Vax V027 User manual

123

Putting your cleaner together

Remove your Rapide XL from the

carton with caution. The handle is

connected to the body by a cord.

Note: Do not tug or pull on the

cord.

Line up the handle to the upper

body of the machine and slide into

place.

Secure from the back with the

two smaller screws.

Phillips screwdriver required

a Handle

b Solution trigger

c Soap on/off

d Power on/off

eClean water tank release

f Clean water tank carry handle

gClean water tank

h Cleaning solution soap tank

i Drain cap

jHose water supply port

kDual brushbars

l Front suction nozzle

mDirty water tank

n Floor/tools selector

o Hose attachment cover

p Dirty water tank handle

q Dirty water tank nozzle tab

r Dirty water tank latch

s Detachable tool storage

tExtra long Stair Hose

u Water supply connector

vUpholstery wash tool

w Upholstery tool trigger

x Solution/hose clip

yQuickcord release

zCarrying handle

aa Clean water tank cap

bb Hose storage clips

cc Power cord

dd Cord wrap

ee Handle release pedal

ff Carpet treatment wand

gg AAA carpet cleaner

hh Multi hard floor solution

iiPre-treatment solution

jj Post-treatment solution

kk Carpet treatment wand water supply port

ll Flexible hose

mm Power Wash Brush

nn Batteries for power wash brush

ooSolution tube and clips ( 3 large, 2 small)

pp Telescopic tube

qq Hydrodry hard floor wash head

xmm

multi

pre

treatment

pre-treatment

carpetsolution

solutionde prélavage

pourtapis et moquettes

teppichvorwaschspray

tapitreiniger spray

Parts checklist

post

treatment

pre-treatment

carpetsolution

solutionde prélavage

pourtapis et moquettes

teppichvorwaschspray

tapitreiniger spray

V027(Y) User Guide 5/10/06 11:47 am Page 1

45 6

Putting your cleaner together

Feed the cord through the slots on

the back of the handle and push

into place.

Place a nut into the recess in the

back of the upper handle. While

holding the nut in place insert one

of the large screws through the

front of the upper handle and

tighten.

Repeat the process with the second

screw.

Remove the backing tape from the

screw cover and press into place.

12 1

Clean water tank

Note: Make sure the cleaning

solution tank is resting in place with

the solution tube pressed fully into

tube opening.

Line up the grooves of the clean

water tank with the support posts

inside the handle. Tilt the top of

clean water tank inward and push

until it locks into place.

To install the tool caddy, line up the

tabs of the tool caddy storage with

round tabs on the back of the

handle (above quick cord clip).

Tool storage

V027(Y) User Guide 5/10/06 11:47 am Page 2

234

Tool storage

Slide the tool caddy

downwards until it is

secured in place.

Note: The tool caddy can

be removed for storage on

awall.

12 3

Pre-treating your carpets

with the carpet treatment

wand and solution

Remove the clean water tank by

pressing the clean water tank

release and pulling the tank by

the handle. Put to one side to fill

later.

While the clean water tank is

removed, loosen the solution tank

by gently pushing out the solution

plug from the plug opening.

Note:The solution tank can be

filled while it is attached to the

cleaner but you should use care

when refilling.

Remove the solution tank by

pulling up and out.

Note: After spraying rinse the

machine and carpet treatment

wand with clean water.Wash the

carpet as described in this guide,

using VAX AAA carpet cleaner.

Push the upholstery tool

onto the end of the extra

long stair hose.

Starting on the left of the

machine, wrap the hose around

the back section of the hose

caddy. Wrap the hose around the

back of the machine for a second

and third time,using the front

section of the hose caddy. Secure

in place using the hose clips. To

store the Power Wash Brush,

place on the left hand side of the

machine on the holder provided.

The carpet treatment wand is

stored on the right hand side of

the machine, clipping into place

at both the top and the bottom.

Attach the tube of the carpet

treatment wand into the carpet

treatment wand water supply

port. Press firmly until it locks into

place.

Note: Once the carpet treatment

wand is attached it can remain in

place between uses.

V027(Y) User Guide 5/10/06 11:47 am Page 3

5 6

Remove solution tank cap. CAUTION:Do not overfill. You

should leave

1-2 cm of air space.

Fill the tank with pre-treatment

solution.

Replace the solution tank cap.

Return the solution tank to the

cleaner making sure the solution

tube lines up with the groove in the

back of the solution tank. Firmly

press the solution tube into the plug

opening of the solution tank.

CAUTION: Maximum water

temperature 40oC

Remove the clean water tank cap

and put in a safeplace. Slowly fill

the clean water tank with warm tap

water (max 40oC) and replace the

cap.

Return clean water tank by lining

up the grooves of the clean water

tank with the support posts on the

inside of the handle.Rock clean

water tank inward until it locks into

place.

If you have not already done so,

attach the carpet treatment wand to

the carpet treatment wand water

supply port at the back of the

machine. Press firmly until it locks

into place.

N.B Once the carpet treatment

wand is attached it can remain in

place between pre-treatments

V027(Y) User Guide 5/10/06 11:47 am Page 4

Pre-treating your carpets with

the carpet treatment wand and

solution

Using the wand and the trigger,

apply pre-treatment solution to

carpets. Turning the spray nozzle

clockwise or anti-clockwise will

alter the spray pattern.

Caution: DO NOT turn the soap

switch ON without solution in the

tank. DO NOT allow the solution

tank to run dry.

To pre-treat carpets be sure that the

unit is stood in the upright position.

Turn the power and soap switches

on. The pre-treatment solution and

water automatically mix within the

machine.

Releasing the trigger will stop

solution flow. The treated areas

should be left for 10 to 15 minutes.

For heavy stains, mild agitation may

be used.

Note:Do not over wet carpets.

12 3

Howto operate your

cleaner - setting up

Remove the clean water tank by

pressing the clean water tank

release and pulling the tank bythe

handle. Put to one side to fill later.

While the clean water tank is

removed, loosen the solution tank

bygently pushing out the solution

plug from the plug opening.

Note:The solution tank can be

filled while it is attached to the

cleaner but you should use care

when refilling.

Remove the solution tank by pulling

up and out.

Note: The float in your Rapide XL is the transparent, pivoting moulded part in the dirty water tank, it will shut off the suction

when the dirty water tank is full. For best results use a smooth steady motion keeping the nozzle flat against the carpet.

Tipping the cleaner and breaking the seal of the nozzle against the carpet will cause the float to rise cutting off suction. Once

the float is activated, empty the dirty water tank.

If the tank does not appear full turn off the power switch and wait for the float to settle. For best results use only VAX AAA

Carpet Cleaner.

11 12

V027(Y) User Guide 5/10/06 11:47 am Page 5

45 6

How to operate your

cleaner

Remove solution tank cap. CAUTION:Do not overfill. You should leave

1-2 cm of air space.

Fill the tank with VAX AAA Carpet Cleaner.

The cleaner can be stored with solution in the

solution tank. It does not have to be removed

after each use. However the solution tanks

should be rinsed out periodically.

Note: One fill up of the solution tank will last for

approximately 4 clean water reservoir fill ups.

Replace the solution tank cap.

Return the solution tank to the

cleaner making sure the solution

tube lines up with the groove in the

back of the solution tank. Firmly

press the solution tube into the plug

opening of the solution tank.

Howto operate your

cleaner

CAUTION: Maximum water

temperature 40oC

Remove the clean water tank cap

and put in a safe place. Slowly fill the

clean water tank with warm tap water

and replace the cap.

Return clean water tank by lining

up the grooves of the clean water

tank with the support posts on the

inside of the handle. Rock clean

water tank inward until it locks into

place.

V027(Y) User Guide 5/10/06 11:47 am Page 6

12 3

How to operate your cleaner

Caution: DO NOTturn the soap

switch ON without solution in the

tank. DO NOT allow the solution

tank to run dry.

Plug the cord into an electrical

socket. Step on the handle release

pedal to put the cleaner into a

cleaning position.

Turn main power switch and soap

switch to the ON position

Howto operate your cleaner Burst clean feature

To spray cleaning solution, depress

the solution release trigger (3a) and

move the cleaner backward and

forward. Release the trigger and

push the unit backand forth in the

same track to remove dirty water

and solution from the carpet.

For heavily soiled areas, repeat if

necessary.

N.B The brushbar starts rotating

automatically when the machine is

reclined.

o rinse your carpet, turn the soap

switch to the OFF position. Repeat

the same process (as in step 3)

The burst clean switch is located on

the side of the machine and

illuminates when turned on. This

feature increases the brushbar

speed and pump flow rate to tackle

more stubborn stains and high

traffic areas. Switch off to wash

carpets as normal.

Howto carryyour cleaner

Grab the carrying handle on the

backof the cleaner to transport from

room to room.

Do not pick the cleaner up by the

clean water tank handle.

Turn

off

V027(Y) User Guide 5/10/06 11:47 am Page 7

Hose attachments

Put the cleaner in its upright

position. Turn the soap and power

switches to the OFF position.

Remove the hose from its stored

position on the backof the cleaner.

Lift the hose attachment cover

located on the top of the dirty water

tank.

Insert the end of the hose into the

tool opening and twist clockwise

until it locks into place.

45 6

Attach the water supply connector

into the hose water supply port at

the side of the machine. Press

firmly until it locks into place.

Move the floor/tools selector to the

tools (upward) position.

Caution: DO NOT turn the soap

switch ON without solution in the

tank. DO NOTallowthe solution

tank to run dry.

To wash upholstery, be sure that

the main power and soap switches

are both turned ON.

Note: Do not allow upholstery to

become too wet.

Turn

12 3

V027(Y) User Guide 5/10/06 11:47 am Page 8

78 9

Hose attachments

While depressing the blue solution spray

trigger, pull the attachment in a downward

motion. Release the trigger and push the

attachment forward in the same path to

remove dirty water and solution from

upholstery. For heavily soiled areas, repeat if

necessary. To rinse, remember to turn the

soap switch to the OFF position and repeat

process.

Note: Make sure upholstery is thoroughly

dry before using.

Remove the hose from the fitting by

twisting it counterclockwise to

unlock. Close the hose attachment

cover until it snaps into place.

Disconnect water supply connector

from the water supply port by

pressing the grey button and

pulling.

19 10 11

Move the tool/floor selector to the

floor position (upward).

Return tools to their storage

position on the back of the cleaner.

V027(Y) User Guide 5/10/06 11:47 am Page 9

Hard floor cleaning

Before assembling the accessories

for hard floor cleaning, ensure that

the cleaning solution soap tank is

filled with Multi hard floor solution.

Please refer to the bottle for

measuring quanitites.

Do not use Vax AAA carpet cleaner.

N.B The Hydrodryhead should only

be used on sealed hard floors. If in

doubt, consult the flooring

manufacturer.

Wrap the solution tube around the

hose and secure into place using

the clips provided.

Attach one end of the solution tube

into the hose water supply port at the

side of the machine. Press firmly into it

locks into place

Attach the other end of the solution

tube into the Hydrodry hard floor wash

head.

Move the floor/tools selector to the

tools (upward) position. Caution: DO NOT turn the soap

switch ON without solution in the

tank. DO NOT allow the solution

tank to run dry.

To wash hard floors, turn main

power and soap switch to the “ON”

position.

On the Hydrodry hard floor wash

head ensure that the rocker switch is

pushed down towards the back of the

head to allow water and solution to

reach the floor

owash hard floors, move the wash

head, slowly and in even motions, over

the area to be cleaned.

To suck up excess water and dry hard

floors,the rocker switch should be

pushed forward. This prevents water and

solution flow from the clean water tank.

12 3

456

V027(Y) User Guide 5/10/06 11:47 am Page 10

Insert the four AA batteries into

your Power Wash Brush in

locations shown. Next see section

17 for machine preparation.

Now attach the Power Wash Brush

to the hose attachment bypushing

hose end into Power Wash Brush

until it clicks into place. In order to

release solution onto the desired

areas depress the blue solution

spray trigger. Release the trigger

and press the Power Button to

activate the Power Wash Brush.

Use Brush on desired areas, repeat

as necessary.

To rinse, remember to turn the soap

switch to the OFF position and repeat

process. If further drying is required

switch off the Power Wash Brush and

go over the area again. To remove

Power Wash Brush from hose push

Release Button as shown. When

finished See section 18 parts 8-11 for

disconnection and storage

instructions.

Battery Compartment 2

Hose Release Button

Power Button

Battery Compartment 1

Oscillating Brushes

Disconnect water supply connector

from the water supply port by

pressing the grey button and

pulling.

Disconnect water supply connector

from the water supply port by

pressing the grey button and

pulling.

Move the tool/floor selector to the

floor position (upward).

Disconnect all attachments and

allowthem to drybefore storing.

78 9

Power Wash Brush

V027(Y) User Guide 5/10/06 11:47 am Page 11

4 5 6

Dirty water tank can be rinsed out

with hot tap water to remove any

remaining debris. Wipe and let dry

thoroughly before storing to prevent

mildewfrom forming.

Note: Do not use any chemicals

when cleaning.

Return the dirty water tank cap. Lift the dirty water tank handle and

pull out the filter to clean. Rinse

under hot water and return to the

dirty water tank.

Emptying the dirty

water tank

Depress the dirty water tank latch

and simultaneously pull the dirty

water tank nozzle tab up and away

from the cleaner.

Remove the dirty water tank by

lifting the dirty water tank handle

and pulling the tank out of the base.

Note: The nozzle does not need to

be completely removed to empty

the dirty water tank.

Place the dirty water tank over a

large sink and remove the dirty

water tank cap by twisting it to the

left (counterclockwise) and out in a

safe place. Empty the water into the

sink.

24 123

V027(Y) User Guide 5/10/06 11:47 am Page 12

7 8

Emptying the dirty

water tank

Return dirty water tank to the base

of the cleaner by tipping the nozzle

down into the basin and dropping it

into place.

Lift the front of the cleaner base off

the carpeting with one hand. Line

upthe black tabs with the grooves

of the front nozzle. Lift the front

nozzle upwards towards the cleaner

and press under the latch until it

locks into place.

Post-treating your carpets

with the carpet wand and

post-treatment solution

N.B The carpet treatment wand will

need priming before using to allow

the correct solution to run through.

Holding over the sink, depress the

trigger for approximately 20

seconds. The wand will then to

ready for post-treatment.

Remove the clean water tank by

pressing the clean water tank

release and pulling the tank by the

handle. Put to one side to fill later.

While the clean water tank is

removed, loosen the solution tank

by gently pushing out the solution

plug from the plug opening.

Note:The solution tank can be

filled while it is attached to the

cleaner but you should use care

when refilling.

Remove the solution tank by pulling

up and out.

Note: After spraying rinse the

machine and carpet treatment

wand with clean water.Wash the

carpet as described in this guide,

using VAX AAA carpet cleaner.

V027(Y) User Guide 5/10/06 11:47 am Page 13

Removesolution tank cap.

CAUTION: Do not overfill. You

should leave

1-2 cm of air space.

Fill the tank with post-treatment

solution.

Replace the solution tank cap.

Returnthe solution tank to the

cleaner making sure the solution

tube lines up with the groove in the

back of the solution tank. Firmly

press the solution tube into the plug

opening of the solution tank.

CAUTION: Maximum water

temperature 40oC

Remove the clean water tank cap

and put in a safeplace.Slowly fill the

clean water tank with hot tap water

(max 40oC) and replace the cap.

Return clean water tank by lining

up the grooves of the clean water

tank with the support posts on the

inside of the handle. Rock clean

water tank inward until it locks into

place.

Ensure the carpet treatment

wand is still attached securely to

the carpet treatment wand water

supply port

V027(Y) User Guide 5/10/06 11:47 am Page 14

Caution: DO NOT turn the soap

switch ON without solution in the

tank. DO NOT allow the solution

tank to run dry.

To post-treat carpets be sure that

the unit is stood in the upright

position. Turn the power and soap

switches on. The post-treatment

solution and water automatically mix

within the machine

Belt removal and

replacement

Remove dirty water tank and front

nozzle (see page 20) put them to

one side.

Use a Phillips screwdriver to

removetwo(2) screws.

Remove the belt cover.

Removethe broken belt.

Phillips screwdriver required

123

N.B The carpet treatment wand will

need priming before using to allow the

correct solution to run through. Holding

over the sink, depress the trigger for

approximately 20 seconds. The wand

will then to ready for post-treatment.

Using the wand and the trigger, apply

post-treatment solution to

carpets. Turning the spray nozzle

clockwise or anti-clockwise will

alter the spraypattern.

Releasing the trigger will stop

solution flow.

The treated areas should be left to dry.

Once dry, vacuum thoroughly.

Empty the dirty water tank as

previously directed.

Note: Do not over wet carpets.

V027(Y) User Guide 5/10/06 11:47 am Page 15

oinstall a newbrushbar. Feed the

brushbar through the opening until

the screw plate and screw hole are

lined up (as above).

Note: The black cap behind the

silver screw plate will be through the

hole.

Tilt cleaner off the carpet. Grasp

the brush bar and pull the right side

of its chamber.

Tilt the brushbar down to the

ground and remove the silver cap.

Slide the worn brushbar out of the

cleaner.

Replace the silver cap to right side

of the brushbar. Lift the brushbar up

and align with the brushbar

chamber. Push the screw plate

towards the screw hole until the

flush and replace the screw.

3 4

Remove the screw that holds the

brushbar in place.

Brush removal and

replacement

1. Loop the belt around the rear shaft.

2. Loop the top of the belt above the small

pulley and the bottom of the belt around the

lower small pulley.

3. Feed the entire belt over the first large

pulley.

4. Loop the belt around the front large pulley

and rotate the front brushbar forward until

the belt is in place.

Note: Make sure the entire belt stays on top of

the first large pulley by lightly placing a finder

on top to guide it.

Return the nozzle cover to the

original position.

Secure by replacing the two (2)

screws.

V027(Y) User Guide 5/10/06 11:47 am Page 16

•Do not leave the appliance when plugged in. Unplug it from socket when not in use.

•Toprevent electric shockdo not use outdoors

• Not to be used as a toy. Close supervision is necessary when used by or near children or the infirm.

•Use only as described in this user guide.

•Donot use with a damaged cord or plug.

• Do not pull or carryby the cord, use the cord as a handle, allow the cord to come into contact with hot or sharp surfaces

or close a door on the cord.

• Do not unplug by pulling on the cord.

• Do not handle the plug or appliance with wet hands.

• Do not put anyobjects into openings or operate with openings blocked, keep them free of anything that mayreduce

airflow.

•Keep hair, loose clothing, fingers, and all parts of the body away from openings and moving parts.

• Do not vacuum any glowing, burning or smoking particles.

• Do not use without the solution reservoir and dirty water tank in place.

• Turn off all controls before unplugging.

• Do not use to pick up flammable or combustible liquids such as petrol, or use in areas where they may be present.

• Keep the carpet washer on the floor.

• Do not use an extension cord with this carpet washer.

• Do not attempt to remove blockages with sharp objects as they may cause damage.

• Store the carpet washer indoors. Put the carpet washer away after use to prevent tripping accidents.

•Using improper voltage mayresult in damage to the motor and possible injury to the user. The correct

voltage is listed on the ratings plate.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified

persons in order to avoid hazard.

•This carpet washer is intended for household use only.

• The appliance must be unplugged from the mains socket outlet after use, and before cleaning or maintaining the

appliance.

•Ahazard mayoccur if the appliance runs over the power supply cord.

•Carpets should be dry vacuumed thoroughly before washing with the Rapide XL and Rapide XL Pro.

For further information in the UK, call the VAX HELPLINE : 0870 606 1248

Safety

Troubleshooting

Problem

Cleaner won’t run

Vacuum won’t pick up/loss of

suction

Water escaping from the

Vacuum

Cleaner attachments won’t

spray

Cleaner won’t dispense

solution

No soap dispensing

Will not dispense water

Possible Cause

•Power cord not firmly pushed into

amains socket.

•Blown fuse or tripped circuit breaker.

•Nozzle hose attachment cover not

closed.

•Dirty water tank is not installed

correctly.

•Nozzle not installed correctly.

•Floor/Tool selector in wrong position.

•Dirty water tank is full.

•Brushbar worn.

•Broken or worn belt.

•Nozzle/Dirt passage clogged.

•Clogged hose inlet.

•Dirty water tank is full.

•Dirty water tank not installed correctly

•Hose not installed correctly.

•Solution tank not installed correctly.

•Water supply hose not connected

properly

•Solution tank not installed correctly

•Pickup tube blocked.

•No soap.

•Soap switch off.

•Soap tank empty with soap power ON

Possible solution

•Plug cord in firmly.

•Check fuse/breaker. Replace fuse or

reset breaker.

•Close the hose attachment cover.

•See ‘Emptying the dirty water tank’

•See ‘Emptying the dirty water tank’.

•Move selector to the correct position.

•Empty dirty water tank.

•Replace the brushbar.

•Replace the belt.

•Remove hose, remove obstruction.

•Remove hose, clean inlet.

•See ‘How to operate your cleaner’.

•See ‘Emptying the dirty water tank’.

•See ‘Emptying the dirty water tank’

•See ‘Hose attachments’.

•See ‘How to operate your cleaner’.

•See ‘Hose attachments’.

•See ‘How to operate your cleaner’.

•Clean pick up tube by soaking in water

•Fill soap tank with Vax AAA Carpet

Cleaner.

•Turn soap switch on.

•Fill soap tank or shut soap power OFF.

V027(Y) User Guide 5/10/06 11:47 am Page 17

Mon-Fri. 9.00am to 5.00pm. An answer phone is available out of these hours. If you have queries or concerns about using your VAX, call the HELPLINE. Calls are charged at the UK national rate.

Please make a note of the serial number and model number of your VAX before calling. There are over 400 approved VAX Service Agents in the UK. For your nearest Service Agent please call VAX Care.

EEC STATEMENT OF COMPLIANCE
