Vax VX62 Installation instructions

LET’S GET STARTED.
POWERFUL.
VERSATILE.
2-IN-1.
VX62
Verso
CORDLESS
LET’S GET STARTED.
POWERFUL.
VERSATILE.
Verso
CORDLESS

Let’s talk safety
Basic
safety
precautions
This vacuum cleaner is intended for household use only
and NOT for commercial or industrial use.
READ ALL THE INSTRUCTIONS BEFORE USING THIS APPLIANCE
• Only use the vacuum cleaner indoors and keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and openings whilst using
the vacuum cleaner.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should not play with
the vacuum cleaner. Cleaning and user maintenance should not be made by children.
• Only Vax recommended tools and accessories should be used with this vacuum
cleaner
• Do not use charger with damaged cord or plug. If appliance or charger is not
working as it should, has been dropped, damaged, left outdoors or dropped into
water, take it to a Vax authorised repair agent prior to continuing use. Please
contact our Customer Care Line on: AU: 1300 361 505 / NZ: 0800 800 900
(Mon-Fri 8.30am to 5.00pm) or visit www.vax.com.au / vax.co.nz for your nearest
Vax authorised repair agent.
Please keep instructions for further use.
Battery Safety Precautions:
• Do not place vacuum or batteries near re or heat. This will reduce the risk
of explosion and possible injury.
• Do not crush, drop or damage battery pack. Do not use a battery pack or charger
that has been dropped or received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or damaged battery immediately.
• Batteries can explode in the presence of a source of ignition, such as a pilot
light. To reduce the risk of serious personal injury, never use any cordless
product in the presence of open ame. An exploded battery can propel debris
and chemicals. If exposed, ush with water immediately.
• Do not charge vacuum in a damp or wet location. Following this rule will reduce
the risk of electric shock.
• For best results, charge the battery tool in a location where the temperature is
more than 10°C but less than 37°C. To reduce the risk of serious personal injury,
do not store outside or in vehicles.

• Under extreme usage or temperature conditions, battery leakage may occur. If liquid comes in
contact with the skin, wash immediately with soap and water, then neutralize with lemon juice or
vinegar. If liquid gets into the eyes, ush them with clean water for at least 10 minutes, then seek
immediate medical attention. Following this rule will reduce the risk of serious personal injury.
• Store the battery pack where the temperature is below 27°C.
• The battery must be removed from the appliance before it is scrapped.
• The appliance must be disconnected from the supply mains when ever removing the battery.
• The battery is to be disposed of safely.
WARNING: For the purpose of recharging the battery, only use detachable supply unit type
YLJXA-A300050 provided with this appliance.
Charger Safety Precautions:
• The charger must not be damp, and should never be used in a damp environment.
• Do not use the charger if it has suered any heavy shock or jolting, or is damaged in any other way.
• Do not conduct charging in a position which may become exposed to sunlight or other heat
source. Recommended temperature range at charging vicinity is 10° to 25° C.
• Do not conduct charging operations in the vicinity of ammable materials. Example: Cloth,
packaging materials, paint, spray paint or aerosols, lubricant, thinners, petrol containers, gas
containers or gas appliances.
• Do not cover any ventilating slots and provide adequate ventilation during operation.
• Never modify, disassemble or attempt to repair the product yourself.
• Do not allow the charger or batteries to become contaminated with any material which could
be conductive.
• Remove the plug of the product from the power socket when it is not in use or when cleaning it.
• Protect battery contacts to avoid a short circuit caused by metallic objects which could cause
a re or explosion!
• Do not charge batteries which show signs they have leaked electrolyte. Dispose of them properly.
• Never charge a damaged battery.

Let’s talk safety
Don’ts
Do’s
• Do not pull or carry by charger cord, use cord as a handle, close a door on cord, or
pull cord around sharp edges or corners. Do not place product on cord. Do not run
appliance on cord.
• Don’t handle the charger plug or use the vacuum cleaner with wet hands.
• Don’t use this vacuum cleaner if it has been dropped, damaged, immersed in water or
left outdoors.
• Don’t leave the vacuum cleaner in one spot for an extended period of time when the
brushbar is activated. This vacuum cleaner is tted with a rotating brushbar which if
left in one place may cause damage to the oor surface.
• Don’t attempt to remove blockages with sharp objects as this may cause damage to
the vacuum cleaner.
• Always make sure the lter and dirt container are tted correctly before using
your vacuum cleaner.
• Always turn o and unplug from charger and remove the battery before carrying
out any maintenance.
• Turn o all controls on the vacuum cleaner before disconnecting or connecting the battery.
• Take extra care when cleaning on the stairs.
• Always protect the charger cord from heated surfaces or near open ames.
• Keep all openings clear and free from debris as this may aect the airow/suction.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as per
user guide instructions ensure they are thoroughly dry before storing away.
• Always use the charger supplied with the vacuum cleaner.
• Use only SAA approved 10amp extension cords. Care should be taken to arrange
the extension cord as it can be a trip hazard.
• Always carry the vacuum cleaner by the handle.

• Do not pull or carry by charger cord, use cord as a handle, close a door on cord, or
pull cord around sharp edges or corners. Do not place product on cord. Do not run
appliance on cord.
• Don’t handle the charger plug or use the vacuum cleaner with wet hands.
• Don’t use this vacuum cleaner if it has been dropped, damaged, immersed in water or
left outdoors.
• Don’t leave the vacuum cleaner in one spot for an extended period of time when the
brushbar is activated. This vacuum cleaner is tted with a rotating brushbar which if
left in one place may cause damage to the oor surface.
• Don’t attempt to remove blockages with sharp objects as this may cause damage to
the vacuum cleaner.
• Don’t try to short the terminals of the battery and the charger.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in damage or injury to the user.
The correct voltage is listed on the rating label.
• Don’t vacuum up hot coals, cigarette butts, ash, matches or smoking hot burning items or use in an
area where there may be harmful uids (chlorine, bleach, and ammonia drain cleaner).
• Do not vacuum hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t not vacuum plaster dust, concrete dust or any other building or vitreous material.
• Do not vacuum our, baking soda or any other powder-based carpet refresher or deodoriser.
CAUTION: The battery used in this device may present a risk of re or chemical burn if mistreated.
Do not disassemble, heat or incinerate.
Do not disassemble and do not dispose of in re. Do not attempt to disassemble the battery or remove
any component projecting from the battery terminals.
The battery and charger have no user serviceable parts. Fire or injury may result.
Prior to disposal, protect exposed terminals with heavy insulating tape to prevent shorting.
WARNING: For best performance terminals on battery, battery charger and vacuum cleaner must be
clean and free from dust and dirt.

Thank you for buying this Cordless Verso.
Taking care of your carpets and hard oors
The Cordless Verso series is designed to make vacuuming carpets and hard oors regularly,
as eective and efficient as possible and this user guide will help you get the most out
of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer
and Vax will help you take good care of them.
Taking care of your Cordless Verso
Also inside this guide are instructions on maintaining your new machine, so that it’s ready
when you are to tackle your carpets and hard oors.
We’re here if you need us
For troubleshooting simply visit or call:
Australia: 1300 361 505* New Zealand: 0800 800 900*
vax.com.au vax.co.nz
*Monday – Friday: 8:30am -5:00pm
Calls are charged at the standard local rate. Please make note of the serial
number and model number of the product before calling.

Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
Included with
your machine
Charger
2-in-1 Crevice Tool/
Dusting Brush
Cordless Verso

Getting to know your machine
Technical Specification Charger Specification
Battery Specification
Accessories &Consumables
Subject to technical change without notice. *Turn off brushbar on hard floors. Images are illustrative only.
To purchase consumables and accessories, please visit vax.com.au
On/O button
Suction control button
2-in-1 crevice tool/dusting
brush and holder
Handheld release button (hidden)
Machine charging port
LED charging indicator light
Handheld On/O switch (hidden)
Dirt container release
button (hidden) Dirt container
Floorhead
LED headlights
Brushbar
Name Verso 25.2V
Model number VX62
Battery voltage 25.2V
Run time Up to 80 mins*
Charge time 5 hours
Weight 3.4kg
Dust bin capacity 0.8l
Model number YLJXA-A300050
Input voltage 100-240V ~50/60Hz 0.5A
Output voltage 30.0V 500mA
Rating 2.0 Ah
50.4Wh / 25.2V
Pre-motor lter Model No. VX62F

Getting started
Assembling your 2-in-1 vacuum cleaner
Line up the handle with
the main body and lower
into place.
Insert the screw into the
back of the handle. Using
a cross head screw driver
tighten until the handle is
secured into place.
Line up the handheld
nozzle with the back
of the main body. Push
the handheld onto the
main body until it clicks
into place.
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Accessories &Consumables
Store the 2-in-1 Tool on
board the vacuum cleaner
by pushing the tool rmly
into the tool holder located
on the back of the handle.
Before you begin
CAUTION: Always switch o the vacuum cleaner before connecting or disconnecting the handheld/attachments or
removing and emptying the dirt container.
IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does
overheat the thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o.
Remove and empty the dirt container. Also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool
for approximately 1 hour (if you have washed the lter please wait 24 hours for the lter to fully dry before putting
back into the machine). For best cleaning results, lters require cleaning every 4-6 uses or as needed depending
upon use. If the vacuum cleaner is blocked, switch o before removing the blockage.
Pre-motor lter Model No. VX62F
Plug the charger into the charging port, located on
the top of the handle of the handheld and plug
into the mains.
Once fully charged (5
hours) the LED indicator
on the handheld will
illuminate green.
When the vacuum needs
recharging the LED light
on the handheld will ash
red and the machine will
cut out.
Charging your 2-in-1 vacuum cleaner
NOTE: Initial charge is 5 hours, charging will be required before rst use. Failure to fully charge the battery before
rst use may result in poor battery performance. Charge time is 5 hours thereafter.
The vacuum can be charged with the handheld either attached to or detached from the main body.

As an upright vacuum cleaner
Unplug the charger
from the mains and
from the handheld.
Place foot on the
oorhead and pull the
handle backwards to
recline the machine.
Press the On/O button
on the handle to switch
the machine on.
To select between high
and low suction press the
extended runtime button.
CAUTION: Never leave the vacuum cleaner in one spot for an extended period of time when in use as this may
damage the oor surface. Vax cannot be held responsible for damage to the oor surface if this recommendation
is not followed.
TIP
The brushbar will not rotate when the vacuum
cleaner is locked in the upright position.
Using your machine
As a handheld vacuum cleaner
CAUTION: Always take extra care when cleaning stairs. Always switch the handheld o before connecting or
disconnection the accessories, carrying out any maintenance or troubleshooting checks and before returning the
handheld to the main body.
Press the handheld
release button.
Lift to remove the
handheld from the
main body.
Push the On/O switch
forward to switch the
handheld on.

Using your machine
Dusting brush
Crevice tool
For a more detailed clean,
line up the 2-in-1 Tool
with the nozzle on the
handheld and push rmly
into place.
Before returning the
handheld to the main body,
pull the On/O switch
backwards to switch
the handheld o. Pull to
remove the 2-in-1 Tool
from the handheld nozzle.
1
1
2
2

Emptying the dirt container
Press the handheld
release button.
Lift to remove the
handheld from the
main body.
Press the dirt container
release button to remove
the dirt container.
CAUTION: Always switch o the vacuum cleaner before carrying out any maintenance or troubleshooting. Do not use
your vacuum cleaner without the lters in place.
Pull to remove the
pre-motor lter out of
the dirt container.
Pull to separate the dirt
container from
the handheld.
Hold dirt container over a
bin allowing dirt/debris to
fall out.
TIP
Don’t overll the dirt
container to avoid blocking
the air ow through the
vacuum cleaner and replace
lters every 6-9 months.
Taking care of your machine
Cleaning the filter
Press the handheld
release button.
Lift to remove the
handheld from the
main body.
Press the dirt container
release button to remove
the dirt container.
Pull to separate the dirt
container from
the handheld.
CAUTION: For best cleaning results lters require cleaning every 4-6 uses or as needed depending upon use.
Do not use your vacuum cleaner without the lter in place.

Taking care of your machine
Pull the foam lter to
separate and remove
from of lter frame.
Tap the lter over a bin to
remove any dust and
debris. Do not wash the
filter frame.
Pull to remove the
pre-motor lter out of
the dirt container.
Wash foam lter under
running water (max 40’C).
Leave for at least 24
hours or until fully dry
before replacing into
the machine.
24hr
Cleaning the terminals
Using a dry cloth or soft dusting brush, remove
any dust or debris from terminals on main body
and handheld.
CAUTION: For best performance all terminals must be free from dust and dirt.

Replacing and cleaning a blockage from the brushbar
CAUTION: If the brushbar has been obstructed, the Motor Protection Sensor may have been activated. Remove the
handheld from the main body and clear any obstruction from the brushbar. Wait 30 minutes for the vacuum cleaner
to reset itself. Return the handheld to the main body and retry.
Let’s talk technical
Cleaning blockages
CAUTION: Use a blunt instrument such as a broom handle or something similar when removing a blockage from
the main body or oorhead.
Place foot on the oor
head and pull the handle
backwards to recline the
main body.
Lift to remove the handheld
from the main body.
Press the handheld
release button.
Lift the main body o
the oor with the oor
head unlocked.
Use a blunt instrument such as a broom handle to clear
any blockage in the hose connecting to the oorhead.
Using a pair of scissors
remove any threads or
hair caught around the
brushbar.
To release the brushbar
pull and lift the release
lock located underneath
the oorhead.
Remove the brushbar
lifting the side of the
brushbar nearest the
release lock rst.
Replace the brushbar. Fit the
inverted round end of the
brushbar rst, then line up
and push the other side of
brushbar into the oorhead.
Ret the release lock.

Accessories
Pre-Motor Filter
VX62F
Reach mode tools
Don’t forget your accessories!
AU: www.vax.com.au / NZ: www.vax.co.nz

• Check the vacuum cleaner is fully charged. Go to ‘Using your machine’.
• Check the charger is plugged into the mains and correctly connected to the vacuum
cleaner. Go to ‘Getting started’.
• Check the handheld has been correctly tted into the main body.
• Check terminals on the main body and handheld are clean. Go to ‘Let’s talk technical’.
• If the brushbar has been obstructed, the Motor Protection Sensor may have been
activated. Remove the handheld and clear any obstruction from the brushbar. Wait 30
minutes for the vacuum cleaner to reset itself. Replace the handheld and retry.
• Check the charger is plugged into the mains and correctly connected to the vacuum
cleaner. Go to ‘Getting started’.
• Check the charger cable for damage. If damaged please contact our Customer Care
Line on: AU 1300 361 505 / NZ 0800 800 900
• If the brushbar has been obstructed, the Motor Protection Sensor may have been
activated. Remove the handheld and clear any obstruction from the brushbar. Wait
30 minutes for the vacuum cleaner to reset itself. Replace the handheld and retry.
• The brushbar may be blocked. Go to ‘Let’s talk technical’.
• Empty the dirt container and clean lters. Go to ‘Taking care of your machine’.
• There may be a blockage in the vacuum cleaner. Go to ‘Let’s talk technical’.
• The brushbar may not be turning. Go to ‘Why won’t the brushbar turn?’ below.
• The vacuum cleaner may need recharging. Go to ‘Getting Started’.
• Low suction has been selected, increase to high suction. Go to ‘Using your machine’.
SolutionProblem
Why does my vacuum
cleaner have no power?
Why isn’t my vacuum
cleaner charging?
Why won’t the vacuum
cleaner pick up?
Why won’t the vacuum
cleaner pick up?
What to do if it goes wrong
Why won’t the
brushbar turn?
• If the brush bar has been obstructed, the Motor Protection Sensor may have been
activated. Remove the handheld and clear any obstruction from the brush bar. Wait
30 minutes for the vacuum cleaner to reset itself. Replace the handheld and retry.
• The brushbar may be obstructed. Go to ‘Let’s talk technical’.
Why is the LED light
Continually ashing?
• The red light will ash when the vacuum needs recharging. Go to ‘Getting started’.

* Calls are charged at the standard local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.
Getting in touch

Notes

Notes

Distributed by Techtronic Industries Australia Pty. Ltd.
31 Gilby Road, Mt Waverley, VIC 3149 Australia.
Careline AU: 1300 361 505 www.vax.com.au
Careline NZ: 0800 800 900 www.vax.co.nz
