vc999 85.47i D Installation instructions

ORIGINAL OPERATING MANUAL
Art. no. 512.320
Shrink Tank
85.47i
VC999 VERPACKUNGSSYSTEME AG Tel. ++41 (0) 71 35 35 900
Melonenstrasse 2 Fax ++41 (0) 71 35 35 901
CH-9100 Herisau / Switzerland E-Mail [email protected]

EC Declaration of Conformity
In accordance with Machinery Directive 2006/42/EC, Appendix II A
In accordance with EMC Directive 2004/108/EC
In accordance with Low Voltage Directive 2006/95/EC
Manufacturer Authorized Representative in the Community
VC999 VERPACKUNGSSYSTEME AG ............................................................
Melonenstrasse 2 ............................................................
CH-9100 Herisau ............................................................
We hereby declare that the following product
Product name: Shrink Tank VC999 85.47i
is in conformity with the relevant-
provisions of the above referenced
directives – including any valid amendments
at the time of the declaration.
The following harmonized standards
have been applied:
EN ISO 12100-1 / -2 Safety of machinery, devices and systems
DIN EN 60 204-1 Electrical equipment for industrial machinery
Place: Date:
Herisau 12.02.2009
Document Custodian:
Uriel Inauen
VC999 VERPACKUNGSSYSTEME AG
Melonenstrasse 2
CH-9100 Herisau

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 3/34
NOTICE
The following handover declaration has to be completed by the owner. The owner is obliged to
return the original, completed handover declaration to us. The owner hereby certifies that
he/she has understood and taken full note of the operating manual. By signing this document
the owner certifies that he/she shall observe the safety instructions contained in the operating
manual and shall inform each and every machine user or persons working at the machine of the
relevant safety instructions.
The owner shall be liable for any personal injuries or damage to property resulting from non-
observance of the safety instructions.

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 5/34
Contents
ChapterDescription Page
EC Declaration of Conformity.........................2
Handover Declaration ....................................3
Contents.........................................................5
1 Introduction ..................................................6
1.1 General information........................................6
1.2 Definitions.......................................................7
1.3 Protection of copyright....................................7
2 Safety and warranty ....................................8
2.1 Explanation of the safety instructions.............8
2.2 Warning safety signs at the machine.............8
2.3 Residual risks.................................................9
2.4 General safety instructions.............................9
2.5 Machine stability...........................................10
2.6 Requirements for operators .........................10
2.7 Warranty and liability.................................10
3 Proper use...................................................11
4 Technical Data............................................12
4.1 Dimensioned Drawings................................13
5 Description..................................................14
5.1 Versions .......................................................14
5.2 Components.................................................14
5.3 Control Panel................................................15
6 Site Requirements......................................16
6.1 Services connections in building..................16
7 Transport and Installation.........................16
7.1 Instruction for Transport...............................16
7.2 Installation....................................................16
8 Works before first Start-Up.......................17
8.1 Electrical Connection ...................................17
8.2 Compressed Air Connection........................17
8.3 Water Connection.........................................18
8.4 Steam Connection........................................18
8.5 Installing Steam Exhaust Pipe .....................18
8.6 Connect Drain for Water ..............................19
8.7 Connect Water Overflow..............................19
8.8 Clean the Machine .......................................19
9 Commissioning ..........................................19
9.1 Forbidden Operations ..................................19
10 Daily Start-Up..............................................20
10.1 Bag Material.................................................20
10.2 Preparing Machine.......................................20
10.2.1 Switching on Machine ..................................20
10.3 Switching off Machine ..................................20
ChapterDescription Page
11 Programming...........................................20
11.1 Program Level...........................................20
11.1.1 Heating ......................................................20
11.1.2 Water Intake..............................................20
11.1.3 Set Temperature of Water.........................20
11.1.4 Dwell Time.................................................20
Flow chart for program Level.....................21
11.2 ABC-Level .................................................22
11.2.1 Switch languages ......................................22
11.2.2 Mode of operation......................................22
11.2.3 Conveyor belts...........................................22
11.2.4 Timer for automatic heating.......................22
11.2.5 Decalcification program.............................22
11.2.6 Automatic Cut-Out when
Product Feed stops ...................................22
11.2.7 Mode of Heating........................................22
11.2.8 Hours and Cycles Operated......................22
11.2.9 Key.............................................................22
11.2.10 EPROM test...............................................22
Decalcifying program.................................23
Flow chart ABC level.................................24
12 Possible Malfunctions ............................25
12.1 Announcement ..........................................25
12.2 Fault Announcements on Display Panel...26
12.3 Trouble-Shooting.......................................27
13 Maintenance.............................................28
13.1 Cleaning ....................................................28
13.1.1 Cleaning Materials.....................................28
13.1.2 Cleaning Schedules ..................................28
13.2 Maintenance..............................................29
13.2.1 Vertical guide for Immersion Platform.......29
13.2.2 Service Unit...............................................30
13.2.3 Immersion Platform ...................................30
13.2.4 Electrical Fuses.........................................30
13.2.5 Changing Electronic Boards......................30
14 Repairs .....................................................31
15 Disposal....................................................31
16 Pneumatics diagram ...............................32
17 Circuit diagrams......................................33

Shrink Tank VC999 85.47i
Page 6/34 Art. no. 512.320 2009-11-17
1. Introduction
1.1 General information
• his operating manual is an integral part of your machine. The information and safety instructions
contained herein have to be carefully read and adhered to by members of staff authorized to operate
the machine. Superiors who are responsible for machine operation shall be liable for damages and
their consequences resulting from incorrect handling of the machine. It is therefore in the interest of
the operator that this operating manual is strictly adhered to.
• The manufacturer shall not be liable for any damages which occur due to non-observance of this
operating manual in its entirety.
• Only the information contained in this operating manual can prevent faults during operation and
guarantee trouble-free operation. It is therefore imperative that this operating manual is actually read
und understood by members of staff authorized to operate the machine..
• This machine is a state-of-the-art device at the time of delivery. It complies with CE regulations and
the latest version of machinery directive 2006/42/EC at the time of delivery.
• In the unlikely event that problems should occur, or if questions arise, please do not hesitate to
contact our Customer Service.
• Due to technical changes and improvements to the machine some of the diagrams contained in this
operating manual may not be exact. However, the diagrams are fully understandable in order to
explain processes or a course of action.
• Dimensions and designs are subject to change.
Customer Service Dept. Switzerland
The manufacturer’s address is displayed on the name plate. Always state the type of machine and the
machine’s serial number, which are also displayed on the name plate, when contacting us.
Manufacturer: VC999 VERPACKUNGSSYSTEME AG
Address: Melonenstrasse 2
CH-9100 Herisau / Switzerland
Phone: ++41 (0)71 35 35 900
Fax: ++41 (0)71 35 35 901
E-mail: [email protected]
Website: www.vc999.ch
Represented by:

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 7/34
1.2 Definitions
The following terms are used in this Operating Manual to describe the people who work with or on the
machine:
Buyer
The buyer is the person who purchases the machine from the manufacturer or its representative, even if
he/she always allows a third party to use the machine. The buyer is also the manufacturer’s customer
and is the owner as defined by law.
Owner
The owner is the person who operates or uses the machine, even if he/she is not the actual owner as
defined by law. The owner also becomes liable for the legal risk resulting from operation or connected to
operation of the machine when operating the machine.
Operator, operating personnel
Operators or operating personnel are the people responsible and authorized to operate the machine.
These people should possess sufficient know-how in order to handle and operate the machine correctly.
Usually, one or several people are given responsibility for the machine and provided with one of the two
copies of the operating manual for future reference.
It is expected that these people have been briefed about the machine and the operating manual on-site
and are especially aware of the safety regulations for correct handling of the machine and have been
expressly informed about compliance with the aforesaid regulations.
Specialist, specialist personnel
Specialists are specially trained people who, due to their vocational training, are qualified to carry out
special tasks at the machine.
These people are, e.g., electricians, mechanics, specialist engineers and appropriately qualified cleaning
staff. These people also have to be familiar with the contents of the operating manual.
1.3 Protection of copyright
This Operating Manual must be treated as confidential. All the data and information contained in this
Operating Manual are protected by the Copyright Act. Breaches of copyright are punishable by law and
will result in fines.
This documentation contains information protected by copyright. Any reproduction, copying, scanning or
forwarding to third parties is expressly prohibited without the express prior permission of VC999
VERPACKUNGSSYSTEME AG. Violation is expressly prohibited by law, and may result in severe civil
and criminal penalties.

Shrink Tank VC999 85.47i
Page 8/34 Art. no. 512.320 2009-11-17
2. Safety and warranty
2.1 Explanation of the safety instructions
All the safety instructions in this operating manual provide the operator with early warning of possible
dangers, possible damage to the machine and peripheral equipment and of flawed, productive work.
Any sections which are of particular importance to the operator are marked by a warning symbol. The
operator must read and comply with this information.
Meanings:
DANGER
indicates a hazardous situation which, if not avoided, will result in death or serious injury!
WARNING
indicates a hazardous situation which, if not avoided, could result in death or serious injury!
CAUTION
indicates a hazardous situation which, if not avoided, may result in minor or moderate injury!
NOTICE
indicates a situation which, if not avoided, may result in considerable damage to equipment or
environmental harm!
2.2 Warning safety signs at the machine
All possible areas of danger are described in this operator manual and additionally indicated at the
machine via warning safety signs. Please always pay attention to this safety information and act with the
respective caution.
WARNING: ELECTRICAL HAZARD
This area contains an electrical appliance; danger of death! Risk of electric shock when coming
into direct contact with live parts! Only fully qualified electricians should carry out work on
electrical appliances.

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 9/34
2.3 Residual risks
Despite taking all precautions residual risks remain. Residual risks are potential, not obvious risks.
Pay particular attention to:
• Risk of burns when touching hot surfaces and due to hot steam*.
• Trapping fingers and general injuries from uncoordinated operation.
• Risk of injury from unskilled transport or movement of the machine.
• Risks from working on the electric equipment.
2.4 General safety instructions
Pay particular attention to the following instructions:
• Everybody involved with the installation, start-up, operation and servicing (inspection, maintenance,
repair work) of the machine at the owner’s company has to have carefully read and understood the
entire operating manual and especially the chapter entitled "Safety and warranty".
• This machine is a state-of-the-art device at the time of delivery. The respective safety regulations for
machine operation have been observed.
• All parts, whether self-manufactured or purchased from a component firm, comply with technical
standards and EU regulations in accordance with machinery directive 2006/42/EC.
• A continuous quality control of our own and third party parts is carried out prior to assembly at our
production plant.
• All safety and protective equipment is included in this safety concept which is geared towards
protecting all the people who are employed to work on or with this machine against dangers.
NOTICE
Technical intervention in the functioning and effectiveness of the safety devices, safety
switches and covers or casing is expressly prohibited.
If any of the safety and protective devices are either entirely or partially put out of service,
claims for recourse against the manufacturer shall not be accepted.
The machine is then considered unsafe for operation as defined by law and should neither be
operated nor provided to third parties for operation.
WARNING
Electrical hazard! Danger of death - electric shock!
If the operator manual expressly states that the power supply has to be disconnected for
certain tasks at the machine, these tasks should only be carried out after it has been ensured
that accidental switching on of the power supply cannot occur directly or via a third party. This
means:
• The power supply has to be disconnected either by disconnecting the machine from the
mains or by disconnecting the plug,
or:
• The main switch has to be secured accordingly, i.e. using a padlock or placing a seal
through the provided holes in the switch.

Shrink Tank VC999 85.47i
Page 10/34 Art. no. 512.320 2009-11-17
NOTICE
The owner is solely responsible for workplace safety and adherence to statutory regulations
regarding machine handling.
• This operating manual is part of the machine. If it is lost or damaged, immediately order a replacement
copy via our Customer Service. Please always state the type of machine and the machine’s serial
number (on the nameplate).
2.5 Machine stability
Machine stability is guaranteed on a flat surface during normal operation if the machine is standing
correctly on all 4 machine feet and is leveled horizontally.
Stability must be guaranteed during the full life of the machine, in particular during transport, assembly,
operation, inoperative periods, disassembly, inspections, and foreseeable faults.
In these situations, the machine must be sufficiently secured against moving, tilting and falling to prevent
personal injuries and damage to the machine and the environment.
The owner is solely responsible for adherence to these requirements.
2.6 Requirements for operators
The machine should only be operated, serviced, and repaired by authorized and fully trained and
qualified personnel. It is the responsibility of the owner to inform operators of possible dangers.
Ensure that responsibilities with regard to assembly, operation, and repairs are clearly defined and
communicated by the owner to guarantee that health and safety regulations are observed.
Operators are obliged to make sure the machine is in efficient working order prior to operation and to
inform superiors immediately about any changes which constitute a risk to human safety or device
functioning.
The operator must ensure that only authorized personnel work at the machine.
2.7 Warranty and liability
The agreements and written consent in the contract of sale apply.
All warranty claims refer to the replacement of defective materials. Further claims are not accepted.
Warranty refers to normal operation during a shift/day.
The warranty periods are reduced accordingly for multiple shift operation.
Warranty claims against the manufacturer are excluded if any modifications or changes which have not
been expressly authorized by the manufacturer or agreed with the manufacturer are carried out at the
machine or to its components.
The same applies for commissioning without prior written acceptance.

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 11/34
3. Intended use
This machine is a technical tool which is solely intended for packaging suitable products at your
workplace. It should only be used to shrink hermetically sealed shrink bags containing food (e.g. meat,
cold cuts, cheese, etc.). Any other use is strictly prohibited!
NOTICE
Do not place objects or living things inside the machine for whatever purpose (e.g. cleaning,
heating up, etc.)!
NOTICE
This machine may be the source of dangers if it is applied improperly or for purposes other
than those for which it has been designed. In order to ensure that the machines are used as
prescribed, it is also important to comply with the installation, operation and maintenance
conditions specified by the manufacturer.
The owner is responsible for the suitability, condition and characteristics of the shrink packaging. The
machine manufacturer is not responsible for the content of the packages.

Shrink Tank VC999 85.47i
Page 12/34 Art. no. 512.320 2009-11-17
4. Technical Data
Electrical Connection Values (Fig.1, Pos. 1)
Equipment as in EN 60204-1
230 V / 3 / 50 Hz 0.5 kW 10 AT
20.5 kW 60 AT
30.5 kW 100 AT
400 V / 3 / 50 Hz 0.5 kW 6 AT
20.5 kW 40 AT
30.5 kW 60 AT
208 V / 3 / 60 Hz 0.5 kW 10 AT
20.5 kW 60 AT
30.5 kW 100 AT
220 V / 3 / 60 Hz 0.5 kW 10 AT
20.5 kW 60 AT
30.5 kW 100 AT
380 V / 3 / 60 Hz 0.5 kW 6 AT
20.5 kW 40 AT
30.5 kW 60 AT
440 V / 3 / 60 Hz 0.5 kW 6 AT
20.5 kW 40 AT
30.5 kW 60 AT
575 V / 3 / 60 Hz 0.5 kW 6 AT
20.5 kW 40 AT
30.5 kW 40 AT
The connection values for your machine can be found on
the type label (19) on the left hand side of the machine.
Electrical connection can be made from above or below
(see section 8.1).
Output
Up to a max of 8 cycles / min.
Product Area
900 x 460 x 250 mm max 50 kg
Water Connection (Fig. 1, Pos. 2)
R½“
Tank holds about 210 litres
Steam Connection (Fig. 1, Pos. 3)
R½“ 6 - 8 bar
Steam needed to bring water from
20° to 90°C: 30 kg
Connection for Compressed Air (Fig. 1, Pos. 4)
For compressed air hose ID 9 mm
6 - 8 bar
Uses 17 NL compressed air per cycle at 6 bar
Steam Exhaust (Fig. 1, Pos. 5)
For steam exhaust pipe, outside diameter 160 mm.
Steam exhaust can be regulated manually
Water Discharge (Fig. 1, Pos. 6)
Threaded joint R1¼“
Water Overflow (Fig. 1, Pos. 7)
Threaded joint R1“
Weight
Weight (without accessories) 400 kg approx.
Standard Equipment
Electrical or steam heating
Cannot be operated with no water in tank
Steam exhaust (regulated by water temperature)
Automatic temperature control
Automatic level control of water
Automatic fault indication
Fully automatic microprocessor-controlled operating
cycle (automatic and continuous working)
Adjustable immersion time
Programmable water heating (timer)
Operator guidance by LCD display with option to change
language
Additional Equipment
In - and outlet rollers
Intake - and discharge conveyor
Outlet extension roller 500 mm
Outlet extension roller 900 mm
Noise Level when Operating
according to in DIN 45635
Preparation / Work place 70 dB(A)

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 13/34
4.1 Dimensioned Drawings
Variant 1
With intake -
or discharge belt conveyor
Variant 2
With in -
and outlet rollers
Fig. 1

Shrink Tank VC999 85.47i
Page 14/34 Art. no. 512.320 2009-11-17
5. Description
Construction of Machine
The machine stands on four feet, adjustable for height
and is arranged for integration into a vacuum packing
line.
Principle of Operation
The VC999 85.47i Shrink Tank operates on the method
of shrinkage by brief immersion in hot water. Incoming
product is registered by the photo cell (21) and starts
the fully automatic immersion cycle. The product is
brought into the machine and immersed in the hot
water. This causes the shrinkable bag (especially
projecting portions) to fit closely to the product.
When the immersion cycle is complete the product is
automatically removed from the Shrink Tank.
5.1 Versions
The machine is available in the following version:
Type VC999/85.47i D
Type VC999/85.47i ED 20 kW
Type VC999/85.47i E 20 kW
Type VC999/85.47i E 30 kW
Explanation:
D = steam heated
E = electrically heated
20 kW = electrically heated 20 kilowatt
30 kW = electrically heated 30 kilowatt
5.2 Components
Fig. 2
12 Machine
13 Swing-up steam hood
14 Machine foot, height adjustable
15 Operating panel
16 Main switch
17 Emergency button
18 Immersion platform
19 Type label
20 Plug for intake or discharge belt conveyor
and draining tub
21 Photo-cell

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 15/34
Fig. 3
22 Removable back
23 Thermorelays for intake conveyor
24 Thermorelays for discharge conveyor
25 Thermorelays for chain drive
26 Thermorelays for steam exhaust
27 Circuit breaker
28 Fine-wire fuse, 200mAT
29 Fine-wire fuse, 2.5 AT
30 Fine-wire fuse, 1 AT
5.3 Control Panel
Fig. 4
1 DISPLAY
2 ON key
3 OFF key
4 HEAT key
5 NEXT-STEP key
6 UP key
7 DOWN key
8 HELP key
9 ABC key = ABC level (languages, method of
heating/automatic cut-off/running time and cycles)
10 STOP key
11 START key
17 EMERGENCY button

Shrink Tank VC999 85.47i
Page 16/34 Art. no. 512.320 2009-11-17
6. Site Requirements
Operating Space
The machine must be protected against constant
exposure to spray, water jets or washing-down water.
Foundation
A level industrial floor is satisfactory.
Ambient Temperature
The machine works at a room temperature of 5-35°C.
NOTICE
If there is danger of (severe) frost, drain tank to prevent
frost damage.
Space for Operation and Maintenance
There should be enough clear space left behind the
machine to ensure access for maintenance work.
6.1 Services connections in building
Power Supply
See chapter 4, Technical Data
• The connecting values (voltage etc.) for your
machine can be found on the type label (19) on the
left hand side of the machine.
Water Supply
See chapter 4, Technical Data
Steam Supply
See chapter 4, Technical Data
7.Transport and Installation
The machine is completely assembled and is in one
unit.
The delivery comprises
Equipment as ordered
Operating Instructions for machine
• Remove wrapping.
• Check that there has been no loss or damage in
transit.
• In the event of damage in transit keep packaging
and notify VC999 and the carrier at once.
7.1 Instruction for Transport
NOTICE
• Keep machine upright during transport. Do not tilt!
• If the machine has inadvertently been tilted or
dropped in transit notify the VC999 Customer
Service!
7.2 Installation
• Place the machine in its permanent position and
adjust level using the adjustable feet (14).

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 17/34
8. Works before first Start-Up
Before the arrival of the VC999 Customer Service the
customer should carry out the following work:
• Electrical Connection (Chapter 8.1)
• Compressed Air Connection (Chapter 8.2)
• Water Connection (Chapter 8.3)
• Steam Connection (Chapter 8.4)
• Installing Steam Exhaust Pipe (Chapter 8.5)
• Connect Drain for Water (Chapter 8.6)
• Connect Water Overflow (Chapter 8.7)
• Clean the Machine (Chapter 8.8)
8.1 Electrical Connection
WARNING
Electrical hazard! Danger of death –electric shock!
The machine may only be connected to the power
supply by a qualified expert (electrician) and in
compliance with local regulations!
The machine is supplied without connecting cable.
This 4-core connecting cable (3 phases + E) should
be measured by the electrician and connected to the
main switch.
The cable is brought into the machine from above
through the conduit gland (Fig. 1, Pos. 1) or from
below through the opening in the machine. In this
case the conduit gland (Fig. 1, Pos. 1) must be
exchanged for the closure plug in the main switch
box.
As well an earth potential differential cable has to be
installed. The wire must have the same section as the
main cable wire. A special terminal (54) is prepared
left of the air service unit.
• Check whether the local supply voltage, frequency
and fuse protection conform with the data on the
type label (19) or the technical data in chapter 4. If
not the machine should not be connected.
NOTICE
If the direction in which the platform moves does not
correspond to the installation of the equipment the
machine should be switched off and 2 or 3 phases of
the motor driving the platform have to be
interchanged.
NOTICE
The first switch-on of the machine must only be
done by the VC999 Customer Service.
8.2 Compressed Air Connection
• Remove back panel (22).
• Push the compressed air hose (ID 9 mm) on to the
nipple of the compressed (31) air maintenance unit
and secure with a hose clip.
Fig. 5
• Replace back panel (22).
NOTICE
To keep to a minimum the amount of condensate
entering the service unit or the point of use an air
dryer must be installed in the air supply line.
Otherwise a water-trap at least is necessary. The
condensate which collects in the sight-glass (33) of
the service unit is vented automatically through the
valve (34) at every switch-on.

Shrink Tank VC999 85.47i
Page 18/34 Art. no. 512.320 2009-11-17
8.3 Water Connection
The VC999 85.47i Shrink Tank can be fed with cold or
warm water.
NOTICE
With hard water it is desirable to install a water softener
in the water supply line. This reduces lime deposits and
minimises cleaning.
For the water-pressure a manometer and a regulating
tap should be provided on site.
To clean the filter (38) the Shrink Tank must be
disconnected from the water supply by means of a
stopcock.
Clean the filter 1 day after first start-up according to
Section 13.1.2.
Water connection from above: Connect by flexible
hose to item 35, threaded joint R½“.
Fig. 6
Water connection from below:
• Take down back panel on right.
• Remove cover cap (36), screw on to upper
connection (35) and tighten.
• Connect by flexible hose to bend (37).
• Replace back panel.
NOTICE
When installing take care that no impurities get into
the supply line and that the water unit is not twisted
when tightening.
8.4 Steam Connection
Only for versions with steam heating:
NOTICE
A manometer (setting 6 bar max) and a safety value
set for 8 bar must be provided on site. To clean the
filter (40) it must be possible to isolate the shrink tank
from the steam supply with a steam valve.
WARNING
Risk of scalding from the discharge of hot steam!
Steam connection from above:
• Connect steam supply to tube (39) (R½“).
Steam connection from below:
• Take down back panel on right.
• Remove tube (39).
• Mount plug (41) on opposite side as seal.
• Connect steam supply to bottom of T-piece (42)
(R½“).
• Replace panel.
Fig. 7
8.5 Installing Steam Exhaust Pipe
The joint opening for the steam exhaust tube is
arranged for an outside tube diameter of 160 mm (Fig.
1, item) (of chapter 4 in Technical Data).
Take care when installing the steam drain line that too
much condensate cannot run back into the Shrink
Tank (provide siphon with drain opening).

Shrink Tank VC999 85.47i
2009-11-17 Art. no. 512.320 Page 19/34
8.6 Connect Drain for Water
For water-drainage we suggest a ball-cock with an
inside thread R 1/4". A drain hose can be attached.
8.7 Connect Water Overflow
An overflow hose (Item 43, Fig. 10) ø 30 x 450 mm is
connected by the manufacturer. A longer hose can be
attached if necessary.
8.8 Clean the Machine
• Remove adhesive tapes and waste packaging
• Check the tank for soiling and, if necessary, clean it
• Clean outer machine surfaces with commercial
chrome cleaner
9. Commissioning
WARNING
Risk of injuries! The first start-up must always be
undertaken by a VC999 Customer Service
Representative. Unauthorised first start-up can lead
to injuries and damage to goods and property!
The Customer's Staff are fully instructed on this
occasion.
9.1 Forbidden Operations
• Do not process spoiled foodstuffs.
• Do not bring products into use if the heat seal in
the shrink pack is faulty.
• Only use approved vacuum bags.
• Do not immerse any products which could be
damaged or destroyed by hot water.

Shrink Tank VC999 85.47i
Page 20/34 Art. no. 512.320 2009-11-17
10. Daily Start-Up
NOTICE
The machine may only be used by workers who,
because of their training and knowledge or
practical experience, can ensure satisfactory
working and who are aware of the hazards.
10.1 Bag Material
NOTICE
Only use vacuum bags which have been approved for
hot water shrinkage and the packaged goods. – Please
obtain certification of capability from the film
manufacturer. Always consider the following:
- Resistance to heat
- Strength
- Hygiene regulations
10.2 Preparing Machine
10.2.1 Switching on Machine
Turn main switch (16) to 'l' position.
Press ON key (2) on control panel.
− The machine switches on.
− For a few seconds the machine type is shown on
the display (1).
− The control system then goes into the basic
mode last set.
− When the water reaches the working temperature
the machine is ready for use.
− If within a definite period (pre-set) immersion
cycles have not been started or keys pressed the
control switches off automatically.
10.3 Switching off Machine
After the last products have been conveyed from the
shrink tank press OFF (3) key on control panel.
Disconnect power by turning main switch (16) to 'O'
position.
NOTICE
The main switch (16) can be fitted with a lock to prevent
tampering.
11. Programming
The programming of the shrink tank is divided into a
program level and an ABC level.
11.1 Program Level
See section Flow Diagram level.
11.1.1 Heating
The "HEATING' key (4) brings in the heating menu.
From this point the heating can be switched on with
the START key (11) AUTOMATIC or switched off with
the STOP key (10).
If the heating is set to AUTOMATIC a * is shown
alongside when the heating is actually on.
11.1.2 Water Intake
Either setting 'AUTOMATIC' or 'OFF' can be selected.
• In automatic operation the water intake is automatic.
The control system monitors water level from the
level indicator and controls the water inlet valves
accordingly.
Water intake is stopped at the 'OFF' setting. The level is
not regulated.
11.1.3 Set Temperature of Water
The water temperature can be set between 50ºC and
100ºC (122º-212ºF). The display (1) shows both the
set and the actual water temperature.
NOTICE
The set temperature should be chosen with regard to
the vacuum bags used and the product being packed.
11.1.4 Dwell Time
The dwell time is the time for which the immersion
platform (18) and hence the products are immersed in
water. It can be set at 0.0-9.9 sec/10 to 59sec/1.0 to
9.59 min.
NOTICE
The dwell time should be chosen with regard both to
the vacuum bags used and the product being packed.
