1. Introduction
Thank you for your purchase of the Professional Wireless Pool
Thermometer with time, date, and indoor temperature. The following
user guide provides step by step instructions for installation, operation
and troubleshooting.
Important Note: nly install in fresh/chlorinated water. Do not
install in salt water. Do not exceed the operational range (-3 °C to 60
°C).
2. Getting Started
The Professional Wireless Pool Thermometer consists of a display
console (receiver), and a wireless thermometer (remote transmitter).
1.1 Parts List
QT
Y
Item
1 Display Console
Frame Dimensions (LxWxH): 4.5 x 3.0 x 0.75 in.
LCD Dimensions (LxW): 2.5 x 2.0in.
1 Pool Float Thermometer transmitter
Dimensions (LxWxH): 5.5 x 3.5 x 3.5in.
Version 1.4 Page 2

1.2 Remote Pool Thermometer Sensor Set p
Note: To avoid permanent damage, please take note of the battery
polarity before inserting batteries.
1. Twist off the transmitter cover (counterclockwise), as shown in
Figure 1 (overleaf). Be careful not to stress the sensor wire.
Figure 1
2. Insert two AA batteries and close the battery door, as shown in
Figure 2. Take care not to pinch the sensor wire.
Figure 2
3. Locate the dip switches on the inside cover of the lid of the
transmitter.
Figure 3 displays all three switches in the FF position.
Version 1.4 Page 3

Figure 3
4. Channel Number: The display console supports up to three
transmitters. To set each channel number (the default is Channel
1), change Dip Switches 1 and 2, as referenced in Table 1.
5. Temperature nits of Measure: To change the transmitter
display units of measure (°F vs. °C), change Dip Switch 3, as
referenced in Table 1(the default is °C).
DIP SWITCH F NCTION
1 2 3
D WN D WN --- Channel 1 (factory
default setting)
UP D WN --- Channel 2
D WN UP --- Channel 3
--- --- D WN °F
--- --- UP °C (factory default
setting)
Table 1
6. Verify the correct channel number (CH) and temperature units of
measure (°F vs °C) are on the display, as shown in and Figure
5.
Figure 4 Figure 4
Note: The following illustration shows the full segments of the
transmitter LCD for description purposes only and will not appear
like this during normal operation.
Version 1.4 Page 4

Figure 6
1. Transmitter channel number
2. Water temperature
3. Water temperature units (°F vs. °C)
4. Transmitter indication (flashes when sent)
Verify the gasket is properly seated in the guide on transmitter cover.
Twist on the transmitter cover (clockwise), as shown in Figure 7.
Figure 7
1.3 Display Console Set p
Note: To avoid permanent damage, please take note of the battery
polarity before inserting batteries.
Remove the battery door on the back of the display. Insert two AAA
(alkaline or lithium, avoid rechargeable) batteries in the back of the
display console.
All of the LCD segments will light up for a few seconds to verify all
segments are operating properly, and the unit will beep.
Replace the battery door, and fold out the desk stand and place the
console in the upright position.
The console will instantly display indoor temperature, and the default
date and time. The thermometer transmitter will display --, then
Version 1.4 Page 5

update remote temperature on the display within a few minutes. Do
not touch any buttons until the remote sensor reports in, otherwise
the remote sensor search mode will be terminated, and you must
power down and power up the console again by removing batteries.
When the remote sensor data has been received, the console will
automatically switch to the normal mode, and all further settings can
be performed.
If the remote does not update, please reference the troubleshooting
guide in Section 7.
1.4 Display Console Layout
Note: The following illustration shows the full segments of the
receiver LCD for description purposes only and will not appear like this
during normal operation.
Figure8
1. Transmitter channel number
2. Water temperature units (°F vs. °C)
3. Water temperature
4. Indoor temperature units (°F vs. °C)
5. Indoor temperature
Version 1.4 Page 6

6. Time and snooze alarm
7. Time of day
8. Date
9. day of week
10. MIN/MAX icon
11. transmitter reception (flashes when received)
The normal display mode is as shown in Figure 9.
Figure9
1.5 Sensor Operation Verification
Verify the indoor and remote (water) temperature matches closely
while in the same location. The sensors should be within 3°C (the
accuracy is ± 3°C). Allow about 30 minutes for both sensors to
stabilize.
3. Remote Sensor Installation
Place the remote sensor into the water (pool, spa, etc). The
temperature will take a few hours to stabilize. There is bracket on the
thermometer to optionally tether the float.
Version 1.4 Page 7

4. Console Operation
1.6 Buttons
The display console includes the following buttons (and location)
1. MODE: on the back of the display
2. C/F: on the back of the display
3. MAX/MIN: on the back of the display
4. SET: on the back of the display
5. CHANNEL: on the top of the display
6. CLEAR: on the top of the display
1.7 Set (Program) Mode
Press the MODE button to switch between TIME -> ALARM -> DATE
The following section defines how to set the time, alarm and date.
Note: After 60 seconds of inactivity, the display will automatically
revert to the normal display mode (automatic time out).
Note: Press and hold the C/F button for two seconds to advance
rapidly.
4.2.1 Set Time
1. While in the TIME mode, press the SET button, and the hour will
begin flashing. Press the C/F button to advance the hour. Make
special note of the AM / PM icon.
2. Press the SET button again, and the minute will begin flashing.
Press the C/F button to advance the minute.
3. Press the SET button again, and the second will begin flashing.
Press the C/F button to toggle between 12 hour and 24 hour
display mode.
4. Press the SET button again to return to normal mode.
4.2.2 Set Alarm Time
1. While in the ALARM mode, press the SET button, and the alarm
hour will begin flashing. Press the C/F button to advance the
alarm hour. Make special note of the AM / PM icon.
2. Press the SET button again, and the alarm minute will begin
Version 1.4 Page 8

flashing. Press the C/F button to advance the alarm minute.
3. Press the SET button again to return to normal mode.
4.2.3 Set Date
1. While in the DATE mode, press the SET button, and the year
will begin flashing. Press the C/F button to advance the year.
2. Press the SET button again, and the month will begin flashing.
Press the C/F button to advance the month.
3. Press the SET button again, and the day will begin flashing.
Press the C/F button to advance the day.
4. Press the SET button again to return to normal mode.
1.8 Alarm Mode
4.3.1 Activating / Deactivating the Alarm
1. While in the ALARM mode, press the C/F button to activate the
alarm. The alarm icon will appear .
2. Press the C/F button again to deactivate the alarm. The alarm
icon will disappear.
4.3.2 Cancelling the Alarm
When an alarm has been triggered, the alarm will sound and the alarm
icon will flash for 60 seconds. Press any button on the back of the
display to silence the alarm.
4.3.3 Snooze Alarm
When an alarm has been triggered, the alarm will sound and the alarm
icon will flash for 60 seconds. Press the CHANNEL button on the
top of the display or allow the alarm to time out to enter the snooze
mode. The snooze icon will flash (zz). After five minutes, the alarm
will sound again. After five consecutive snooze alarms, the snooze
alarm mode will be deactivated.
Version 1.4 Page 9

1.9 Min/Max Mode
Note: If you have multiple remote temperature sensors, select the
Channel you wish to view the min/max data before you enter the
min/max mode.
Note: Resetting the minimum and maximum values resets all three
channels at the same time for multi-channel operation.
1. Minimum Values. While in Normal Mode, press the MIN/MAX
button to enter the min/max mode. The minimum water
temperature and indoor temperature will be displayed. Press the
CLEAR button (on the top of the display) to clear the minimum
values to the current measured values.
2. Maximum Values. Press the MIN/MAX button again, and the
maximum water temperature and indoor temperature will be
displayed. Press the CLEAR button (on the top of the display) to
clear the maximum values to the current measured values.
3. Press the MIN/MAX button again to exit the min/max mode.
1.10 °C/°F nits of Measure
To toggle between °C/°F temperature units of measure on the
display, press the C/F button on the back of the display.
1.11 Multi-Channel Operation
The KAP LTHERMA supports up to three remote thermometers (only
one is included in the package).
4.6.1 Multi-channel Sensor Initialization
Place the multiple remote sensors about 10 feet from the console.
Power up the sensors and console in the following order:
1. Power up the first remote thermometer and set the channel
number dip switches, as described in Section 1.3. Verify the
display reads Channel 1.
2. Power up the second remote thermometer and set the channel
number dip switches, as described in Section 1.3. Verify the
display reads Channel 2.
Version 1.4 Page 10

3. Power up the third remote thermometer (if available) and set the
channel number dip switches, as described in Section 1.3. Verify
the display reads Channel 3.
4. Power up the console last and wait about 3 minutes. Press the
CHANNEL button on the top of the display to verify all three
sensors are communicating to the console.
5. nce verified, you are ready to install the remote thermometers.
4.6.2 Multi-channel Sensor Accuracy Note
Verify the temperature values match closely with the console and
sensor array in the same location. The sensors should be within 3°C
(the accuracy is ± 3°C).
Allow about 30 minutes for all sensors to stabilize.
4.7 Maintenance
We recommend inspecting the gasket inside the lid of the floating
thermometer with each battery change. Moisten with pool gasket
lubricant (available from most pool stores). Inspect for any moisture
inside the floating thermometer. Replace the gasket every year.
To replace the gasket, slide the gasket over the float potion of the
floating thermometer and insert into the gasket guide on the lid.
5. Glossary of Terms
Term Definition
Accuracy Accuracy is defined as the ability of a
measurement to match the actual value of the
quantity being measured.
Range Range is defined as the amount or extent a value
can be measured.
6. Specifications
1.12 Wireless Specifications
Line of sight wireless transmission (in open air): 300 feet under
ideal conditions, 100 feet under most conditions.
Frequency: 433 MHz
Update Rate: 10 seconds on the remote, 90 seconds on the
display console.
Version 1.4 Page 11

1.13 Measurement Specifications
The following table provides specifications for the measured
parameters.
Measurement Range Accuracy Resolution
Indoor
Temperature
-40 to 60 °C ± 3 °C 0.05 °C
Water
Temperature
-50 to 60 °C ± 3 °C 0.05 °C
1.14 Power Consumption
Display console : 2 x AAA 1.5V Alkaline batteries
Remote sensor : 2 x AA 1.5V Alkaline batteries
Battery life: Minimum 12 months for base station
Minimum 12 months for remote thermometer sensor (use lithium
batteries in cold water climates)
7. Troubleshooting Guide
Problem Solution
Wireless remote not
reporting in to console.
The maximum line of sight
communication range is 100m. Move
the display console closer to the remote
sensor.
Cycle power on the console by
removing and re-inserting the
batteries. The console may have exited
the search mode.
Install a fresh set of batteries in the
remote thermo-hygrometer. For cold
weather environments, install lithium
batteries.
Make sure the remote sensors are not
transmitting through solid metal (acts
as an RF shield) or earth barrier (down
a hill).
Version 1.4 Page 12

Move the display console away from
electrical noise emitting devices, such
as computers, TVs and other wireless
transmitters or receivers.
Radio Frequency (RF) Sensors cannot
transmit through metal barriers
(example, aluminum siding) or
multiple, thick walls.
Display console contrast is
weak
Replace console batteries with a fresh
set of batteries.
Temperature on remote
sensor and display console
disagree
The remote sensor updates every 10
seconds. The display reads the sensor
every 90 seconds.
If transmission is intermittently lost,
the sensor and console temperature
values will disagree.
8. Liability Disclaimer
Please help in the preservation of the environment and dispose of used
batteries via an authorized depot.
The electrical and electronic wastes contain hazardous substances.
Disposal of electronic waste into nature and/or in unauthorized
grounds strongly damages the environment.
Reading the “User manual” is highly recommended. Kogan cannot
accept any responsibility for any incorrect readings and any
consequences that occur should an inaccurate reading take place.
This product is designed for use in the home only as indication of
weather conditions. This product is not to be used for medical
purposes or for public information.
This product is not a toy. Keep out of the reach of children.
Version 1.4 Page 13

No part of this manual may be reproduced without written
authorization of the manufacturer.
9. FCC Statement
Statement according to FCC part 15.19:
This device complies with part 15 of the FCC rules. peration is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Statement according to FCC part 15.21:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
10. Warranty:
ur product is covered by a Full 12 months warranty provided from
the date of purchase. If product develops a fault due to normal use we
will repair the item with replacement parts as required. This warranty
does not cover damage caused by mishandling, misuse, accidental
damage, damage caused by an act of god, or wear and tear. The
warranty is a return to base warranty; this means that the Kogan
customer support team must authorize the return and supply a
postage label that will cover postage costs. We will return the repaired
item to you at our own cost. If an item cannot be repaired, a
replacement item will be sent. If the product is found to not be faulty,
Kogan reserves the right to recoup the cost of the prepaid postage.
Version 1.4 Page 14
Table of contents
Other Kogan Thermometer manuals
