation
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
To avoid placing on un-
stable location
Select a level
and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove
the power plug soon, and contact with an engineer for repairing, do not
open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure to
using the device for an extended period of time, be sure to disconnect the plug from the receptacle.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liabilit
y for any resulting defects or problems. Make sure the electrical
connection is carried out by qualified personnel. All electrical and mechanical connections
have to be carried out according to the European safety standards.
2 / 4
Table of contents
................................
................................
................................
For safe and efficient operation
................................
................................
................................
................................................................
................................
................................
................................
................................
................................
................................................................
................................
device is suitable for indoor use (not outdoors) only.
All modifications to the device will void the warranty.
Repairs are to carry out by skilled personnel only.
Use only fuses of the same type and original parts as spare parts.
Protect the unit from rain and humidity to avoid fire and electric shocks.
ure to unplug the power supply before opening the housing.
For safe and efficient operation
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32
°F /0°C, or exceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
stable location
and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
the power plug soon, and contact with an engineer for repairing, do not
open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure to
hold the plug. When not
using the device for an extended period of time, be sure to disconnect the plug from the receptacle.
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
y for any resulting defects or problems. Make sure the electrical
connection is carried out by qualified personnel. All electrical and mechanical connections
have to be carried out according to the European safety standards.
................................
............................ 2
................................
............................... 2
................................
....... 3
................................
.............. 3
................................
.. 4
Use only fuses of the same type and original parts as spare parts.
Protect the unit from rain and humidity to avoid fire and electric shocks.
ure to unplug the power supply before opening the housing.
the power plug soon, and contact with an engineer for repairing, do not
hold the plug. When not
using the device for an extended period of time, be sure to disconnect the plug from the receptacle.
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
y for any resulting defects or problems. Make sure the electrical
connection is carried out by qualified personnel. All electrical and mechanical connections

3 / 4
2. Introduction
Thank you for buying the Splitter DMX Boostar 4. It is a powerful device.
For a successful installation and operation, please read this manual carefully.
3. Control
Both DMX In connections and DMX Out connections have 3pol and 5pol connectors.
1. Ground 1. Ground
2. Signal (-) 2. Signal (-)
3. Signal (+) 3. Signal (+)
4. Not used
5. Not used
With each DMX Out you can connect up to 32 DMX
devices.
If you connect the Splitter with a
DMX device it is not allowed to
connect more than 31 DMX devices
before the splitter.

4 / 4
4. Technical data
Power supply
Voltage 90 – 240 V AC / 50-60 Hz
Fuse F500mA 250V 5x20mm (5 pcs.)
Hardware
Protection class IP20
Suitability Indoor
Dimensions (L/B/H) 345 x 250 x 140 mm
Weight 2,9 kg
Importer:
B & K Braun GmbH
Industriestraße 2
D-76307 Karlsbad
www.bkbraun.com
[e-mail]
