Vax C91-MZ SERIES User manual

User Guide
vax.co.uk
GB
Vax Careline 0870 606 1248
Bagless Cylinder
Get Cleaning...
What’s your Vax’s model number?
What’s your serial number? ( ocated on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
C91-MZ Series
C 9 1 –M Z – –
– – – – –
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 1

---
1
Machine Overview
Max
5
1 On/off button
2 Auto cord rewind button (hidden)
3 Floor tool parking slot (hidden)
4 Carry handle
5 Dirt container carry handle
6 Dirt container release button
7 Separator
8 Dirt container
9 Max fill line
10 Hose inlet
Unit
Accessories
15
14
18
17
2Vax Careline
0870 606 1248
Filters
7
8
2
3
4
10
9
6
17
18
!
Dirt container must be emptied
as soon as this line is reached.
11 Crevice tool
12 Turbobrush (not standard on all models)
13 Combination floor tool
14 Telescopic extension tube
15 Flexible hose & handle
16 2-in-1 tool
17 Pre-motor filter (hidden)
18 Post-motor filter (hidden)
12
13
16
11
(dusting brush & upholstery tool)
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 2

FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
surfaces.
2. Turn off the vacuum cleaner controls before
disconnecting or connecting from the mains supply.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose and
accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord is
damaged return the vacuum cleaner to a Vax
Authorised Service Agent or a suitably qualified
person for examination, repair or adjustment.
8. Do not pull or carry by cord. Do not use the cord
as a handle, close a door on the cord or pull cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord
away from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air-
flow. Keep all openings free of dust, lint, hair or
anything that might reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches
or any hot, smoking or burning objects.
13. Do not pick up flammable or combustible
materials (lighter fluid, petrol, kerosene etc.) or use
in the presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material
(chlorine, bleach, ammonia, drain cleaner etc.).
15. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
16. Do not use without A of the filters in place.
17. Take extra care when vacuuming on stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner
21. Use only CE-approved 13 amp extension cords.
Non-approved cords may overheat. Care should
be taken to arrange the cord so that the cord
cannot be tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dirt container, or before
connecting/disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging the cord into the electrical
outlet, make sure the switch is in the ‘off’ position. Hold the
vacuum cleaner firmly when starting and in use.
IMPORTANT: If the inlet, hose or telescopic tube
is blocked, switch off the vacuum cleaner and
remove the blockage(s) before re-starting the vacuum
cleaner.
IMPORTANT: Cleaning filters improves vacuum
performance. Vax recommends that your filters
should be checked and cleaned periodically. If your filters are
washable make sure they are completely dry before
inserting back into the vacuum cleaner.
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason the unit should overheat,
the thermostat will automatically turn the unit off. Should this
occur, unplug the vacuum cleaner from the electrical outlet
and turn off the switch. Remove dirt container and empty.
Clean filters. Allow the unit to cool for approximately one (1)
hour. To re-start, plug into an electrical outlet and switch back
on.
This vacuum cleaner is intended for household use
only and NOT for commercial or industrial use.
PLEASE EEP INSTRUCTIONS FOR FURTHER USE.
!
General Safety Information
!
!
!
!
vax.co.uk 3
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 3

---
Operation
Assembling your vacuum cleaner
Operating the appliance
NOTE: Fully unwind
power cord before every
use. A yellow mark on
the cord indicates the
recommended cord
length. Do not exceed
the cord length beyond
the yellow mark.
Packing away and storage
4Vax Careline
0870 606 1248
NOTE: For convenience
there is a parking slot located
at the rear of the vacuum
cleaner where the floor tool
and tubes can be attached
for storage and carrying.
eep your Vax like new
IMPORTANT: The condition of the filters affects the
performance of your machine. Please check and clean
filters periodically (depending on the level of use). For full
cleaning instructions, see page 5.
!
IMPORTANT: Do not use the vacuum cleaner without
all of the filters in place.
!
NOTE: The crevice tool, dusting brush and upholstery tool can all be attached to the telescopic
tube or to the handle.
Switch vacuum cleaner on
14 15
14
14
13
Carpets
Hard floors
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 4

Maintenance (Keep your Vax as good as new)
Emptying and cleaning the dirt container
Cleaning the post-motor filter
vax.co.uk 5
Cleaning the HEPA pre-motor filter
tap
24hr
tap
tap
Advanced cleaning
!
1
2
1
2
!
40° C max
WARNING: Do not wash the post-motor filter.
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 5

---
Maintenance (Keep your Vax as good as new)
6Vax Careline
0870 606 1248
Cleaning Blockages
WARNING: To reduce the risk of electric shock, turn the vacuum cleaner off and unplug from
the electrical outlet before performing maintenance/troubleshooting checks.
Disconnect the hose from the vacuum cleaner and remove any blockages found then reconnect
the hose securely.
Removing debris from the TurboBrush (not standard on all models)
The brushbar will stop rotating if it becomes blocked. Using a pair of scissors, cut through any threads
or hairs caught around the brushbar.
!
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 6

FAQs
!
WARNING: to reduce the risk of personal injury, unplug the vacuum cleaner
before performing maintenance/troubleshooting checks.
Is there an accessory missing?
•Check the ‘Machine Overview’ page in this
guide to make sure the part is definitely
included in your unit.
•If it is missing, we’re here to help. Simply call
us on 0870 606 1248
Why won’t the vacuum cleaner pick up?
• The filters may be clogged: Refer to the
Maintenance sections (Page 5).
• The Dirt Container is full or blocked: Refer to
the Maintenance sections (Page 5).
• The Dirt Container may be incorrectly
installed: Refer to the Maintenance sections
(Page 5).
Why is dust escaping from the vacuum?
• The filters may not be installed correctly. Refer
to the Maintenance sections (Page 5).
• The Dirt container may be incorrectly
installed: Remove the Dirt Container from the
unit by pressing the Dirt Container Release
Button (6) and reattach it to the unit,
ensuring it is locked firmly back into place.
• The filters may be clogged: Refer to the
Maintenance sections (Page 5).
What do I do if an accessory/the unit
becomes damaged or broken?
• Visit www.vax.co.uk for parts and spares.
• Please call our Vax careline to purchase new
spares or order a replacement:
0870 606 1248
Why won’t the accessories pick up
properly?
• The accessory may be blocked: Refer to the
Maintanance section (Page 6).
• The accessory may be faulty: call our
Vax Careline to order a replacement:
0870 606 1248
Why will the vacuum cleaner not run?
• It may not be plugged into the electrical
outlet correctly: Ensure that the plug is
pushed into the electrical outlet securely.
• The electrical outlet may not be working:
Check the fuse or breaker and consult an
electrician.
• The motor Thermostat may have tripped:
Switch off and unplug the vacuum cleaner.
eave for one hour before switching the
vacuum cleaner back on.
vax.co.uk 7
Don’t take your machine
back to the shop, simply
contact us
C91-MZ Mach Zen Se ies Use Guide.qxd:Use guide 7/7/09 16:15 Page 7

---
8Vax Careline
0870 606 1248
Other Information
U Service & Help
Vax Customer Careline 0870 6061248
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
Any queries or concerns about using the Vax, call the Vax Careline. Calls are charged at the UK
national rate.
Please make a note of the serial number and model number of the carpet cleaner before calling.
There are over 400 approved Vax Service Agents in the UK. For the nearest Service Agent, please
call the Vax Customer Careline or visit vax.co.uk
Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 1600 W
Capacity: 2.6
Filters: Pre-motor filter (washable)
HEPA post-motor filter (lifetime - tap to clean)
Cord length: 8m (approx)
Weight: 6.5kg
Subject to technical change without notice.
EEC Statement of Compliance
Manufacturer/EEC importer: Vax imited, hereby on our own responsibility, declare that the
C91-MZ Mach Zen series is manufactured in compliance with the following Directives:
Safety: 2006/95/EC ow Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your ocal Authority or retailer for recycling advice.
