Vaughan Richmond WA0319 User manual

Care Instructions - Read Before Installation
- This box contains fragile and valuable goods that
have been carefully packed. Please take utmost care
in unpacking the parcel as damage can occur in this
process.
- Please be sure you have received the correct
number of boxes i.e. 1 of 2, 2 of 2 etc.
- Under no circumstances should the product be
lifted out by the neck or light tting.
- If you have received any damaged goods or are
missing any part of your order, please contact our
sales oce as soon as possible
Recycling
-
Recyclable packaging used, please consult with
your local recycling centre for further information.
- Waste electrical products should not be disposed
of with conventional household waste. Please
recycle all parts when possible.
Cleaning Instructions
Brass - all types: Use a soft dry lint free cloth
Bronze, Nickel, Silver & Chrome: Use a dry cloth
only, no chemical cleaners
Glass: We recommend using a strong alcohol such as
isopropyl alcohol. Note: some modern cleaning
solutions can contain chemicals that can leave a
greasy lm on glass.
Gilt Wood: Use a dry cloth only
Ceramic: Use a damp cloth only
Wood: Wax polish i.e. Antique wax
Alabaster: Dust with a soft brush or a clean dry cloth.
Avoid water or water-based cleaners. Any marks that
cannot be removed by dusting must be cleaned by a
specialist.
Lacquered Furniture: Furniture polish
Crystal: Damp cloth
Card/Laminated Shades: Use a Feather duster only
Silk Shades: Gently tap to lift dust
Needlework: Dry-clean
-Any decorative parts made from other materials
must be removed and cleaned separately to avoid
damage - e.g. alabaster.
After choosing a suitable location that meets all the requirements of
the safety information install the unit following the steps overleaf.

- Carefully unpack all parts and check for damage or missing parts
before commencing installation.
- Installation of this product must be carried out by a qualied
electrician.
- Disconnect the electrical supply before installation. Switch o the
electricity at the fuse box by removing the relevant fuse or switching
o the circuit breaker before proceeding with the installation.
- Install should be carried out in accordance with the wiring regulations
and building codes applicable to the country of installation.
- Before making any xing hole(s), check that there are no obstructions
hidden beneath the mounting surface such as pipes or cables.
- Ensure that the support for the light is of sucient structural strength and that any xing screws do not
interfere with the connecting cables.
- The unit can get very hot during use. Switch the product o and allow to cool before handling or changing
bulbs. .
- Ensure adequate ventilation space is allowed between the unit and any object above, in front or to either
side of the unit. Suggested minimum space is 0.5m above and 0.5m on all sides.
- To prevent tarnishing, it is advisable to wear gloves at all times when handling the product.
- Mains connector must be a lever slicing connector; with a minimum of 3 terminals; rated to 240v 16A
(minimum); conforming to IEC 60998-2-1 or IEC 60998-2-4
Safety Information - Read Before Installation
VAUGHAN
Installation Guide
www.vaughandesigns.com
Richmond Wall Lantern
WA0319
Rev 1

Live = (Brown)
Earth = (Green/Yellow)
Neutral = (Blue)
LLEENN
6. Having identied the house-
hold wiring, connect the building
supply and the product wires
together in the terminal block/s as
shown above.
5. Hang the product onto the
bracket using the hook provided.
Hook Bracket
Wall
BracketHook
4. Pierce the grommet in the back
of the product and feed the
household cabling through the
grommet into the terminal
enclosure at the bottom of the
product.
3. Hang the product onto the
bracket and mark the xing holes
for the lower tab. Remove the
product from the wall, pre-drill
the holes and install the wall
plugs.
2. Measure and mark out the wall
xings prior to installation. Mount
the bracket to the wall.
1. Remove the screws on the
cover located on the underside of
the product. This will expose the
sealed terminal block.
After choosing a suitable location that meets all the requirements of
the safety information install the unit following the steps overleaf.

- Carefully unpack all parts and check for damage or missing parts
before commencing installation.
- Installation of this product must be carried out by a qualied
electrician.
- Disconnect the electrical supply before installation. Switch o the
electricity at the fuse box by removing the relevant fuse or switching
o the circuit breaker before proceeding with the installation.
- Install should be carried out in accordance with the wiring regulations
and building codes applicable to the country of installation.
- Before making any xing hole(s), check that there are no obstructions
hidden beneath the mounting surface such as pipes or cables.
- Ensure that the support for the light is of sucient structural strength and that any xing screws do not
interfere with the connecting cables.
- The unit can get very hot during use. Switch the product o and allow to cool before handling or changing
bulbs. .
- Ensure adequate ventilation space is allowed between the unit and any object above, in front or to either
side of the unit. Suggested minimum space is 0.5m above and 0.5m on all sides.
- To prevent tarnishing, it is advisable to wear gloves at all times when handling the product.
- Mains connector must be a lever slicing connector; with a minimum of 3 terminals; rated to 240v 16A
(minimum); conforming to IEC 60998-2-1 or IEC 60998-2-4

www.vaughandesigns.com
Richmond Wall Lantern Richmond Wall Lantern
WA0319

9. To access the bulb, lift the latch
to release the door.
8. Secure the bottom of the
product to the wall using
mounting screws.
Ensure the product is safely
secured.
7. Reattached the cover previously
removed ensuring it is correctly
secured to the product.
11. When the bulb has been
replaced, reassemble the gasket
and the glass cap ensuring the
cap is secured tightly.

NOTE: The cap must be tightly
secured, failure to secure
the cap will result in water ingress
and risk of electrical shock.
10. To replace the bulb, unscrew
the glass cap on the lamp holder
and remove the bulb.
www.vaughandesigns.com
Richmond Wall Lantern
WA0319

1. Retirez les vis du couvercle situé sur la face inférieure
du produit. Le bornier scellé est alors exposé.
2. Marquez et percez les trous d'emplacement dans le
mur de montage, en fonction des trous de montage du
produit. Fixez le produit au mur, à l'aide des vis fournies.
3. Accrochez le produit sur le support et marquez les
trous de xation de la languette inférieure. Retirez le
produit du mur et pré-percez les trous et installez les
chevilles.
4. Faites passer le câblage domestique par le trou de
câble dans le boîtier de la borne au bas du produit.
5. Accrochez le produit sur le support à l'aide du crochet
fourni.
6. Après avoir identié le câblage domestique, connectez
les ls d'alimentation du bâtiment et les ls du produit
ensemble dans le bornier comme indiqué ci-dessus.
7. Remettez le couvercle retiré précédemment en place
en vous assurant qu'il est correctement xé au produit.
8. Fixez le bas du produit au mur à l'aide de vis de
montage. Assurez-vous que le produit est bien xé au
mur.
9. Pour accéder à l'ampoule, tirez sur le loquet an de
libérer la porte.
10. Pour remplacer l'ampoule, dévissez le bouchon en
verre du support de lampe et retirez l'ampoule.
11. Une fois l'ampoule remplacée, remettez le joint et le
bouchon en verre en vous assurant que le bouchon est
bien xé. REMARQUE : Le bouchon doit être fermement
xé. Si le bouchon n'est pas xé, il y aura une inltration
d'eau et un risque de décharge électrique.
Français
1. Quite los tornillos de la tapa ubicada en la parte inferior
del producto. Esto expondrá el bloque de terminales
sellado.
2. Marque y taladre los oricios de ubicación en la pared
de montaje, según los oricios de instalación del
producto. Monte el producto en la pared con los tornillos
proporcionados.
3. Cuelgue el producto en el soporte y marque los
oricios de jación para la pestaña inferior. Retire el
producto de la pared y taladre previamente los oricios e
instale los tacos de pared.
4. Pase el cableado de la casa a través del oricio del cable
de la caja de terminales situado en la parte inferior del
producto.
5. Cuelgue el producto en el soporte usando el gancho
provisto.
6. Una vez identicado el cableado de la casa, conecte el
suministro del edicio y los cables del producto juntos en
el bloque de terminales como se muestra arriba.
7. Vuelva a colocar la cubierta que quitó anteriormente y
compruebe que esté correctamente jada al producto.
8. Asegure la parte inferior del producto a la pared con
tornillos de montaje. Compruebe que el producto esté
asegurado a la pared.
9. Para acceder a la bombilla, tire del pestillo para abrir la
compuerta.
10. Para reemplazar la bombilla, desenrosque la tapa de
vidrio del portalámparas y retire la bombilla.
11. Una vez reemplazada la bombilla, cambie la junta y la
tapa de vidrio y compruebe que la tapa esté bien
asegurada. NOTA: la tapa tiene que estar bien asegurada;
Español
1. Entfernen Sie die Schrauben an der Abdeckung auf der
Unterseite des Produkts. Dadurch wird der vergossene
Klemmleiste oengelegt.
2. Markieren und bohren Sie Aufnahmebohrungen an der
Befestigungswand, im Einklang mit den Befestigungslöchern
am Produkt. Befestigen Sie das Produkt mit den beigefügten
Schrauben an der Wand.
3. Hängen Sie das Produkt an die Halterung und markieren Sie
die Befestigungslöcher für die untere Lasche. Entfernen Sie das
Produkt von der Wand, bohren Sie die Löcher vor und
installieren Sie die Dübel.
4. Führen Sie die Hausverkabelung durch das Kabelloch im
Anschlussklemmen-Gehäuse unten am Produkt.
5. Hängen Sie das Produkt mit dem mitgelieferten Haken an
die Halterung.
6. Nach Identikation der Hausstromverkabelung verbinden Sie
die Gebäudeversorgung und die Produktkabel in der
Klemmleiste wie oben gezeigt. Wenn Sie damit fertig sind,
vergewissern Sie sich, dass die exiblen Dichtungen und die
Klemmleiste korrekt gesichert sind.
7. Bringen Sie die zuvor entfernte Abdeckung wieder an und
stellen sie sicher, dass Sie korrekt am Produkt befestigt sind.
8. Befestigen Sie den Boden des Produkts mit Hilfe der
Befestigungsschrauben an der Wand. Stellen Sie sicher, dass
das Produkt an der Wand befestigt ist.
9. Um an die Glühbirne zu gelangen, ziehen Sie an der
Verriegelung, um die Klappe zu entriegeln.
10. Um die Glühbirne zu wechseln, schrauben Sie die
Glaskappe auf dem Lampenhalter ab und entfernen die
Glühbirne.
Deutsche
1. Rimuovere le viti dalla copertura situata sul lato inferiore del
prodotto. Ciò esporrà il blocco terminale sigillato.
2. Segnare e trapanare i fori di posizione nella parete di
montaggio in base ai fori di montaggio sul prodotto. Montare il
prodotto alla parete utilizzando le viti fornite.
3. Appendere il prodotto alla staa e segnare i fori di ssaggio
per la linguetta inferiore. Rimuovere il prodotto dalla parete,
praticare i fori e installare i tasselli.
4. Collegare all'impianto elettrico domestico attraverso il buco
per i cavi situato all'estremità inferiore del prodotto.
5. Appendere il prodotto alla staa utilizzando il gancio fornito.
6. Dopo aver individuato l'impianto elettrico domestico,
collegare l'alimentazione dell'edicio ai cavi del prodotto nel
blocco terminale come mostrato sopra. Dopodiché, assicurarsi
che i sigilli essibili e la copertura del blocco terminale siano
correttamente ssati.
7. Riattaccare la copertura precedentemente rimossa
assicurandosi che sia correttamente ssata al prodotto.
8. Fissare la parte inferiore del prodotto alla parete utilizzando le
viti di montaggio. Assicurarsi che il prodotto sia ssato alla
parete.
9. Per accedere alla lampadina, tirare il fermo per rilasciare lo
sportello.
10. Per sostituire la lampadina, svitare la copertura di vetro sul
supporto della lampada e rimuovere la lampadina.
11. Una volta sostituita la lampadina, riposizionare la
guarnizione e la copertura di vetro assicurandosi che la
copertura sia ssata saldamente. NOTA: La copertura deve
essere ssata saldamente, onde evitare la penetrazione di
liquidi e il conseguente rischio di shock elettrico.
Italiano
Richmond Wall Lantern
WA0319
WA0319_EU_IG
