Vava VA-IH008 User manual

VA-IH008 VAVA Smart Thermometer
SAFETY INSTRUCTIONS
NOT toys. Do not allow children to play with this product.
Do not place this product under the conditions of fire or high temperature (extremely hot).
Do not forcefully press, knock or rip this product apart.
CAUTION
Please read this user manual carefully and operate correctly as instructed in the user manual
Never try to disassemble this product by yourself. Non-professional maintenance or
dismounting of the spare parts are not allowed.
Do not place and use this this product under high temperature or humidity. Do not expose it
to the sun. (Operating Temperature: 0~45°C / 32~113°F for charging; -10~60°C / 14~140°F for
discharging; Storage Temperature: -20~60°C / -4~140°F)
To reduce the risk of fire or explosion, do not expose the product to rain or fire.
Stop using immediately if leakage or deformation occurs. Please contact us at
[e-mail].
Rinse out with clean water immediately if leakage enters the eyes by accident. Severe cases
should be immediately to the hospital for medical treatment.
Use original or authorized charging device only to avoid abnormalities.
Do not cut up or impale the power bank. Avoid short circuit.
Dispose this product as per local law and regulations
PACKAGE CONTENT
1 x Temperature Sticker
10 x Non-woven tapes
1 x Storage Box
1 x Type-C Charging Cable
1 x User Manual
1 x Thank You Card
PRODUCT DIAGRAM
8
7
2
3
4
6
1
5

1. Power Button
2. Temperature Sticker
3. Non-Woven Tape
4. LED Display
5. Alarm Ring
6. Storage Box
7. °C / °F Switching Button
8. Type-C Charging Port
LED DISPLAY
1. Body Temperature Mode
2. Ambient Temperature Mode
3. Temperature Sticker Charging Indicator
4. Storage Box Charging Indicator
5. Temperature in °C /°F
6. Temperature Measured
SPECIFICATIONS
Temperature Sticker
Measurement Error
＜0.2 °C
RF Transmitting Power
10dbm~12dbm
RF Carrier Frequency
915 MHZ
Charging Voltage
DC 5.0V
Battery Type
25mAh Lithium Polymer Battery
Standby Time
24 hours
Charging Time
1.5 hours
Charging Current
20 mA
Net Weight
Dimension

Storage Box
Measurement Error
＜0.3 °C
RF Carrier Frequency
915 MHZ 接收
Charging Voltage
DC 5.0V
Battery
2000mAh Lithium Polymer Battery
Standby Time
24 hours
Charging Time
3 hours
Charging Current
800 mA
Net Weight
Dimension
GET STARTED
1. Turning ON the Smart Thermometer
•Storage Box
Press and hold the Power Button, the LED display will light up from left to right, correctly
showing the ambient temperature and the battery level of both storage box and
temperature sticker.
•Temperature Sticker
Take the temperature sticker out of the storage box, it will be turned on automatically
with LED indicator (on the temperature sticker) flashing 3 times.
2. Pairing
•The temperature sticker will pair with the storage box automatically.
•Successfully paired: LED Display show the Body Temperature Mode (Body Temperature
Mode indicator on).
3. Body Temperature Measurement
•Paste Non-Woven Tape on Temperature Sticker
1) Take out one piece of non-woven tape, rip off the release paper 1, then paste it to
the back side of the temperature sticker. After pressing for 3s, put the temperature
sensor through the hole of the non-woven tape.
2) Rip off the release paper 2, then fix the temperature sensor on the back side of the non-
woven tape.
•Measure the Body Temperature
1) Paste the fixed temperature sensor to the armpit, and lightly press to make sure it
is closely attached to the skin.
2) Rip off the release paper 3, then paste the temperature sticker to the body. The
temperature sticker will start measuring the body temperature.
4. Ambient Temperature Detection
•Place the temperature sticker back into the storage box with the metal patch facing
down and plug in the power supply.
•At this point, the LED display starts to show the ambient temperature.
5. Switching between °C and °F
•Toggle the switch button on the bottom of the storage box to switch between °C and °F.

ALARM REMINDS
1. Fever Alarm: When the temperature reaches 38°C, fever alarm will be triggered with:
•Beep sound + alarm ring flashing red + temperature display every 1 second
•Manually press the Power button to cancel the alarm.
•If the temperature keep rising (more than 0.5°C), the fever alarm will be re-triggered.
2. Battery Low
•Temperature Sticker
1) When the temperature sticker is in low battery, the charging indicator on the top
left corner of the LED display will flash every 1 second with beep sound.
2) After putting the temperature back to the storage box for charging, or manually
pressing the Power button, the alarm will be cancelled.
•Storage Box
1) When the storage box is in low battery, the charging indicator on the top right
corner of the LED display will flash every 1 second with beep sound.
2) After connecting the storage box for charging via Type-C charging cable, or
manually pressing the Power button, the alarm will be cancelled.
3. Disconnection Alarm
•When the temperature sticker is disconnected with the storage box, the LED display
will show “-- . – C” every 1 second with beep sound.
4. Fall Off Alarm: When the temperature drops below 35°C, fall off alarm will be triggered with:
•Beep sound every 1 second until manually pressing the Power button to cancel the
alarm.
•The LED display will keep flashing “Fall” until the temperature restores to normal or
manually pressing the Power button to cancel the alarm.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
WEEE Compliance
DO not to dispose of product as unsorted municipal waste and to collect such WEEE separately, for
proper treatment, recovery and recycling, please take this product(s) to designated collection
points where it will be accepted free of charge. Please contact your local authority for further
details of your nearest designated collection station.
