Vava VA-CD001 User manual

VAVA DASH CAM
User Guide
VA-CD001
①
③
②
①Ideal Mounting Position ②Car Charger ③ GPS
1 x VAVA Dash Cam
1 x Car Mount
1 x Snapshot Button
1 x VAVA Car Charger
1 x Micro USB Cable with GPS Module
1 x Crowbar
5 x Cable Clips
1 x Button Cell
1 x User Guide
1 x Quick Installation Guide
1 x Thank You Card
What’s In the Box: Specifications Dash CamProduct Diagram
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
Car Mount
Micro USB Port
Magnet
Power / Working Status LED
WiFi Status LED
Reset Button
Micro SD Card Slot
Snapshot Button
GPS Module
Micro USB Cable
VAVA Car Charger
NT96663
Sony IMX291, 1/2.8 in
Full 6G + 1 IR Lens
155°
3-axis Accelerometer
1920*1080/60fps (Default)
1920*1080/30fps
1280*720/30fps
840*480/30fps
Class 10 Micro SDCard up to 128GB (max)
WiFi (between phone andVAVA Dash Cam)
2.4G (betweenSnapshot Button and VAVA Dash Cam)
2GB
-20°C to 70°C
-4°F to158°F
CPU
Vision Processor
Lens
Angle
G-Sensor
Resolution
Storage
Wireless Connections
RAM
Operating Temperature
Snapshot Button
1. Dash cam and Snapshot Button pairing:Once the dash cam is turned on, press and hold the Snapshot Button
for 10 seconds untilyou hear 4 beep sounds and the Bluetooth is connected. If only2 beep sounds are
heard, pairing is disconnectedand the Snapshot Button enters standbymode. Press again to restart.
2. Photo / video taking: 1) Press once to take photos; 2) Pressand hold for 3 seconds with a beep sound to
take videos.
Note: Once the dash cam is pairedwith the Snapshot Button, each time the dash cam is poweredoff, the
Button will enterstandby mode. When the dashcam is turned on again, you need to press the Snapshot Button
to wakeup the Button while taking a snapshot. It takes around 3 secondsto resume normal working status.
Status
Working
Stop working / microSD card storage full
Recording an emergency video clip
Recording a 15 secondvideo clip after the video recording
icon is tapped in the app
Micro SD card error
Snapshot photo has been taken
Connected toWiFi
Not connected toWiFi
LED Indicator
Blue LED light slowly blinks
Blue LED light on
Red LED light blinks
Red LED light fast flashes
Red LED light flashes once
White LED light on
White LED light off
⑨
⑩
①
②③④⑤⑥⑦
⑧
⑪
Installing the VAVA Dash Cam
1. Insertthe micro SD card into the micro SD card slot.
2. Stick the car mount onto yourcar windshield (ideally right in the middle).
3. Fix the VAVADash Cam onto the mount via the magnet.
4. Connect the USB cable to the micro USB port of the dash cam. Run the cablealong the edge of the windshield,
tuck it away in the seams,and extend it all the way to the USB portof the Car Charger. Be sure to keepit away
from the airbag area.
5. Insert the CarCharger into your cigarette lighter, connect the Dash Cam to the Car Charger.
6. Start yourcar to turn on the VAVA Dash Cam.Connect it with your phone (refer to the “VAVA Dash App”
section) and open the VAVA Dash App to view a real-time feed.
FCC Compliance
This device complieswith Part 15 of the FCC Rules: Operation is subject to the following two conditions:
1. This devicemay not cause harmful interference and
2. This device must accept any interferencethat is received, including any interference that may cause
undesired operation.
This device is actingas slave and operating in the 2.4 GHz (2412 ~2462 MHz) band.
Ad Hoc function is supportedbut not able to operate on non-US frequencies.
NOTE:This equipment has been tested and found tocomply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against
harmful interferencein a residential installation. This equipmentgenerates uses and can radiate radio
frequencyenergy and, if not installed and used in accordance with the instructions,may cause harmful
interferenceto radio communications. However, there is no guarantee that interferencewill not occur in a
particular installation. If this equipmentdoes cause harmful interference to radio ortelevision reception,
which can be determined byturning the equipment off and on, the user is encouragedto try to correct the
interferenceby one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separationbetween the equipment and receiver.
-Connect the equipment intoan outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications notexpressly approvedby the party responsible forcompliance could void the
user's authorityto operate the equipment.
Note:
·The dash cam supports up to a class10 micro SD card up to 128GB. Do not removeor insert the micro SD card
when the camera is working.
·Suggested microSD card brands: Samsung, Sandisk, Transcend.
·Stick the Snapshot Buttonwith a 3M adhesive tape on the dashboard or besidesthe steering wheel. Do not put
it on the airbag.
·Stick the GPS module with a 3M adhesive tape on the top left/right corner of windshield.
·Do not use the Car Chargerto charge devices with Quick Chargetechnology.
·Install the car mount on windshields thatare titled on an angle between 17° - 58°.
Attention
·Our apps and camera firmwarewill be updated regularly, you canupdate the firmware via apps.
·Do not use cardboard, papertowel, or napkin to clean the lens.
·Do not attempt to repair, dismantle, or modify the dash camera hardware by yourself.
Warranty
This product is covered by the VAVA Parts and Labor Warrantyfor 18 months (+ 12 months upon product
registration) from thedate of its original purchase and only from authorized retailers and distributors. If the
product has become defective, please contact VAVA Support for assistance or tolaunch a warranty claim.
EmergencyRecording Mode
A 20 second video will be capturedwhen the G-Sensor is activated in caseof sharp turns or a sudden stop. When
the capacityof these videos reaches 30% of the SD card space,the oldest ones will be overwritten bythe new ones.
Parking Mode
When your car is not running,i.e. engine being shut down, the dash cam will automatically power off in 10 seconds
and enter Parking Mode.When a shock or crash is detected, theG-Sensor will activate the dash cam and start
recording a 15 second video. The dash cam will then re-enterthe Parking Mode.
VAVA Dash App
Downloading the VAVA Dash App
For Android / iOS phones,search for “VAVA Dash” in the Google PlayStore or Apple App Store. Download the app
and install it on your phone.
Connecting the VAVA Dash to Your Phone
Connect your Android/ iOS smartphone with the VAVA Dash Cam throughWiFi:
Settings > WLAN > Select “VAVA WiFi” > Enter password> Open the VAVA Dash App
Note: Theinitial WiFi password is 12345678.
Live Preview
Once your phone is connected to the VAVA Dash Cam,open the app to view a real-time video feed and configure
the dash cam.
TakePhotos and Videos
Press the Snapshot Button or tap the snapshot icon in the app to takea photo. Tapthe video recording icon in the
app to record a videofrom 5 seconds before the pressing or tappingto 15 seconds afterwards.The photo and the
video clip will be automaticallydownloaded from the VAVA DashCam onto the VAVA Dash App.
Media Gallery Management
View, edit, and sharecaptured photos and videos.
Path
Check information regardingdriving routes.
TravelLog
Add photos todriving routes and turn it into a Travel Log. Click the share icon topost it on your favorite social
networks (Facebook, Twitter, Instagram, etc.)!
www.vava.com
E-mail: [email protected]m
Tel:[phone] (Monday-Friday:9:00 – 17:00 PST)
Address:46724 Lakeview Blvd,Fremont, CA 94538
NORTH AMERICA
EUROPE
E-mail:
[email protected]m(UK)
[e-mail](DE)
[email protected](FR)
[e-mail](ES)
[email protected](IT)
EU Importer: ZBTInternational TradingGmbH, Halstenbeker Weg98C,
25462 Rellingen,Deutschland
ASIA PACIFIC
E-mail: [e-mail](JP)
JP Importer: 株式会社ニアバイダイレクトジャパン
MANUFACTURER
Shenzhen NearbyExpressTechnologyDevelopment CompanyLimited
Address: 333Bulong Road, Jialianda Industrial Park, Building 1,
Bantian, Longgang District,Shenzhen, China, 518129
MADE IN CHINA
