VDC Display Systems Marquee 8520 Ultra User manual

Quick Start - Marquee 8520 Ultra VDCDS Doc#: 790200101 / Revision 001
Remote Control Layout and Controls
SOURCE
123RECALL
HELP
POWER
6
9
5
8
4
7
0MUTESTBY
PROJ UTIL PIC
GEOM
CONV
EXIT
DETAIL
VOL
TINT
BRITE
COLOR
CONT
ENTER
*
#
Picture Menu
Utilities Menu
Display Controls
Projector
Status Page
Geometry Menu
Convergence Menu
Exit
Source
Recall
Help
# Test Pattern
Mute
Numeric Keys
Enter
To adjust or set:
Phase
Size
White Balance
Focus
Sync









Blanking
Clamping
Retrace
Decoder Option
s
To access the following utilities:
Source Setup
Channel List
Memories Display
Preferences




To adjust:



Color
Tint
Detail



Contrast
Brightness
Volume
 to command a single
projector in a multi-
projector system
 to display status
pages
To adjust:
Size
Keystone
Side Pin
Top
Bottom









Bow
C Linearity
S Linearity
Skew
 to adjust red, green and
blue convergence
 to exit from a menu or
function



for input selection
for channel up/down selection
for source message display



to select a Recall Memory
to go back one screen during
menu/help display
to view hidden slide bars
when message display is turned off


for context sensitive help
for setup guides
 to select a test pattern
for display
Power
 to turn the projector on or off
Standby
 to turn both picture and
audio on or off
 to turn audio on or off
to turn menus on or off



for menu item selection
for number entry


to select a highlighted
menu item
to select a dialog box
option
Arrow Keys



for adjustments
for menu item selection
for movement between
edit fields



Remote Options
Clock/Events
Service
Display Systems
For Technical Assistance Please Contact:
VDCDS Technical Services: 321.784.4427 or [e-mail]
QUICK START - MARQUEE™ 8520 Two-Piece Series
This document is intended to provide the necessary information to perform the initial assembly, test and quick setup of the
Marquee™ 8520 Two-Piece Series projectors. For complete detailed assembly and operating instructions, refer to the
Marquee™ 8520 Service Manual (VDCDS P/N: 71178-02) contained on the accompanying CD-ROM.
Note: The 8520 projection system is shipped in two-
separate assemblies. Before any testing or operation
of the system can be accomplished, the Electronic
Chassis (EC) and the CRT Head Assembly (HA)
MUST be connected together. Refer to the inside
section (Figure 1 and Figure 2) DO NOT apply any
main power until both sections have been assembled
per this instruction sheet.
Step 1. Once the EC and HA have been assembled
together, connect the AC power cord,
located in the lower-left side of the EC.
Note: Input voltage must be between 90 –
264 VAC, 50/60 Hz.
Step 2. Connect an External Source (Optional)
a) Connect a 3, 4 or 5 wire source to the
projector’s built-in RGB input-slot 1
(VIM). Ensure the source is on and properly connected.
GREENRED BLUE HOR/COMP
RGB and S
y
nc Si
g
nals from Source
BNC
connectors
V
ERT
SYNC
Step 3. Turn the Projector On
a) Hold down the [POWER] key on the keypad for about one second to turn the projector on.
Step 4. Select Internal Test or External Source
a) Internal Test: Press [#] to display the first level test pattern. Press [EXIT] to return to the external
source if available.
b) Select the External Source: Press [SOURCE] [0] [1] to select the source connected to the Video Input
Module (RGB).
Step 5. Adjust the Display: Guided Help provides several on-line tutorials which explains how to operate the
projector and assist you during the setup process.
a) Press [HELP] [1] to select the Guided Source Setup tutorial.
90 - 264 VAC
50 - 60 Hz

Quick Start - Marquee 8520 Ultra VDCDS Doc#: 790200101
VDCDS Doc#: 790200101 / Revision 001 Quick Start - Marquee 8520 Ultra
CRT Head and Electronic Chassis Assembly Instructions
The Marquee 8520 is shipped as two separate pieces, the CRT Head Assembly and Electronic Chassis. Once the two pieces had been removed from their respective packaging, the flex cable and connections from the HA must be installed in the
Electronic Chassis. Refer to Figure 1 and Figure 2 NOTE: Remove all main power before performing the following procedure.
Step 1. Install the CRT Head assembly and Electronic Chassis in their proper location.
Step 2. Open the hinged rear panel of the Electronic Chassis; loosen the three ¼ turn self captive thumb
screws securing the rear panel in place.
Step 3. If necessary, place the Retainer Plate (Item-2) over the connectors/cable assembly (Item-1) and on
to the 90° elbow.
Step 4. Fasten the Retainer Plate (Item-2) in place using the four Phillips screws provided.
Step 5. Feed the cable assembly through the rear panel.
Step 6. Feed the cable/connectors through the retainer lock nut (Item-2).
Step 7. Loosely secure the cable assembly to the rear panel with the retainer locknut.
2
3
1
4
5
6
7
8
10
Interlock Switch (Ref)
Rear Panel (Ref)
9
Figure 1. Electronic Chassis Cable Assembly/Installation (Rear Panel View-Cutaway)
Step 8. Connect the following connectors;
a) Chassis Ground; secure the ground lead/lug (Item-4) to the chassis using the Phillips screw
provided.
b) P20 (Item-5), P21 (Item-6), P22 (Item-7). Align the three plugs to their relevant connectors; twist
CCW until snapped in place.
c) Locate and install the three (3) G-2 connectors (labeled R, G, B) (Item-8) to their respective plugs.
d) Install the three (3) BNC video connectors (R, G, B) (Item-9) to their male counterparts.
e) Feed the HV Lead (Item-10) through the grommet shown in Figure 1, to the front-side of the
chassis.
f) On the lower front-panel, loosen the four (4) self-captive Phillips screws securing the lower front
panel in place and remove.
g) Plug the HV lead from Step e) in to the HV Splitter as shown in Figure 2.
Step 9. Replace the lower front panel and secure.
Step 10. Carefully close the rear panel and secure.
HV SPLITTER
FRONT LOWER
PANEL
PHILLIPS SELF-CAPTIVE
SCREWS
(
4 PLS.
)
Figure 2. Electronic Chassis Cable Assembly/Installation (Front Panel View)
REAR VIEW
FRONT VIEW
