Vax V-091 User manual

8
EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
product V-091/V-091TB/V-091X Performance Cylinder range is manufactured in compliance with
the following Directives:
Safety: 73/23/EEC Low Voltage Directive
EMC: 89/336/EEC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle
wherefacilities exist. Check with your Local Authority or retailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire WR9 0QH, UK
email: [email protected] - website: www.vax.co.uk
Version 1
Instruction Manual
www.vax.co.uk
Vax Careline:
0870 6061248
Please read carefully before using
the cleaner. Always fully extend
the mains cable before use.
Vax V-091/V-091TB/V-091X
V-091 U-G aw 21/10/05 10:56 am Page 1

2 3
Parts Overview
1Dusting brush
2Crevice tool
3Combination floor head
XX--tteenndd
(Model: V-091X only)
TTuurrbbooBBrruusshh
(Model: V-091TB, V-091X only)
Parts Overview
1Hose inlet
2On/off button
3Storage slot
4Post-motor filter cover
5Wheel
6Cord rewind button
7Variable power dial
85-stage LED display
9Carry handle
10 Quick-release dirt container button
(located under safety latch)
11 Dirt container release button
12 Central HEPA filter
13 Dirt container handle
11
10
8
6
1
7
4
5
2
3
9
12
13
11..DDiiaaggrraammAAcccceessssoorriieess
Fig.1/2
Fig.1/3 Fig.1/4
Fig.1/1
31 2
V-091 U-G aw 21/10/05 10:56 am Page 3

4 5
2. Safety Information
FOR HOUSEHOLD USE ONLY
When using the vacuum cleaner, basic safety
precautions should always be observed, including
the following:
1. Only use the vacuum cleaner indoors on dry
surfaces.
2. Turn off the vacuum cleaner controls before
connecting or disconnecting from the mains
supply.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose
and accessories.
4. Close attention is necessary when used by or
near children. Do not allow children to use as
a toy.
5. Use only as described in this manual.
Use only the manufacturer’s recommended
attachments.
6. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped
into water. Do not use the vacuum cleaner with
a damaged cord or plug. If the supply cord or
plug is damaged, return the vacuum cleaner to
a Vax Authorised Service Agent or suitably
qualified person for examination, repair or
adjustment.
7. Do not pull or carry by the cord. Do not use the
cord as a handle, close a door on the cord or
pull the cord around sharp edges or corners.
Do not run the vacuum cleaner over the cord.
Keep the cord away from heated surfaces.
8. Do not handle the plug or vacuum cleaner with
wet hands. Do not use outdoors or on wet
surfaces.
9. Do not put any objects into openings. Do not
use with any openings blocked and do not
restrict air flow. Keep all openings free of dust,
lint, hair or anything that may reduce airflow.
10. Keep hair, loose clothing, fingers and all parts
of the body away from openings and moving
parts.
11. Do not pick up hot coals, cigarette butts,
matches or any hot, smoking or burning
objects.
12. Do not pick up flammable or combustible
materials (lighter fluid, petrol, kerosene, etc) or
use in the presence of explosive liquids or
vapours.
13. Do not vacuum up harmful or toxic material
(chlorine bleach, ammonia, drain cleaner, etc).
14. Do not vacuum up hard or sharp objects such
as glass, nails, screws, coins, etc.
15. Do not use without the filters in place.
16. Take extra care when vacuuming on stairs.
17. Keep vacuuming area well lit.
18. Store the vacuum cleaner indoors in a cool, dry
area.
19. Turn off the on/off switch before unplugging the
vacuum cleaner.
20. Use only CE-approved 13 amp extension
cords. Non-approved extension cords may
overheat. Care should be taken to arrange the
cord so that the cord cannot be pulled or
tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet
before assembling, opening or emptying the dirt
container, or before connecting/disconnecting the
attachments.
CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging the cord into the electrical
outlet, make sure the switch is in the ‘off’ position.
Hold the vacuum cleaner firmly when starting and
in use.
IMPORTANT: If the inlet, hose or telescopic tube is
blocked, switch off the vacuum cleaner and remove
the blockage(s) before re-starting the vacuum
cleaner.
IMPORTANT: Washing filters improved vacuum
performance. Make sure all the filters are
completely dry before inserting back into the
vacuum cleaner.
This vacuum cleaner is intended for household use
only and not for commercial or industrial use.
Motor Thermostat
IMPORTANT:The motor is equipped with a
thermal cut-out. If for any reason, the vacuum
cleaner should over-heat, the thermostat will
automatically turn the unit off. Should this occur,
unplug the vacuum cleaner from the electrical
outlet and turn the unit off. Remove the dirt
container and empty. Clean the filters. Allow the
cleaner to cool for approximately one (1) hour. To
re-start, plug into an electrical outlet and switch
back on.
3. How to Assemble
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before assembling or
removing the accessories.
1. Insert the flexible hose into the inlet on the main
body of the vacuum cleaner. Push in until it
clicks into position (Fig.3/1).
2. Push the telescopic extension tube on to the
end of the handle (Fig.3/2).
3. The telescopic extension tube can be
lengthened or shortened by pushing the button
in and sliding the tube apart or together as
required (Fig.3/3).
4. Fit the combination floor head by pushing onto
the extension tube (Fig.3/4).
4. How to Operate
Cord Release
Fully unwind the power cord. A yellow mark on the
power cord indicates the recommended cord
length. Do not exceed the cord length beyond the
red mark.
On/off Button
1. Insert the power plug into the electrical outlet.
Make sure the vacuum cleaner is switched off.
2. Press the on/off switch located on the top of
the vacuum cleaner, to switch on the vacuum
cleaner and press the button again to turn the
vacuum cleaner off.
Carpet Cleaning
For carpet and rug cleaning, press the rocker
switch on the combination floor head to raise the
brushes.
Hard Floor Cleaning
For hard floor cleaning, press the rocker switch on
the combination floor head to lower the brushes.
Cord Rewind
To rewind the power cord, press the cord rewind
button, located on the top of the vacuum cleaner,
and guide the power cord with one hand. This will
prevent the cord from whipping which could cause
damage or injury.
Variable Power
Located between the on/off and cord rewind
buttons there is a variable power dial. Slide this
clockwise and anti-clockwise to adjust the suction
power. The 5-stage indicator lights suggest the
suction power for common tasks.
Carry Handle
Use the carry handle located at the rear end of the
vacuum cleaner to move from room to room.
Hose Storage
For convenience there is a slot located on either
side of the vacuum cleaner where the floor tool and
hose can be parked for carrying and storage.
5. Accessories
1. The accessories can be attached directly to the
handle by removing the telescopic tubes and
pushing in the desired accessory.
2. The accessories can also be attached to the
telescopic extension tube for extra reach.
Remove the combination floor head and push
on the desired accessory.
Crevice tool: for crevices, corners and cracks,
etc.
Dusting brush: for delicate surfaces.
Upholstery tool: for carpet, upholstery, stairs, etc.
TurboBrush: for pet hair and larger carpeted
areas. (NOTE: not recommended for hard floors).
X-tend (Model: V-091X only): for bottom-to-top
stair cleaning.
1. The hose fits directly into the hose inlet on the
vacuum cleaner.
2. The handle fits directly on to the telescopic
extension tube.
3. To release the extra length hose, press the
release clips located on the handle.
Safety Information How to Assemble / How to Operate / Accessories
Fig.3/1
Fig.3/2
Fig.3/3
Fig.3/4
V-091 U-G aw 21/10/05 10:56 am Page 5

6 7
Troubleshooting / UK Service & Help / Technical Specification
Dirt Container & Filters: Removal & Replacement / Storage
9. Troubleshooting
WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner before performing
maintenance/troubleshooting checks.
PROBLEM: Vacuum cleaner won't run
Cause: Not properly plugged into electrical outlet.
Solution: Plug in securely.
Cause: No electricity in the electrical outlet.
Solution: Check fuse or breaker.
Cause: On/off switch not turned on.
Solution: Push on/off switch to ‘on’.
Cause: Motor thermostat has tripped.
Solution: Switch off and unplug the vacuum cleaner. Leave for one (1) hour before switching the
vacuum cleaner back on.
Cause: Blown fuse/tripped breaker.
Solution: Reset circuit breaker or replace fuse.
PROBLEM: Cleaner won’t pick up/loss of suction.
Cause: Dirt container not installed properly.
Solution: Review dirt container replacement.
Cause: Dirt container full or blocked.
Solution: Empty dirt container.
Cause: Clogged filters.
Solution: Remove, clean and replace filters.
PROBLEM: Accessories won’t pick up.
Cause: Accessories are not attached correctly.
Solution: Refer to section 5.
PROBLEM: Dust escaping from the vacuum cleaner.
Cause: Dirt container full.
Solution: Empty dirt container.
Cause: Dirt container not installed correctly.
Solution: Review dirt container replacement.
Cause: Hose/X-tend (Model: V-091X only) not installed correctly.
Solution: Review installation.
Cause: Filter not installed completely.
Solution: Remove, clean and replace filters.
6. Dirt Container & Filters: Removal
& Replacement
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before removing the dirt
container.
IMPORTANT: Do NOT use the vacuum cleaner
without ALL of the filters in place.
Emptying the Dirt Container
1. Press the button located on the dirt container
handle to pull out the dirt container (Fig.6/1)
2. Lift up the safety latch (Fig.6/2)
3. Press the button located under the safety latch
to empty the dirt into a rubbish bin. When all
of the dirt has fallen, close the dirt container
flap, close the safety latch and replace the dirt
container.
Cleaning the Filter
1. Remove the dirt container as directed.
2. Release the filter safety latch located on top of
the dirt container and pull out the central filter
unit.
3. Remove the filter shroud by rotating it anti-
clockwise and pulling away from the central
filter (Fig.6/4).
4. Gently tap the filter against the side of a
rubbish bin to remove excess dirt.
5. The central filter can be washed in warm water
[max 40(C]. Allow to air dry completely before
replacing.
NOTE: Do NOT use any detergents or boiling
water to wash the filter. Vax recommends washing
the filter every time you empty the dust container.
6. Return the central filter to the filter shroud and
rotate clockwise to secure.
7. Replace the central filter unit to the dirt
container ensuring the filter safety catch has
been reset.
8. Replace the dirt container as directed.
Post-motor Filter
NOTE: This is located on the right hand side of the
vacuum cleaner.
1. Release the post-motor cover and remove the
filter by pressing in the catch on the left hand
side.
2. The post-motor filter can be washed in warm
water [max 40(C]. Allow to air dry for 24 hours
before replacing.
NOTE: Do NOT use any detergents or boiling
water to wash the filter. Vax recommends washing
the filter every 9-12 months.
3. Replace the post-motor filter and cover before
re-starting the vacuum cleaner.
7. Cleaning Blockages
WARNING: To reduce the risk of electric shock,
the power cord must be disconnected before
performing maintenance/troubleshooting checks.
1. Turn the vacuum cleaner off and unplug from
the electrical outlet.
2. The flexible hose and X-tend (Model: V-091X
only) can be disconnected from the vacuum
cleaner by pushing in the button on the hose
and pulling away from the machine. Remove
any blockages found then reconnect the hose
securely.
8. Storage
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet and rewind the power cord
as directed before storing.
NOTE: Always store the vacuum cleaner base
down.
Fig.6/1
Fig.6/2
Fig.6/4
10. UK Service & Help
Vax Care 0870 6061248
Monday-Friday. 9.00am to 5.00pm.
An answerphone will be available out of these
hours. Any queries or concerns about using your
Vax, call the Vax Careline. Calls are charged at the
UK national rate.
Please make a not of the model number and serial
number of your Vax before calling. There are over
400 approved Vax Service Agents in the UK. For
the nearest Vax Service Agent, please call the Vax
Careline or visit www.vax.co.uk
www.vax.co.uk
11. Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 2200W-2400W (dependant on
model)
Capacity: 3 litres approx
Filters: Washable central HEPA filter [with
filter shroud]
Post-motor filter
Cord length: 5.5m (approx)
Weight: 7.5kg
Subject to technical change
without notice.
V-091 U-G aw 21/10/05 10:56 am Page 7
