Vax POWERMAX VRS18W User manual

---
Version 1.0
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: [email protected]. k - website: vax.co. k
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 12

vax.co. k VRS18W
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
User G ide
Get cleaning...
What’s yo r Vax model n mber? (Located on the flap of the packaging)
What’s yo r serial n mber? (Located on the base of the machine)
Note these down in case yo need them in f t re. Please keep instr ctions for f rther se.
– – – – –
e.g. V R S 1 8 W
VRS18W
Carpet Washer
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 1

VRS18W
1. Diagram
vax.co.uk
2 parts overview
1 Handle
2 Clean water tank release button
3 Clean water tank
4 Dirty water tank release latch
5 Dirty water tank handle
6 Exhaust filter
7 Brushbar (hidden)
8 Dirty water tank
9 Solution release trigger
10 Cord clip
11 Cord wrap
12 Cord
13 On/off button
14 Unit recline pedal
15 Vax carpet cleaning solution
14
9
10
Fig.1/1
2
1
3
5
7
4
12
13
11
15
8
6
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 2

3
safety information
2. Safety Information
FOR HOU EHOLD U E ONLY.
This carpet washer is intended for household use only and
OT for commercial or industrial use.
Please keep instructions for further use.
When using the carpet washer, basic safety precautions
should always be observed, including the following:
1. Do not leave the carpet washer unattended when
plugged in. Unplug the appliance from the socket
when not in use.
2. Only use the carpet washer indoors.
3. Turn off all controls on the carpet washer before
disconnecting or connecting from the mains supply.
4. Always unplug the carpet washer before
connecting or disconnecting the hose
and accessories.
5. Always unplug the carpet washer before carrying
out any maintenance.
6. Children should be supervised to ensure that they
do not play with the appliance.
7. This appliance is not intended for use by children
under eight years of age and persons with
reduced physical, sensory or mental capabilities or
lack of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance in a safe way and understands
the hazards involved.
8. Cleaning and maintenance shall not be made by
children without supervision.
9. The appliance should only be used as described in
the quick start guide or in the full online user guide.
10. Only Vax recommended attachments and solution
should be used with this appliance.
11. Do not use this carpet washer if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use this carpet washer with a
damaged cord or plug. If the supply cord is
damaged return the carpet washer to a Vax
authorised Service Agent.
12. Do not pull or carry this appliance by the cord. Do
not use the cord as a handle, close a door on
the cord or pull the cord around sharp edges or
corners. Do not run the carpet washer over the
cord. Keep the cord away from heated surfaces.
13. Do not handle the plug or the carpet washer with
wet hands.
14. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
15. Do not pick up with the machine any hot coals,
cigarette butts, matches or any hot, smoking or
burning objects.
16. Do not pick up with the machine any flammable or
combustible materials (lighter fluid, petrol, kerosene
ect.) or use the machine in the presence of
explosive liquids or vapours.
17. Do not use the machine on areas where there may
be harmful or toxic material (chlorine, bleach,
ammonia, drain cleaner ect.)
18. Store the carpet washer in a cool, dry area.
19. Do not use an extension cord with this machine.
20. Do not carry the appliance while its switched on.
21. To prevent dirty water from running into the
motor, do not hold the appliance upside-down or
lay it on its side. Use the appliance in a normal
cleaning position.
22. Do not use without all water tanks and solution
tanks in place.
23. Do not use the carpet washer unless the carpets
have been dry vacuumed thoroughly first.
24. Keep the unit on the floor.
25. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict
airflow. Keep all openings free of dust, lint, hair or
anything that might reduce airflow.
26. Do not attempt to remove blockages with sharp
objects as they may cause damage.
27. Using improper voltage may result in damage to the
motor and possible injury to the user.
The correct voltage is listed on the rating label.
28. Do not use without all of the filters in place.
29. Take extra care when cleaning on the stairs.
30. Keep the area you are cleaning well lit.
31. Do not unplug the machine by pulling on the cord.
IMPORTANT: If the hose or tools are blocked, switch off
the carpet washer and remove the blockage(s) before
re-starting your machine.
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason the unit should overheat, the
thermostat will automatically turn the unit off. Should
this occur, unplug the carpet washer from the electrical
outlet and turn off the switch. Check the hose for
blockages. Clean the filters. Allow the unit to cool for
approximately one hour (if you have cleaned the filters
you will need to wait twenty four hours for the filters to
dry before putting them back in the machine). To re-start
the machine, plug it into an electrical outlet and switch it
back on.
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 3

vax.co.uk
4 assembly
3. How to Assemble
Use a crosshead screwdriver
Components
Assembly
Line up mid-section with base unit and slot into place (Fig
3/6).
Insert handle into mid-section ensuring that the solution
trigger is at the back of the machine and the screw hole
in the handle is lined up with the screw hole in the mid-
section (Fig 3/7).
Insert and tighten (Fig 3/8).
Fig.3/5 - Clean Water Tank
Fig.3/6
Fig.3/7
Fig.3/4 - 3 Screws
Fig.3/3 - Handle
Fig.3/2 - Mid-Section
Fig.3/1 - Base Unit
Align screw holes
WARNING: Always switch off and unplug your
machine from the electrical outlet before filling the
clean water tank, emptying the dirty water tank,
before assembling, opening, before connecting/
disconnecting the attachments, or carrying out
maintenance or troubleshooting checks.
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 4

5
assembly / before cleaning
Twist cord holder until it is facing upwards (Fig 3/9).
Finally insert clean water tank and machine is fully
assembled (Fig 3/10).
4. Before cleaning
IMPORTANT: Do not use the carpet washer as a
dry vacuum.
1. Vacuum carpet thoroughly. Use a vacuum cleaner
with a revolving brushbar for best results.
2. Remove as much furniture from the room as
possible. If unable to remove the furniture, place
plastic or foil under and around the legs until the
carpet has dried completely.
Helpful hints for cleaning carpets:
IMPORTANT: Only use Vax carpet cleaning solution.
Using other solutions may cause excess foaming.
Excessive foam will prevent the machine from working
effectively. Using other solutions will invalidate the
guarantee.
1. Do not oversaturate carpet with cleaning solution
while using the carpet washer.
2. For heavily soiled areas, additional applications may
be necessary.
3. Allow plenty of time to dry carpet thoroughly.
4. Wipe cleaning solution from woodwork and wood to
prevent any damage.
5. Try not to w alk on carpet until it is completely dry.
6. After carpet is thoroughly dry, vacuum the carpet
using a vacuum cleaner with a revolving brushbar.
7. Before cleaning, determine where to start and end,
making sure not to walk over previously
cleaned areas.
Check for colour fastness:
Before cleaning carpet, test for colour fastness. Dampen
a white cloth with solution. In a small hidden area of your
carpet, gently rub the cloth over the area. Check each
colour for colour bleeding. If the cloth remains clean, it
should be safe to clean the carpet.
After cleaning:
• Allow carpet to dry completely. Try not to walk on
the carpet until it is dry.
• If it is necessary to walk on the carpet, place white
towels on the areas to be walked on.
• If the carpet is not dry and the furniture must be
placed back in the room, use plastic or foil under the
furniture to prevent staining the carpet.
• Thoroughly clean the dirty water tank with warm
(max 40ºC) tap water.
Fig.3/8
Fig.3/9
Fig.3/10
Insert Screw Insert Screw
Insert Screw
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 5

vax.co.uk
6 preparing the machine
5. Preparing the Machine
Hold the handle of the clean water tank and press ‘PULL
TO RELEASE’. Tilt Clean Water Tank away from the carpet
washer and remove (Fig 5/1).
Unscrew the measuring cap from the reverse side of the
clean water tank. Fill measuring cap with solution (Use
only 1 capful of solution per full tank). Pour into clean
water tank (Fig 5/2).
Fill remainder of clean water tank with warm (max 40°C)
tap water. Replace cap (Fig 5/3).
Place bottom of clean water tank into carpet washer and
push back until it locks into place (Fig 5/4).
Fig.5/3
Fig.5/4
Fig.5/1
Fig.5/2
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 6

7
usage
6. Usage
IMPORTANT: ever leave unit unattended with power
on. Turn off when emptying and filling tanks. Do not
over-saturate the car pet
Plug cord into electrical socket. Turn on the machine by
using the on/off switch located on the side of the machine.
Step onto handle release pedal to put the machine into
cleaning position (Fig.6/1).
While depressing the solution spray trigger, pull carpet
washer in a backward motion. Release the trigger and
push the unit forward in the same path to agitate and
remove dirty water and solution from carpet. (For more
heavily soiled areas, repeat if necessary).
IMPORTANT: For best cleaning results use a steady,
moderate, forward and backward motion. Always work
from back to front across the room to avoid stepping on
wet carpet and lowering the pile.
When dirty water tank is full lift dirty water tank latch
and remove from base unit using the handle (Fig.6/2).
Twist dirty water tank outlet cap to the left and remove,
empty, rinse and replace (Fig.6/3)
When finished cleaning remove the dirty water tank and
rinse with warm water and allow it to dry before storage.
Also remove filter (as shown) rinse with warm water (max
40˚C) and allow it to dry thoroughly before storing.
MPORTANT: Do not use any chemicals when cleaning.
NOTE: Do not store cleaner with solution in clean water
tank or dirty water in dirty water tank. Mineral deposits
and mildew can form with will affect the performance of
the carpet washer.
!
Fig.6/2
Fig.6/3
Fig.6/4
Fig.6/1
Fig.6/5
Fig.6/6
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
CAUTION: The carpet washer is a very powerful unit. Before
plugging the cord into the electrical outlet, make sure all
controls on the unit are turned off. Hold the carpet washer
firmly when starting and in use.
IMPORTANT: Cleaning filters maintains cleaning
performance. Vax recommends that your filters should be
checked and cleaned periodically. If your filters are
washable make sure they are completely dry before
inserting back into the machine.
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 7

vax.co.uk
8 troubleshooting / uk service and help
7. Troubleshooting
WARNING: To reduce risk of personal injury, unplug
carpet washer before servicing.
Problem: The carpet washer won't run
Cause: ot properly plugged into electrical outlet.
olution: Plug in firmly.
Cause: o electricity in electrical outlet.
olution: Check fuse or breaker.
Cause: On/off switch not turned on.
olution: Push on/off switch to ‘on’.
Cause: Blown fuse/tripped breaker.
olution: Reset circuit breaker or replace fuse.
9. Consumables
To purchase spares and accessories, please visit
vax.co.uk
Filter kit (Type 51) 1-1-130680-00
8. UK Service & Help
Vax Careline
(UK) 0844 412 8455
(ROI) 1-800 928 308
Monday-Friday 8.30am to 6.30pm
Saturday and Sunday 9.00am to 5.00pm
Any queries or concerns about using the Vax, call the
Vax Careline.
Please make a note of the serial number and model
number of the carpet cleaner before calling. For the
nearest Service Agent, please call the Vax Careline.
vax.co.uk
10. Technical Specification
Voltage: 220 ~ 240V 50Hz
Motor Power: 500W
Clean water tank volume: 2.1 litres
Dirty water tank volume: 1.7 litres
Cord length: 5.5m
Weight: 5.6kg
Subject to technical change without notice
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 8

9
technical specification
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
This page has been left intentionally blank
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 9

www.vax.co.uk
10
This page has been left intentionally blank
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 10

11
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
This page has been left intentionally blank
VRS18W Updated UG 06.07.14_V1.0 04/07/2014 15:30 Page 11
