VAVIE WE-UF-02 User manual

1
VAVIE ALKALINE WAT ER PURIFIER
USER MANUAL
Model Name: Water Element
Model Number: WE-UF-02
Contents
Product Description ................................................................................................................................ 2
External Structure Diagram .................................................................................................................... 2
Different pH Levels Explanation............................................................................................................ 3
Water Dispensing Procedure................................................................................................................... 3
Self-Cleaning .......................................................................................................................................... 4
Benefits of Drinking Alkaline Water...................................................................................................... 4
Dispenser Cleaning Instructions ............................................................................................................. 5
Troubleshooting...................................................................................................................................... 5
Technical Specification........................................................................................................................... 6
Usage Guideline...................................................................................................................................... 6
Precautions.............................................................................................................................................. 7
Maintenance............................................................................................................................................ 7
Filter Description.................................................................................................................................... 8
Online Warranty Registration................................................................................................................. 8
Terms and Conditions............................................................................................................................. 8
Packing list.............................................................................................................................................. 8

2
Product Description
1. The feed water of this unit is from the input tap source (municipal/domestic water).
The water purifier is optimized to produce alkaline water using tap water having a
TDS range of 50-300 ppm.
2. The output is either purified water by ultra-filtration or alkaline water or acidic water
(depending upon the selection of switch knob). Please note that acidic water is not
suitable for drinking.
3. Has external PP filter followed by 2-stage built-in filters (Active carbon and Ultra-
Filtration) for water purification. Hence, installing the water ionizer is simple and
convenient.
4. This Ionizer has large electroplates which increases usage life of the ionizer. System
also has self-cleaning function.
5. This unit was manufactured by applying international advanced technology, with
features of beautiful shape, attractive appearance and ease to use. It is suitable to use
at home, hotel, office space and school place and to meet the different needs of the
people.
6. This unit has adapted modular structure with stable quality, easy maintenance, energy
saving, safe and convenient to use.
7. Additional features include high effluent flow rate, no leakage and longer lifespan.
8. There is a separate discharge outlet at the back which should be connected by a pipe
to remove the discharge water (produced while dispensing alkaline water and acidic
water).
External Structure Diagram

3
Different pH Levels Explanation
CHOICE
OF
WATER
pH LEVELS
SUITABLE
FOR
DRINKING
USES
Alkaline
Water 3
(Strong)
Produces water of pH
9.5
No
For removing the astringent taste in
some type of vegetables.
Alkaline
Water 2
(Medium)
Produces water of pH
9.0
Yes
Strong alkaline water penetrates well
allowing vegetables and other
ingredients to cook quickly without
removing its flavour.
Alkaline
Water 1
(Mild)
Produces water of pH
8.5
Yes
Beneficial for health by acting as a
powerful antioxidant, an effective
alkalizing agent and a powerful
detoxifier.
Purified
Water by
3-stage
Filtration
Input feed (municipal)
water passes through a
3 stage filter (PP +
ACF + UF) to provide
Purified water.
Yes
1. PP filter removes sediment, rust,
suspended solids, and colloids.
2. Activated Carbon filtration can
effectively reduce certain organic
compounds, chlorine and taste/odour
causing compounds in the drinking
water.
3. UF filter removes harmful viruses,
bacteria and heavy metals.
Acidic
Water 1
(Mild)
Produces water of pH
5.5
No
For beauty and skin care.
Acidic
Water 2
(Strong)
Produces water of pH
3.5
No
For cleaning the kitchen.
*Please note that the pH value of the alkaline / acidic water will have a tolerance of +/- 0.5 depending
on feed tap water.
*There will be a beep sound while dispensing Acidic water. This is to indicate to the users that it is
not suitable for drinking.
Water Dispensing Procedure
A. PURIFIED WATER:
1. Input tap water should be connected to the PP filter which then connects to the
water purifier input.
2. Ensure that the power cord is connected and switched ON.
3. Ensure that the selector switch knob is at “Purified Water” position.
4. Rotate the manual knob to dispense purified water.

4
B. ALKALINE WATER:
1. Input tap water should be connected to the PP filter which then connects to the
water purifier input.
2. Ensure that the power cord is connected and turned ON.
3. Rotate the selector switch knob to “Alkaline Water” position. Based on the
requirement, you can choose any of the 3 levels:
a. Mild Alkaline Level 1
b. Medium Alkaline Level 2
c. Strong Alkaline Level 3
4. Rotate the manual knob to dispense alkaline water.
C. ACIDIC WATER:
1. Input tap water should be connected to the PP filter which then connects to the
water purifier input.
2. Ensure that the power cord is connected and turned ON.
3. Rotate the selector switch knob to “Acidic Water” position. Based on the
requirement, you can choose any of the 2 levels:
a. Mild Acidic Level 1
b. Strong Acidic Level 2
4. Rotate the manual knob to dispense acidic water.
Note: There will be discharge when dispensing alkaline /acidic water. Make sure the
discharge pipeline is connected to outlet else the floor will become wet and slippery.
Self-Cleaning
In addition to these different water selections, there is Self-Cleaning feature available. This
cleaning functionality is to avoid cases where the pH levels are not up to par or when
changing water levels. The unit will automatically self-initiate cleaning when the alkaline
water has been used every 10 times.
Benefits of Drinking Alkaline Water
WHAT IS ALKALINE WATER?
Alkaline water is the delicious and healthy water created from progressive water technology.
This dispenser, through the process of ionization, can instantaneously produce alkaline water.
Drinking alkaline water provides various health benefits thereby “Simplifying Healthy
Living”.
POWERFUL ANTIOXIDANT
The centrepiece of ionized alkaline water is its antioxidant properties. These hydroxyl ions
seek out and neutralize free radicals, making them wonderful free radical scavengers and
enabling a body rich in oxygen and energy.

5
BALANCE BODY pH AS AN EFFECTIVE ALKALIZING AGENT
Keeping the body alkaline is people’s first line of defence in fighting any disease and alkaline
ionized water creates a major impact in balancing the body’s pH. A body that is too acidic
provides ideal environment for diseases to manifest and thrive in.
SUPERIOR HYDRATOR AND A POWERFUL DETOXIFIER
One of primary causes of disease is chronic cellular dehydration, which leaves the body’s
cells in a perpetual state of weakness and defence. Drinking alkaline water is six times more
hydrating than “conventional” drinking water. Effective hydration helps skin look healthier
and smoother.
Dispenser Cleaning Instructions
NOTE: For your safety, please confirm that the machine is disconnected with power before
performing the below listed progresses.
1. All the new products have been checked before delivery; you can directly plug and
play.
2. Please use the listed commercial disinfectants to perform the cleaning procedure;
Follow the guideline cleaning procedure as shown in the user manual to disinfect and
wash the unit; after washing, drain the washed water out; the cleaning frequency is
normally 6 months per time.
3. Please request for our service to clean the water purifier. It will be beneficial to
prolong the unit lifetime for providing good performance. Please DO NOT
disassemble the machine on your own.
4. Non-abrasive neutral household detergent can be applied to clean the body surface,
but make sure that the detergent containing water does not flow into the internal body.
5. If the dispenser is not used for a long time, please turn off the inlet valve to prevent
leakage and purifier damage.
Troubleshooting
Problem
Likely Cause
Actions
No outflow from the
faucets
The input tap water
does not pass through
the filters.
Ensure that the tap water passes through the
external PP filter and is fed to the inlet of
the water purifier.
Alkaline water not
coming through the
faucet
1. Feed tap water
not opened
2. Selector switch
not at alkaline
water position.
1. Ensure that the feed tap water inlet
is turned ON for continuous water
flow.
2. Make sure that the selector knob for
alkaline water is selected for
dispensing.
Acidic water not
coming through the
faucet
1. Feed tap water
not opened
2. Selector switch
1. Ensure that the feed tap water inlet
is turned ON for continuous water
flow.
2. Make sure that the selector knob for

6
not at acidic
water position.
acidic water is selected for
dispensing.
Loud noise
The machine is not
placed steady
Make sure the unit is on a level floor or
counter strong enough to support it when
fully loaded.
Fuselage electric
leakage
The ground wire didn’t
connect to the ground
properly.
Use the standard triplex receptacle outlet
with leakage protector, and promptly
eliminate leakage fault.
Blue LED Blinks
four times every 1
second
Water is too pure to
ionize
Need to change the input water type.
Blue LED Blinks
twice every 1
seconds
Feed water flow is too
slow for ionizing the
water
Minimum flow rate for ionization should be
at least 0.6L/min.
Blue LED Blinks
once every 1
seconds
Previous water stored
inside the ionizer is
being discharged.
Wait for the LED blinking to stop, then use
the dispensed water
Technical Specification
Model Name
Water Element
Model Number
WE-UF-02
Rated Voltage
230V AC
Rated Frequency
50Hz
Protected Against
Electric Shock
Class I Type
Feed water type
Direct pipeline water as feed water input
Different water
levels
1. Alkaline 3 (Strong) – pH 9.5
2. Alkaline 2 (Medium) – pH 9.0
3. Alkaline 1 (Mild) – pH 8.5
4. UF Purified water
5. Acidic water (Mild) – pH 5.5
6. Acidic water (Strong) – pH 3.5
Please note that the pH value of the alkaline / acidic water will have a
tolerance of +/- 0.5 depending on feed tap water.
ACIDIC WATER IS NOT SUITABLE FOR DRINKING
Self-cleaning
Cleaning will start once every 10 cycles of alkaline / acidic water
being dispensed
Self-flushing
LED blinks once every 1s when water is flushing (when mode is
changed). Wait for the LED blinking to stop, then use the dispensed
water
Usage Guideline
1. Ensure that the following piping are connected:
a. inlet tap water to external PP filter input
b. External PP filter output to the purifier inlet
c. Purifier discharge to common discharge outlet

7
2. Now insert the power cord to the socket and turn ON dispenser. Turn on the tap water
and let the water to pass through for a few minutes to ensure there are no leakages.
3. Open the manual output knob to get UF purified water (ensure that the selection knob
is at Purified water position and inlet tap water flows through the purifier).
4. For Alkaline water output, rotate the selection knob to “Alkaline water” (1 or 2 or 3)
and open the manual output knob to drink fresh instantaneous alkaline water.
5. For Acidic water output, rotate the selection knob to “Acidic water” (1 or 2) and open
the manual output knob for acidic water.
Please note that Alkaline 3, Acidic Water 1 and 2 is not meant for drinking.
Precautions
1. This product is for indoor use. DO NOT expose the dispenser to sunlight.
2. DO NOT modify the power plug or extend the power cable, thereby preventing fires
caused by overheated wires.
3. If the power cable is damaged, the cable spare will be provided by the manufacturer
or replaced by specified technical service contractor.
4. DO NOT place the dispenser near the liquid splashing place. It should be placed at a
dry and cool environment. DO NOT use it under direct sunlight or in outdoor
premises. Keep it away from any flammable substances.
5. If the dispenser is shutting down for long term, please switch off the power supply,
unplug the power cord and let the discharge water drain out.
6. If this machine is used after a long time, please allow the water to flow through the
filters and discharge out before starting to use.
7. When doing the cleaning process or stopping the machine for a long term, please pull
out the power. DO NOT clean the dispenser by immersing it into water; DO NOT use
water to leach the dispenser body or use gasoline organic solvent to scrub the machine
body. Please use wet cloth to wipe the body surface slightly.
8. DO NOT pull the power cord hard. This unit must be applied three-pin socket with
leakage protector.
9. When not in use, please turn off the power for energy saving and accident prevention.
10. DO NOT make unauthorized alterations to the internal circuit for fires.
11. DO NOT apply voltage greater than 230V AC.
12. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
13. Children should be supervised to ensure that they DO NOT play with the appliance.
14. The dispenser must not be immersed in water.
Maintenance
When cleaning this dispenser, turn off the power first and unplug the power cord. Then use
detergent wetted cloth to wipe the unit body. Re-wipe the body out of detergent with clean
wet cloth. DO NOT clean the unit by splashing water. For long-term product use, please call
our service center for maintenance every 6 months.

8
Filter Description
Replace the filter regularly to maintain water purity
In order to make sure every filter works properly and the water quality is up to the standard,
users should reference the following time to estimate the replacement cycle (water production:
20L/day).
Name
Recommended Replacement Cycle
External PP filter
3~6 months
Activated carbon fiber filter (ACF)
10~12 months
Ultrafiltration membrane filter (UF)
1~2 years
Special remind: As the life of filter degrades due to the change of raw water temperature, raw water
pressure, raw water quality, purified water usage and the use of the environment and so on, users
should replace their filter according to the actual situation.
Online Warranty Registration
1. Register online on the VaVie official website: www.vavie.com.sg
2. Please enter the necessary information on the “Warranty Registration” page.
3. Contact us
• If you have any enquires, suggestions, or feedbacks regarding our products and
services, please do contact us by email, call our Service Hotline, or visit our website:
• Email: [email protected]
• Official website: www.vavie.com.sg
Terms and Conditions
1. One year free maintenance is provided (two times a year) which includes:
a. Checking for electrical parts
b. Checking for water leakage
2. Please call and make arrangement to service your VaVie Water dispenser at your
location*.
* Service locations must be within Singapore only.
Packing list
1. VaVie Alkaline Water Purifier (WE-UF-02)
2. Switching Power Supply - 1
3. Manual valve – 1
4. Elbow joints - 3
5. PE piping
6. Tap and pipe accessories – 1 set
7. PP Filter - 1
8. Wall mount screws – 2 sets

9
___________________________________________________________________________
Tritech Water Technologies Pte Ltd
2, Kaki Bukit Place, Tritech Building, #06-00 Singapore 416180
Tel: [phone] Fax: [phone]
Email: [e-mail] Web: www.vavie.com.sg
___________________________________________________________________________
