Vax U89-VU-R-A User manual

---
EEC STATEME T OF COMPLIA CE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
U89-VU and U88-VU series bagless upright vacuum cleaners are manufactured in compliance
with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: [e-mail] - website: vax.co.uk
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 12

vax.co.uk Please read carefully before using this cleaner.
Always fully extend the mains cord before use.
Retain for future reference.
instruction manual
WAR I G: This cleaner has a constantly
rotating brushbar which, when left in
contact with lino, parquet and other hard flooring
could potentially cause some damage to the floor
surface.
OTE: Vax recommends that you raise the height
of the brushbar when using this cleaner on lino and
hard flooring. Vax cannot be held responsible for
damage to these surfaces if the customer fails to
take notice of this recommendation.
!
Vax model number:
U89-VU-R-A
U88-VU-R-A
Vax Careline: (UK) 0844 412 8455
(R I) 1-800 928 308
Version 1.2
Bagless upright
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 1

1. Diagram
vax.co.uk
2 parts overview
5
7
9
4
3
2
1
17
16
14
11
6
8
10
Fig.1/1
1 Handle
2 TurboTool caddy
3 TurboTool
4 Dirt container release button
5 Dirt container handle
6 Cord
7 Central filter
8 Dirt container
9 Brushbar height adjust
10 Brushbar
11 Dusting brush
12 Crevice tool and extension wand
13 Hose
14 Hose storage
15 Lower hose
16 Power on/off
17 Unit recline pedal
14
15
13
12
WAR I G: This cleaner has a
constantly rotating brushbar
which, when left in contact with lino,
parquet and other hard flooring
could potentially cause some
damage to the floor surface.
OTE: Vax recommends that you
raise the height of the brushbar
when using this cleaner on lino and
hard flooring. Vax cannot be held
responsible for damage to these
surfaces if the customer fails to
take notice of this recommendation.
!
PLEASE OTE: some parts may vary according to model.
Please check inside flap of box for more details.
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 2

3
safety information
2. Safety Information
For Household Use Only
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. nly use the vacuum cleaner indoors on dry
surfaces. Do not handle the plug or vacuum cleaner
with wet hands. Do not use outdoors or on wet
surfaces.
2. Turn off the vacuum cleaner controls before
connecting or disconnecting from the electrical
socket.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose and
accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual.
Use only the manufacturer’s recommended
attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord or plug is
damaged, it must be replaced by the manufacturer
or a recommended Service Agent to avoid hazard
and invalidating the guarantee.
8. Do not pull or carry by the cord. Do not use the cord
as a handle, close a door on the cord or pull the cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
9. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air
flow. Keep all openings free of dust, lint, hair or
anything that may reduce airflow.
10. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
11. Do not pick up hot coals, cigarette butts, matches or
any hot, smoking or burning objects.
12. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene, etc) or use in the
presence of explosive liquids or vapours.
13. Do not vacuum up harmful or toxic material (chlorine
bleach, ammonia, drain cleaner, etc).
14. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
15. Do not use without the filters in place.
16. Take extra care when vacuuming stairs.
17. Keep vacuuming area well lit.
18. Store the vacuum cleaner indoors in a cool, dry area.
19. Turn off the on/off switch before unplugging the
vacuum cleaner.
20. Use only CE-approved 13 amp extension cords. Non-
approved extension cords may overheat. Care should
be taken to arrange the cord so that the cord cannot
be pulled or tripped over.
WAR I G: Always switch off and unplug the
vacuum cleaner from the electrical socket
before assembling, opening or emptying the
dirt container, or before
connecting/disconnecting the attachments.
CAUTIO : The vacuum cleaner is powerful,
therefore aways ensure the power button is
in the off position before plugging into the
electrical socket.
IMPORTA T: If the inlet or hose is blocked,
switch off the vacuum cleaner and remove the
blockage(s) before re-starting.
IMPORTA T: Cleaning filters maintains vacuum
performance.
This vacuum cleaner is intended for household use only
and not for commercial or industrial use.
Please keep these instructions for further use.
!
!
!
!
Motor Thermostat
IMPORTA T: The motor is equipped with a
thermal cut-out. If for any reason, the vacuum
cleaner should over-heat, the thermostat will
automatically turn the unit off. Should this occur,
unplug the vacuum cleaner from the electrical outlet
and turn off the switch. Remove the dirt container
and empty. Clean the filters. Allow the cleaner to cool
for approximately one (1) hour. To re-start, plug into
an electrical outlet and switch back on.
!
Vax Careline: (UK) 0844 412 8455 (R I) 1-800 928 308
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 3

4 assembly
3. How to Assemble
IMPORTA T: Always unplug the vacuum cleaner
from the electrical socket before assembling or
removing the accessories.
Tool required: Crosshead screwdriver
1. Push back panel onto base of unit. Insert hose storage
hook and secure in place with two screws provided
(Fig.3/1).
2. Place the handle onto the back panel and push down
firmly (Fig.3/2).
3. Insert the lock pin into the hole located at the bottom of
the handle, and secure into place with the small screw
provided (Fig.3/3).
4. Attach hose onto cleaner (Fig. 3/4) and place the dirt
container onto the unit.
5. Store the TurboTool in the caddy on the handle
(Fig.3/5).
!
Crosshead screwdriver required
Fig.3/1
Fig.3/2
Fig.3/3
Fig.3/5
Fig.3/4
Back of
unit
vax.co.uk
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 4

5
operation / accessories
4. How to perate
1. Plug the cord into an electrical socket. Switch on by
pressing the on/off pedal, located on the back left of the
cleaner (1).
To recline the unit press the unit recline pedal (2) down.
Move the handle to the desired position (a) for storage and
position (b) for normal operation. To clean under furniture,
press the unit recline pedal again and use position (c)
(Fig.4/1).
5. Accessories
OTE: This unit is fitted with a constantly rotating
brushbar. To avoid damage to your carpet, ensure the
brushbar is raised when using the accessories.
1. Make sure the vacuum cleaner has been switched off
and is in an upright position. Remove the lower hose by
twisting and pulling away from the side connector.
Remove the hose from the hose holder (Fig.5/1).
2. Choose the accessory that suits your need or use the
hose alone.
For hard to reach areas when additional hose length is
required attach the extension wand directly to the hose.
OTE: The crevice tool and TurboTool can be attached to
both the hose and extension tube directly.
OTE: The dusting brush can only be attached to the hose
directly.
To fit the attachments push them firmly on to the end of
the extension wand or hose handle (Fig.5/2). To remove
the tool, twist and pull apart gently.
TurboTool
Make sure the cleaner is turned off before attaching the
TurboTool. For best pick up use backward strokes on the
surface being cleaned.
Fig.4/1
a
b
c
1
2
Fig.5/1
Fig.5/2
WAR I G: This cleaner has a constantly
rotating brushbar which, when left in contact
with lino, parquet and other hard flooring could
potentially cause some damage to the floor surface.
OTE: Vax recommends that you raise the height of
the brushbar when using this cleaner on lino and hard
flooring. Vax cannot be held responsible for damage to
these surfaces if the customer fails to take notice of
this recommendation.
High – long carpet pile and hard floors
Low – short carpet pile
!
Vax Careline: (UK) 0844 412 8455 (R I) 1-800 928 308
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 5

vax.co.uk
6 dirt container & filter / belt & brush replacement
6. Dirt Container & Filter:
Removal and Replacement
1. Make sure the vacuum cleaner has been switched off
and unplugged from the electrical socket. To remove the
dirt container from the vacuum cleaner press the release
catch and pull forward.
To remove the lid, turn anti-clockwise and lift lid away.
Empty the dirt container (Fig.6/1).
2. The filter inside the dirt container should be replaced
every 12 months. It should be cleaned each time the dirt
container is emptied.
To remove, twist and pull the filter out. To clean, tap
gently against the side of a dust bin. Do not use a brush to
clean as this may damage the filter.
Replace filter. Push firmly into place to prevent dust and
dirt leaking out. Replace the lid and re-attach the dirt
container (Fig.6/2).
7. Belt and Brush:
Removal and Replacement
1. Unplug the vacuum cleaner from the electrical socket.
Press the unit recline pedal and turn the vacuum cleaner
over so that the base lies flat and face up. Use a
screwdriver to remove the three screws shown below.
Remove the nozzle guard. (Fig.7/1).
Lift and remove the brushbar (Fig. 7/2), then slide the belt
off the motor shaft and dispose of it. Place a new belt on
the motor shaft and then slip the brushbar through the
belt (Fig.7/2a).
The belt should sit on the section of the brushbar without
bristles. Re-fit the brushbar. Ensure the end caps are in the
correct position. Rotate the brushbar to check the belt is
not twisted. Replace the nozzle guard.
Fig.7/1
Fig.6/1
Fig.6/2
Fig.7/2 Fig.7/2a
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 6

7
clearing blockages / troubleshooting
8. Clearing Blockages
WAR I G: To reduce the risk of injury from
moving parts, unplug before servicing.
Clearing blockages from the TurboTool
1. Turn the TurboTool over and slide off the locking ring
(Fig.8/1).
2. Detach lower housing and remove the blockage (Fig.8/2).
3. To re-assemble the TurboTool, ensure that the tabs are
engaged and pivot the lower housing closed. Slip the
locking ring over the neck of the TurboTool and into the
groove to finish (Fig.8/3).
9. Troubleshooting
WAR I G: To reduce the risk of personal injury,
unplug the vacuum cleaner before performing
maintenance or troubleshooting checks.
PROBLEM: Vacuum cleaner won't run
Cause: Not properly plugged into electrical socket.
Solution: Plug in firmly.
Cause: Blown fuse/tripped circuit.
Solution: Reset circuit or replace fuse.
Cause: Thermal cut out.
Solution: Refer to page 3 for information.
PROBLEM: Cleaner won’t pick up/loss of suction.
Cause: Lower hose not connected properly.
Solution: Refer to page 4 for fitting information.
Cause: Dirt container not installed correctly, or full.
Solution: Empty dirt container and re-attach.
Cause: Broken or worn belt.
Solution: Replace the belt.
Cause: Clogged filters.
Solution: Remove, clean and replace filters.
Cause: Nozzle/hose or hose inlet is clogged.
Solution: Remove nozzle/hose and obstruction.
PROBLEM: Dust escaping from the vacuum cleaner.
Cause: Dirt container full.
Solution: Empty dirt container.
Cause: Dirt container not installed correctly.
Solution: Re-attach dirt container replacement
Cause: Hose not installed properly.
Solution: Review vacuum cleaner assembly.
!
LOCKING RING
Fig.8/1
Fig.8/2
TABS
Fig.8/3
!
Vax Careline: (UK) 0844 412 8455 (R I) 1-800 928 308
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 7

vax.co.uk
8 uk service & help / technical specification
10. UK Service & Help
(UK) 0844 412 8455
(R I) 1-800 928 308
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
Any queries or concerns about using your Vax, call the
Vax Careline. Please make a note of the model number
and serial number of your Vax before calling. For the
nearest Vax Service Agent, please call the Vax Careline or
visit vax.co.uk
11. Consumables
To purchase spares and accessories, please visit
vax.co.uk
HEPA filter kit (1-9-127361-00)
Belt kit (1-1-130670-00)
12. Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 2200W
Capacity: 4 L (approx)
Filters: Antibacterial HEPA
Cord length: 10 m (approx)
Weight: 8.05kg
Subject to technical change without notice.
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 8

9
This page has been left intentionally blank
Vax Careline: (UK) 0844 412 8455 (R I) 1-800 928 308
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 9

This page has been left intentionally blank
vax.co.uk
10
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 10

11
This page has been left intentionally blank
Vax Careline: (UK) 0844 412 8455 (R I) 1-800 928 308
U88 & U89-VU-R-A UG Ame ds [Oct 11]_UG 31/10/2011 16:30 Page 11
